GUN125L-DNTHHW (2016)
Toyota Hilux
(1712- )
PREMIUM PACKAGE
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 47749F - CLIP, PIN HOLD | ||||
| 47749-50090 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
2 | ||
| 52021 - REINFORCEMENT SUB-ASSY, FRONT BUMPER | ||||
| 52021-KK010 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
1 | ||
| 52119A - COVER, FRONT BUMPER | ||||
| 52119-0M943 |
GUN12#,135..(SADCB,SAXTR)..(H,M) PAINT REQ. |
1 | ||
| 52119-YP905 |
GUN125..LHD..SADCB..6FC..H PAINT REQ.,UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
1 | ||
| 52119-0M945 |
GUN125,135..(SADCB,SAXTR)..(H,M) PAINT REQ.,TOYOTA STOP & START SYSTEM-WITH |
1 | ||
| 52119-YP905 |
GUN125..LHD..SADCB..6FC..H PAINT REQ.,UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOG LAMP-WITH(LED) |
1 | ||
| 52119-0M980 |
GUN125..LHD..SADCB..S..CBU PAINT REQ.,UKRAINE SPEC(EURO 6 REGULATION)&FRONT BUMPER-PAINTED & WITH(WIDE FENDER)&FRONT FOG LAMP-WITH |
1 | ||
| 52119-YP905 |
GUN125..SADCB..6FC..H PAINT REQ.,PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH&FRONT FOG LAMP-WITH(LED) |
1 | ||
| 52119-0M980 |
GUN125..LHD..SADCB..S..CBU PAINT REQ.,RUSSIA & UKRAINE SPEC&FRONT BUMPER-PAINTED & WITH(WIDE FENDER)&FRONT FOG LAMP-WITH |
1 | ||
| 52119-YP905 |
GUN125..SADCB..6FC..H PAINT REQ.,PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
1 | ||
| 52119-YP905 |
GUN125..SADCB..6FC..H PAINT REQ.,PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH |
1 | ||
| 52119-YP905 |
GUN125..SADCB..6FC..H PAINT REQ.,PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOG LAMP-WITH(LED) |
1 | ||
| 52119D - SCREW, NO.1 | ||||
| 90159-60217 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
6 | ||
| 52125A - BRACKET, FOG LAMP MOUNTING, RH | ||||
| 52125-0K080 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&FRONT FOG LAMP-WITH(LED) |
1 | ||
| 52125-0K080 |
GUN125..LHD..SADCB..6F..M RUSSIA & UKRAINE SPEC |
1 | ||
| 52125-YP060 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOGLAMP-WITH(LED) |
1 | ||
| 52125-0K080 |
GUN125..LHD..SADCB..S..CBU RUSSIA & UKRAINE SPEC&FRONT FOG LAMP-WITH |
1 | ||
| 52125-0K080 |
GUN125..LHD..SADCB..S..CBU RUSSIA & UKRAINE SPEC&FRONT BUMPER-PAINTED & WITH(WIDE FENDER)&FRONT FOG LAMP-WITH |
1 | ||
| 52125-YP060 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
1 | ||
| 52125-0K080 |
GUN125..LHD..SADCB..M;GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION) |
1 | ||
| 52125-0K080 |
GUN125..LHD..SADCB..S..CBU UKRAINE SPEC(EURO 6 REGULATION)&FRONT BUMPER-PAINTED & WITH(WIDE FENDER)&FRONT FOG LAMP-WITH |
1 | ||
| 52125-YP080 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
1 | ||
| 52125-YP080 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH&FRONT FOGLAMP-WITH(LED) |
1 | ||
| 52125-YP080 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH |
1 | ||
| 52125-0K060 |
GUN125..6FC..S;GUN125,135..THDCB..6F..S..DCRE FRONT BUMPER-PAINTED & WITH(WIDE FENDER)&FRONT FOG LAMP-WITH |
1 | ||
| 52125-0K080 |
GUN125..LHD..SADCB..S..CBU UKRAINE SPEC(EURO 6 REGULATION)&FRONT FOG LAMP-WITH |
1 | ||
| 52125-YP080 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOG LAMP-WITH(LED) |
1 | ||
| 52125-0K060 |
GUN125..6FC..S;GUN135..THDCB..S;GUN125..THDCB..6F..S..DCRE FRONT FOG LAMP-WITH |
1 | ||
| 52126A - BRACKET, FOG LAMP MOUNTING, LH | ||||
| 52126-YP060 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOGLAMP-WITH(LED) |
1 | ||
| 52126-0K080 |
GUN125..LHD..SADCB..S..CBU RUSSIA & UKRAINE SPEC&FRONT BUMPER-PAINTED & WITH(WIDE FENDER)&FRONT FOG LAMP-WITH |
1 | ||
| 52126-YP060 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
1 | ||
| 52126-0K080 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&FRONT FOG LAMP-WITH(LED) |
1 | ||
| 52126-0K080 |
GUN125..LHD..SADCB..6F..M RUSSIA & UKRAINE SPEC |
1 | ||
| 52126-0K080 |
GUN125..LHD..SADCB..M;GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION) |
1 | ||
| 52126-0K080 |
GUN125..LHD..SADCB..S..CBU RUSSIA & UKRAINE SPEC&FRONT FOG LAMP-WITH |
1 | ||
| 52126-YP080 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOG LAMP-WITH(LED) |
1 | ||
| 52126-YP080 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH&FRONT FOGLAMP-WITH(LED) |
1 | ||
| 52126-YP080 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH |
1 | ||
| 52126-0K080 |
GUN125..LHD..SADCB..S..CBU UKRAINE SPEC(EURO 6 REGULATION)&FRONT FOG LAMP-WITH |
1 | ||
| 52126-0K080 |
GUN125..LHD..SADCB..S..CBU UKRAINE SPEC(EURO 6 REGULATION)&FRONT BUMPER-PAINTED & WITH(WIDE FENDER)&FRONT FOG LAMP-WITH |
1 | ||
| 52126-YP080 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
1 | ||
| 52126-0K060 |
GUN125..6FC..S;GUN135..THDCB..S;GUN125..THDCB..6F..S..DCRE FRONT FOG LAMP-WITH |
1 | ||
| 52126-0K060 |
GUN125..6FC..S;GUN125,135..THDCB..6F..S..DCRE FRONT BUMPER-PAINTED & WITH(WIDE FENDER)&FRONT FOG LAMP-WITH |
1 | ||
| 52161T - PIECE, FRONT BUMPER | ||||
| 52161-0K040 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
2 | ||
| 52411 - GUARD, FRONT BUMPER | ||||
| 52411-YP030 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
1 | ||
| 52411-YP030 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOGLAMP-WITH(LED) |
1 | ||
| 52411-YP030 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
1 | ||
| 52411-YP030 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOG LAMP-WITH(LED) |
1 | ||
| 52411-YP030 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH |
1 | ||
| 52411-YP030 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH&FRONT FOGLAMP-WITH(LED) |
1 | ||
| 52421A - PAD, FRONT BUMPER | ||||
| 52421-60191 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
3 | ||
| 52492 - BOLT, BUMPER PAD, NO.2 | ||||
| 52491-60010 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
3 | ||
| 52521A - CLIP(FOR FRONT BUMPER RETAINER) | ||||
| 90467-05114 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
6 | ||
| 53112E - GRILLE, RADIATOR, LOWER NO.1 | ||||
| 53112-YP060 |
GUN125..SADCB..6FC..H NO PAINT REQ.,PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
1 | ||
| 53112-YP060 |
GUN125..SADCB..6FC..H NO PAINT REQ.,PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH&FRONT FOG LAMP-WITH(LED) |
1 | ||
| 53112-YP060 |
GUN125..SADCB..6FC..H NO PAINT REQ.,PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH |
1 | ||
| 53112-YP060 |
GUN125..SADCB..6FC..H NO PAINT REQ.,PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOG LAMP-WITH(LED) |
1 | ||
| 53112-YP060 |
GUN125..LHD..SADCB..6FC..H NO PAINT REQ.,UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOG LAMP-WITH(LED) |
1 | ||
| 53112-YP060 |
GUN125..LHD..SADCB..6FC..H NO PAINT REQ.,UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
1 | ||
| 53162A - DEFLECTOR, FRONT BUMPER STONE, RH | ||||
| 53162-KK010 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
1 | ||
| 53163A - DEFLECTOR, FRONT BUMPER STONE, LH | ||||
| 53163-KK010 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
1 | ||
| 53879M - RETAINER, FRONT FENDER LINER | ||||
| 53879-50020 |
GUN12#;GUN135..SAXTR..IV3;GUN135..SAXTR..S..CBU;GUN135..SADCB,SASCB,THDCB |
2 | ||
| 75392 - RETAINER, OUTSIDE MOULDING | ||||
| 75392-0K010 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH |
19 | ||
| 75392-0K010 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH&FRONT FOGLAMP-WITH(LED) |
19 | ||
| 75392-0K010 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOGLAMP-WITH(LED) |
19 | ||
| 75392-0K010 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
19 | ||
| 75392-0K010 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOG LAMP-WITH(LED) |
19 | ||
| 75392-0K010 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
19 | ||
| 75392 - RETAINER, OUTSIDE MOULDING | ||||
| 75392-0K010 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH |
19 | ||
| 75392-0K010 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH&FRONT FOGLAMP-WITH(LED) |
19 | ||
| 75392-0K010 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOGLAMP-WITH(LED) |
19 | ||
| 75392-0K010 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
19 | ||
| 75392-0K010 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOG LAMP-WITH(LED) |
19 | ||
| 75392-0K010 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
19 | ||
| 81481E - COVER, FOG LAMP, RH | ||||
| 52127-0K170 |
GUN125..LHD..SADCB..S..CBU RUSSIA & UKRAINE SPEC&FRONT BUMPER-PAINTED & WITH(WIDE FENDER)&FRONT FOG LAMP-WITH |
1 | ||
| 52127-0K170 |
GUN125..LHD..SADCB..S..CBU UKRAINE SPEC(EURO 6 REGULATION)&FRONT BUMPER-PAINTED & WITH(WIDE FENDER)&FRONT FOG LAMP-WITH |
1 | ||
| 52127-0K170 |
GUN125..LHD..SADCB..6F..M RUSSIA & UKRAINE SPEC |
1 | ||
| 52127-0K170 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&FRONT FOG LAMP-WITH(LED) |
1 | ||
| 52127-YP100 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
1 | ||
| 52127-0K170 |
GUN125..LHD..SADCB..S..CBU UKRAINE SPEC(EURO 6 REGULATION)&FRONT FOG LAMP-WITH |
1 | ||
| 52127-YP100 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOGLAMP-WITH(LED) |
1 | ||
| 52127-0K170 |
GUN125..LHD..SADCB..S..CBU RUSSIA & UKRAINE SPEC&FRONT FOG LAMP-WITH |
1 | ||
| 52127-0K170 |
GUN125..LHD..SADCB..M;GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION) |
1 | ||
| 52127-YP110 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH&FRONT FOGLAMP-WITH(LED) |
1 | ||
| 52127-YP110 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOG LAMP-WITH(LED) |
1 | ||
| 52127-YP110 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH |
1 | ||
| 52127-YP110 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
1 | ||
| 81482C - COVER, FOG LAMP, LH | ||||
| 52128-0K170 |
GUN125..LHD..SADCB..S..CBU RUSSIA & UKRAINE SPEC&FRONT BUMPER-PAINTED & WITH(WIDE FENDER)&FRONT FOG LAMP-WITH |
1 | ||
| 52128-0K170 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&FRONT FOG LAMP-WITH(LED) |
1 | ||
| 52128-YP100 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOGLAMP-WITH(LED) |
1 | ||
| 52128-YP100 |
GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION)&PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
1 | ||
| 52128-0K170 |
GUN125..LHD..SADCB..M;GUN125..LHD..SADCB..6FC..H UKRAINE SPEC(EURO 6 REGULATION) |
1 | ||
| 52128-0K170 |
GUN125..LHD..SADCB..S..CBU UKRAINE SPEC(EURO 6 REGULATION)&FRONT FOG LAMP-WITH |
1 | ||
| 52128-0K170 |
GUN125..LHD..SADCB..S..CBU UKRAINE SPEC(EURO 6 REGULATION)&FRONT BUMPER-PAINTED & WITH(WIDE FENDER)&FRONT FOG LAMP-WITH |
1 | ||
| 52128-YP110 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&FRONT FOG LAMP-WITH(LED) |
1 | ||
| 52128-0K170 |
GUN125..LHD..SADCB..6F..M RUSSIA & UKRAINE SPEC |
1 | ||
| 52128-YP110 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH |
1 | ||
| 52128-YP110 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK)&TOYOTA STOP & START SYSTEM-WITH&FRONT FOGLAMP-WITH(LED) |
1 | ||
| 52128-YP110 |
GUN125..SADCB..6FC..H PREMIUM FULL PACKAGE(HOOD MOLD = BLACK) |
1 | ||
| 52128-0K170 |
GUN125..LHD..SADCB..S..CBU RUSSIA & UKRAINE SPEC&FRONT FOG LAMP-WITH |
1 | ||
| Common parts | ||||
| 90105-T0144 | ||||
| 90109-06272 | ||||
| 90159-T0033 | ||||
| 90167-40057 | ||||
| 90179-06349 | ||||
| 90183-06030 | ||||
| 90189-T0019 | ||||
| 90467-05170 | ||||
| 90467-09232 | ||||
| 90467-09237 | ||||
| Linked diagrams | ||||
| 8102 | ||||
