WU720L-TKFRLV3 (2011)

Toyota Dyna

Production Jul 2011 - Sep 9999
Engine W04D
Transmission 6F MTM
Displacement 2500cc
Power 168 HP (125 kW)

ILLUST NO. 2 OF 2(1107- )

Click highlighted areas on diagram

diagram 46275A 47398A 89176B
Part # Description Qty Price
89176B - LABEL, AIR BAG SENSOR COVER CAUTION
89176-37040

XZU710,720..MTM..GCC

SRS AIR BAG-WITH(DRIVER & PASSENGER)

 1
89176-37040

XZU710,720..MTM..GCC

SRS AIR BAG-WITH(DRIVER)

 1

ILLUST NO. 1 OF 2(1107- )

Click highlighted areas on diagram

diagram 17792E 47288 74544D 74552 74566B 74567A 74572A 74598A 75476 75476A
Part # Description Qty Price
47288 - LABEL, BRAKE FLUID NOTICE
47287-28020

WU710,720;XZU710,720..MTM..GCC

 1
74544D - PLATE, TIRE CARRIER CAUTION
74544-37070

WU700,710,720,XZU710,720..MTM..GCC

 1
74552 - PLATE, SAFETY CAUTION
74552-37L80

WU720,XZU720..75T..GCC

 1
74566B - PLATE, POWER TAKE OFF CAUTION
74566-37140

XZU710,720..6F..GCC..IV3

POWER TAKE OFF-ELECTLIC TYPE 20KG + DUMP LEVER

 1
74567A - PLATE, E.C.E APPROVED NUMBER
74567-37090

XZU710,720..6F..GCC

 1
74572A - LABEL, FUEL INLET OPERATIONAL INFORMATION
74572-37021

WU710,720;XZU710,720..SCB..MTM..GCC

FUEL TANK-100L & W(SUB TANK)

 1
74572-37020

WU710,720,XZU720..GCC,GEN

FUEL TANK-100L & W(SUB TANK)

 1
74598A - LABEL, PASSENGER AIR BAG CAUTION
74598-20010

XZU710,720..MTM..GCC

SRS AIR BAG-WITH(DRIVER & PASSENGER)

 1
75476 - PLATE, TILT CAUTION
75476-37390

WU700,710,720;XZU710,720..SCB..MTM..GCC

 1
75476A - PLATE, TILT OPERATIONAL CAUTION
75476-37340

WU700,710,720,XZU710,720..SCB..MTM..GCC

 1
