BU30L-MRDHT3 (1977)
Toyota Dyna
(7708- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 46501 - DRUM SUB-ASSY, PARKING BRAKE | ||||
| 46501-36040 |
BU30,RU30;BU20,RU20..EUR 7 INCHES |
1 | ||
| 46501-36040 |
RU25,30;BU30..T3 7 INCHES |
1 | ||
| 46501-36020 |
BU20,JU20,RU20..EUR;BU25,30,HU30,RU25,30 7 INCHES |
1 | ||
| 46501A - BOLT, SERRATION(FOR PARKING BRAKE DRUM) | ||||
| 90114-11124 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
4 | ||
| 46506 - ADJUSTER SUB-ASSY, PARKING BRAKE SHOE, RH OR CENTER | ||||
| 46506-36010 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
1 | ||
| 46520 - PLATE SUB-ASSY, PARKING BRAKE | ||||
| 46503-36040 |
BU30;BU20..EUR 7 INCHES |
1 | ||
| 46550 - SHOE ASSY, PARKING BRAKE, RH OR CENTER NO.2 | ||||
| 46530-36010 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
2 | ||
| 46550 - SHOE ASSY, PARKING BRAKE, RH OR CENTER NO.2 | ||||
| 46530-36010 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
2 | ||
| 46550A - SPRING, TENSION, NO.1(FOR PARKING BRAKE SHOE RETURN) | ||||
| 90506-18001 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
2 | ||
| 46550A - SPRING, TENSION, NO.1(FOR PARKING BRAKE SHOE RETURN) | ||||
| 90506-18001 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
2 | ||
| 46550C - WASHER, TYPE C(FOR PARKING BRAKE SHOE) | ||||
| 90213-06013 |
BU2#,30,HU30,JU20,RU2#,30 |
2 | ||
| 46550C - WASHER, TYPE C(FOR PARKING BRAKE SHOE) | ||||
| 90213-06013 |
BU2#,30,HU30,JU20,RU2#,30 |
2 | ||
| 46550E - SPRING, TENSION, NO.2(FOR PARKING BRAKE SHOE RETURN) | ||||
| 90506-14012 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
1 | ||
| 46555 - SPRING, BRAKE SHOE HOLD DOWN | ||||
| 90501-16025 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
2 | ||
| 46556 - PIN, SHOE HOLD DOWN SPRING | ||||
| 47447-22010 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
2 | ||
| 46577 - COVER, ADJUSTING CAM HOLE | ||||
| 46577-36010 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
1 | ||
| 46601 - LEVER SUB-ASSY, PARKING BRAKE SHOE | ||||
| 46601-36030 |
BU30;BU20..EUR 7 INCHES |
1 | ||
| Common parts | ||||
| 90101-10470 | ||||
| 90119-10338 | ||||
| 94531-01000 | ||||
| 94613-11200 | ||||
(7708-7905) ; (7905- )EUR,GEN,GHI
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 46101 - HANDLE SUB-ASSY, PARKING BRAKE CONTROL | ||||
| 46101-36100 |
BU20,30,HU30,JU20,RU20,30..LHD |
1 | ||
| 46101-36101 |
BU2#,30,HU30,JU20,RU2#,30..LHD |
1 | ||
| 46101-36102 |
BU2#,30,31,32,HU30,RU2#,30..LHD |
1 | ||
| 46101 - HANDLE SUB-ASSY, PARKING BRAKE CONTROL | ||||
| 46101-36100 |
BU20,30,HU30,JU20,RU20,30..LHD |
1 | ||
| 46101-36101 |
BU2#,30,HU30,JU20,RU2#,30..LHD |
1 | ||
| 46101-36102 |
BU2#,30,31,32,HU30,RU2#,30..LHD |
1 | ||
| 46110E - SPRING, TORSION(FOR PARKING BRAKE PLUNGER) | ||||
| 90508-14039 |
BU2#,3#,40,HU30,JU20,RU2#,30,WU40,50..LHD |
1 | ||
| 46110F - BRACKET, PARKING BRAKE, LOWER | ||||
| 55177-95400 |
BU2#,3#,40,HU30,JU20,RU2#,30,WU40,50..LHD |
1 | ||
| 46114 - PIN, PARKING BRAKE PLUNGER | ||||
| 46114-20010 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 UPR |
1 | ||
| 46114-30010 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 LWR |
1 | ||
| 46114 - PIN, PARKING BRAKE PLUNGER | ||||
| 46114-20010 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 UPR |
1 | ||
| 46114-30010 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 LWR |
1 | ||
| 46115 - WASHER, PARKING BRAKE PLUNGER | ||||
| 46115-20010 |
BU2#,30,HU30,JU20,RU2#,30 |
1 | ||
| 46115-20010 |
HU30;BU2#,30,RU2#,30..EUR,GEN |
1 | ||
| 46116 - GUIDE, PARKING BRAKE PLUNGER | ||||
| 46116-36100 |
BU2#,3#,40,HU30,JU20,RU2#,30,WU40,50..LHD |
1 | ||
| 46117 - SLEEVE, PARKING BRAKE PLUNGER | ||||
| 46117-30020 |
BU2#,3#,40,HU30,JU20,RU2#,30,WU40,50..LHD |
1 | ||
| 46131 - BRACKET SUB-ASSY, PARKING BRAKE | ||||
| 46131-36060 |
BU20,30,HU30,JU20,RU20,30 |
1 | ||
| 46131-36070 |
BU2#,3#,40,HU30,JU20,RU2#,30,WU40,50..LHD |
1 | ||
| 46301 - LEVER SUB-ASSY, PARKING BRAKE INTERMEDIATE | ||||
| 46301-36050 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
1 | ||
| 46301E - PIN, W/HOLE(FOR INTERMEDIATE LEVER) | ||||
| 90240-08010 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
1 | ||
| 46311 - PAWL, PARKING BRAKE | ||||
| 46311-28010 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
1 | ||
| 46311A - SPRING(FOR PARKING BRAKE PAWL) | ||||
| 90508-08041 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
1 | ||
| 46311B - PIN, PARKING BRAKE PAWL PIVOT | ||||
| 90249-05010 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
1 | ||
| 46311D - WASHER, TYPE C(FOR PARKING BRAKE PAWL) | ||||
| 90213-03007 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
1 | ||
| 46321A - SPRING, TENSIION(FOR PARKING BRAKE INTERMEDIATE LEVER) | ||||
| 90508-35002 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
1 | ||
| 46321B - BUSH(FOR PARKING BRAKE INTERMEDIATE LEVER) | ||||
| 90386-13007 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
2 | ||
| 46321B - BUSH(FOR PARKING BRAKE INTERMEDIATE LEVER) | ||||
| 90386-13007 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
2 | ||
| 46321C - TUBE(FOR PARKING BRAKE INTERMEDIATE LEVER) | ||||
| 90387-10004 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
1 | ||
| 46351 - SHAFT, INTERMEDIATE LEVER PIVOT | ||||
| 91111-71070 |
BU20,30,HU30,JU20,RU20,30 |
1 | ||
| 46410 - CABLE ASSY, PARKING BRAKE, NO.1 | ||||
| 46410-36120 |
BU2#,3#,HU30,JU20,RU2#,30 |
1 | ||
| 46410D - PIN(FOR PARKING BRAKE FRONT CABLE) | ||||
| 90240-08094 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
1 | ||
| 46420 - CABLE ASSY, PARKING BRAKE, NO.2 | ||||
| 46420-36100 |
BU30..LHD;BU20,RU20..EUR |
1 | ||
| 46420-36100 |
BU30,RU25,30..LHD..(GEN,GHI) |
1 | ||
| 46420E - GROMMET(FOR PARKING BRAKE CABLE CLAMP) | ||||
| 90480-26006 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
1 | ||
| 46420F - SEAL, DUST(FOR PARKING BRAKE CABLE) | ||||
| 90303-10001 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
1 | ||
| 46420G - SPRING(FOR PARKING CABLE INNER WIRE SET) | ||||
| 90501-14003 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
1 | ||
| 46420P - SPACER, PARKING BRAKE | ||||
| 90560-08002 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
1 | ||
| 46420Q - RING, E(FOR PARKING BRAKE CABLE) | ||||
| 96160-00700 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
1 | ||
| 46451 - BRACKET, CABLE SUPPORT | ||||
| 46451-36021 |
BU2#,3#,40,HU30,JU20,RU2#,30,WU40,50..LHD |
1 | ||
| 46481 - CONNECTOR, PARKING CABLE | ||||
| 46481-36011 |
BU2#,3#,HU30,JU20,RU2#,30 |
1 | ||
| Common parts | ||||
| 90461-08225 | ||||
| 90468-08001 | ||||
| 91611-40812 | ||||
| 91651-40814 | ||||
| 91651-40816 | ||||
| 91656-40816 | ||||
| 94120-40600 | ||||
| 94512-01000 | ||||
| 95381-02520 | ||||
(7708- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 46501 - DRUM SUB-ASSY, PARKING BRAKE | ||||
| 46501-36040 |
BU30,RU30;BU20,RU20..EUR 7 INCHES |
1 | ||
| 46501-36040 |
RU25,30;BU30..T3 7 INCHES |
1 | ||
| 46501-36020 |
BU20,JU20,RU20..EUR;BU25,30,HU30,RU25,30 7 INCHES |
1 | ||
| 46501A - BOLT, SERRATION(FOR PARKING BRAKE DRUM) | ||||
| 90114-11124 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
4 | ||
| 46506 - ADJUSTER SUB-ASSY, PARKING BRAKE SHOE, RH OR CENTER | ||||
| 46506-36010 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
1 | ||
| 46520 - PLATE SUB-ASSY, PARKING BRAKE | ||||
| 46503-36040 |
BU30;BU20..EUR 7 INCHES |
1 | ||
| 46550 - SHOE ASSY, PARKING BRAKE, RH OR CENTER NO.2 | ||||
| 46530-36010 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
2 | ||
| 46550 - SHOE ASSY, PARKING BRAKE, RH OR CENTER NO.2 | ||||
| 46530-36010 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
2 | ||
| 46550A - SPRING, TENSION, NO.1(FOR PARKING BRAKE SHOE RETURN) | ||||
| 90506-18001 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
2 | ||
| 46550A - SPRING, TENSION, NO.1(FOR PARKING BRAKE SHOE RETURN) | ||||
| 90506-18001 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
2 | ||
| 46550C - WASHER, TYPE C(FOR PARKING BRAKE SHOE) | ||||
| 90213-06013 |
BU2#,30,HU30,JU20,RU2#,30 |
2 | ||
| 46550E - SPRING, TENSION, NO.2(FOR PARKING BRAKE SHOE RETURN) | ||||
| 90506-14012 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
1 | ||
| 46555 - SPRING, BRAKE SHOE HOLD DOWN | ||||
| 90501-16025 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
2 | ||
| 46556 - PIN, SHOE HOLD DOWN SPRING | ||||
| 47447-22010 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
2 | ||
| 46557 - CUP, BRAKE SHOE HOLD DOWN | ||||
| 47449-20011 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
4 | ||
| 46557 - CUP, BRAKE SHOE HOLD DOWN | ||||
| 47449-20011 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
4 | ||
| 46577 - COVER, ADJUSTING CAM HOLE | ||||
| 46577-36010 |
BU2#,3#,40,HU30,40,50,JU20,RU2#,30,WU40,50 |
1 | ||
| 46601 - LEVER SUB-ASSY, PARKING BRAKE SHOE | ||||
| 46601-36030 |
BU30;BU20..EUR 7 INCHES |
1 | ||
| 46612 - STRUT, PARKING BRAKE SHOE LEVER | ||||
| 46612-36030 |
BU30;BU20..EUR 7 INCHES |
1 | ||
| 46612B - SPRING, COMPRESSION(FOR PARKING BRAKE SHOE STRUT) | ||||
| 90504-10001 |
BU30..T3;BU23,25,31,32,36,40,HU30,40,50,RU25,30,WU40,50 7 INCHES |
1 | ||
| Common parts | ||||
| 90101-10443 | ||||
| 90101-10470 | ||||
| 90119-10338 | ||||
| 94531-01000 | ||||
| 94613-11200 | ||||
(7708- )BU2#,30,31,32,HU30,JU20,RU2#,30
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 46229 - SUPPORT, PARKING BRAKE CABLE GUIDE | ||||
| 46229-36010 |
JU20,RU20,30 |
1 | ||
| 46229-36020 |
BU20,30 |
1 | ||
| 46229 - SUPPORT, PARKING BRAKE CABLE GUIDE | ||||
| 46229-36010 |
JU20,RU20,30 |
1 | ||
| 46229-36020 |
BU20,30 |
1 | ||
| Common parts | ||||
| 90461-10083 | ||||
| 90461-10232 | ||||
| 90461-10302 | ||||
| 90461-10932 | ||||
| 90461-12086 | ||||
| 90461-16393 | ||||
| 90462-23215 | ||||
| 91611-40816 | ||||
| 91611-40820 | ||||
| 94110-40800 | ||||
