RX60RG-XWMDSW (1980)
Toyota Cressida
(8009- )WG
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 48231 - SPRING, COIL, REAR | ||||
| 48231-23020 |
RX60..WG..EUG |
2 | ||
| 48257 - INSULATOR, REAR COIL SPRING | ||||
| 48257-23010 |
LX60,MX62,RX6#..WG |
2 | ||
| 48257A - INSULATOR, REAR COIL SPRING, LOWER | ||||
| 48258-30010 |
LX60,MX62,RX6#..WG |
2 | ||
| 48306 - BUMPER SUB-ASSY, REAR SPRING | ||||
| 48306-14030 |
LX60,MX62,RX6#..WG |
2 | ||
| 48351 - BUMPER, DIFFERENTIAL CARRIER | ||||
| 48351-29015 |
MX62..SED;GX60,LX60,RX6#,TX62 |
1 | ||
| 48530 - ABSORBER ASSY, SHOCK, REAR RH | ||||
| 48531-29775 |
LX60,RX60..WG..EUG |
1 | ||
| 48530A - BUSH(FOR REAR SHOCK ABSORBER) | ||||
| 90540-10004 |
GX6#,LX60,MX6#,RX6#,TX62 ABSORBER X BODY(LWR) |
2 | ||
| 90540-10005 |
LX60,MX62,RX6#..WG ABSORBER X BODY(UPR) |
2 | ||
| 90385-16060 |
LX60,MX62,RX6#,TX62 ABSORBER X AXLE HOUSING |
2 | ||
| 48530A - BUSH(FOR REAR SHOCK ABSORBER) | ||||
| 90540-10004 |
GX6#,LX60,MX6#,RX6#,TX62 ABSORBER X BODY(LWR) |
2 | ||
| 90540-10005 |
LX60,MX62,RX6#..WG ABSORBER X BODY(UPR) |
2 | ||
| 90385-16060 |
LX60,MX62,RX6#,TX62 ABSORBER X AXLE HOUSING |
2 | ||
| 48530A - BUSH(FOR REAR SHOCK ABSORBER) | ||||
| 90540-10004 |
GX6#,LX60,MX6#,RX6#,TX62 ABSORBER X BODY(LWR) |
2 | ||
| 90540-10005 |
LX60,MX62,RX6#..WG ABSORBER X BODY(UPR) |
2 | ||
| 90385-16060 |
LX60,MX62,RX6#,TX62 ABSORBER X AXLE HOUSING |
2 | ||
| 48530B - WASHER, REAR SHOCK ABSORBER CUSHION, NO.1 | ||||
| 90948-02002 |
LX60,MX62,RX6#..WG T=2.3,LWR |
2 | ||
| 90948-02045 |
LX60,MX62,RX6#..WG T=3.2,UPR |
2 | ||
| 48530B - WASHER, REAR SHOCK ABSORBER CUSHION, NO.1 | ||||
| 90948-02002 |
LX60,MX62,RX6#..WG T=2.3,LWR |
2 | ||
| 90948-02045 |
LX60,MX62,RX6#..WG T=3.2,UPR |
2 | ||
| 48530D - WASHER, REAR SHOCK ABSORBER CUSHION, NO.3 | ||||
| 90948-03007 |
GX6#,LX60,MX6#,RX6#,TX62 |
2 | ||
| 48530E - WASHER, REAR SHOCK ABSORBER CUSHION, NO.4 | ||||
| 90948-03004 |
GX6#,LX60,MX6#,RX6#,TX62 |
2 | ||
| 48540 - ABSORBER ASSY, SHOCK, REAR LH | ||||
| 48531-29775 |
LX60,RX60..WG..EUG |
1 | ||
| 48710 - ARM ASSY, UPPER CONTROL | ||||
| 48710-23010 |
RX60..WG..EUR |
2 | ||
| 48710 - ARM ASSY, UPPER CONTROL | ||||
| 48710-23010 |
RX60..WG..EUR |
2 | ||
| 48715A - BOLT, HEXAGON(FOR UPPER CONTROL ARM) | ||||
| 90105-14006 |
GX60,LX60,MX62,RX6#,TX62 AXLE HOUSING X CONTROL ARM |
2 | ||
| 90105-14009 |
LX60,MX62,RX6#..WG BODY X CONTROL ARM |
2 | ||
| 48715A - BOLT, HEXAGON(FOR UPPER CONTROL ARM) | ||||
| 90105-14006 |
GX60,LX60,MX62,RX6#,TX62 AXLE HOUSING X CONTROL ARM |
2 | ||
| 90105-14009 |
LX60,MX62,RX6#..WG BODY X CONTROL ARM |
2 | ||
| 48720 - ARM ASSY, LOWER CONTROL, RH | ||||
| 48720-23040 |
RX60..WG..EUG |
1 | ||
| 48725A - BOLT(FOR LOWER CONTROL ARM) | ||||
| 90105-14006 |
LX60,MX62,RX6#..WG |
4 | ||
| 48730 - ARM ASSY, LOWER CONTROL, LH | ||||
| 48720-23040 |
RX60..WG..EUG |
1 | ||
| 48740 - ROD ASSY, REAR LATERAL CONTROL | ||||
| 48740-23010 |
LX60,MX62,RX6#..WG |
1 | ||
| 48745 - BUSH, LATERAL CONTROL ROD | ||||
| 90386-20001 |
GX60,LX60,MX62,RX6#,TX62 L=12,HOUSING SIDE |
1 | ||
| 48706-14010 |
LX60,MX62,RX6#..WG BODY SIDE |
1 | ||
| 90385-20001 |
GX60,LX60,MX62,RX6#,TX62 L=15,HOUSING SIDE |
2 | ||
| 48745 - BUSH, LATERAL CONTROL ROD | ||||
| 90386-20001 |
GX60,LX60,MX62,RX6#,TX62 L=12,HOUSING SIDE |
1 | ||
| 48706-14010 |
LX60,MX62,RX6#..WG BODY SIDE |
1 | ||
| 90385-20001 |
GX60,LX60,MX62,RX6#,TX62 L=15,HOUSING SIDE |
2 | ||
| 48745 - BUSH, LATERAL CONTROL ROD | ||||
| 90386-20001 |
GX60,LX60,MX62,RX6#,TX62 L=12,HOUSING SIDE |
1 | ||
| 48706-14010 |
LX60,MX62,RX6#..WG BODY SIDE |
1 | ||
| 90385-20001 |
GX60,LX60,MX62,RX6#,TX62 L=15,HOUSING SIDE |
2 | ||
| 48745 - BUSH, LATERAL CONTROL ROD | ||||
| 90386-20001 |
GX60,LX60,MX62,RX6#,TX62 L=12,HOUSING SIDE |
1 | ||
| 48706-14010 |
LX60,MX62,RX6#..WG BODY SIDE |
1 | ||
| 90385-20001 |
GX60,LX60,MX62,RX6#,TX62 L=15,HOUSING SIDE |
2 | ||
| 48745A - BOLT, HEXAGON(FOR LATERAL CONTROL ROD) | ||||
| 90101-12032 |
LX60,MX62,RX6#..WG |
1 | ||
| 48802 - LINK SUB-ASSY, STABILIZER | ||||
| 48802-14020 |
MX62,RX60..ARL,EUR |
2 | ||
| 48802D - BUSH, STABILIZER LINK | ||||
| 90385-11021 |
MX62,RX60..ARL,EUR |
2 | ||
| 48802E - SPACER(FOR REAR STABILIZER BAR) | ||||
| 90560-10275 |
MX62,RX60..ARL,EUR |
2 | ||
| 48805 - BAR SUB-ASSY, REAR STABILIZER | ||||
| 48805-23010 |
RX60..WG..EUR OD=14 |
1 | ||
| 48815R - BUSH, STABILIZER(FOR REAR) | ||||
| 48815-14060 |
MX62,RX60..WG..(ARL,EUR) ID=14 |
2 | ||
| 48817R - CUSHION, STABILIZER(FOR REAR) | ||||
| 48817-30010 |
MX62,RX60..ARL,EUR |
4 | ||
| 48817-30020 |
MX62,RX60..ARL,EUR |
4 | ||
| 48817R - CUSHION, STABILIZER(FOR REAR) | ||||
| 48817-30010 |
MX62,RX60..ARL,EUR |
4 | ||
| 48817-30020 |
MX62,RX60..ARL,EUR |
4 | ||
| 48817S - RETAINER, CUSHION, NO.1(FOR STABILIZER REAR BAR) | ||||
| 90948-02032 |
MX62,RX60..ARL,EUR T=1.6 |
4 | ||
| 90948-02015 |
MX62,RX60..ARL,EUR T=1.2 |
4 | ||
| 48817S - RETAINER, CUSHION, NO.1(FOR STABILIZER REAR BAR) | ||||
| 90948-02032 |
MX62,RX60..ARL,EUR T=1.6 |
4 | ||
| 90948-02015 |
MX62,RX60..ARL,EUR T=1.2 |
4 | ||
| 48817S - RETAINER, CUSHION, NO.1(FOR STABILIZER REAR BAR) | ||||
| 90948-02032 |
MX62,RX60..ARL,EUR T=1.6 |
4 | ||
| 90948-02015 |
MX62,RX60..ARL,EUR T=1.2 |
4 | ||
| 48817S - RETAINER, CUSHION, NO.1(FOR STABILIZER REAR BAR) | ||||
| 90948-02032 |
MX62,RX60..ARL,EUR T=1.6 |
4 | ||
| 90948-02015 |
MX62,RX60..ARL,EUR T=1.2 |
4 | ||
| 48817U - BOLT(FOR REAR STABILIZER) | ||||
| 90102-10015 |
MX62,RX60..ARL,EUR |
2 | ||
| 48817U - BOLT(FOR REAR STABILIZER) | ||||
| 90102-10015 |
MX62,RX60..ARL,EUR |
2 | ||
| 48832R - BRACKET, REAR STABILIZER BAR, NO.1 RH | ||||
| 48832-22020 |
MX62,RX60..ARL,EUR |
1 | ||
| 48833R - BRACKET, REAR STABILIZER BAR, NO.1 LH | ||||
| 48832-22020 |
MX62,RX60..ARL,EUR |
1 | ||
| 48836R - BRACKET, REAR STABILIZER END, RH | ||||
| 48825-22010 |
MX62,RX60..ARL,EUR |
1 | ||
| 48837R - BRACKET, REAR STABILIZER END, LH | ||||
| 48825-22010 |
MX62,RX60..ARL,EUR |
1 | ||
| Common parts | ||||
| 90179-10022 | ||||
| 90201-12010 | ||||
| 90201-14006 | ||||
| 91165-71230 | ||||
| 91611-40812 | ||||
| 91611-40820 | ||||
| 91611-61016 | ||||
| 91611-61020 | ||||
| 94115-51200 | ||||
| 94115-71400 | ||||
| 94141-41000 | ||||
| 94182-10800 | ||||
| 94184-61000 | ||||
| 94184-61200 | ||||
| 94512-01200 | ||||
| 94512-01400 | ||||
| 94531-01200 | ||||
| 94612-12000 | ||||
| 95381-02525 | ||||
