LN50R-MR3 (1983)
Toyota Hilux
(8308- )LN5#,60,65,67,RN58..T1,T3,TW
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 77023 - FILTER SUB-ASSY, FUEL SUCTION TUBE | ||||
| 77023-12050 |
RN58..SR5;LN50,51,55,56,RN50,55,67,YN5# |
1 | ||
| 77023-22040 |
LN50,51,55,56,60,61,65 |
1 | ||
| 77023 - FILTER SUB-ASSY, FUEL SUCTION TUBE | ||||
| 77023-12050 |
RN58..SR5;LN50,51,55,56,RN50,55,67,YN5# |
1 | ||
| 77023-22040 |
LN50,51,55,56,60,61,65 |
1 | ||
| 77031 - CAP ASSY, FUEL TANK | ||||
| 77310-35061 |
LN5#..T1..(ARL,EUR,GEN) |
1 | ||
| 77031B - GASKET (FOR FUEL TANK CAP) | ||||
| 77316-12050 |
LN5#,YN5#..T1..(ARL,EUR,GEN,ME) |
1 | ||
| 77100 - TANK ASSY, FUEL | ||||
| 77100-35250 |
LN50,51 52LITER |
1 | ||
| 77100 - TANK ASSY, FUEL | ||||
| 77100-35250 |
LN50,51 52LITER |
1 | ||
| 77100A - PLUG(FOR FUEL TANK) | ||||
| 90105-12018 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# |
1 | ||
| 77100A - PLUG(FOR FUEL TANK) | ||||
| 90105-12018 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# |
1 | ||
| 77100B - GASKET(FOR FUEL TANK) | ||||
| 90430-12245 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# |
1 | ||
| 77100B - GASKET(FOR FUEL TANK) | ||||
| 90430-12245 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,6#,YN5#,6# |
1 | ||
| 77100D - HOSE, FUEL, NO.1(FOR FUEL TANK) | ||||
| 77408-35020 |
LN5#,60,65,67,RN5#,67,YN5#,60,62,65,67..T1 L=340 |
1 | ||
| 77201 - PIPE SUB-ASSY, FUEL TANK INLET | ||||
| 77201-35200 |
LN5#,YN5#..T1..(ARL,EUR,GEN,ME) |
1 | ||
| 77206 - TUBE SUB-ASSY, FUEL TANK SUCTION | ||||
| 77203-35220 |
LN50,51 |
1 | ||
| 77206 - TUBE SUB-ASSY, FUEL TANK SUCTION | ||||
| 77203-35220 |
LN50,51 |
1 | ||
| 77206A - GASKET (FOR FUEL TANK SUCTION TUBE) | ||||
| 77169-14020 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,67,YN5#,6# |
1 | ||
| 77206A - GASKET (FOR FUEL TANK SUCTION TUBE) | ||||
| 77169-14020 |
RN58..SR5;LN50,51,55,56,60,61,65,RN50,55,67,YN5#,6# |
1 | ||
| 77213 - HOSE, FUEL TANK SUB INLET | ||||
| 77213-35090 |
YN58..4F;YN58..T1..(SR5,STD);LN50,51,55,56,RN50,55,YN50,51,52,55,56,57..T1..(4F,4FC,4H,5F) |
1 | ||
| 77241 - TUBE, FUEL MAIN, NO.1 | ||||
| 77251-35300 |
LN50,51,60..STD |
1 | ||
| 77241A - HOSE, FUEL, NO.1 (FOR MAIN TUBE, NO.1) | ||||
| 95332-08030 |
LN5#,6#..RHD *H,L=260,ID=7.6 |
1 | ||
| 77241B - HOSE, FUEL, NO.2 (FOR MAIN TUBE, NO.1) | ||||
| 90445-14120 |
LN50,51 |
1 | ||
| 77277 - TUBE, FUEL RETURN, NO.1 | ||||
| 77255-35160 |
LN50,51,60..STD |
1 | ||
| 77277A - HOSE, FUEL, NO.1(FOR RETURN TUBE, NO.1) | ||||
| 90447-12034 |
LN5#,6# |
1 | ||
| 77277B - HOSE, FUEL, NO.2(FOR RETURN TUBE, NO.1) | ||||
| 90445-12134 |
LN50,51,YN50,52 |
1 | ||
| 77285B - CLAMP, FUEL TUBE W/GROMMET, NO.1 | ||||
| 77285-35040 |
LN5#,60,65,67..T1,T3,TW |
6 | ||
| 77285B - CLAMP, FUEL TUBE W/GROMMET, NO.1 | ||||
| 77285-35040 |
LN5#,60,65,67..T1,T3,TW |
6 | ||
| 77606 - PROTECTOR SUB-ASSY, FUEL TANK, NO.1 | ||||
| 77161-35050 |
YN58..4F;YN58..T1..(SR5,STD);LN50,51,55,56,RN50,55,YN50,51,52,55,56,57..(RCB,XTR)..(4F,4FC,4H,5F) |
1 | ||
| 77606 - PROTECTOR SUB-ASSY, FUEL TANK, NO.1 | ||||
| 77161-35050 |
YN58..4F;YN58..T1..(SR5,STD);LN50,51,55,56,RN50,55,YN50,51,52,55,56,57..(RCB,XTR)..(4F,4FC,4H,5F) |
1 | ||
| 77701A - HOSE, FUEL, NO.1 (FOR BREATHER VALVE) | ||||
| 90446-12007 |
LN50,51,YN50,52 L=456 |
1 | ||
| 77701A - HOSE, FUEL, NO.1 (FOR BREATHER VALVE) | ||||
| 90446-12007 |
LN50,51,YN50,52 L=456 |
1 | ||
| 77701B - HOSE, FUEL, NO.2 (FOR BREATHER VALVE) | ||||
| 95332-06010 |
LN50,51,YN50,52 *H,L=70 |
1 | ||
| 77701B - HOSE, FUEL, NO.2 (FOR BREATHER VALVE) | ||||
| 95332-06010 |
LN50,51,YN50,52 *H,L=70 |
1 | ||
| 77701T - VALVE, CHECK (FOR MAIN FUEL TANK) | ||||
| 90917-10054 |
YN55,57..GEN,ME,SA;LN50,51,RN58,YN50,51,52,56,58..T1..(EUR,GEN,ME,SA) |
1 | ||
| 77701T - VALVE, CHECK (FOR MAIN FUEL TANK) | ||||
| 90917-10054 |
YN55,57..GEN,ME,SA;LN50,51,RN58,YN50,51,52,56,58..T1..(EUR,GEN,ME,SA) |
1 | ||
| Common parts | ||||
| 90159-60221 | ||||
| 90159-60232 | ||||
| 90168-50041 | ||||
| 90170-08194 | ||||
| 90170-11006 | ||||
| 90179-08146 | ||||
| 90179-10033 | ||||
| 90201-06547 | ||||
| 90460-13081 | ||||
| 90460-22001 | ||||
| 90460-65004 | ||||
| 90461-08323 | ||||
| 90461-12284 | ||||
| 90462-10079 | ||||
| 90463-12002 | ||||
| 90463-15003 | ||||
| 90464-00108 | ||||
| 90480-01226 | ||||
| 90480-18492 | ||||
| 90480-28006 | ||||
| 90949-01299 | ||||
| 91611-60616 | ||||
| 91616-40816 | ||||
| 91616-40820 | ||||
| 91626-40618 | ||||
| 91631-40614 | ||||
| 91651-40614 | ||||
| 91651-60816 | ||||
| 91651-60825 | ||||
| 91656-40816 | ||||
| 91656-60816 | ||||
| 91656-60825 | ||||
| 93319-14010 | ||||
| 93385-15010 | ||||
| 93510-55010 | ||||
| 94110-40600 | ||||
| 96132-30600 | ||||
| 96132-30800 | ||||
