KDN145L-TRMDYW (2001)

Toyota Hilux

Production Aug 2001 - Aug 2005
Engine 2KDFTV
Transmission MTM
Displacement 2500cc
Power 168 HP (125 kW)

(7808- )

Click highlighted areas on diagram

diagram 37199 37199 74519 74533 74562 74582
Part # Description Qty Price

(9708- )

Click highlighted areas on diagram

diagram 28897A 36369 41991A 74529 74559A 74567A 74582 74751 88723H 9026903029
Part # Description Qty Price
28897A - PLATE, BATTERY CAUTION
28897-54030

2KDFTV..KDN145..DLX;2KDFTV..KDN150,165,170

 1
74559A - PLATE, FUEL CAUTION
74559-89101

KDN145,150,165,170,190

 1
74567A - PLATE, E.C.E APPROVED NUMBER
74567-20261

KDN145,150,165,170,190

 1
74582 - PLATE, LOAD SENSING VALVE MARKING
47939-35400

KDN145..SCB

 1
74751 - LABEL, TIRE PRESSURE INFORMATION
42661-35520

KDN145..LHD..SCB

W(195R14C-8 TIRE)

 1
42661-35530

KDN145

 1
88723H - LABEL, COOLER SERVICE CAUTION
88723-20040

KDN145..SCB;KDN165..CBU;KDN165..SCB..IV3;KDN145,150,170,190..(DCB,XTR)..CBU

 1
Common parts
90269-03029
