LH80L-MDBW (1987)

Toyota Dyna100

Production Aug 1987 - May 1995
Engine 2L
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

(8708- )

Click highlighted areas on diagram

diagram 11278 11278 11284 11291 11293 11293 11298 1356410010 17700C 17791 17792 23923
Part # Description Qty Price
11284 - PLATE, ENGINE BOLT INFORMATION
11284-54020

2L..LH80

 1
11284-54010

2L..LH80

 1
11284-54040

2L..LH80

 1
11293 - PLATE, ENGINE CAUTION & ENGINE NAME
11293-54030

2L..LH80

 1
11293 - PLATE, ENGINE CAUTION & ENGINE NAME
11293-54030

2L..LH80

 1
11298 - PLATE, EMISSION CONTROL INFORMATION
11298-54190

2L..LH80..EUR..CBU

NORWAY SPEC

 1
11298-54191

2L..LH80..EUR..CBU

NORWAY SPEC

 1
17700C - PLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)
17791-64020

2Y..YH81;2L..LH80..EUR

 1
17791-64020

2L,2Y..LH80,YH81

 1
90917-07108

2L..LH80..EUR

CYCLONE TYPE

 1
17791 - LABEL, MAINTENANCE INFORMATION
17791-55010

2L..LH80

 1
Common parts
13564-10010
