RZH112R-RRMRE (1995)
Toyota Hiace Van,Commuter
(8908- )
2-SPOKE(PP:POLYPROPYLENE)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45100 - WHEEL ASSY, STEERING | ||||
| 45100-2615003 |
LH10#,11#,125,RZH10#,11#,125 2-SPOKE,URETHANE,GRAY,TRIM1# |
1 | ||
| 45100-2614003 |
LH10#,11#,125,RZH10#,11#,125..STD 2SPOKE,POLYPROPYLENE,GRAY,TRIM1# |
1 | ||
| 45105A - CUSHION(FOR HORN BUTTON CONTACT PLATE) | ||||
| 90540-08014 |
LH10#,11#,125,RZH10#,11#..(GL,STD)..(GCC,GEN) |
4 | ||
| 45130 - BUTTON ASSY, HORN | ||||
| 45130-2616003 |
LH10#,11#,RZH102,104,11#..GEN W(URETHANE STEERING WHEEL),GRAY,TRIM1# |
1 | ||
| 45130-2614003 |
LH10#,11#,RZH10#,11#..GEN GRAY,TRIM1# |
1 | ||
| 45142 - SEAT, HORN BUTTON CONTACT, NO.1 | ||||
| 45142-12090 |
LH10#,11#,125,RZH10#,11#,125 |
2 | ||
| 45142-26030 |
LH10#,11#,125,RZH10#,11#..(GL,STD)..(GCC,GEN) CHINA SPEC |
2 | ||
| 45142F - SPRING(FOR HORN BUTTON CONTACT SEAT) | ||||
| 90501-09106 |
LH10#,11#,125,RZH10#,11#..(GL,STD)..(GCC,GEN) |
4 | ||
| 45143 - SEAT, HORN BUTTON CONTACT, NO.2 | ||||
| 45143-26020 |
LH10#,11#,125,RZH10#,11#..(GL,STD)..(GCC,GEN) |
1 | ||
| 45155 - SPACER, HORN BUTTON CONTACT PLATE | ||||
| 45155-22040 |
LH10#,11#,125,RZH10#,11#..(GL,STD)..(GCC,GEN) |
4 | ||
| 45180 - COVER SUB-ASSY, STEERING WHEEL | ||||
| 45180-2602003 |
LH10#,11#,125,RZH10#,11#,125 W(URETHANE STEERING WHEEL),GRAY,TRIM1# |
1 | ||
| 45180-2601003 |
LH10#,11#,125,RZH10#,11#,125..STD GRAY,TRIM1# |
1 | ||
| 45180-26010B0 |
LH10#,11#,RZH10#,11#..(DX,GL,STD)..(CIS,GCC,GEN) BLUISH GRAY,TRIM1# |
1 | ||
| 45201P - NUT, STEERING WHEEL SET | ||||
| 90179-12086 |
LH10#,11#,125,RZH10#,11#,125 |
1 | ||
| Common parts | ||||
| 90159-50016 | ||||
| 90168-40098 | ||||
| 90168-40099 | ||||
| 90168-41001 | ||||
| 93315-14012 | ||||
| 93510-13020 | ||||
(8908-9808)
2-SPOKE(URETHANE)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45100 - WHEEL ASSY, STEERING | ||||
| 45100-2615003 |
LH10#,11#,125,RZH10#,11#,125 2-SPOKE,URETHANE,GRAY,TRIM1# |
1 | ||
| 45100-2614003 |
LH10#,11#,125,RZH10#,11#,125..STD 2SPOKE,POLYPROPYLENE,GRAY,TRIM1# |
1 | ||
| 45105 - PLATE SUB-ASSY, HORN BUTTON CONTACT, NO.1 | ||||
| 45105-26050 |
RZH103..SGL;RZH103..RHD..CBR;RZH113..LHD..EFI;LH112,RZH113..CBR,DSL;LH10#,113,114,115,125,RZH102,104,105,112,114,115,125..DX,STD W(URETHANE STEERING WHEEL) |
1 | ||
| 45105B - SPACER(FOR HORN BUTTON CONTACT PLATE) | ||||
| 90561-02001 |
LH10#,11#,125,RZH10#,11#,125 |
2 | ||
| 45125 - MARK, STEERING WHEEL PAD | ||||
| 45125-26110 |
LH10#,11#,RZH102,104,11#..GEN |
1 | ||
| 45130 - BUTTON ASSY, HORN | ||||
| 45130-2616003 |
LH10#,11#,RZH102,104,11#..GEN W(URETHANE STEERING WHEEL),GRAY,TRIM1# |
1 | ||
| 45130-2614003 |
LH10#,11#,RZH10#,11#..GEN GRAY,TRIM1# |
1 | ||
| 45180 - COVER SUB-ASSY, STEERING WHEEL | ||||
| 45180-2602003 |
LH10#,11#,125,RZH10#,11#,125 W(URETHANE STEERING WHEEL),GRAY,TRIM1# |
1 | ||
| 45180-2601003 |
LH10#,11#,125,RZH10#,11#,125..STD GRAY,TRIM1# |
1 | ||
| 45180-26010B0 |
LH10#,11#,RZH10#,11#..(DX,GL,STD)..(CIS,GCC,GEN) BLUISH GRAY,TRIM1# |
1 | ||
| 45201P - NUT, STEERING WHEEL SET | ||||
| 90179-12086 |
LH10#,11#,125,RZH10#,11#,125 |
1 | ||
| Common parts | ||||
| 90159-40208 | ||||
| 90159-50016 | ||||
| 90167-41001 | ||||
| 90168-40098 | ||||
| 93315-14012 | ||||
| 93510-13010 | ||||
(8908- )
URETHANE WHEEL
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90159-40208 | ||||
| 90159-50016 | ||||
| 90167-41001 | ||||
| 90168-40098 | ||||
| 93315-14012 | ||||
| 93510-13010 | ||||
(8908- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90168-40098 | ||||
| 90168-40099 | ||||
| 93315-13012 | ||||
| 93315-14012 | ||||
| 93510-13010 | ||||
