HU50R-MRDT3 (1982)
Toyota Dyna
(8204-8408)2H
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 16261 - HOSE, WATER BY-PASS | ||||
| 16261-56011 |
B,2B,3B..BU2#,3# |
1 | ||
| 99555-40090 |
2H..HU40,50 |
1 | ||
| 99553-40090 |
2H..HU40,50 |
1 | ||
| 16261A - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS HOSE) | ||||
| 96111-10330 |
2H..HU40,50 |
2 | ||
| 90044-60053 |
B,2B,3B..BU2#,3#,40 |
2 | ||
| 16261A - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS HOSE) | ||||
| 96111-10330 |
2H..HU40,50 |
2 | ||
| 90044-60053 |
B,2B,3B..BU2#,3#,40 |
2 | ||
| 16323 - HOUSING, WATER INLET | ||||
| 16323-68010 |
2H..HU40,50 |
1 | ||
| 16323B - PLUG(FOR WATER INLET HOUSING) | ||||
| 90341-20002 |
2H..HU40,50 |
2 | ||
| 16323B - PLUG(FOR WATER INLET HOUSING) | ||||
| 90341-20002 |
2H..HU40,50 |
2 | ||
| 16325 - GASKET, WATER INLET HOUSING, NO.1 | ||||
| 16325-68010 |
2H..HU40,50 |
1 | ||
| 16331 - OUTLET, WATER | ||||
| 16331-68010 |
2H..HU40,50 |
1 | ||
| 16331A - THERMOSTAT | ||||
| 90916-03026 |
2H..HU40,50 *WAX 82-95,*WAX 82-95 |
1 | ||
| 16333 - HOUSING, WATER OUTLET | ||||
| 16333-68010 |
2H..HU40,50 |
1 | ||
| 16341 - GASKET, WATER OUTLET | ||||
| 16341-68010 |
2H..HU40,50 |
1 | ||
| 16343 - GASKET, WATER OUTLET HOUSING | ||||
| 16343-68010 |
2H..HU40,50 |
1 | ||
| 16361A - BELT, V(FOR FAN & ALTERNATOR) | ||||
| 99343-01065 |
2H..HU40,50 |
1 | ||
| 16381 - BAR, FAN BELT ADJUSTING | ||||
| 16381-68010 |
2H..HU40,50 |
1 | ||
| 16400 - RADIATOR ASSY | ||||
| 16400-68060 |
2H..HU40,50 |
1 | ||
| 16400B - PLUG, RADIATOR DRAIN COCK | ||||
| 16417-24200 |
2H..HU40,50 |
1 | ||
| 16417-24200 |
B,2B,3B..BU2#,3#,40 |
1 | ||
| 16400F - PACKING(FOR RADIATOR DRAIN COCK) | ||||
| 16418-24200 |
2H..HU40,50 |
1 | ||
| 16418-24200 |
B,2B,3B..BU2#,3#,40 |
1 | ||
| 16470 - TANK ASSY, RADIATOR RESERVE | ||||
| 16470-68010 |
2H..HU40,50 |
1 | ||
| 16470-56090 |
2H..HU40,50..GEN..IV3 W/LSPV |
1 | ||
| 16470 - TANK ASSY, RADIATOR RESERVE | ||||
| 16470-68010 |
2H..HU40,50 |
1 | ||
| 16470-56090 |
2H..HU40,50..GEN..IV3 W/LSPV |
1 | ||
| 16470A - HOSE OR PIPE(FOR RADIATOR RESERVE TANK) | ||||
| 90445-12067 |
2H..HU40,50 L=330 |
1 | ||
| 90445-12521 |
2H..HU40,50..GEN..IV3 W/LSPV |
1 | ||
| 16470A - HOSE OR PIPE(FOR RADIATOR RESERVE TANK) | ||||
| 90445-12067 |
2H..HU40,50 L=330 |
1 | ||
| 90445-12521 |
2H..HU40,50..GEN..IV3 W/LSPV |
1 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
B,2B,3B..BU2#,3#,40 |
2 | ||
| 90467-11085 |
H,2H..HU30,40,50 |
2 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
B,2B,3B..BU2#,3#,40 |
2 | ||
| 90467-11085 |
H,2H..HU30,40,50 |
2 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
B,2B,3B..BU2#,3#,40 |
2 | ||
| 90467-11085 |
H,2H..HU30,40,50 |
2 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
B,2B,3B..BU2#,3#,40 |
2 | ||
| 90467-11085 |
H,2H..HU30,40,50 |
2 | ||
| 16470C - BRACKET(FOR RADIATOR RESERVE TANK) | ||||
| 16611-68010 |
2H..HU40,50 |
1 | ||
| 16611-56030 |
2H..HU40,50..GEN..IV3 W/LSPV |
1 | ||
| 16470C - BRACKET(FOR RADIATOR RESERVE TANK) | ||||
| 16611-68010 |
2H..HU40,50 |
1 | ||
| 16611-56030 |
2H..HU40,50..GEN..IV3 W/LSPV |
1 | ||
| 16471 - CAP SUB-ASSY, RESERVE TANK | ||||
| 16405-68010 |
2H..HU40,50 |
1 | ||
| 16471-34030 |
B,2B,3B..BU2#,3#,40 |
1 | ||
| 16471-34030 |
2H..HU40,50..GEN..IV3 W/LSPV |
1 | ||
| 16471 - CAP SUB-ASSY, RESERVE TANK | ||||
| 16405-68010 |
2H..HU40,50 |
1 | ||
| 16471-34030 |
B,2B,3B..BU2#,3#,40 |
1 | ||
| 16471-34030 |
2H..HU40,50..GEN..IV3 W/LSPV |
1 | ||
| 16472 - HOSE, BREATHER | ||||
| 85338-68010 |
2H..HU40,50 |
1 | ||
| 16571 - HOSE, RADIATOR, INLET | ||||
| 16571-68040 |
2H..HU40,50 |
1 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90460-50016 |
B,2B,3B..BU2#,3#,40 ID=50 |
2 | ||
| 96111-10500 |
2H..HU40,50 |
2 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90460-50016 |
B,2B,3B..BU2#,3#,40 ID=50 |
2 | ||
| 96111-10500 |
2H..HU40,50 |
2 | ||
| 16572 - HOSE, RADIATOR, OUTLET | ||||
| 16572-68040 |
2H..HU40,50 |
1 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 96111-10500 |
2H..HU40,50 RADIATOR SIDE |
1 | ||
| 96111-10560 |
2H..HU40,50 PUMP SIDE |
1 | ||
| 96111-10560 |
B,2B,3B..BU2#,3#,40 WATER PUMP SIDE |
1 | ||
| 90460-50016 |
B,2B,3B..BU2#,3#,40 RADIATOR SIDE |
1 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 96111-10500 |
2H..HU40,50 RADIATOR SIDE |
1 | ||
| 96111-10560 |
2H..HU40,50 PUMP SIDE |
1 | ||
| 96111-10560 |
B,2B,3B..BU2#,3#,40 WATER PUMP SIDE |
1 | ||
| 90460-50016 |
B,2B,3B..BU2#,3#,40 RADIATOR SIDE |
1 | ||
| 16701 - SHROUD SUB-ASSY, FAN | ||||
| 16711-68030 |
2H..HU40,50 |
1 | ||
| Common parts | ||||
| 90119-08162 | ||||
| 90345-51003 | ||||
| 90430-20004 | ||||
| 91611-60820 | ||||
| 91611-60822 | ||||
| 91611-60825 | ||||
| 91611-60835 | ||||
| 91611-60840 | ||||
| 91611-61018 | ||||
| 91611-61025 | ||||
| 91651-40814 | ||||
| 91651-40816 | ||||
| 91656-40616 | ||||
