WU410R-TKMQS (2002)
Toyota Dyna
(0212-0610)WU410,420..RHD ; (0610-0801)WU410,420..SA ; (0801- )WU410..75T..SA
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 44327M - GASKET, PRESSURE PORT, NO.2 | ||||
| 90461-10832 |
WU412,42#;WU410..65T;WU410..75T..GEN |
1 | ||
| 90461-10832 |
WU410..GCC,GEN |
1 | ||
| 44348D - HOSE, OIL RESERVOIR TO PUMP, NO.2 | ||||
| 44348-37280 |
WU410..GCC,GEN |
1 | ||
| 44348-37410 |
WU412,42#;WU410..65T;WU410..75T..GEN |
1 | ||
| 44369 - BRACKET, OIL RESERVOIR, NO.1 | ||||
| 44369-37110 |
WU410..GCC,GEN |
1 | ||
| 44406B - BOLT, UNION(FOR RETURN TUBE) | ||||
| 90401-14003 |
XZU412,422..5F..TD;XZU412,422..RHD..DSL;WU410,XZU404,414,424,434..ARL,GCC,GEN |
1 | ||
| 44406C - GASKET(FOR RETURN TUBE) | ||||
| 90430-14235 |
XZU412,422..5F..TD;XZU412,422..RHD..DSL;WU410,XZU404,414,424,434..ARL,GCC,GEN |
2 | ||
| 44406C - GASKET(FOR RETURN TUBE) | ||||
| 90430-14235 |
XZU412,422..5F..TD;XZU412,422..RHD..DSL;WU410,XZU404,414,424,434..ARL,GCC,GEN |
2 | ||
| 44410A - BOLT, UNION(FOR PRESSURE FEED TUBE) | ||||
| 90401-14003 |
XZU412,422..5F..TD;XZU412,422..RHD..DSL;WU410,XZU404,414,424,434..ARL,GCC,GEN |
1 | ||
| 44410B - GASKET(FOR PRESSURE FEED TUBE) | ||||
| 90430-14235 |
XZU412,422..5F..TD;XZU412,422..RHD..DSL;WU410,XZU404,414,424,434..ARL,GCC,GEN |
2 | ||
| 44410B - GASKET(FOR PRESSURE FEED TUBE) | ||||
| 90430-14235 |
XZU412,422..5F..TD;XZU412,422..RHD..DSL;WU410,XZU404,414,424,434..ARL,GCC,GEN |
2 | ||
| 44411 - HOSE, PRESSURE FEED | ||||
| 44411-37141 |
WU412,42#;WU410..65T;WU410..75T..GEN |
1 | ||
| 44411-37141 |
WU410..GCC,GEN |
1 | ||
| 44411C - BOLT, UNION(FOR PRESSURE FEED HOSE) | ||||
| 90401-16027 |
XZU414,424,434..ARL,GEN;WU410,XZU404,412,422..5F..(ARL,GCC,GEN) |
1 | ||
| 44411D - GASKET(FOR PRESSURE FEED HOSE) | ||||
| 44327-30030 |
WU410..GCC,GEN |
1 | ||
| 44412 - HOSE, RETURN | ||||
| 44412-37080 |
XZU412,422..5F..TD;XZU412,422..RHD..DSL;WU410,XZU404,414,424,434..ARL,GCC,GEN |
1 | ||
| 44413 - TUBE, PRESSURE FEED, NO.1 | ||||
| 44413-37200 |
WU410..RHD..GEN |
1 | ||
| 44413-37260 |
WU420;WU410..RHD..65T;WU410..75T..GEN |
1 | ||
| 44416 - TUBE, RETURN(FOR STEERING GEAR OUTLET) | ||||
| 44416-37380 |
WU410,420,XZU404,41#,42#,43#..RHD |
1 | ||
| 44416-37381 |
WU410,XZU404,412,414,422,424,434..RHD..(ARL,GEN) |
1 | ||
| 44416-37570 |
WU410..RHD..65T;WU410..75T..GEN;WU420,XZU423,433..SA |
1 | ||
| 44423 - TUBE, OIL PUMP TO GEAR BOX | ||||
| 44423-37070 |
WU410..GCC,GEN |
1 | ||
| 44423-37070 |
WU420;WU410..65T;WU410..75T..GEN |
1 | ||
| 44447A - BRACKET, HOSE SUPPORT, NO.1 | ||||
| 44447-37020 |
WU410..GCC,GEN NO.1 |
1 | ||
| 44447-37260 |
WU412,42#;WU410..65T;WU410..75T..GEN NO.3 |
1 | ||
| 44447-37020 |
WU412,42#;WU410..65T;WU410..75T..GEN NO.2 |
1 | ||
| 44447C - BRACKET, HOSE SUPPORT NO.2 | ||||
| 44447-37080 |
WU410..GCC,GEN |
1 | ||
| 44453 - STAY, PUMP, FRONT | ||||
| 44453-37010 |
WU410..GCC,GEN |
1 | ||
| 44457B - BRACKET, POWER STEERING TUBE SUPPORT, NO.2 | ||||
| 44457-37130 |
WU410,XZU404,412,414,422,424,434..RHD..(ARL,GEN) |
2 | ||
| 44457B - BRACKET, POWER STEERING TUBE SUPPORT, NO.2 | ||||
| 44457-37130 |
WU410,XZU404,412,414,422,424,434..RHD..(ARL,GEN) |
2 | ||
| Common parts | ||||
| 90031-05122 | ||||
| 90034-61047 | ||||
| 90119-08873 | ||||
| 90179-08068 | ||||
| 90467-16019 | ||||
| 90467-21010 | ||||
| 90959-01599 | ||||
| 90959-01600 | ||||
| 91651-60616 | ||||
| 91651-60816 | ||||
| 91651-B0820 | ||||
| 94130-00802 | ||||
| 96991-14080 | ||||
| Linked diagrams | ||||
| 4502 | ||||
| 4505 | ||||
(0610- )RHD..GEN ; (0801- )WU420 ; (0801-)WU410..65T..SA
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 44327M - GASKET, PRESSURE PORT, NO.2 | ||||
| 90461-10832 |
WU412,42#;WU410..65T;WU410..75T..GEN |
1 | ||
| 90461-10832 |
WU410..GCC,GEN |
1 | ||
| 44348D - HOSE, OIL RESERVOIR TO PUMP, NO.2 | ||||
| 44348-37280 |
WU410..GCC,GEN |
1 | ||
| 44348-37410 |
WU412,42#;WU410..65T;WU410..75T..GEN |
1 | ||
| 44369 - BRACKET, OIL RESERVOIR, NO.1 | ||||
| 44369-37110 |
WU410..GCC,GEN |
1 | ||
| 44411 - HOSE, PRESSURE FEED | ||||
| 44411-37141 |
WU412,42#;WU410..65T;WU410..75T..GEN |
1 | ||
| 44411-37141 |
WU410..GCC,GEN |
1 | ||
| 44411C - BOLT, UNION(FOR PRESSURE FEED HOSE) | ||||
| 90401-16027 |
XZU414,424,434..ARL,GEN;WU410,XZU404,412,422..5F..(ARL,GCC,GEN) |
1 | ||
| 44411D - GASKET(FOR PRESSURE FEED HOSE) | ||||
| 44327-30030 |
WU410..GCC,GEN |
1 | ||
| 44412 - HOSE, RETURN | ||||
| 44412-37080 |
XZU412,422..5F..TD;XZU412,422..RHD..DSL;WU410,XZU404,414,424,434..ARL,GCC,GEN |
1 | ||
| 44413 - TUBE, PRESSURE FEED, NO.1 | ||||
| 44413-37200 |
WU410..RHD..GEN |
1 | ||
| 44413-37260 |
WU420;WU410..RHD..65T;WU410..75T..GEN |
1 | ||
| 44416 - TUBE, RETURN(FOR STEERING GEAR OUTLET) | ||||
| 44416-37380 |
WU410,420,XZU404,41#,42#,43#..RHD |
1 | ||
| 44416-37381 |
WU410,XZU404,412,414,422,424,434..RHD..(ARL,GEN) |
1 | ||
| 44416-37570 |
WU410..RHD..65T;WU410..75T..GEN;WU420,XZU423,433..SA |
1 | ||
| 44423 - TUBE, OIL PUMP TO GEAR BOX | ||||
| 44423-37070 |
WU410..GCC,GEN |
1 | ||
| 44423-37070 |
WU420;WU410..65T;WU410..75T..GEN |
1 | ||
| 44447A - BRACKET, HOSE SUPPORT, NO.1 | ||||
| 44447-37020 |
WU410..GCC,GEN NO.1 |
1 | ||
| 44447-37260 |
WU412,42#;WU410..65T;WU410..75T..GEN NO.3 |
1 | ||
| 44447-37020 |
WU412,42#;WU410..65T;WU410..75T..GEN NO.2 |
1 | ||
| 44447A - BRACKET, HOSE SUPPORT, NO.1 | ||||
| 44447-37020 |
WU410..GCC,GEN NO.1 |
1 | ||
| 44447-37260 |
WU412,42#;WU410..65T;WU410..75T..GEN NO.3 |
1 | ||
| 44447-37020 |
WU412,42#;WU410..65T;WU410..75T..GEN NO.2 |
1 | ||
| 44447A - BRACKET, HOSE SUPPORT, NO.1 | ||||
| 44447-37020 |
WU410..GCC,GEN NO.1 |
1 | ||
| 44447-37260 |
WU412,42#;WU410..65T;WU410..75T..GEN NO.3 |
1 | ||
| 44447-37020 |
WU412,42#;WU410..65T;WU410..75T..GEN NO.2 |
1 | ||
| 44448C - CLAMP, PRESSURE FEED, NO.2 | ||||
| 44448-37080 |
WU412,42#;WU410..65T;WU410..75T..GEN NO.2 |
1 | ||
| 44448C - CLAMP, PRESSURE FEED, NO.2 | ||||
| 44448-37080 |
WU412,42#;WU410..65T;WU410..75T..GEN NO.2 |
1 | ||
| 44448C - CLAMP, PRESSURE FEED, NO.2 | ||||
| 44448-37080 |
WU412,42#;WU410..65T;WU410..75T..GEN NO.2 |
1 | ||
| Common parts | ||||
| 47371-37040 | ||||
| 90031-05123 | ||||
| 90179-08068 | ||||
| 90467-16019 | ||||
| 90467-21010 | ||||
| 91651-60616 | ||||
| 91651-B0822 | ||||
| 94130-00802 | ||||
| 96991-14080 | ||||
| Linked diagrams | ||||
| 4502 | ||||
| 4505 | ||||
