GUN135L-BNFXHW (2016)
Toyota Hilux
(1604- )LHD..SADCB,SASCB,SAXTR
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 53866J - SEAL, FRONT FENDER TO COWL SIDE, RH | ||||
| 53866-0K050 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
1 | ||
| 53867H - SEAL, FRONT FENDER TO COWL SIDE, LH | ||||
| 53867-0K050 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
1 | ||
| 55701 - PANEL SUB-ASSY, COWL | ||||
| 55700-KK020 |
GUN12#..LHD;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
1 | ||
| 55705B - PANEL SUB-ASSY, COWL TOP SIDE, RH | ||||
| 55705-KK010 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
1 | ||
| 55706B - PANEL SUB-ASSY, COWL TOP SIDE, LH | ||||
| 55706-KK010 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
1 | ||
| 55798A - SUPPORT, COWL WATER EXTRACT SEAL | ||||
| 55798-0K010 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
1 | ||
| 55799C - CLIP, COWL TOP VENTILATOR LOUVER | ||||
| 90467-07215 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
2 | ||
| 55799C - CLIP, COWL TOP VENTILATOR LOUVER | ||||
| 90467-07215 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
2 | ||
| 56111 - GLASS, WINDSHIELD | ||||
| 56101-0K590 |
GUN125,135..LHD..(SADCB,SASCB,SAXTR)..(S,X) PRE-COLLISION SYSTEM-WITH,TYPE A:REFER ILLUST. |
1 | ||
| 56101-0K390 |
GUN135..SAXTR..S;GUN135..(SADCB,SASCB)..(S,X);GUN125..LHD..(SADCB,SASCB,SAXTR)..(S,X) |
1 | ||
| 56101-0K591 |
GUN135..SAXTR..S;GUN135..(SADCB,SASCB)..(S,X);GUN125..LHD..(SADCB,SASCB,SAXTR)..(S,X) PRE-COLLISION SYSTEM-WITH,TYPE B:REFER ILLUST. |
1 | ||
| 56115C - STOPPER, WINDSHIELD GLASS | ||||
| 56115-30100 |
GUN126;GUN135..THDCB..M;GUN135..SADCB,SASCB;GUN125..THDCB..DCRE;GUN135..SAXTR..S..HDCR;GUN125..SADCB,SASCB,SAXTR;GUN125..THDCB..(H,M)..HDCR;GUN135..(SAXTR,THDCB)..(S,X)..DCRE |
1 | ||
| 56116C - STOPPER, WINDSHIELD GLASS, NO.2 | ||||
| 56116-22050 |
GUN126;GUN135..THDCB..M;GUN135..SADCB,SASCB;GUN125..THDCB..DCRE;GUN135..SAXTR..S..HDCR;GUN125..SADCB,SASCB,SAXTR;GUN125..THDCB..(H,M)..HDCR;GUN135..(SAXTR,THDCB)..(S,X)..DCRE |
1 | ||
| 56117A - DAM, WINDOW GLASS ADHESIVE | ||||
| 56117-KK060 |
GUN135..SAXTR..S;GUN135..(SADCB,SASCB)..(S,X);GUN125..(SADCB,SASCB,SAXTR)..(S,X) L=2620,PRE-COLLISION SYSTEM-WITH |
1 | ||
| 56117-KK060 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB L=2620 |
1 | ||
| 56117-KK060 |
GUN12#,135..H,M L=2620,AUDIO-*DA & CD & *BT & RDS & DAB |
1 | ||
| 56118A - DAM, WINDOW GLASS ADHESIVE, NO.2 | ||||
| 56117-KK030 |
GUN135..SAXTR..S;GUN135..(SADCB,SASCB)..(S,X);GUN125..(SADCB,SASCB,SAXTR)..(S,X) L=1248,PRE-COLLISION SYSTEM-WITH |
1 | ||
| 56117-KK030 |
GUN12#,135..H,M L=1248,AUDIO-*DA & CD & *BT & RDS & DAB |
1 | ||
| 56117-KK030 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB L=1248 |
1 | ||
| Common parts | ||||
| 67867-0C010 | ||||
| 90467-10216 | ||||
| Linked diagrams | ||||
| 8604 | ||||
| 8617 | ||||
