WU90R-MDDTQ3 (1984)
Toyota Dyna
(8409- )WU9#..RHD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 44348A - HOSE, OIL RESERVOIR TO PUMP, NO.1 | ||||
| 44348-36080 |
WU9#..ARL,GEN |
1 | ||
| 44348B - CLAMP(FOR OIL RESERVOIR TO PUMP HOSE) | ||||
| 90460-26001 |
RU75,85,WU9#..ARL,GEN |
2 | ||
| 90460-26001 |
RU75,85,WU9#,YU6#,8#..(L1,L2,T1,T3)..(ARL,EUR,GEN) |
2 | ||
| 44348B - CLAMP(FOR OIL RESERVOIR TO PUMP HOSE) | ||||
| 90460-26001 |
RU75,85,WU9#..ARL,GEN |
2 | ||
| 90460-26001 |
RU75,85,WU9#,YU6#,8#..(L1,L2,T1,T3)..(ARL,EUR,GEN) |
2 | ||
| 44369 - BRACKET, OIL RESERVOIR, NO.1 | ||||
| 44369-36010 |
WU9#..ARL,GEN |
2 | ||
| 44369 - BRACKET, OIL RESERVOIR, NO.1 | ||||
| 44369-36010 |
WU9#..ARL,GEN |
2 | ||
| 44379 - BRACKET, OIL RESERVOIR, NO.2 | ||||
| 44379-36100 |
WU9#..ARL,GEN |
1 | ||
| 44386A - SUPPORT, OIL RESERVOIR | ||||
| 44386-36070 |
WU9#..ARL,GEN |
1 | ||
| 44411 - HOSE, PRESSURE FEED | ||||
| 44411-36120 |
WU90..RHD..(ARL,GEN) |
1 | ||
| 44411B - CUSHION(FOR PRESSURE FEED HOSE) | ||||
| 90540-18002 |
WU9#..ARL,GEN |
1 | ||
| 44411C - BOLT, UNION(FOR PRESSURE FEED HOSE) | ||||
| 90401-14003 |
WU9#..ARL,GEN |
2 | ||
| 90401-14003 |
WU9#,YU6#,8#..(L1,L2,T1,T3)..(ARL,EUR,GEN) |
2 | ||
| 44411C - BOLT, UNION(FOR PRESSURE FEED HOSE) | ||||
| 90401-14003 |
WU9#..ARL,GEN |
2 | ||
| 90401-14003 |
WU9#,YU6#,8#..(L1,L2,T1,T3)..(ARL,EUR,GEN) |
2 | ||
| 44411D - GASKET(FOR PRESSURE FEED HOSE) | ||||
| 90430-14235 |
WU9#..ARL,GEN |
4 | ||
| 90430-14235 |
WU9#,YU6#,8#..(L1,L2,T1,T3)..(ARL,EUR,GEN) |
4 | ||
| 44411D - GASKET(FOR PRESSURE FEED HOSE) | ||||
| 90430-14235 |
WU9#..ARL,GEN |
4 | ||
| 90430-14235 |
WU9#,YU6#,8#..(L1,L2,T1,T3)..(ARL,EUR,GEN) |
4 | ||
| 44411D - GASKET(FOR PRESSURE FEED HOSE) | ||||
| 90430-14235 |
WU9#..ARL,GEN |
4 | ||
| 90430-14235 |
WU9#,YU6#,8#..(L1,L2,T1,T3)..(ARL,EUR,GEN) |
4 | ||
| 44411D - GASKET(FOR PRESSURE FEED HOSE) | ||||
| 90430-14235 |
WU9#..ARL,GEN |
4 | ||
| 90430-14235 |
WU9#,YU6#,8#..(L1,L2,T1,T3)..(ARL,EUR,GEN) |
4 | ||
| 44416 - TUBE, RETURN(FOR STEERING GEAR OUTLET) | ||||
| 44416-36090 |
WU90..RHD..(ARL,GEN) |
1 | ||
| 44416C - HOSE(FOR RETURN TUBE TO RESERVIOR) | ||||
| 90445-18129 |
WU9#..ARL,GEN |
1 | ||
| 44417 - TUBE, RETURN, NO.2 | ||||
| 44417-36070 |
WU9#..ARL,GEN |
1 | ||
| 44417D - HOSE(FOR RETURN TUBE TO RESERVOIR) | ||||
| 90445-18131 |
WU9#..ARL,GEN |
1 | ||
| 44423 - TUBE, OIL PUMP TO GEAR BOX | ||||
| 44423-36150 |
WU9#..ARL,GEN |
1 | ||
| 44423F - BOLT, UNION | ||||
| 90401-14003 |
RU75,85,WU9#..ARL,GEN |
1 | ||
| 44423G - GASKET, UNION BOLT | ||||
| 90430-14235 |
RU75,85,WU9#..ARL,GEN |
2 | ||
| 44423G - GASKET, UNION BOLT | ||||
| 90430-14235 |
RU75,85,WU9#..ARL,GEN |
2 | ||
| 44423H - NUT, UNION | ||||
| 90402-16005 |
WU9#..ARL,GEN |
1 | ||
| 44423P - GASKET, UNION NUT | ||||
| 90430-16168 |
WU9#..ARL,GEN |
1 | ||
| 44447 - BRACKET, POWER STEERING OIL COOLER TUBE SUPPORT | ||||
| 44447-36110 |
WU9#..ARL,GEN |
1 | ||
| 44448 - BRACKET, PRESSURE FEED HOSE SUPPORT, NO.1 | ||||
| 44447-36090 |
WU9#..ARL,GEN |
1 | ||
| 44457 - BRACKET, TUBE SUPPORT, NO.1 | ||||
| 44457-36050 |
WU9#..ARL,GEN |
1 | ||
| 44459 - BRACKET, TUBE SUPPORT, NO.3 | ||||
| 44459-36060 |
WU9#..ARL,GEN |
1 | ||
| Common parts | ||||
| 90119-08329 | ||||
| 90201-08035 | ||||
| 90460-01001 | ||||
| 90461-10494 | ||||
| 90461-10619 | ||||
| 90461-12292 | ||||
| 90480-17002 | ||||
| 91611-60614 | ||||
| 91611-60820 | ||||
| 91611-60825 | ||||
| 91611-60860 | ||||
| 91651-40820 | ||||
| 91651-60620 | ||||
| 91651-60845 | ||||
| 94110-40800 | ||||
| 94511-00800 | ||||
| 96991-14080 | ||||
