RX81L-AEMES (1988)
Toyota Cressida
(8808- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 69205 - HANDLE SUB-ASSY, FRONT DOOR INSIDE, RH | ||||
| 69205-2204002 |
GX81,LX80,MX8#,RX8# NEW MAROON,TRIM3# |
1 | ||
| 69205-2204006 |
GX81,LX80,MX8#,RX8# SABLE,TRIM4# |
1 | ||
| 69205-2204004 |
GX81,LX80,MX8#,RX8# DARK BLUE,TRIM8# |
1 | ||
| 69205B - CUSHION(FOR FRONT DOOR INSIDE HANDLE) | ||||
| 90541-04018 |
GX81,LX80,MX8#,RX8# |
2 | ||
| 90541-04018 |
GX81,LX80,MX8#,RX8# |
2 | ||
| 69206B - HANDLE SUB-ASSY, FRONT DOOR INSIDE, LH | ||||
| 69206-2204002 |
GX81,LX80,MX8#,RX8# NEW MAROON,TRIM3# |
1 | ||
| 69206-2204004 |
GX81,LX80,MX8#,RX8# DARK BLUE,TRIM8# |
1 | ||
| 69206-2204006 |
GX81,LX80,MX8#,RX8# SABLE,TRIM4# |
1 | ||
| 69210 - HANDLE ASSY, FRONT DOOR, OUTSIDE RH | ||||
| 69210-22120 |
MX83,RX80..GL,XL;GX81,LX80,MX81,RX81..LHD |
1 | ||
| 69210 - HANDLE ASSY, FRONT DOOR, OUTSIDE RH | ||||
| 69210-22120 |
MX83,RX80..GL,XL;GX81,LX80,MX81,RX81..LHD |
1 | ||
| 69210B - CUSHION(FOR FRONT DOOR OUTSIDE HANDLE) | ||||
| 90541-04018 |
GX81,LX80,MX8#,RX8# |
4 | ||
| 69210B - CUSHION(FOR FRONT DOOR OUTSIDE HANDLE) | ||||
| 90541-04018 |
GX81,LX80,MX8#,RX8# |
4 | ||
| 69220 - HANDLE ASSY, FRONT DOOR OUTSIDE, LH | ||||
| 69220-22110 |
GX81,MX83..RHD;LX80,MX81,RX8#..GL,XL |
1 | ||
| 69220 - HANDLE ASSY, FRONT DOOR OUTSIDE, LH | ||||
| 69220-22110 |
GX81,MX83..RHD;LX80,MX81,RX8#..GL,XL |
1 | ||
| 69277B - BEZEL, FRONT DOOR INSIDE HANDLE, RH | ||||
| 69277-2206002 |
GX81,LX80,MX8#,RX8# NEW MAROON,TRIM3# |
1 | ||
| 69277-2206004 |
GX81,LX80,MX8#,RX8# DARK BLUE,TRIM8# |
1 | ||
| 69277-2206006 |
GX81,LX80,MX8#,RX8# SABLE,TRIM4# |
1 | ||
| 69278B - BEZEL, FRONT DOOR INSIDE HANDLE, LH | ||||
| 69278-2202002 |
GX81,LX80,MX8#,RX8# NEW MAROON,TRIM3# |
1 | ||
| 69278-2202006 |
GX81,LX80,MX8#,RX8# SABLE,TRIM4# |
1 | ||
| 69278-2202004 |
GX81,LX80,MX8#,RX8# DARK BLUE,TRIM8# |
1 | ||
| 69293A - SNAP, FRONT DOOR OUTSIDE HANDLE | ||||
| 69293-12050 |
GX81,LX80,MX8#,RX8# RH |
1 | ||
| 69293-12060 |
GX81,LX80,MX8#,RX8# LH |
1 | ||
| 69293A - SNAP, FRONT DOOR OUTSIDE HANDLE | ||||
| 69293-12050 |
GX81,LX80,MX8#,RX8# RH |
1 | ||
| 69293-12060 |
GX81,LX80,MX8#,RX8# LH |
1 | ||
| 69310 - LOCK ASSY, FRONT DOOR, RH | ||||
| 69030-22310 |
GX81,MX81,RX8#..LHD..(GL,GLX)..GEN |
1 | ||
| 69310 - LOCK ASSY, FRONT DOOR, RH | ||||
| 69030-22310 |
GX81,MX81,RX8#..LHD..(GL,GLX)..GEN |
1 | ||
| 69315D - LINK, FRONT DOOR OUTSIDE LOCKING, RH | ||||
| 69315-22020 |
GX81,LX80,MX8#,RX8# |
1 | ||
| 69316A - LINK, FRONT DOOR OUTSIDE LOCKING, LH | ||||
| 69316-22030 |
GX81,LX80,MX8#,RX8# |
1 | ||
| 69320 - LOCK ASSY, FRONT DOOR, LH | ||||
| 69040-22370 |
GX81,MX81,RX8#..LHD..(GL,GLX)..GEN |
1 | ||
| 69320 - LOCK ASSY, FRONT DOOR, LH | ||||
| 69040-22370 |
GX81,MX81,RX8#..LHD..(GL,GLX)..GEN |
1 | ||
| 69410 - PLATE ASSY, FRONT DOOR LOCK STRIKER | ||||
| 69410-20070 |
GX81,LX80,MX8#,RX8# |
2 | ||
| 69711B - LINK, FRONT DOOR LOCK REMOTE CONTROL, RH | ||||
| 69711-22070 |
GX81,LX80,MX8#,RX8# |
1 | ||
| 69712A - LINK, FRONT DOOR LOCK REMOTE CONTROL, LH | ||||
| 69712-22070 |
GX81,LX80,MX8#,RX8# |
1 | ||
| 69719 - CUSHION, DOOR LOCK CONTROL | ||||
| 69719-22010 |
GX81,LX80,MX8#,RX8# |
1 | ||
| 69725 - PROTECTOR, FRONT DOOR INSIDE LOCKING LINK, RH | ||||
| 69725-22010 |
GX81,LX80,MX8#,RX8#..ARL,GEN |
1 | ||
| 69726A - PROTECTER, FRONT DOOR INSIDE LOCKING LINK, LH | ||||
| 69726-22010 |
GX81,LX80,MX8#,RX8#..ARL,GEN |
1 | ||
| 69749A - CLAMP, FRONT DOOR LOCK LINK, NO.1 | ||||
| 69749-20030 |
GX81,LX80,MX8#,RX8# |
2 | ||
| 69750B - LINK ASSY, FRONT DOOR INSIDE LOCKING, RH | ||||
| 69750-22020 |
GX81,LX80,MX8#,RX8# |
1 | ||
| 69759 - SNAP, DOOR LOCK CONTROL LINK, NO.1 | ||||
| 69759-24020 |
GX81,LX80,MX8#,RX8# BLUE |
1 | ||
| 69759-24060 |
GX81,LX80,MX8#,RX8# GRAY |
2 | ||
| 69759-24050 |
GX81,LX80,MX8#,RX8# GREEN |
2 | ||
| 69759-24010 |
GX81,LX80,MX8#,RX8# NATURAL |
1 | ||
| 69759 - SNAP, DOOR LOCK CONTROL LINK, NO.1 | ||||
| 69759-24020 |
GX81,LX80,MX8#,RX8# BLUE |
1 | ||
| 69759-24060 |
GX81,LX80,MX8#,RX8# GRAY |
2 | ||
| 69759-24050 |
GX81,LX80,MX8#,RX8# GREEN |
2 | ||
| 69759-24010 |
GX81,LX80,MX8#,RX8# NATURAL |
1 | ||
| 69759 - SNAP, DOOR LOCK CONTROL LINK, NO.1 | ||||
| 69759-24020 |
GX81,LX80,MX8#,RX8# BLUE |
1 | ||
| 69759-24060 |
GX81,LX80,MX8#,RX8# GRAY |
2 | ||
| 69759-24050 |
GX81,LX80,MX8#,RX8# GREEN |
2 | ||
| 69759-24010 |
GX81,LX80,MX8#,RX8# NATURAL |
1 | ||
| 69759 - SNAP, DOOR LOCK CONTROL LINK, NO.1 | ||||
| 69759-24020 |
GX81,LX80,MX8#,RX8# BLUE |
1 | ||
| 69759-24060 |
GX81,LX80,MX8#,RX8# GRAY |
2 | ||
| 69759-24050 |
GX81,LX80,MX8#,RX8# GREEN |
2 | ||
| 69759-24010 |
GX81,LX80,MX8#,RX8# NATURAL |
1 | ||
| 69759A - SILENCER, SEPARATION DOOR LOCK LINK | ||||
| 69759-20120 |
GX81,LX80,MX8#,RX8# |
2 | ||
| 69759S - SNAP, FRONT DOOR INSIDE HANDLE | ||||
| 69759-24070 |
GX81,LX80,MX8#,RX8# RH |
2 | ||
| 69759-14050 |
GX81,LX80,MX8#,RX8# LH |
2 | ||
| 69759S - SNAP, FRONT DOOR INSIDE HANDLE | ||||
| 69759-24070 |
GX81,LX80,MX8#,RX8# RH |
2 | ||
| 69759-14050 |
GX81,LX80,MX8#,RX8# LH |
2 | ||
| 69760A - LINK ASSY, FRONT DOOR INSIDE LOCKING, LH | ||||
| 69760-22020 |
GX81,LX80,MX8#,RX8# |
1 | ||
| Common parts | ||||
| 90105-06082 | ||||
| 90148-60003 | ||||
| 90148-60025 | ||||
| 90159-60081 | ||||
| 90159-80031 | ||||
| 90164-25001 | ||||
| 90168-40006 | ||||
| 90168-40048 | ||||
| 90168-60015 | ||||
| 90189-06125 | ||||
| 93520-54010 | ||||
| Linked diagrams | ||||
| 8401 | ||||
