GX71R-XEMGKN (1988)
Toyota Cressida Wagon
(8812- )GX71,RX73
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 41101 - CARRIER SUB-ASSY, DIFFERENTIAL, REAR | ||||
| 41101-22050 |
GX71,RX73 |
1 | ||
| 41108A - PLUG (FOR REAR DIFFERENTIAL CARRIER COVER) | ||||
| 90341-18006 |
GX71,MX75,RX73 FILLER |
1 | ||
| 90341-18030 |
GX71,MX75,RX73 DRAIN |
1 | ||
| 41108A - PLUG (FOR REAR DIFFERENTIAL CARRIER COVER) | ||||
| 90341-18006 |
GX71,MX75,RX73 FILLER |
1 | ||
| 90341-18030 |
GX71,MX75,RX73 DRAIN |
1 | ||
| 41108B - GASKET (FOR REAR DIFFERENTIAL CARRIER COVER) | ||||
| 12157-10010 |
GX71,MX75,RX73 |
2 | ||
| 41108B - GASKET (FOR REAR DIFFERENTIAL CARRIER COVER) | ||||
| 12157-10010 |
GX71,MX75,RX73 |
2 | ||
| 41108C - PLUG, BREATHER (FOR REAR DIFFERENTIAL CARRIER COVER) | ||||
| 90930-03031 |
GX71,MX75,RX73 |
1 | ||
| 41110 - CARRIER ASSY, DIFFERENTIAL, REAR | ||||
| 41110-22490 |
GX71 *FGR=41:10=4.100 |
1 | ||
| 41114 - BOLT, REAR DIFFERENTIAL BEARING CAP | ||||
| 90105-12053 |
GX71,RX73 |
4 | ||
| 90105-12163 |
GX71,RX73 |
4 | ||
| 41181H - COVER, REAR DIFFERENTIAL CARRIER | ||||
| 41181-22012 |
GX71,RX73 |
1 | ||
| 41181-22011 |
GX71,RX73 |
1 | ||
| 41201 - FINAL GEAR KIT, DIFFERENTIAL, REAR | ||||
| 41201-80007 |
GX71 *FGR=41:10=4.100 |
1 | ||
| 41201A - BEARING (FOR REAR DRIVE PINION REAR) | ||||
| 90366-35023 |
RX72..5F;GX71,RX73 |
1 | ||
| 90366-35023 |
GX71,RX73 |
1 | ||
| 41201B - BEARING (FOR REAR DRIVE PINION FRONT) | ||||
| 90366-30022 |
GX71,RX7#,YX72 |
1 | ||
| 41201C - SEAL, OIL (FOR REAR DIFFERENTIAL CARRIER) | ||||
| 90311-38010 |
GX71,MX75,RX73 |
1 | ||
| 41201D - WASHER, PLATE (FOR REAR DIFFERENTIAL DRIVE PINION) | ||||
| 90201-35398 |
GX71,RX7#,YX72 T=2.42,MARK 07 |
1 | ||
| 90201-35400 |
GX71,RX7#,YX72 T=2.48,MARK 09 |
1 | ||
| 90201-35397 |
GX71,RX7#,YX72 T=2.39,MARK 06 |
1 | ||
| 90201-35399 |
GX71,RX7#,YX72 T=2.43,MARK 08 |
1 | ||
| 90201-35402 |
GX71,RX7#,YX72 T=2.54,MARK 11 |
1 | ||
| 90201-35404 |
GX71,RX7#,YX72 T=2.60,MARK 13 |
1 | ||
| 90201-35403 |
GX71,RX7#,YX72 T=2.57,MARK 12 |
1 | ||
| 90201-35396 |
GX71,RX7#,YX72 T=2.36,MARK 05 |
1 | ||
| 90201-35401 |
GX71,RX7#,YX72 T=2.51,MARK 10 |
1 | ||
| 90201-35435 |
GX71,RX7#,YX72 T=2.27,MARK 02 |
1 | ||
| 90201-35436 |
GX71,RX7#,YX72 T=2.30,MARK 03 |
1 | ||
| 90201-35441 |
GX71,RX7#,YX72 T=2.72,MARK 17 |
1 | ||
| 90201-35434 |
GX71,RX7#,YX72 T=2.24,MARK 01 |
1 | ||
| 90201-35437 |
GX71,RX7#,YX72 T=2.33,MARK 04 |
1 | ||
| 90201-35439 |
GX71,RX7#,YX72 T=2.66,MARK 15 |
1 | ||
| 90201-35438 |
GX71,RX7#,YX72 T=2.63,MARK 14 |
1 | ||
| 90201-35440 |
GX71,RX7#,YX72 T=2.69,MARK 16 |
1 | ||
| 41204 - FLANGE SUB-ASSY, REAR DRIVE PINION COMPANION, REAR | ||||
| 41204-20030 |
GX71,RX7#,YX72 |
1 | ||
| 41204A - WASHER, PLATE (FOR REAR DRIVE PINION) | ||||
| 90201-18485 |
GX71,RX7#,YX72 |
1 | ||
| 41204B - NUT (FOR REAR DRIVE PINION) | ||||
| 90179-18001 |
GX71,RX7#,YX72 |
1 | ||
| 41214 - SLINGER, REAR DIFFERENTIAL DRIVE PINION OIL | ||||
| 41214-30021 |
GX71,RX7#,YX72 |
1 | ||
| 41222 - PLATE, REAR DIFFERENTIAL RING GEAR SET BOLT LOCK | ||||
| 41222-35030 |
RX72..5F;GX71,RX73 |
5 | ||
| 41222A - BOLT (FOR REAR DIFFERENTIAL RING GEAR SET) | ||||
| 90101-11353 |
RX72..5F;GX71,MX75,RX73 |
10 | ||
| 41231 - SPACER, REAR DIFFERENTIAL DRIVE PINION BEARING | ||||
| 41231-22010 |
RX72..5F;GX71,RX73 |
1 | ||
| 41252 - DEFLECTOR, DUST (FOR REAR DIFFERENTIAL) | ||||
| 41252-30010 |
GX71,RX7#,YX72 |
1 | ||
| 41301A - BEARING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90368-50006 |
GX71,RX73 |
2 | ||
| 41301A - BEARING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90368-50006 |
GX71,RX73 |
2 | ||
| 41302 - CASE SUB-ASSY, REAR DIFFERENTIAL | ||||
| 41311-22060 |
GX71,RX73 |
1 | ||
| 41309J - SHAFT, DIFFERENTIAL SIDE GEAR | ||||
| 41309-22012 |
GX71,RX73 |
2 | ||
| 41309J - SHAFT, DIFFERENTIAL SIDE GEAR | ||||
| 41309-22012 |
GX71,RX73 |
2 | ||
| 41331 - GEAR, REAR DIFFERENTIAL SIDE | ||||
| 41331-22041 |
GX71,RX73 |
2 | ||
| 41331-14040 |
GX71,RX73 |
2 | ||
| 41331 - GEAR, REAR DIFFERENTIAL SIDE | ||||
| 41331-22041 |
GX71,RX73 |
2 | ||
| 41331-14040 |
GX71,RX73 |
2 | ||
| 41334A - BOLT, SERRATION (FOR REAR DIFFERENTIAL SIDE GEAR SHAFT) | ||||
| 90114-10028 |
GX71,RX73 |
8 | ||
| 41334A - BOLT, SERRATION (FOR REAR DIFFERENTIAL SIDE GEAR SHAFT) | ||||
| 90114-10028 |
GX71,RX73 |
8 | ||
| 41334B - SEAL, OIL (FOR REAR DIFFERENTIAL SIDE GEAR SHAFT) | ||||
| 90311-38011 |
GX71,RX73 |
2 | ||
| 41334B - SEAL, OIL (FOR REAR DIFFERENTIAL SIDE GEAR SHAFT) | ||||
| 90311-38011 |
GX71,RX73 |
2 | ||
| 41334C - WASHER, PLATE (FOR REAR DIFFERENTIAL SIDE GEAR SHAFT) | ||||
| 90201-65007 |
GX71,RX73 T=2.58 |
2 | ||
| 90201-65012 |
GX71,RX73 T=2.73 |
2 | ||
| 90201-65009 |
GX71,RX73 T=2.64 |
2 | ||
| 90201-65013 |
GX71,RX73 T=2.76 |
2 | ||
| 90201-65011 |
GX71,RX73 T=2.70 |
2 | ||
| 90201-65015 |
GX71,RX73 T=2.82 |
2 | ||
| 90201-65008 |
GX71,RX73 T=2.61 |
2 | ||
| 90201-65016 |
GX71,RX73 T=2.85 |
2 | ||
| 90201-65017 |
GX71,RX73 T=2.88 |
2 | ||
| 90201-65020 |
GX71,RX73 T=2.97 |
2 | ||
| 90201-65010 |
GX71,RX73 T=2.67 |
2 | ||
| 90201-65018 |
GX71,RX73 T=2.91 |
2 | ||
| 90201-65014 |
GX71,RX73 T=2.79 |
2 | ||
| 90201-65028 |
GX71,RX73 T=3.21 |
2 | ||
| 90201-65025 |
GX71,RX73 T=3.12 |
2 | ||
| 90201-65024 |
GX71,RX73 T=3.09 |
2 | ||
| 90201-65021 |
GX71,RX73 T=3.00 |
2 | ||
| 90201-65027 |
GX71,RX73 T=3.18 |
2 | ||
| 90201-65026 |
GX71,RX73 T=3.15 |
2 | ||
| 90201-65022 |
GX71,RX73 T=3.03 |
2 | ||
| 90201-65019 |
GX71,RX73 T=2.94 |
2 | ||
| 90201-65029 |
GX71,RX73 T=3.24 |
2 | ||
| 90201-65023 |
GX71,RX73 T=3.06 |
2 | ||
| 41334C - WASHER, PLATE (FOR REAR DIFFERENTIAL SIDE GEAR SHAFT) | ||||
| 90201-65007 |
GX71,RX73 T=2.58 |
2 | ||
| 90201-65012 |
GX71,RX73 T=2.73 |
2 | ||
| 90201-65009 |
GX71,RX73 T=2.64 |
2 | ||
| 90201-65013 |
GX71,RX73 T=2.76 |
2 | ||
| 90201-65011 |
GX71,RX73 T=2.70 |
2 | ||
| 90201-65015 |
GX71,RX73 T=2.82 |
2 | ||
| 90201-65008 |
GX71,RX73 T=2.61 |
2 | ||
| 90201-65016 |
GX71,RX73 T=2.85 |
2 | ||
| 90201-65017 |
GX71,RX73 T=2.88 |
2 | ||
| 90201-65020 |
GX71,RX73 T=2.97 |
2 | ||
| 90201-65010 |
GX71,RX73 T=2.67 |
2 | ||
| 90201-65018 |
GX71,RX73 T=2.91 |
2 | ||
| 90201-65014 |
GX71,RX73 T=2.79 |
2 | ||
| 90201-65028 |
GX71,RX73 T=3.21 |
2 | ||
| 90201-65025 |
GX71,RX73 T=3.12 |
2 | ||
| 90201-65024 |
GX71,RX73 T=3.09 |
2 | ||
| 90201-65021 |
GX71,RX73 T=3.00 |
2 | ||
| 90201-65027 |
GX71,RX73 T=3.18 |
2 | ||
| 90201-65026 |
GX71,RX73 T=3.15 |
2 | ||
| 90201-65022 |
GX71,RX73 T=3.03 |
2 | ||
| 90201-65019 |
GX71,RX73 T=2.94 |
2 | ||
| 90201-65029 |
GX71,RX73 T=3.24 |
2 | ||
| 90201-65023 |
GX71,RX73 T=3.06 |
2 | ||
| 41334D - RING, SHAFT SNAP (FOR REAR DIFFERENTIAL SIDE GEAR SHAFT | ||||
| 90521-29002 |
GX71,RX73 T=2.5 |
2 | ||
| 41334D - RING, SHAFT SNAP (FOR REAR DIFFERENTIAL SIDE GEAR SHAFT | ||||
| 90521-29002 |
GX71,RX73 T=2.5 |
2 | ||
| 41336 - COVER, DUST(FOR REAR DIFFERENTIAL SIDE GEAR SHAFT) | ||||
| 41336-22010 |
GX71,RX73 |
2 | ||
| 41336 - COVER, DUST(FOR REAR DIFFERENTIAL SIDE GEAR SHAFT) | ||||
| 41336-22010 |
GX71,RX73 |
2 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-30020 |
RX72..5F;GX71,RX73 |
2 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-30020 |
RX72..5F;GX71,RX73 |
2 | ||
| 41342 - SHAFT, REAR DIFFERENTIAL PINION | ||||
| 41342-22020 |
RX72..5F;GX71,RX73 |
1 | ||
| 41343 - PIN, REAR DIFFERENTIAL PINION SHAFT | ||||
| 90250-06058 |
GX71,RX7#,YX72 |
1 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-30060 |
RX72..5F;GX71,RX73 |
2 | ||
| 41351 - WASHER, REAR DIFFERENTIAL PINION THRUST | ||||
| 41351-30060 |
RX72..5F;GX71,RX73 |
2 | ||
| 41361 - WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-30100 |
GX71,RX73 T=1.6 |
2 | ||
| 41361-30080 |
GX71,RX73 T=1.4 |
2 | ||
| 41361-30090 |
GX71,RX73 T=1.5 |
2 | ||
| 41361-30060 |
RX72..5F;GX71,RX73 T=1.2 |
2 | ||
| 41361-30040 |
RX72..5F;GX71,RX73 T=1.0 |
2 | ||
| 41361-30050 |
RX72..5F;GX71,RX73 T=1.1 |
2 | ||
| 41361-30070 |
RX72..5F;GX71,RX73 T=1.3 |
2 | ||
| 41361 - WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-30100 |
GX71,RX73 T=1.6 |
2 | ||
| 41361-30080 |
GX71,RX73 T=1.4 |
2 | ||
| 41361-30090 |
GX71,RX73 T=1.5 |
2 | ||
| 41361-30060 |
RX72..5F;GX71,RX73 T=1.2 |
2 | ||
| 41361-30040 |
RX72..5F;GX71,RX73 T=1.0 |
2 | ||
| 41361-30050 |
RX72..5F;GX71,RX73 T=1.1 |
2 | ||
| 41361-30070 |
RX72..5F;GX71,RX73 T=1.3 |
2 | ||
| Common parts | ||||
| 90119-08254 | ||||
