LH80R-MDB (1987)
Toyota Dyna100
(8708- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 82650E - BREAKER ASSY, WIRING CIRCUIT | ||||
| 82650-12020 |
LH80,YH81..RHD 14A |
1 | ||
| 82650-12020 |
LH80,YH81..RHD 14A |
1 | ||
| 87116A - SPRING, HOLDING (FOR COOLER UNIT CASE) | ||||
| 87116-14010 |
LH80,YH81..RHD |
6 | ||
| 87116-14010 |
LH80,YH81..ARL,GEN |
6 | ||
| 88501 - EVAPORATOR SUB-ASSY, COOLER, NO.1 | ||||
| 88501-95403 |
LH80,YH81..RHD |
1 | ||
| 88501-37020 |
LH80,YH81..RHD |
1 | ||
| 88510 - UNIT ASSY, COOLER | ||||
| 88510-26400 |
LH80,YH81..RHD |
1 | ||
| 88510-95A17 |
LH80,YH81..RHD |
1 | ||
| 88510R - GROMMET (FOR COOLER UNIT) | ||||
| 90099-21010 |
LH80..GEN SUCTION |
1 | ||
| 90099-21010 |
LH80,YH81..GEN SUCTION |
1 | ||
| 90099-32098 |
LH80,YH81..RHD..GEN LIQUID PIPE |
1 | ||
| 90480-36010 |
LH80,YH81..RHD..GEN SUCTION |
1 | ||
| 90099-21010 |
LH80..GEN;YH81..LHD..GEN SUCTION |
1 | ||
| 90099-21010 |
LH80,YH81..RHD..GEN SUCTION |
1 | ||
| 90099-21010 |
LH80,YH81..GEN SUCTION |
1 | ||
| 88510R - GROMMET (FOR COOLER UNIT) | ||||
| 90099-21010 |
LH80..GEN SUCTION |
1 | ||
| 90099-21010 |
LH80,YH81..GEN SUCTION |
1 | ||
| 90099-32098 |
LH80,YH81..RHD..GEN LIQUID PIPE |
1 | ||
| 90480-36010 |
LH80,YH81..RHD..GEN SUCTION |
1 | ||
| 90099-21010 |
LH80..GEN;YH81..LHD..GEN SUCTION |
1 | ||
| 90099-21010 |
LH80,YH81..RHD..GEN SUCTION |
1 | ||
| 90099-21010 |
LH80,YH81..GEN SUCTION |
1 | ||
| 88515 - VALVE, COOLER EXPANSION | ||||
| 88515-16031 |
LH80,YH81..RHD |
1 | ||
| 88515-28090 |
LH80,YH81..ARL,GEN |
1 | ||
| 88536 - BRACKET, COOLING UNIT, NO.1 | ||||
| 88536-95A34 |
LH80,YH81..RHD..GEN DEALER OPTION |
1 | ||
| 88536-95A32 |
LH80,YH81..RHD..GEN MAKER OPTION |
1 | ||
| 88536A - BRACKET, COOLING UNIT, NO.2 | ||||
| 88536-95404 |
LH80,YH81..ARL,GEN |
1 | ||
| 88536-95404 |
LH80,YH81..ARL,GEN |
1 | ||
| 88536B - BRACKET, COOLING UNIT, NO.3 | ||||
| 88536-95405 |
LH80,YH81..RHD |
1 | ||
| 88536-95405 |
LH80,YH81..RHD |
1 | ||
| 88539 - HOSE, COOLER UNIT DRAIN, NO.1 | ||||
| 88539-95A11 |
LH80,YH81..RHD |
1 | ||
| 88539-95A11 |
LH80,YH81..RHD |
1 | ||
| 88566 - DUCT, COOLER AIR, NO.1 | ||||
| 88566-95407 |
LH80,YH81..ARL,GEN |
1 | ||
| 88566-95407 |
LH80,YH81..ARL,GEN |
1 | ||
| 88578A - PACKING, COOLER STABILIZER AMPLIFIER | ||||
| 88578-95400 |
LH80,YH81..ARL,GEN |
1 | ||
| 88578-95400 |
LH80,YH81..ARL,GEN |
1 | ||
| 88578-95400 |
LH80,YH81..GEN |
2 | ||
| 88605 - HARNESS SUB-ASSY, COOLER WIRING, NO.1 | ||||
| 88605-95405 |
LH80..RHD |
1 | ||
| 88605-95405 |
LH80..GEN MAKER OPT |
1 | ||
| 88605-95405 |
LH80..GEN |
1 | ||
| 88605-26590 |
LH80..GEN DEALER OPT |
1 | ||
| 88605-95408 |
LH80..GEN DEALER OPT |
1 | ||
| 88605-26600 |
LH80..GEN MAKER OPT |
1 | ||
| 88625 - THERMISTOR, COOLER, NO.1 | ||||
| 88625-95A00 |
LH80,YH81..RHD |
1 | ||
| 88625-95A00 |
LH80,YH81..ARL,GEN |
1 | ||
| 88630 - RELAY ASSY, COOLER | ||||
| 88630-60020 |
LH80,YH81..RHD..GEN DEALER OPTION |
1 | ||
| 90987-02004 |
LH80,YH81..RHD..GEN MAKER OPTION |
1 | ||
| 88630-60020 |
LH80,YH81..ARL,GEN |
1 | ||
| 88630A - RELAY ASSY, COOLER | ||||
| 88630-95401 |
LH80,YH81..RHD |
1 | ||
| 88630-95401 |
LH80,YH81..RHD |
1 | ||
| 88645G - SWITCH, PRESSURE | ||||
| 88645-20050 |
LH80,YH81..ARL,GEN NO.1 |
1 | ||
| 88645-95J00 |
LH80,YH81..RHD NO.1 |
1 | ||
| 88645-17010 |
LH80,YH81..RHD NO.2 |
1 | ||
| 88645G - SWITCH, PRESSURE | ||||
| 88645-20050 |
LH80,YH81..ARL,GEN NO.1 |
1 | ||
| 88645-95J00 |
LH80,YH81..RHD NO.1 |
1 | ||
| 88645-17010 |
LH80,YH81..RHD NO.2 |
1 | ||
| 88650 - AMPLIFIER ASSY, COOLER STABILIZER | ||||
| 88650-14030 |
LH80..RHD |
1 | ||
| 88650-14030 |
LH80..GEN |
1 | ||
| 88688A - BRACKET, COOLER STABILIZER AMPLIFIER | ||||
| 88688-95425 |
LH80,YH81..ARL,GEN |
1 | ||
| 88688-95425 |
LH80..GEN;YH81..ARL,GEN |
1 | ||
| Common parts | ||||
| 88569-12030 | ||||
| 90044-04009 | ||||
| 90044-64009 | ||||
| 90099-00930 | ||||
| 90099-21010 | ||||
| 90179-08123 | ||||
| 90464-00052 | ||||
| 90480-36010 | ||||
| 93315-15012 | ||||
| 93381-18016 | ||||
| 93385-18016 | ||||
| 93530-55016 | ||||
(8708- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 88510 - UNIT ASSY, COOLER | ||||
| 88510-95A17 |
LH80,YH81..RHD |
1 | ||
| 88510-26400 |
LH80,YH81..RHD |
1 | ||
| 88510R - GROMMET (FOR COOLER UNIT) | ||||
| 90099-21010 |
LH80..GEN SUCTION |
1 | ||
| 90099-21010 |
LH80,YH81..GEN SUCTION |
1 | ||
| 90099-32098 |
LH80,YH81..RHD..GEN LIQUID PIPE |
1 | ||
| 90480-36010 |
LH80,YH81..RHD..GEN SUCTION |
1 | ||
| 90099-21010 |
LH80..GEN;YH81..LHD..GEN SUCTION |
1 | ||
| 90099-21010 |
LH80,YH81..RHD..GEN SUCTION |
1 | ||
| 90099-21010 |
LH80,YH81..GEN SUCTION |
1 | ||
| 88510R - GROMMET (FOR COOLER UNIT) | ||||
| 90099-21010 |
LH80..GEN SUCTION |
1 | ||
| 90099-21010 |
LH80,YH81..GEN SUCTION |
1 | ||
| 90099-32098 |
LH80,YH81..RHD..GEN LIQUID PIPE |
1 | ||
| 90480-36010 |
LH80,YH81..RHD..GEN SUCTION |
1 | ||
| 90099-21010 |
LH80..GEN;YH81..LHD..GEN SUCTION |
1 | ||
| 90099-21010 |
LH80,YH81..RHD..GEN SUCTION |
1 | ||
| 90099-21010 |
LH80,YH81..GEN SUCTION |
1 | ||
| 88536 - BRACKET, COOLING UNIT, NO.1 | ||||
| 88536-95A34 |
LH80,YH81..RHD..GEN DEALER OPTION |
1 | ||
| 88536-95A32 |
LH80,YH81..RHD..GEN MAKER OPTION |
1 | ||
| 88536A - BRACKET, COOLING UNIT, NO.2 | ||||
| 88536-95404 |
LH80,YH81..ARL,GEN |
1 | ||
| 88536-95404 |
LH80,YH81..ARL,GEN |
1 | ||
| 88536B - BRACKET, COOLING UNIT, NO.3 | ||||
| 88536-95405 |
LH80,YH81..RHD |
1 | ||
| 88536-95405 |
LH80,YH81..RHD |
1 | ||
| 88539 - HOSE, COOLER UNIT DRAIN, NO.1 | ||||
| 88539-95A11 |
LH80,YH81..RHD |
1 | ||
| 88539-95A11 |
LH80,YH81..RHD |
1 | ||
| 88566 - DUCT, COOLER AIR, NO.1 | ||||
| 88566-95407 |
LH80,YH81..ARL,GEN |
1 | ||
| 88566-95407 |
LH80,YH81..ARL,GEN |
1 | ||
| 88578A - PACKING, COOLER STABILIZER AMPLIFIER | ||||
| 88578-95400 |
LH80,YH81..ARL,GEN |
1 | ||
| 88578-95400 |
LH80,YH81..ARL,GEN |
1 | ||
| 88578-95400 |
LH80,YH81..GEN |
2 | ||
| 88605 - HARNESS SUB-ASSY, COOLER WIRING, NO.1 | ||||
| 88605-95405 |
LH80..RHD |
1 | ||
| 88605-95405 |
LH80..GEN MAKER OPT |
1 | ||
| 88605-95405 |
LH80..GEN |
1 | ||
| 88605-26590 |
LH80..GEN DEALER OPT |
1 | ||
| 88605-95408 |
LH80..GEN DEALER OPT |
1 | ||
| 88605-26600 |
LH80..GEN MAKER OPT |
1 | ||
| 88630 - RELAY ASSY, COOLER | ||||
| 88630-60020 |
LH80,YH81..RHD..GEN DEALER OPTION |
1 | ||
| 90987-02004 |
LH80,YH81..RHD..GEN MAKER OPTION |
1 | ||
| 88630-60020 |
LH80,YH81..ARL,GEN |
1 | ||
| 88630A - RELAY ASSY, COOLER | ||||
| 88630-95401 |
LH80,YH81..RHD |
1 | ||
| 88630-95401 |
LH80,YH81..RHD |
1 | ||
| 88650 - AMPLIFIER ASSY, COOLER STABILIZER | ||||
| 88650-14030 |
LH80..RHD |
1 | ||
| 88650-14030 |
LH80..GEN |
1 | ||
| 88688A - BRACKET, COOLER STABILIZER AMPLIFIER | ||||
| 88688-95425 |
LH80..GEN;YH81..ARL,GEN |
1 | ||
| 88688-95425 |
LH80,YH81..ARL,GEN |
1 | ||
| Common parts | ||||
| 90099-21010 | ||||
| 90179-08123 | ||||
| 90464-00052 | ||||
| 90480-36010 | ||||
| 91611-60816 | ||||
| 91651-40825 | ||||
| 93566-15512 | ||||
