LN40R-QRW (1980)
Toyota Hilux
(7808-8108)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 83100B - BULB, COMBINATION METER, NO.1 | ||||
| 99132-12034 |
LN3#,4#,RN3#,4# 12V 3.4W,12V 3.4W |
12 | ||
| 83100G - GLASS, COMBINATION METER | ||||
| 83138-89132 |
RN3#,40,41;RN46..EUR,GEN;RN46..ARL..IV3 |
1 | ||
| 83138-89251 |
RN46..ARL..IV3;RN46..EUR,GEN,ME;LN46..T1..ARL..CBU;RN3#,40,41..DLX,STD W/O CLOCK |
1 | ||
| 83101 - SOCKET SUB-ASSY, COMBINATION METER BULB | ||||
| 83101-20040 |
LN3#,4#,RN3#,4# BULB=3.4W |
12 | ||
| 83102 - PLATE SUB-ASSY, COMBINATION METER CIRCUIT, NO.1 | ||||
| 83102-89130 |
RN3#,40,41;RN46..EUR,GEN;RN46..ARL..IV3 |
1 | ||
| 83102-89130 |
RN36;RN46..ARL..IV3;RN30,31,4#..EUR,GEN,PHL,SA |
1 | ||
| 83247-89211 |
LN40..5H..ECB |
1 | ||
| 83110 - SPEEDOMETER ASSY | ||||
| 83110-89135 |
RN3#,4#..EUR,GEN MILE & KM |
1 | ||
| 83110-89132 |
RN3#,4#..EUR,GEN,PHL,SA KM |
1 | ||
| 83110-89182 |
LN4#..RHD..EUR MILE & KM |
1 | ||
| 83111 - MECHANISM, SPEEDOMETER | ||||
| 83112-89132 |
RN3#,4#..EUR,GEN,PHL,SA KM |
1 | ||
| 83112-89135 |
RN3#,4#..EUR,GEN MILE |
1 | ||
| 83132 - CASE, COMBINATION METER | ||||
| 83132-89130 |
RN3#,40,41;RN46..EUR,GEN;RN46..ARL..IV3 |
1 | ||
| 83134 - COVER, COMBINATION METER, NO.1 | ||||
| 83134-89201 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN46..T1..(EUR,GEN);LN3#,40,RN30,31,40,41..DLX,STD W/O CLOCK & TACHOMETER |
1 | ||
| 83134-89130 |
RN3#,40,41;RN46..EUR,GEN;RN46..ARL..IV3 |
1 | ||
| 83134-89237 |
LN3#,4#;RN46..ARL..CBU |
1 | ||
| 83135 - POINTER, SPEEDOMETER | ||||
| 83135-89130 |
LN3#,4#,RN3#,4# |
1 | ||
| 83145 - LENS, METER, NO.1 | ||||
| 83145-89114 |
LN3#,4#,RN3#,4# |
2 | ||
| 83145 - LENS, METER, NO.1 | ||||
| 83145-89114 |
LN3#,4#,RN3#,4# |
2 | ||
| 83145A - LENS, METER, NO.2 | ||||
| 83145-89113 |
RN46..EUR,GEN;RN46..ARL..IV3;LN30,40,RN3#,40,41 |
1 | ||
| 83145-89220 |
LN3#,4#,RN3#,4#..EUR,GEN,PHL,SA |
1 | ||
| 83145B - LENS, METER, NO.3 | ||||
| 83145-89112 |
RN46..EUR,GEN;RN46..ARL..IV3;LN30,40,RN3#,40,41 |
1 | ||
| 83145-89213 |
LN3#,4#,RN3#,4# |
1 | ||
| 83145-89238 |
LN40,RN40..RHD..EUR W/RR FOG LAMP |
1 | ||
| 83145C - LENS, METER, NO.4 | ||||
| 83145-89223 |
LN3#,4#;RN46..ARL..CBU |
1 | ||
| 83145D - LENS, METER, NO.5 | ||||
| 83145-89111 |
RN46..EUR,GEN;RN46..ARL..IV3;LN30,40,RN3#,40,41 |
1 | ||
| 83145-89219 |
LN3#,4#,RN3#,4#..EUR,GEN,PHL,SA |
1 | ||
| 83145E - LENS, METER, NO.6 | ||||
| 83145-89119 |
RN30,31,40,41..EUR,GEN,PHL |
1 | ||
| 83310 - GAGE ASSY, FUEL RECEIVER | ||||
| 83310-89130 |
LN3#,4#,RN3#,4# |
1 | ||
| 83410 - GAGE ASSY, WATER TEMPERATURE RECEIVER | ||||
| 83410-89130 |
RN46..EUR,GEN;RN46..ARL..IV3;LN30,40,RN3#,40,41 |
1 | ||
| Common parts | ||||
| 83161-20080 | ||||
| 83161-20360 | ||||
| 83161-20380 | ||||
| 83161-20400 | ||||
| 83165-20020 | ||||
| 83165-20100 | ||||
| 90159-40029 | ||||
| 90183-04083 | ||||
| 93540-13016 | ||||
| 93540-14012 | ||||
| 94115-40400 | ||||
(8108- )RN46..ARL,EUR,GEN,ME ; (8108- )LN4#,RN3#,40,41..DLX,STD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 83100B - BULB, COMBINATION METER, NO.1 | ||||
| 99132-12034 |
LN3#,4#,RN3#,4# 12V 3.4W,12V 3.4W |
12 | ||
| 83100B - BULB, COMBINATION METER, NO.1 | ||||
| 99132-12034 |
LN3#,4#,RN3#,4# 12V 3.4W,12V 3.4W |
12 | ||
| 83100G - GLASS, COMBINATION METER | ||||
| 83138-89132 |
RN3#,40,41;RN46..EUR,GEN;RN46..ARL..IV3 |
1 | ||
| 83138-89251 |
RN46..ARL..IV3;RN46..EUR,GEN,ME;LN46..T1..ARL..CBU;RN3#,40,41..DLX,STD W/O CLOCK |
1 | ||
| 83101 - SOCKET SUB-ASSY, COMBINATION METER BULB | ||||
| 83101-20040 |
LN3#,4#,RN3#,4# BULB=3.4W |
12 | ||
| 83101 - SOCKET SUB-ASSY, COMBINATION METER BULB | ||||
| 83101-20040 |
LN3#,4#,RN3#,4# BULB=3.4W |
12 | ||
| 83102 - PLATE SUB-ASSY, COMBINATION METER CIRCUIT, NO.1 | ||||
| 83102-89130 |
RN3#,40,41;RN46..EUR,GEN;RN46..ARL..IV3 |
1 | ||
| 83102-89130 |
RN36;RN46..ARL..IV3;RN30,31,4#..EUR,GEN,PHL,SA |
1 | ||
| 83247-89211 |
LN40..5H..ECB |
1 | ||
| 83110 - SPEEDOMETER ASSY | ||||
| 83110-89135 |
RN3#,4#..EUR,GEN MILE & KM |
1 | ||
| 83110-89132 |
RN3#,4#..EUR,GEN,PHL,SA KM |
1 | ||
| 83110-89182 |
LN4#..RHD..EUR MILE & KM |
1 | ||
| 83132 - CASE, COMBINATION METER | ||||
| 83132-89130 |
RN3#,40,41;RN46..EUR,GEN;RN46..ARL..IV3 |
1 | ||
| 83134 - COVER, COMBINATION METER, NO.1 | ||||
| 83134-89201 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN46..T1..(EUR,GEN);LN3#,40,RN30,31,40,41..DLX,STD W/O CLOCK & TACHOMETER |
1 | ||
| 83134-89130 |
RN3#,40,41;RN46..EUR,GEN;RN46..ARL..IV3 |
1 | ||
| 83134-89237 |
LN3#,4#;RN46..ARL..CBU |
1 | ||
| 83145 - LENS, METER, NO.1 | ||||
| 83145-89114 |
LN3#,4#,RN3#,4# |
2 | ||
| 83145A - LENS, METER, NO.2 | ||||
| 83145-89113 |
RN46..EUR,GEN;RN46..ARL..IV3;LN30,40,RN3#,40,41 |
1 | ||
| 83145-89220 |
LN3#,4#,RN3#,4#..EUR,GEN,PHL,SA |
1 | ||
| 83145B - LENS, METER, NO.3 | ||||
| 83145-89112 |
RN46..EUR,GEN;RN46..ARL..IV3;LN30,40,RN3#,40,41 |
1 | ||
| 83145-89213 |
LN3#,4#,RN3#,4# |
1 | ||
| 83145-89238 |
LN40,RN40..RHD..EUR W/RR FOG LAMP |
1 | ||
| 83145C - LENS, METER, NO.4 | ||||
| 83145-89223 |
LN3#,4#;RN46..ARL..CBU |
1 | ||
| 83310 - GAGE ASSY, FUEL RECEIVER | ||||
| 83310-89130 |
LN3#,4#,RN3#,4# |
1 | ||
| 83410 - GAGE ASSY, WATER TEMPERATURE RECEIVER | ||||
| 83410-89130 |
RN46..EUR,GEN;RN46..ARL..IV3;LN30,40,RN3#,40,41 |
1 | ||
| Common parts | ||||
| 83161-20100 | ||||
| 83161-20320 | ||||
| 83161-20380 | ||||
| 83161-20420 | ||||
| 83165-20120 | ||||
| 94115-40400 | ||||
| 94511-00400 | ||||
(8108-8307)RN46..GEN,SA ; (8108-8307)RN36..EUR,GEN ; (8108-8307)RN46..LHD..EUR ; (8
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 83100B - BULB, COMBINATION METER, NO.1 | ||||
| 99132-12034 |
LN3#,4#,RN3#,4# 12V 3.4W,12V 3.4W |
12 | ||
| 83100B - BULB, COMBINATION METER, NO.1 | ||||
| 99132-12034 |
LN3#,4#,RN3#,4# 12V 3.4W,12V 3.4W |
12 | ||
| 83100G - GLASS, COMBINATION METER | ||||
| 83138-89132 |
RN3#,40,41;RN46..EUR,GEN;RN46..ARL..IV3 |
1 | ||
| 83138-89251 |
RN46..ARL..IV3;RN46..EUR,GEN,ME;LN46..T1..ARL..CBU;RN3#,40,41..DLX,STD W/O CLOCK |
1 | ||
| 83101 - SOCKET SUB-ASSY, COMBINATION METER BULB | ||||
| 83101-20040 |
LN3#,4#,RN3#,4# BULB=3.4W |
12 | ||
| 83101 - SOCKET SUB-ASSY, COMBINATION METER BULB | ||||
| 83101-20040 |
LN3#,4#,RN3#,4# BULB=3.4W |
12 | ||
| 83102 - PLATE SUB-ASSY, COMBINATION METER CIRCUIT, NO.1 | ||||
| 83102-89130 |
RN3#,40,41;RN46..EUR,GEN;RN46..ARL..IV3 |
1 | ||
| 83102-89130 |
RN36;RN46..ARL..IV3;RN30,31,4#..EUR,GEN,PHL,SA |
1 | ||
| 83247-89211 |
LN40..5H..ECB |
1 | ||
| 83110 - SPEEDOMETER ASSY | ||||
| 83110-89135 |
RN3#,4#..EUR,GEN MILE & KM |
1 | ||
| 83110-89132 |
RN3#,4#..EUR,GEN,PHL,SA KM |
1 | ||
| 83110-89182 |
LN4#..RHD..EUR MILE & KM |
1 | ||
| 83132 - CASE, COMBINATION METER | ||||
| 83132-89130 |
RN3#,40,41;RN46..EUR,GEN;RN46..ARL..IV3 |
1 | ||
| 83134 - COVER, COMBINATION METER, NO.1 | ||||
| 83134-89201 |
LN46..TW;LN46..ARL..IV3;RN46..ARL..CBU;LN46..T1..(EUR,GEN);LN3#,40,RN30,31,40,41..DLX,STD W/O CLOCK & TACHOMETER |
1 | ||
| 83134-89130 |
RN3#,40,41;RN46..EUR,GEN;RN46..ARL..IV3 |
1 | ||
| 83134-89237 |
LN3#,4#;RN46..ARL..CBU |
1 | ||
| 83145 - LENS, METER, NO.1 | ||||
| 83145-89114 |
LN3#,4#,RN3#,4# |
2 | ||
| 83145A - LENS, METER, NO.2 | ||||
| 83145-89113 |
RN46..EUR,GEN;RN46..ARL..IV3;LN30,40,RN3#,40,41 |
1 | ||
| 83145-89220 |
LN3#,4#,RN3#,4#..EUR,GEN,PHL,SA |
1 | ||
| 83310 - GAGE ASSY, FUEL RECEIVER | ||||
| 83310-89130 |
LN3#,4#,RN3#,4# |
1 | ||
| 83410 - GAGE ASSY, WATER TEMPERATURE RECEIVER | ||||
| 83410-89130 |
RN46..EUR,GEN;RN46..ARL..IV3;LN30,40,RN3#,40,41 |
1 | ||
| Common parts | ||||
| 83161-20080 | ||||
| 83161-20100 | ||||
| 83161-20300 | ||||
| 83161-20320 | ||||
| 83161-20380 | ||||
| 83165-20120 | ||||
| 94115-40400 | ||||
| 94511-00400 | ||||
