RX60L-XEMDCC (1980)
Toyota Cressida
(8009- )RX60,TX62..SED
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 77135 - BRACKET, CHECK VALVE | ||||
| 77135-22030 |
LX60,MX63,RX60,TX62..SED |
1 | ||
| 77135 - BRACKET, CHECK VALVE | ||||
| 77135-22030 |
LX60,MX63,RX60,TX62..SED |
1 | ||
| 77241 - TUBE, FUEL MAIN, NO.1 | ||||
| 77251-22201 |
RX60,TX62..SED |
1 | ||
| 77241A - HOSE, FUEL, NO.1 (FOR MAIN TUBE, NO.1) | ||||
| 95332-06020 |
RX6#,TX62 *H,L=140 |
1 | ||
| 77241B - HOSE, FUEL, NO.2 (FOR MAIN TUBE, NO.1) | ||||
| 95332-06030 |
RX60,TX62..SED *H,L=240 |
1 | ||
| 77252 - PROTECTOR, FUEL TUBE | ||||
| 77266-22030 |
RX6#,TX62 |
1 | ||
| 77253 - PROTECTOR, FUEL TUBE, NO.2 | ||||
| 77267-22020 |
RX6#,TX62 |
1 | ||
| 77254 - TUBE, FUEL EMISSION, NO.1 | ||||
| 77227-22040 |
LX60,RX60,TX62..SED |
1 | ||
| 77254 - TUBE, FUEL EMISSION, NO.1 | ||||
| 77227-22040 |
LX60,RX60,TX62..SED |
1 | ||
| 77254 - TUBE, FUEL EMISSION, NO.1 | ||||
| 77227-22040 |
LX60,RX60,TX62..SED |
1 | ||
| 77254A - HOSE, FUEL, NO.1 (FOR EMISSION TUBE, NO.1) | ||||
| 95332-06010 |
LX60,RX60,TX62..SED *H,L=70 |
1 | ||
| 77254A - HOSE, FUEL, NO.1 (FOR EMISSION TUBE, NO.1) | ||||
| 95332-06010 |
LX60,RX60,TX62..SED *H,L=70 |
1 | ||
| 77254A - HOSE, FUEL, NO.1 (FOR EMISSION TUBE, NO.1) | ||||
| 95332-06010 |
LX60,RX60,TX62..SED *H,L=70 |
1 | ||
| 77254B - HOSE, FUEL, NO.2 (FOR EMISSION TUBE, NO.1) | ||||
| 95332-06020 |
LX60,MX62,RX60,TX62..SED *H,L=170 |
1 | ||
| 77277 - TUBE, FUEL RETURN, NO.1 | ||||
| 77255-22101 |
RX60..SED |
1 | ||
| 77277A - HOSE, FUEL, NO.1(FOR RETURN TUBE, NO.1) | ||||
| 95332-06060 |
RX60 *H,L=550 |
1 | ||
| 77277B - HOSE, FUEL, NO.2(FOR RETURN TUBE, NO.1) | ||||
| 95332-06030 |
LX60,RX60..SED *H,L=240 |
1 | ||
| 77701T - VALVE, CHECK (FOR MAIN FUEL TANK) | ||||
| 90917-10020 |
GX6#,LX60,RX6#,TX62 |
1 | ||
| 77701T - VALVE, CHECK (FOR MAIN FUEL TANK) | ||||
| 90917-10020 |
GX6#,LX60,RX6#,TX62 |
1 | ||
| 77701U - HOSE, FUEL (FOR CHECK VALVE) | ||||
| 95332-06010 |
GX6#,LX60,MX63,RX60,TX62 *H,L=90 |
1 | ||
| 77701U - HOSE, FUEL (FOR CHECK VALVE) | ||||
| 95332-06010 |
GX6#,LX60,MX63,RX60,TX62 *H,L=90 |
1 | ||
| Common parts | ||||
| 90119-06139 | ||||
| 90461-08091 | ||||
| 90461-08233 | ||||
| 90461-10076 | ||||
| 90461-14008 | ||||
| 90461-14010 | ||||
| 90461-14011 | ||||
| 90461-14012 | ||||
| 90464-00175 | ||||
| 90480-01024 | ||||
| 90480-01031 | ||||
| 90480-01039 | ||||
| 90480-17011 | ||||
| 91511-40412 | ||||
| 91651-40614 | ||||
| 91656-40620 | ||||
| 91666-40616 | ||||
| 91666-60820 | ||||
| 96132-30600 | ||||
(8009- )SED
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 77023 - FILTER SUB-ASSY, FUEL SUCTION TUBE | ||||
| 77023-12050 |
RX6#,TX62 |
1 | ||
| 77031 - CAP ASSY, FUEL TANK | ||||
| 77310-12100 |
LX60,MX62,RX6#,TX62 |
1 | ||
| 77310-12090 |
LX60,MX62,RX6#,TX62 |
1 | ||
| 77031B - GASKET (FOR FUEL TANK CAP) | ||||
| 77316-12050 |
GX6#,LX60,MX62,RX6#,TX62 |
1 | ||
| 77033 - LOCK SUB-ASSY, FUEL TANK CAP | ||||
| 77037-12010 |
TX62;GX6#,LX60,MX6#,RX6#..DLX,GL,SXL,XL |
1 | ||
| 77035 - CABLE SUB-ASSY, FUEL LID LOCK CONTROL | ||||
| 77035-22080 |
GX6#,LX60,RX60..SED..LHD..(DLX,GL) |
1 | ||
| 77100 - TANK ASSY, FUEL | ||||
| 77001-29015 |
GX6#,LX60,MX62..SED;RX60..SED..(EUR,GEN,ME,SAA) |
1 | ||
| 77100A - PLUG(FOR FUEL TANK) | ||||
| 90341-24036 |
RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) |
1 | ||
| 77100B - GASKET(FOR FUEL TANK) | ||||
| 90430-24047 |
RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) |
1 | ||
| 77100D - HOSE, FUEL, NO.1(FOR FUEL TANK) | ||||
| 90445-22003 |
RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) |
1 | ||
| 77201 - PIPE SUB-ASSY, FUEL TANK INLET | ||||
| 77201-22100 |
LX60,MX62,RX60,TX62..SED |
1 | ||
| 77206 - TUBE SUB-ASSY, FUEL TANK SUCTION | ||||
| 77017-22080 |
RX60..SED..(EUR,GEN,ME,SAA) |
1 | ||
| 77206G - GASKET (FOR FUEL TANK SUCTION TUBE) | ||||
| 77169-14020 |
MX63,RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) |
1 | ||
| 77213 - HOSE, FUEL TANK SUB INLET | ||||
| 77213-22050 |
MX63,RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) |
1 | ||
| 77231 - PROTECTOR, INLET TUBE | ||||
| 77277-22020 |
GX6#,LX60,MX62..SED;RX60..SED..(EUR,GEN,ME,SAA) |
1 | ||
| 77295 - SHIELD, FUEL FILLER PIPE | ||||
| 77292-22050 |
MX63,RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) UPR |
1 | ||
| 77291-22010 |
LX60,MX62,RX60,TX62..SED LWR |
1 | ||
| 77295 - SHIELD, FUEL FILLER PIPE | ||||
| 77292-22050 |
MX63,RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) UPR |
1 | ||
| 77291-22010 |
LX60,MX62,RX60,TX62..SED LWR |
1 | ||
| 77306 - LEVER SUB-ASSY, FUEL LID LOCK OPEN | ||||
| 77051-2201006 |
TX62;LX60,MX62,RX6#..DLX,GL,SXL,XL DARK BROWN,BROWN,TRIM0#,4# |
1 | ||
| 77051-2201001 |
TX62;LX60,RX6#..DLX,GL,SXL,XL BLACK,BLACK,TRIM2# |
1 | ||
| 77051-2201001 |
TX62;LX60,MX62,RX6#..DLX,GL,SXL,XL BLACK,BLACK,TRIM2# |
1 | ||
| 77051-2201004 |
TX62;LX60,MX62,RX6#..DLX,GL,SXL,XL BLUE,BLUE,TRIM8# |
1 | ||
| 77051-2201004 |
TX62;LX60,RX6#..DLX,GL,SXL,XL BLUE,BLUE,TRIM8# |
1 | ||
| 77308 - COVER SUB-ASSY, FUEL INLET BOX | ||||
| 77350-22030 |
MX63,RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) |
1 | ||
| 77308A - CUSHION(FOR FUEL INLET BOX COVER) | ||||
| 90541-08003 |
GX6#,LX60,MX6#,RX6#,TX62 |
2 | ||
| 77366 - SPRING, FUEL FILLER OPENING LID HINGE | ||||
| 77366-12010 |
GX6#,LX60,MX6#,RX6#,TX62 |
1 | ||
| 77387 - RING, FUEL INLET BOX | ||||
| 77391-16010 |
MX63,RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) |
1 | ||
| 77606 - PROTECTOR SUB-ASSY, FUEL TANK, NO.1 | ||||
| 77641-22030 |
LX60,MX62,RX60..SED..(ARL,EUR,GEN) |
1 | ||
| 77611 - BAND, FUEL TANK | ||||
| 77601-22050 |
RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) FR RH |
1 | ||
| 77602-22030 |
RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) FR LH |
1 | ||
| 77603-22030 |
RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) RR |
2 | ||
| 77611 - BAND, FUEL TANK | ||||
| 77601-22050 |
RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) FR RH |
1 | ||
| 77602-22030 |
RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) FR LH |
1 | ||
| 77603-22030 |
RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) RR |
2 | ||
| 77611 - BAND, FUEL TANK | ||||
| 77601-22050 |
RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) FR RH |
1 | ||
| 77602-22030 |
RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) FR LH |
1 | ||
| 77603-22030 |
RX60,TX62..SED;GX6#,LX60,MX62..SED..(ARL,EUR,GEN,ME) RR |
2 | ||
| Common parts | ||||
| 90119-10086 | ||||
| 90153-50021 | ||||
| 90179-06085 | ||||
| 90179-10033 | ||||
| 90179-10037 | ||||
| 90183-05103 | ||||
| 90201-10038 | ||||
| 90460-24002 | ||||
| 90467-11021 | ||||
| 91661-40616 | ||||
| 91661-60818 | ||||
| 93319-14010 | ||||
| 93385-16010 | ||||
| 93540-55016 | ||||
| 96111-10630 | ||||
| Linked diagrams | ||||
| 8401 | ||||
