LY100L-TBMBSW3 (1995)
Toyota Dyna 100
(9505- )LY100
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 31111 - HOUSING, CLUTCH | ||||
| 31111-22114 |
LY100 |
1 | ||
| 33101A - PLUG(FOR MANUAL TRANSMISSION FILLER) | ||||
| 90341-18006 |
LY100,YY100 |
1 | ||
| 90341-18006 |
LY100,YY100 |
1 | ||
| 33101C - GASKET(FOR MANUAL TRANSMISSION FILLER PLUG) | ||||
| 90430-18008 |
LY100,YY100 |
1 | ||
| 90430-18008 |
LY100,YY100 |
1 | ||
| 33101J - PLUG, BREATHER | ||||
| 90930-03085 |
LY100,YY100 |
1 | ||
| 90930-03085 |
LY100,YY100 |
1 | ||
| 33104 - PLUG SUB-ASSY, DRAIN(MTM) | ||||
| 90341-18032 |
LY100,YY100 |
1 | ||
| 90341-18006 |
LY100,YY100 |
1 | ||
| 90341-18032 |
LY100,YY100 |
1 | ||
| 33104A - GASKET, DRAIN PLUG(MTM) | ||||
| 90430-18008 |
LY100,YY100 |
1 | ||
| 90430-18008 |
LY100,YY100 |
1 | ||
| 33111 - CASE, MANUAL TRANSMISSION | ||||
| 33101-28020 |
LY100,YY100 |
1 | ||
| 33101-35060 |
LY100,YY100 |
1 | ||
| 33101-35060 |
LY100,YY100 |
1 | ||
| 33111C - PLUG(FOR TRANSMISSION CASE) | ||||
| 90331-14004 |
LY100,YY100 OD=14 |
4 | ||
| 90331-14004 |
LY100,YY100 OD=14 |
4 | ||
| 33111J - PIN, STRAIGHT(FOR MANUAL TRANSMISSION CASE) | ||||
| 90250-12002 |
LY100,YY100 L=16,OD=12 |
4 | ||
| 90250-12002 |
LY100,YY100 L=16,OD=12 |
4 | ||
| 33111J - PIN, STRAIGHT(FOR MANUAL TRANSMISSION CASE) | ||||
| 90250-12002 |
LY100,YY100 L=16,OD=12 |
4 | ||
| 90250-12002 |
LY100,YY100 L=16,OD=12 |
4 | ||
| 33111U - PIN, RING(FOR MANUAL TRANSMISSION CASE) | ||||
| 90253-11001 |
LY100,YY100 L=11,OD=11 |
2 | ||
| 90253-11001 |
LY100,YY100 L=11,OD=11 |
2 | ||
| 90253-15001 |
LY100,YY100 L=14,OD=15 |
2 | ||
| 90253-15001 |
LY100,YY100 L=14,OD=15 |
2 | ||
| 33111U - PIN, RING(FOR MANUAL TRANSMISSION CASE) | ||||
| 90253-11001 |
LY100,YY100 L=11,OD=11 |
2 | ||
| 90253-11001 |
LY100,YY100 L=11,OD=11 |
2 | ||
| 90253-15001 |
LY100,YY100 L=14,OD=15 |
2 | ||
| 90253-15001 |
LY100,YY100 L=14,OD=15 |
2 | ||
| 33118 - PLATE, STIFFENER, RH(MTM) | ||||
| 33118-25020 |
LY100 |
1 | ||
| 33119 - PLATE, STIFFENER, LH(MTM) | ||||
| 33119-25020 |
LY100 |
1 | ||
| 33131 - RETAINER, BEARING, FRONT(MTM) | ||||
| 33131-26020 |
LY100,YY100 |
1 | ||
| 33131-26020 |
LY100,YY100 |
1 | ||
| 33131A - SEAL, OIL(FOR TRANSMISSION FRONT BEARING RETAINER) | ||||
| 90311-30014 |
LY100,YY100 |
1 | ||
| 90311-30014 |
LY100,YY100 |
1 | ||
| 33132 - GASKET, FRONT BEARING RETAINER(MTM) | ||||
| 33132-28010 |
LY100,YY100 |
1 | ||
| 33132-28010 |
LY100,YY100 |
1 | ||
| 33151 - RETAINER, OUTPUT SHAFT REAR BEARING(MTM) | ||||
| 33151-35030 |
LY100,YY100 |
1 | ||
| 33151-35030 |
LY100,YY100 |
1 | ||
| Common parts | ||||
| 90119-08332 | ||||
| 90149-80002 | ||||
| 91611-61030 | ||||
| 91612-61045 | ||||
| 91619-61250 | ||||
| 91619-61255 | ||||
| 91651-61032 | ||||
