MS123L-SEPQF (1983)

Toyota Crown

Production Aug 1983 - Oct 1984
Engine 5MGE
Transmission 4FC ATM
Displacement 2500cc
Power 168 HP (125 kW)

(8404-8410)5MGE..ROY

Click highlighted areas on diagram

diagram 19100 19101 19102 19107A 19115 19121 19122 19127 19152 19152 19152A 19152A 19153 19154 19155 19169 19181 19220 19220A 19225 19242 19250 9009080507 9009900124 9009900710 9009900710 9009902198 9009904566 9011908144 9331915010
Part # Description Qty Price
19100 - DISTRIBUTOR ASSY
19100-43150

5MGE..MS123..ROY

 1
19100-43151

5MGE..MS123..ROY

 1
19101 - CAP SUB-ASSY, DISTRIBUTOR
19101-43060

5MGE..MS123

 1
19102 - ROTOR SUB-ASSY, DISTRIBUTOR
19102-43060

5MGE..MS123..ROY

 1
19107A - RING, O, DISTRIBUTOR HOUSING
90099-14018

5M#,6MGE..MS12#

 1
19115 - PIECE, DISTRIBUTOR CAP, CENTER
19115-50010

5M#,6MGE..MS12#

 1
19121 - COVER, DUST PROOF
19121-38210

5MGE..MS123..ROY

 1
19122 - PLATE, STATIONARY, DISTRIBUTOR
19122-88262

5MGE..MS123..ROY

 1
19127 - PACKING, DUST PROOF
19127-52020

5MGE,6MGE..MS123,125

 1
19152 - WEIGHT, GOVERNOR
19152-44170

5MGE..MS123..ROY

NO.1

 2
19152-44170

5MGE..MS123..ROY

 2
19152-43060

5MGE..MS123..ROY

NO.2

 2
19152-45060

5M,5ME..MS122,123

 2
19152 - WEIGHT, GOVERNOR
19152-44170

5MGE..MS123..ROY

NO.1

 2
19152-44170

5MGE..MS123..ROY

 2
19152-43060

5MGE..MS123..ROY

NO.2

 2
19152-45060

5M,5ME..MS122,123

 2
19152A - RING, SNAP(FOR GOVERNOR WEIGHT)
90099-07109

5MGE..MS123..ROY

 4
90099-07109

5M,5ME..MS122,123

 2
19152A - RING, SNAP(FOR GOVERNOR WEIGHT)
90099-07109

5MGE..MS123..ROY

 4
90099-07109

5M,5ME..MS122,123

 2
19153 - SPRING, GOVERNOR, A
19153-43150

5MGE..MS123..ROY

 2
19154 - SPRING, GOVERNOR, B
19153-43150

5MGE..MS123..ROY

 2
19153-43155

5MGE..MS123..ROY

 2
19155 - GEAR, SPIRAL, DISTRIBUTOR
19195-43060

5MGE,6MGE..MS123,125

 1
19169 - STOPPER, CAM GREASE
19169-32010

5M,5ME..MS122,123

 1
19169-63011

5MGE..MS123..ROY

 1
19181 - ROTOR, DISTRIBUTOR, SIGNAL
19181-43150

5MGE..MS123..ROY

 1
19181-43151

5MGE..MS123..ROY

 1
19220 - ADVANCER ASSY, VACUUM, DISTRIBUTOR
19220-43100

5MGE..MS123..ROY

 1
19220A - RING, SNAP(FOR DISTRIBUTOR VACUUM ADVANCER)
90099-07109

5MGE..MS123..ROY

 1
19225 - CAP, RUBBER
19225-41140

5M#,6MGE..MS12#

 1
19242 - CLAMP, CORD
19242-26250

5M,5MGE..MS122,123..GEN,SAA

 1
19250 - GENERATOR ASSY, SIGNAL
19250-43150

5MGE..MS123..ROY

 1
Common parts
90090-80507
90099-00124
90099-00710
90099-02198
90099-04566
90119-08144
93319-15010

(8308- )5M

Click highlighted areas on diagram

diagram 19100 19101 19102 19103 19105 19106 19107A 19115 19121 19122 19127 19133 19144 19145 19151 19152 19152 19152A 19152A 19153 19154 19155 19169 19220 19220 19225 19231 19242 19905 9009900124 9009900124 9009900710 9009900810 9009900871 9009902198 9009902198 9009904566 9009904865 9009905803 9165140820 9165140825 9331914008 9541100400
Part # Description Qty Price
19100 - DISTRIBUTOR ASSY
19100-43150

5MGE..MS123..ROY

 1
19100-43151

5MGE..MS123..ROY

 1
19101 - CAP SUB-ASSY, DISTRIBUTOR
19101-43060

5MGE..MS123

 1
19102 - ROTOR SUB-ASSY, DISTRIBUTOR
19102-43060

5MGE..MS123..ROY

 1
19107A - RING, O, DISTRIBUTOR HOUSING
90099-14018

5M#,6MGE..MS12#

 1
19115 - PIECE, DISTRIBUTOR CAP, CENTER
19115-50010

5M#,6MGE..MS12#

 1
19121 - COVER, DUST PROOF
19121-38210

5MGE..MS123..ROY

 1
19122 - PLATE, STATIONARY, DISTRIBUTOR
19122-88262

5MGE..MS123..ROY

 1
19127 - PACKING, DUST PROOF
19127-52020

5MGE,6MGE..MS123,125

 1
19152 - WEIGHT, GOVERNOR
19152-44170

5MGE..MS123..ROY

NO.1

 2
19152-44170

5MGE..MS123..ROY

 2
19152-43060

5MGE..MS123..ROY

NO.2

 2
19152-45060

5M,5ME..MS122,123

 2
19152 - WEIGHT, GOVERNOR
19152-44170

5MGE..MS123..ROY

NO.1

 2
19152-44170

5MGE..MS123..ROY

 2
19152-43060

5MGE..MS123..ROY

NO.2

 2
19152-45060

5M,5ME..MS122,123

 2
19152A - RING, SNAP(FOR GOVERNOR WEIGHT)
90099-07109

5MGE..MS123..ROY

 4
90099-07109

5M,5ME..MS122,123

 2
19152A - RING, SNAP(FOR GOVERNOR WEIGHT)
90099-07109

5MGE..MS123..ROY

 4
90099-07109

5M,5ME..MS122,123

 2
19153 - SPRING, GOVERNOR, A
19153-43150

5MGE..MS123..ROY

 2
19154 - SPRING, GOVERNOR, B
19153-43150

5MGE..MS123..ROY

 2
19153-43155

5MGE..MS123..ROY

 2
19155 - GEAR, SPIRAL, DISTRIBUTOR
19195-43060

5MGE,6MGE..MS123,125

 1
19169 - STOPPER, CAM GREASE
19169-32010

5M,5ME..MS122,123

 1
19169-63011

5MGE..MS123..ROY

 1
19220 - ADVANCER ASSY, VACUUM, DISTRIBUTOR
19220-43100

5MGE..MS123..ROY

 1
19220 - ADVANCER ASSY, VACUUM, DISTRIBUTOR
19220-43100

5MGE..MS123..ROY

 1
19225 - CAP, RUBBER
19225-41140

5M#,6MGE..MS12#

 1
19242 - CLAMP, CORD
19242-26250

5M,5MGE..MS122,123..GEN,SAA

 1
Common parts
90099-00124
90099-00710
90099-00810
90099-00871
90099-02198
90099-04566
90099-04865
90099-05803
91651-40820
91651-40825
93319-14008
95411-00400

(8308-8404)5MGE..ROY

Click highlighted areas on diagram

diagram 19100 19101 19102 19107A 19115 19121 19122 19127 19152 19152 19152 19152 19152A 19152A 19152A 19152A 19153 19153 19154 19154 19155 19169 19181 19182 19220 19220A 19225 19242 19250 9009080507 9009900124 9009900710 9009900710 9009902198 9009904566 9011908144 9331915010
Part # Description Qty Price
19100 - DISTRIBUTOR ASSY
19100-43150

5MGE..MS123..ROY

 1
19100-43151

5MGE..MS123..ROY

 1
19101 - CAP SUB-ASSY, DISTRIBUTOR
19101-43060

5MGE..MS123

 1
19102 - ROTOR SUB-ASSY, DISTRIBUTOR
19102-43060

5MGE..MS123..ROY

 1
19107A - RING, O, DISTRIBUTOR HOUSING
90099-14018

5M#,6MGE..MS12#

 1
19115 - PIECE, DISTRIBUTOR CAP, CENTER
19115-50010

5M#,6MGE..MS12#

 1
19121 - COVER, DUST PROOF
19121-38210

5MGE..MS123..ROY

 1
19122 - PLATE, STATIONARY, DISTRIBUTOR
19122-88262

5MGE..MS123..ROY

 1
19127 - PACKING, DUST PROOF
19127-52020

5MGE,6MGE..MS123,125

 1
19152 - WEIGHT, GOVERNOR
19152-44170

5MGE..MS123..ROY

NO.1

 2
19152-44170

5MGE..MS123..ROY

 2
19152-43060

5MGE..MS123..ROY

NO.2

 2
19152-45060

5M,5ME..MS122,123

 2
19152 - WEIGHT, GOVERNOR
19152-44170

5MGE..MS123..ROY

NO.1

 2
19152-44170

5MGE..MS123..ROY

 2
19152-43060

5MGE..MS123..ROY

NO.2

 2
19152-45060

5M,5ME..MS122,123

 2
19152 - WEIGHT, GOVERNOR
19152-44170

5MGE..MS123..ROY

NO.1

 2
19152-44170

5MGE..MS123..ROY

 2
19152-43060

5MGE..MS123..ROY

NO.2

 2
19152-45060

5M,5ME..MS122,123

 2
19152 - WEIGHT, GOVERNOR
19152-44170

5MGE..MS123..ROY

NO.1

 2
19152-44170

5MGE..MS123..ROY

 2
19152-43060

5MGE..MS123..ROY

NO.2

 2
19152-45060

5M,5ME..MS122,123

 2
19152A - RING, SNAP(FOR GOVERNOR WEIGHT)
90099-07109

5MGE..MS123..ROY

 4
90099-07109

5M,5ME..MS122,123

 2
19152A - RING, SNAP(FOR GOVERNOR WEIGHT)
90099-07109

5MGE..MS123..ROY

 4
90099-07109

5M,5ME..MS122,123

 2
19152A - RING, SNAP(FOR GOVERNOR WEIGHT)
90099-07109

5MGE..MS123..ROY

 4
90099-07109

5M,5ME..MS122,123

 2
19152A - RING, SNAP(FOR GOVERNOR WEIGHT)
90099-07109

5MGE..MS123..ROY

 4
90099-07109

5M,5ME..MS122,123

 2
19153 - SPRING, GOVERNOR, A
19153-43150

5MGE..MS123..ROY

 2
19153 - SPRING, GOVERNOR, A
19153-43150

5MGE..MS123..ROY

 2
19154 - SPRING, GOVERNOR, B
19153-43150

5MGE..MS123..ROY

 2
19153-43155

5MGE..MS123..ROY

 2
19154 - SPRING, GOVERNOR, B
19153-43150

5MGE..MS123..ROY

 2
19153-43155

5MGE..MS123..ROY

 2
19155 - GEAR, SPIRAL, DISTRIBUTOR
19195-43060

5MGE,6MGE..MS123,125

 1
19169 - STOPPER, CAM GREASE
19169-32010

5M,5ME..MS122,123

 1
19169-63011

5MGE..MS123..ROY

 1
19181 - ROTOR, DISTRIBUTOR, SIGNAL
19181-43150

5MGE..MS123..ROY

 1
19181-43151

5MGE..MS123..ROY

 1
19182 - SHAFT, DISTRIBUTOR, DRIVING
19182-43060

5MGE..MS123..ROY

 1
19220 - ADVANCER ASSY, VACUUM, DISTRIBUTOR
19220-43100

5MGE..MS123..ROY

 1
19220A - RING, SNAP(FOR DISTRIBUTOR VACUUM ADVANCER)
90099-07109

5MGE..MS123..ROY

 1
19225 - CAP, RUBBER
19225-41140

5M#,6MGE..MS12#

 1
19242 - CLAMP, CORD
19242-26250

5M,5MGE..MS122,123..GEN,SAA

 1
19250 - GENERATOR ASSY, SIGNAL
19250-43150

5MGE..MS123..ROY

 1
Common parts
90090-80507
90099-00124
90099-00710
90099-02198
90099-04566
90119-08144
93319-15010
