BU102R-TBMMX3 (2000)
Toyota Dyna200
(0203- )BU102,142..RHD..GEN
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 44348A - HOSE, OIL RESERVOIR TO PUMP, NO.1 | ||||
| 44348-37030 |
BU212..TD;BU102,142,222..RHD..TD |
1 | ||
| 44406B - BOLT, UNION(FOR RETURN TUBE) | ||||
| 90401-14003 |
BU221..LHD;BU211..CBU;BU211..LHD..40T..IV3;BU211..RHD..30T..GEN..IV3;BU10#,11#,14#,212,222..DM1,T1,T2,T3,TW1,TW2 |
1 | ||
| 90401-14003 |
BU141,212,222;BU211..LHD..CBU;BU211..LHD..40T..IV3;BU211..RHD..(CBU,IV3);BU10#,111,142,213,221,223,RZU100..(15T,175T,20T,30T,40T)..(ARL,GEN) |
1 | ||
| 44406C - GASKET(FOR RETURN TUBE) | ||||
| 90430-14235 |
BU221..LHD;BU211..CBU;BU211..LHD..40T..IV3;BU211..RHD..30T..GEN..IV3;BU10#,11#,14#,212,222..DM1,T1,T2,T3,TW1,TW2 |
2 | ||
| 90430-14235 |
BU141,212,222;BU211..LHD..CBU;BU211..LHD..40T..IV3;BU211..RHD..(CBU,IV3);BU10#,111,142,213,221,223,RZU100..(15T,175T,20T,30T,40T)..(ARL,GEN) |
2 | ||
| 44406C - GASKET(FOR RETURN TUBE) | ||||
| 90430-14235 |
BU221..LHD;BU211..CBU;BU211..LHD..40T..IV3;BU211..RHD..30T..GEN..IV3;BU10#,11#,14#,212,222..DM1,T1,T2,T3,TW1,TW2 |
2 | ||
| 90430-14235 |
BU141,212,222;BU211..LHD..CBU;BU211..LHD..40T..IV3;BU211..RHD..(CBU,IV3);BU10#,111,142,213,221,223,RZU100..(15T,175T,20T,30T,40T)..(ARL,GEN) |
2 | ||
| 44410A - BOLT, UNION(FOR PRESSURE FEED TUBE) | ||||
| 90401-14003 |
BU141,212,222;BU211..LHD..CBU;BU211..LHD..40T..IV3;BU211..RHD..(CBU,IV3);BU10#,111,142,213,221,223,RZU100..(15T,175T,20T,30T,40T)..(ARL,GEN) |
1 | ||
| 90401-14003 |
BU221..LHD;BU211..CBU;BU211..LHD..40T..IV3;BU211..RHD..30T..GEN..IV3;BU10#,11#,14#,212,222..DM1,T1,T2,T3,TW1,TW2 |
1 | ||
| 44410B - GASKET(FOR PRESSURE FEED TUBE) | ||||
| 90430-14235 |
BU221..LHD;BU211..CBU;BU211..LHD..40T..IV3;BU211..RHD..30T..GEN..IV3;BU10#,11#,14#,212,222..DM1,T1,T2,T3,TW1,TW2 |
2 | ||
| 90430-14235 |
BU141,212,222;BU211..LHD..CBU;BU211..LHD..40T..IV3;BU211..RHD..(CBU,IV3);BU10#,111,142,213,221,223,RZU100..(15T,175T,20T,30T,40T)..(ARL,GEN) |
2 | ||
| 44410B - GASKET(FOR PRESSURE FEED TUBE) | ||||
| 90430-14235 |
BU221..LHD;BU211..CBU;BU211..LHD..40T..IV3;BU211..RHD..30T..GEN..IV3;BU10#,11#,14#,212,222..DM1,T1,T2,T3,TW1,TW2 |
2 | ||
| 90430-14235 |
BU141,212,222;BU211..LHD..CBU;BU211..LHD..40T..IV3;BU211..RHD..(CBU,IV3);BU10#,111,142,213,221,223,RZU100..(15T,175T,20T,30T,40T)..(ARL,GEN) |
2 | ||
| 44411 - HOSE, PRESSURE FEED | ||||
| 44411-37030 |
BU142..ARL,EUR;BU10#,11#,140,141..(DM1,DM7,T1,T2,T3,T4,TW2)..(ARL,EUR,GEN,TAIW) |
1 | ||
| 44411-37031 |
BU141;BU10#,111,142..(175T,20T,30T)..(ARL,GEN) |
1 | ||
| 44411C - BOLT, UNION(FOR PRESSURE FEED HOSE) | ||||
| 90401-16027 |
BU141;BU212..RHD..TD;BU211..LHD..CBU;BU211..LHD..40T..IV3;BU10#,111,221..ARL,GEN;BU142,211..RHD..(GEN,SA)..(CBU,IV3) |
1 | ||
| 44411D - GASKET(FOR PRESSURE FEED HOSE) | ||||
| 90430-16168 |
BU221..LHD;BU211..CBU;BU211..LHD..40T..IV3;BU211..RHD..30T..GEN..IV3;BU10#,11#,14#,212,222..DM1,T1,T2,T3,TW1,TW2 |
2 | ||
| 44327-30030 |
BU141,211,212,222..CBU,IV3;BU10#,111,142,213,221,223,RZU100..(15T,175T,20T,30T,40T)..(ARL,GEN) |
1 | ||
| 44413 - TUBE, PRESSURE FEED, NO.1 | ||||
| 44413-37170 |
BU102,142..RHD..GEN |
1 | ||
| 44416 - TUBE, RETURN(FOR STEERING GEAR OUTLET) | ||||
| 44416-37400 |
BU102,142..RHD..GEN |
1 | ||
| 44416C - HOSE(FOR RETURN TUBE TO RESERVIOR) | ||||
| 90445-18132 |
BU221..LHD;BU211..CBU;BU211..LHD..40T..IV3;BU211..RHD..30T..GEN..IV3;BU10#,11#,140,141,212,222..DM1,T1,T2,T3,TW1,TW2 |
1 | ||
| 90447-18038 |
BU102,142..RHD..GEN |
1 | ||
| 44423 - TUBE, OIL PUMP TO GEAR BOX | ||||
| 44423-37040 |
BU10#,11#,14#..DM1,T1,T2,T3,TW2 |
1 | ||
| 44423-37041 |
BU141;BU10#,111,142..(175T,20T,30T)..(ARL,GEN) |
1 | ||
| 44447A - BRACKET, HOSE SUPPORT, NO.1 | ||||
| 44447-37030 |
BU142..ARL,EUR;BU10#,11#,140,141..(DM1,DM7,T1,T2,T3,T4,TW2)..(ARL,EUR,GEN,TAIW) |
1 | ||
| 44447-37030 |
BU141;BU10#,111,142..(175T,20T,30T)..(ARL,GEN) |
1 | ||
| Common parts | ||||
| 90119-08A46 | ||||
| 90461-10633 | ||||
| 90467-16008 | ||||
| 90467-21005 | ||||
| 91651-60616 | ||||
| 91651-60816 | ||||
| 91651-B0825 | ||||
| 94130-00802 | ||||
| 96991-14080 | ||||
| Linked diagrams | ||||
| 4502 | ||||
| 4505 | ||||
