GUN125R-DNTMXW (2019)
Toyota Hilux
(0507- )DCB,THDCB
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90119-06869 | ||||
| 90467-06155 | ||||
| 90467-09204 | ||||
| 90467-10161 | ||||
| 90467-10188 | ||||
| 90467-T0008C0 | ||||
| 90467-T0021 | ||||
| Linked diagrams | ||||
| 7152 | ||||
| 7455 | ||||
(1506- )SADCB,THDCB
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 62117B - CLIP, NO.1(FOR COWL SIDE TRIM) | ||||
| 90467-11089A0 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB IVORY |
4 | ||
| 62117C - CLIP, NO.2(FOR COWL SIDE TRIM) | ||||
| 90467-06147 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
2 | ||
| 62170B - BOLT, W/WASHER | ||||
| 91673-80616 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
4 | ||
| 62189A - SPACER, CURTAIN SHIELD AIR BAG CLIP | ||||
| 62189-42010 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
4 | ||
| 62211 - GARNISH, FRONT PILLAR, RH | ||||
| 62211-KK030C0 |
GUN125..(SADCB,SAXTR)..(H,M) BLACK,TRIM21 |
1 | ||
| 62211D - CLIP(FOR FRONT BODY PILLAR GARNISH) | ||||
| 90467-T0021 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
2 | ||
| 62211T - CLIP(FOR FRONT PILLAR GARNISH) | ||||
| 90467-T0021 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
2 | ||
| 62212 - GARNISH, FRONT PILLAR, LH | ||||
| 62212-KK030C0 |
GUN125..(SADCB,SAXTR)..(H,M) BLACK,TRIM21 |
1 | ||
| 62411B - GARNISH, CENTER PILLAR, UPPER RH | ||||
| 62411-KK020B0 |
GUN125..SADCB..(H,M) LT.GRAY,TRIM20 |
1 | ||
| 62412B - GARNISH, CENTER PILLAR, UPPER LH | ||||
| 62412-KK020B0 |
GUN125..SADCB..(H,M) LT.GRAY,TRIM20 |
1 | ||
| 62471F - CLIP (FOR ROOF SIDE, INNER UPPER GARNISH) | ||||
| 90467-10188 |
GUN12#,135..SADCB,THDCB |
2 | ||
| 62471M - CLIP | ||||
| 90467-T0021 |
GUN12#,135..SADCB,SASCB,THDCB |
6 | ||
| 62510K - CLIP(FOR QUARTER TRIM FRONT PANEL) | ||||
| 90467-10188 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
2 | ||
| 62511 - BOARD, QUARTER INSIDE TRIM, RH | ||||
| 62511-KK070B0 |
GUN125..SADCB..(H,M) LT.GRAY,TRIM20 |
1 | ||
| 62511B - CLIP (FOR QUARTER INSIDE TRIM BOARD) | ||||
| 90467-T0021 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
4 | ||
| 62511G - CLIP (FOR QUARTER INSIDE TRIM BOARD) | ||||
| 90467-T0021 |
GUN135..SAXTR..DCRE..IV3;GUN12#..SADCB,SAXTR,THDCB;GUN135..(SADCB,SAXTR,THDCB)..(M,S) |
4 | ||
| 62512 - BOARD, QUARTER INSIDE TRIM, LH | ||||
| 62512-KK070B0 |
GUN125..SADCB..(H,M) LT.GRAY,TRIM20 |
1 | ||
| 64261C - GARNISH, BACK PANEL, UPPER | ||||
| 64261-YP020C0 |
GUN125..RHD..(H,M);GUN125..LHD..SADCB..6FC..H "BLACK RALLY EDITION"*(B),BLACK,TRIM2# |
1 | ||
| 64261-KK050B0 |
GUN125..RHD..(H,M);GUN125..LHD..SADCB..6FC..M;GUN125..LHD..SADCB..6F..(H,M) LT.GRAY,TRIM20 |
1 | ||
| 64271D - CLIP(FOR BACK PANEL TRIM) | ||||
| 90467-T0004C1 |
GUN12#,135..SADCB,THDCB BLACK |
5 | ||
| 64275C - COVER, BACK PANEL TRIM | ||||
| 64275-0K030B0 |
GUN125..SADCB..6FC..H LT.GRAY,TRIM2#,3# |
1 | ||
| 64275-0K030B0 |
GUN135..M..DCRE;GUN125..THDCB..(H,M)..DCRE;GUN125..LHD..SADCB..6FC..H..DCRE;GUN125,135..(SADCB,THDCB)..(S,X) LT.GRAY,TRIM2# |
1 | ||
| 64275-0K030B0 |
GUN125..RHD..(H,M);GUN125..LHD..SADCB..6FC..M;GUN125..LHD..SADCB..6F..(H,M) LT.GRAY,TRIM20 |
1 | ||
| Common parts | ||||
| 90467-18017 | ||||
| 90467-T0021 | ||||
| Linked diagrams | ||||
| 7152 | ||||
(2005- )SADCB,THDCB
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90467-18017 | ||||
| 90467-T0021 | ||||
| Linked diagrams | ||||
| 7152 | ||||
