YH61RV-QRBQ (1982)
Toyota Hiace Van,Commuter
(8212-8401) ; (8401-8508)STD..EUR,GEN,SA
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04817 - HEADLAMP KIT, W/O SEALED BEAM, RH | ||||
| 04817-26020 |
YH51;LH50,60,70,YH50,6#,71..ARL,EUR,GEN *SSB HALOGEN,WHITE |
1 | ||
| 04817-26040 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL HALOGEN |
1 | ||
| 04818 - HEADLAMP KIT, W/O SEALED BEAM, LH | ||||
| 04818-26020 |
YH51;LH50,60,70,YH50,6#,71..ARL,EUR,GEN *SSB HALOGEN,WHITE |
1 | ||
| 04818-26040 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL HALOGEN |
1 | ||
| 81105 - HOUSING SUB-ASSY, HEADLAMP, RH | ||||
| 81105-95J08 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
1 | ||
| 81105-95J00 |
LH50,60,70,YH5#,6#,71 |
1 | ||
| 81106 - HOUSING SUB-ASSY, HEADLAMP, LH | ||||
| 81106-95J08 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
1 | ||
| 81106-95J00 |
LH50,60,70,YH5#,6#,71 |
1 | ||
| 81110 - HEADLAMP ASSY, RH | ||||
| 81110-80285 |
LH50,60,70,YH50,6#,71..RHD..(ARL,GEN,SA) SEALED BEAM |
1 | ||
| 81110-80296 |
LH50,60,70,YH51,60,71..RHD;YH50,61..RHD..(ARL,EUR,GEN) *SSB HALOGEN,WHITE |
1 | ||
| 81110-80384 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL HALOGEN |
1 | ||
| 81110B - BULB(FOR HEADLAMP, NO.1) | ||||
| 90981-13015 |
YH51;LH50,60,70,YH50,6#,71..ARL,EUR,GEN 12V 60/55W,*HAL *WH,12V 60/55W,*SSB HALOGEN,WHITE |
2 | ||
| 81110S - SEALED BEAM UNIT, NO.1 | ||||
| 90981-01022 |
LH50,60,70,YH50,6#,71..RHD..(ARL,GEN,SA) 12V 60/50W,*WB,12V 60/55W,SEALED BEAM |
2 | ||
| 90981-01037 |
LH50,60,70,YH51,60,71..RHD;YH50,61..RHD..(ARL,EUR,GEN) 12V 60/55W,*HWS,12V 60/55W,*SSB HALOGEN,WHITE |
2 | ||
| 90981-05028 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL 12V 50W,*HAL,*WB,12V 50W,HALOGEN |
2 | ||
| 81110S - SEALED BEAM UNIT, NO.1 | ||||
| 90981-01022 |
LH50,60,70,YH50,6#,71..RHD..(ARL,GEN,SA) 12V 60/50W,*WB,12V 60/55W,SEALED BEAM |
2 | ||
| 90981-01037 |
LH50,60,70,YH51,60,71..RHD;YH50,61..RHD..(ARL,EUR,GEN) 12V 60/55W,*HWS,12V 60/55W,*SSB HALOGEN,WHITE |
2 | ||
| 90981-05028 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL 12V 50W,*HAL,*WB,12V 50W,HALOGEN |
2 | ||
| 81111 - RING, SEALED BEAM RETAINING | ||||
| 81111-20360 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
4 | ||
| 81111-22150 |
LH50,60,70,YH5#,6#,71 |
2 | ||
| 81113 - RING, SEALED BEAM MOUNTING, NO.1 RH | ||||
| 81113-22391 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
1 | ||
| 81113-95J00 |
LH50,60,70,YH5#,6#,71 |
1 | ||
| 81121 - SPRING, HEADLAMP TENSION | ||||
| 81121-14320 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
4 | ||
| 81121-62010 |
LH50,60,70,YH5#,6#,71 |
2 | ||
| 81131 - SCREW, HEADLAMP ADJUSTING | ||||
| 81131-10031 |
LH50,60,70,YH5#,6#,71 |
4 | ||
| 81131-20360 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
8 | ||
| 81150 - HEADLAMP ASSY, LH | ||||
| 81150-80282 |
LH50,60,70,YH50,6#,71..RHD..(ARL,GEN,SA) SEALED BEAM |
1 | ||
| 81150-80293 |
LH50,60,70,YH51,60,71..RHD;YH50,61..RHD..(ARL,EUR,GEN) *SSB HALOGEN,WHITE |
1 | ||
| 81150-80378 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL HALOGEN |
1 | ||
| 81153 - RING, SEALED BEAM MOUNTING, NO.1 LH | ||||
| 81153-22391 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
1 | ||
| 81153-95J00 |
LH50,60,70,YH5#,6#,71 |
1 | ||
| Common parts | ||||
| 81136-12571 | ||||
| 93385-16014 | ||||
(8401-8508)GL ; (8401-8508)ARL ; (8508- )GL
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04817 - HEADLAMP KIT, W/O SEALED BEAM, RH | ||||
| 04817-26020 |
YH51;LH50,60,70,YH50,6#,71..ARL,EUR,GEN *SSB HALOGEN,WHITE |
1 | ||
| 04817-26040 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL HALOGEN |
1 | ||
| 04818 - HEADLAMP KIT, W/O SEALED BEAM, LH | ||||
| 04818-26020 |
YH51;LH50,60,70,YH50,6#,71..ARL,EUR,GEN *SSB HALOGEN,WHITE |
1 | ||
| 04818-26040 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL HALOGEN |
1 | ||
| 81105 - HOUSING SUB-ASSY, HEADLAMP, RH | ||||
| 81105-95J08 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
1 | ||
| 81105-95J00 |
LH50,60,70,YH5#,6#,71 |
1 | ||
| 81106 - HOUSING SUB-ASSY, HEADLAMP, LH | ||||
| 81106-95J08 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
1 | ||
| 81106-95J00 |
LH50,60,70,YH5#,6#,71 |
1 | ||
| 81110 - HEADLAMP ASSY, RH | ||||
| 81110-80285 |
LH50,60,70,YH50,6#,71..RHD..(ARL,GEN,SA) SEALED BEAM |
1 | ||
| 81110-80296 |
LH50,60,70,YH51,60,71..RHD;YH50,61..RHD..(ARL,EUR,GEN) *SSB HALOGEN,WHITE |
1 | ||
| 81110-80384 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL HALOGEN |
1 | ||
| 81110 - HEADLAMP ASSY, RH | ||||
| 81110-80285 |
LH50,60,70,YH50,6#,71..RHD..(ARL,GEN,SA) SEALED BEAM |
1 | ||
| 81110-80296 |
LH50,60,70,YH51,60,71..RHD;YH50,61..RHD..(ARL,EUR,GEN) *SSB HALOGEN,WHITE |
1 | ||
| 81110-80384 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL HALOGEN |
1 | ||
| 81110B - BULB(FOR HEADLAMP, NO.1) | ||||
| 90981-13015 |
YH51;LH50,60,70,YH50,6#,71..ARL,EUR,GEN 12V 60/55W,*HAL *WH,12V 60/55W,*SSB HALOGEN,WHITE |
2 | ||
| 81110S - SEALED BEAM UNIT, NO.1 | ||||
| 90981-01022 |
LH50,60,70,YH50,6#,71..RHD..(ARL,GEN,SA) 12V 60/50W,*WB,12V 60/55W,SEALED BEAM |
2 | ||
| 90981-01037 |
LH50,60,70,YH51,60,71..RHD;YH50,61..RHD..(ARL,EUR,GEN) 12V 60/55W,*HWS,12V 60/55W,*SSB HALOGEN,WHITE |
2 | ||
| 90981-05028 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL 12V 50W,*HAL,*WB,12V 50W,HALOGEN |
2 | ||
| 81110S - SEALED BEAM UNIT, NO.1 | ||||
| 90981-01022 |
LH50,60,70,YH50,6#,71..RHD..(ARL,GEN,SA) 12V 60/50W,*WB,12V 60/55W,SEALED BEAM |
2 | ||
| 90981-01037 |
LH50,60,70,YH51,60,71..RHD;YH50,61..RHD..(ARL,EUR,GEN) 12V 60/55W,*HWS,12V 60/55W,*SSB HALOGEN,WHITE |
2 | ||
| 90981-05028 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL 12V 50W,*HAL,*WB,12V 50W,HALOGEN |
2 | ||
| 81110T - SEALED BEAM UNIT, NO.2 | ||||
| 90981-05032 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL 12V 35/50W,*HAL,*WB,12V 35/50W,HALOGEN |
2 | ||
| 81110T - SEALED BEAM UNIT, NO.2 | ||||
| 90981-05032 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL 12V 35/50W,*HAL,*WB,12V 35/50W,HALOGEN |
2 | ||
| 81111 - RING, SEALED BEAM RETAINING | ||||
| 81111-20360 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
4 | ||
| 81111-22150 |
LH50,60,70,YH5#,6#,71 |
2 | ||
| 81111 - RING, SEALED BEAM RETAINING | ||||
| 81111-20360 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
4 | ||
| 81111-22150 |
LH50,60,70,YH5#,6#,71 |
2 | ||
| 81113 - RING, SEALED BEAM MOUNTING, NO.1 RH | ||||
| 81113-22391 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
1 | ||
| 81113-95J00 |
LH50,60,70,YH5#,6#,71 |
1 | ||
| 81114 - RING, SEALED BEAM MOUNTING, NO.2 RH | ||||
| 81154-22391 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
1 | ||
| 81121 - SPRING, HEADLAMP TENSION | ||||
| 81121-14320 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
4 | ||
| 81121-62010 |
LH50,60,70,YH5#,6#,71 |
2 | ||
| 81121 - SPRING, HEADLAMP TENSION | ||||
| 81121-14320 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
4 | ||
| 81121-62010 |
LH50,60,70,YH5#,6#,71 |
2 | ||
| 81131 - SCREW, HEADLAMP ADJUSTING | ||||
| 81131-10031 |
LH50,60,70,YH5#,6#,71 |
4 | ||
| 81131-20360 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
8 | ||
| 81150 - HEADLAMP ASSY, LH | ||||
| 81150-80282 |
LH50,60,70,YH50,6#,71..RHD..(ARL,GEN,SA) SEALED BEAM |
1 | ||
| 81150-80293 |
LH50,60,70,YH51,60,71..RHD;YH50,61..RHD..(ARL,EUR,GEN) *SSB HALOGEN,WHITE |
1 | ||
| 81150-80378 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL HALOGEN |
1 | ||
| 81150 - HEADLAMP ASSY, LH | ||||
| 81150-80282 |
LH50,60,70,YH50,6#,71..RHD..(ARL,GEN,SA) SEALED BEAM |
1 | ||
| 81150-80293 |
LH50,60,70,YH51,60,71..RHD;YH50,61..RHD..(ARL,EUR,GEN) *SSB HALOGEN,WHITE |
1 | ||
| 81150-80378 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL HALOGEN |
1 | ||
| 81153 - RING, SEALED BEAM MOUNTING, NO.1 LH | ||||
| 81153-22391 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
1 | ||
| 81153-95J00 |
LH50,60,70,YH5#,6#,71 |
1 | ||
| 81154 - RING, SEALED BEAM MOUNTING, NO.2 LH | ||||
| 81114-22391 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
1 | ||
| Common parts | ||||
| 81136-12571 | ||||
| 93385-16014 | ||||
(8508- )STD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 81105 - HOUSING SUB-ASSY, HEADLAMP, RH | ||||
| 81105-95J08 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
1 | ||
| 81105-95J00 |
LH50,60,70,YH5#,6#,71 |
1 | ||
| 81106 - HOUSING SUB-ASSY, HEADLAMP, LH | ||||
| 81106-95J08 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
1 | ||
| 81106-95J00 |
LH50,60,70,YH5#,6#,71 |
1 | ||
| 81110 - HEADLAMP ASSY, RH | ||||
| 81110-80285 |
LH50,60,70,YH50,6#,71..RHD..(ARL,GEN,SA) SEALED BEAM |
1 | ||
| 81110-80296 |
LH50,60,70,YH51,60,71..RHD;YH50,61..RHD..(ARL,EUR,GEN) *SSB HALOGEN,WHITE |
1 | ||
| 81110-80384 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL HALOGEN |
1 | ||
| 81110B - BULB(FOR HEADLAMP, NO.1) | ||||
| 90981-13015 |
YH51;LH50,60,70,YH50,6#,71..ARL,EUR,GEN 12V 60/55W,*HAL *WH,12V 60/55W,*SSB HALOGEN,WHITE |
2 | ||
| 81110S - SEALED BEAM UNIT, NO.1 | ||||
| 90981-01022 |
LH50,60,70,YH50,6#,71..RHD..(ARL,GEN,SA) 12V 60/50W,*WB,12V 60/55W,SEALED BEAM |
2 | ||
| 90981-01037 |
LH50,60,70,YH51,60,71..RHD;YH50,61..RHD..(ARL,EUR,GEN) 12V 60/55W,*HWS,12V 60/55W,*SSB HALOGEN,WHITE |
2 | ||
| 90981-05028 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL 12V 50W,*HAL,*WB,12V 50W,HALOGEN |
2 | ||
| 81110S - SEALED BEAM UNIT, NO.1 | ||||
| 90981-01022 |
LH50,60,70,YH50,6#,71..RHD..(ARL,GEN,SA) 12V 60/50W,*WB,12V 60/55W,SEALED BEAM |
2 | ||
| 90981-01037 |
LH50,60,70,YH51,60,71..RHD;YH50,61..RHD..(ARL,EUR,GEN) 12V 60/55W,*HWS,12V 60/55W,*SSB HALOGEN,WHITE |
2 | ||
| 90981-05028 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL 12V 50W,*HAL,*WB,12V 50W,HALOGEN |
2 | ||
| 81111 - RING, SEALED BEAM RETAINING | ||||
| 81111-20360 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
4 | ||
| 81111-22150 |
LH50,60,70,YH5#,6#,71 |
2 | ||
| 81113 - RING, SEALED BEAM MOUNTING, NO.1 RH | ||||
| 81113-22391 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
1 | ||
| 81113-95J00 |
LH50,60,70,YH5#,6#,71 |
1 | ||
| 81121 - SPRING, HEADLAMP TENSION | ||||
| 81121-14320 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
4 | ||
| 81121-62010 |
LH50,60,70,YH5#,6#,71 |
2 | ||
| 81131 - SCREW, HEADLAMP ADJUSTING | ||||
| 81131-10031 |
LH50,60,70,YH5#,6#,71 |
4 | ||
| 81131-20360 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
8 | ||
| 81150 - HEADLAMP ASSY, LH | ||||
| 81150-80282 |
LH50,60,70,YH50,6#,71..RHD..(ARL,GEN,SA) SEALED BEAM |
1 | ||
| 81150-80293 |
LH50,60,70,YH51,60,71..RHD;YH50,61..RHD..(ARL,EUR,GEN) *SSB HALOGEN,WHITE |
1 | ||
| 81150-80378 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL HALOGEN |
1 | ||
| 81153 - RING, SEALED BEAM MOUNTING, NO.1 LH | ||||
| 81153-22391 |
YH51..4H..ARL;LH51,61,71,YH61,71..ARL |
1 | ||
| 81153-95J00 |
LH50,60,70,YH5#,6#,71 |
1 | ||
| Common parts | ||||
| 81136-12571 | ||||
| 93385-16014 | ||||
