BU60L-MDB (1984)
Toyota Dyna
(8409- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 87116A - SPRING, HOLDING (FOR COOLER UNIT CASE) | ||||
| 87116-14010 |
BU65..CBU;BU60,61,62,63,7#,8#..ARL,GEN,GHD,SA |
4 | ||
| 88501 - EVAPORATOR SUB-ASSY, COOLER, NO.1 | ||||
| 88501-95402 |
BU60,61,62,7#,80,81,85..LHD..GEN |
1 | ||
| 88501-95404 |
BU60,61,62,7#,80,81,85..LHD..GEN |
1 | ||
| 88510 - UNIT ASSY, COOLER | ||||
| 88510-95402 |
BU60,61,62,7#,80,81,85..LHD..GEN |
1 | ||
| 88510R - GROMMET (FOR COOLER UNIT) | ||||
| 90480-36003 |
BU60,61,62,63,7#,80,81,82,85..ARL,GEN,GHD,SA SUCTION PIPE |
1 | ||
| 90099-21010 |
BU60,61,62,63,70,80,81,82..ARL,GEN,GHD LIQUID PIPE,W/*BV |
1 | ||
| 90480-36010 |
BU60,61,62,63,7#,8#..ARL,GEN,GHD,SA SUCTION PIPE |
1 | ||
| 90099-32098 |
BU60,61,62,63,70,80,81,82 LIQUID PIPE,W/HEATER |
1 | ||
| 88510R - GROMMET (FOR COOLER UNIT) | ||||
| 90480-36003 |
BU60,61,62,63,7#,80,81,82,85..ARL,GEN,GHD,SA SUCTION PIPE |
1 | ||
| 90099-21010 |
BU60,61,62,63,70,80,81,82..ARL,GEN,GHD LIQUID PIPE,W/*BV |
1 | ||
| 90480-36010 |
BU60,61,62,63,7#,8#..ARL,GEN,GHD,SA SUCTION PIPE |
1 | ||
| 90099-32098 |
BU60,61,62,63,70,80,81,82 LIQUID PIPE,W/HEATER |
1 | ||
| 88510R - GROMMET (FOR COOLER UNIT) | ||||
| 90480-36003 |
BU60,61,62,63,7#,80,81,82,85..ARL,GEN,GHD,SA SUCTION PIPE |
1 | ||
| 90099-21010 |
BU60,61,62,63,70,80,81,82..ARL,GEN,GHD LIQUID PIPE,W/*BV |
1 | ||
| 90480-36010 |
BU60,61,62,63,7#,8#..ARL,GEN,GHD,SA SUCTION PIPE |
1 | ||
| 90099-32098 |
BU60,61,62,63,70,80,81,82 LIQUID PIPE,W/HEATER |
1 | ||
| 88515 - VALVE, COOLER EXPANSION | ||||
| 88515-16030 |
BU65..CBU;BU60,61,62,63,7#,8#..ARL,GEN,GHD |
1 | ||
| 88515-16030 |
BU60,61,62,7#,80,81,85..LHD..GEN |
1 | ||
| 88536 - BRACKET, COOLING UNIT, NO.1 | ||||
| 88536-95403 |
BU65..CBU;BU60,61,62,63,7#,8#..ARL,GEN,GHD,SA |
1 | ||
| 88536A - BRACKET, COOLING UNIT, NO.2 | ||||
| 88536-95404 |
BU65..CBU;BU60,61,62,63,70,80,81,82 |
1 | ||
| 88536B - BRACKET, COOLING UNIT, NO.3 | ||||
| 88536-95406 |
BU60,61,62,70,80,81..LHD |
1 | ||
| 88539 - HOSE, COOLER UNIT DRAIN, NO.1 | ||||
| 88539-95406 |
BU60,61,62,70,80,81..LHD |
1 | ||
| 88539-95410 |
BU60,61,62,70,80,81..LHD |
1 | ||
| 88566 - DUCT, COOLER AIR, NO.1 | ||||
| 88566-95407 |
BU65..CBU;BU60,61,62,63,70,80,81,82 |
1 | ||
| 88578A - PACKING, COOLER STABILIZER AMPLIFIER | ||||
| 88578-95400 |
BU65..CBU;BU60,61,62,63,7#,8#..ARL,GEN,GHD,SA |
2 | ||
| 88605 - HARNESS SUB-ASSY, COOLER WIRING, NO.1 | ||||
| 88605-95405 |
BU65..CBU;BU60,61,62,63,70,80,81,82 |
1 | ||
| 88625 - THERMISTOR, COOLER, NO.1 | ||||
| 88625-95A00 |
BU65..CBU;BU60,61,62,63,7#,8#..ARL,GEN,GHD,SA |
1 | ||
| 88630 - RELAY ASSY, COOLER | ||||
| 88630-60020 |
BU65..CBU;BU60,61,62,63,7#,8#..ARL,GEN,GHD,SA |
1 | ||
| 88630A - RELAY ASSY, COOLER | ||||
| 88630-95403 |
BU60,61,62,7#,80,81,85..LHD..GEN |
1 | ||
| 88645G - SWITCH, PRESSURE | ||||
| 88645-17010 |
BU65..CBU;BU60,61,62,63,7#,8#..ARL,GEN,GHD,SA NO.2 |
1 | ||
| 88645-95J00 |
BU65..CBU;BU60,61,62,63,7#,8#..ARL,GEN,GHD,SA NO.1 |
1 | ||
| 88645G - SWITCH, PRESSURE | ||||
| 88645-17010 |
BU65..CBU;BU60,61,62,63,7#,8#..ARL,GEN,GHD,SA NO.2 |
1 | ||
| 88645-95J00 |
BU65..CBU;BU60,61,62,63,7#,8#..ARL,GEN,GHD,SA NO.1 |
1 | ||
| 88650 - AMPLIFIER ASSY, COOLER STABILIZER | ||||
| 88650-14030 |
BU65..CBU;BU60,61,62,63,7#,8#..ARL,GEN,GHD,SA |
1 | ||
| 88688A - BRACKET, COOLER STABILIZER AMPLIFIER | ||||
| 88688-95425 |
BU65..CBU;BU60,61,62,63,7#,8#..ARL,GEN,GHD,SA |
1 | ||
| Common parts | ||||
| 82711-14110 | ||||
| 90099-00148 | ||||
| 90099-21010 | ||||
| 90179-08123 | ||||
| 93315-15012 | ||||
| 93540-15016 | ||||
