RX60L-XEMDCC (1980)
Toyota Cressida
(8009-8308)L
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 13511 - CAMSHAFT | ||||
| 13511-35010 |
21R#..RX60 |
1 | ||
| 13511 - CAMSHAFT | ||||
| 13511-35010 |
21R#..RX60 |
1 | ||
| 13511A - PIN, STRAIGHT(FOR CAMSHAFT KNOCK) | ||||
| 90250-06001 |
21R#..RX60 L=14,OD=6,L=14,OD=6 |
2 | ||
| 13711 - VALVE, INTAKE | ||||
| 13711-37010 |
21R#..RX60 |
4 | ||
| 13711A - SEAL OR RING, O(FOR VALVE STEM OIL) | ||||
| 90913-02023 |
21R#..RX60 |
8 | ||
| 13711A - SEAL OR RING, O(FOR VALVE STEM OIL) | ||||
| 90913-02023 |
21R#..RX60 |
8 | ||
| 13711D - WASHER, PLATE(FOR VALVE SPRING SEAT) | ||||
| 90201-20579 |
21R#..RX60 |
8 | ||
| 13711D - WASHER, PLATE(FOR VALVE SPRING SEAT) | ||||
| 90201-20579 |
21R#..RX60 |
8 | ||
| 13715 - VALVE, EXHAUST | ||||
| 13715-38011 |
21R#..RX60 |
4 | ||
| 13741 - RETAINER, VALVE SPRING | ||||
| 13741-38010 |
21R#..RX60 |
8 | ||
| 13741 - RETAINER, VALVE SPRING | ||||
| 13741-38010 |
21R#..RX60 |
8 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03005 |
21R#,18R..RX6# |
24 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03005 |
21R#,18R..RX6# |
24 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-38010 |
21R#..RX60 |
8 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-38010 |
21R#..RX60 |
8 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-38010 |
21R#..RX60 |
8 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-38010 |
21R#..RX60 |
8 | ||
| 13801B - NUT, HEXAGON(FOR VALVE ADJUSTING) | ||||
| 90170-08210 |
21R#..RX60 |
12 | ||
| 13801B - NUT, HEXAGON(FOR VALVE ADJUSTING) | ||||
| 90170-08210 |
21R#..RX60 |
12 | ||
| 13801C - SCREW, VALVE ADJUSTING | ||||
| 90913-05016 |
21R#..RX60 |
12 | ||
| 13801C - SCREW, VALVE ADJUSTING | ||||
| 90913-05016 |
21R#..RX60 |
12 | ||
| 13801D - SPRING, COMPRESSION(FOR ROCKER ARM) | ||||
| 90501-12008 |
21R#..RX60 |
8 | ||
| 13801D - SPRING, COMPRESSION(FOR ROCKER ARM) | ||||
| 90501-12008 |
21R#..RX60 |
8 | ||
| 13801D - SPRING, COMPRESSION(FOR ROCKER ARM) | ||||
| 90501-12008 |
21R#..RX60 |
8 | ||
| 13801D - SPRING, COMPRESSION(FOR ROCKER ARM) | ||||
| 90501-12008 |
21R#..RX60 |
8 | ||
| 13901 - SHAFT SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13911-38011 |
21R#..RX60 |
1 | ||
| 13951 - SUPPORT, VALVE ROCKER, NO.1 | ||||
| 13951-38012 |
21R#..RX60 |
1 | ||
| 13951 - SUPPORT, VALVE ROCKER, NO.1 | ||||
| 13951-38012 |
21R#..RX60 |
1 | ||
| 13951B - SCREW OR BOLT(FOR VALVE ROCKER SHAFT LOCK) | ||||
| 93210-16008 |
21R#..RX60 |
3 | ||
| Common parts | ||||
| 90099-05166 | ||||
| 90119-14005 | ||||
| 91511-61435 | ||||
(8009- )21R#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 13511 - CAMSHAFT | ||||
| 13511-35010 |
21R#..RX60 |
1 | ||
| 13511A - PIN, STRAIGHT(FOR CAMSHAFT KNOCK) | ||||
| 90250-06001 |
21R#..RX60 L=14,OD=6,L=14,OD=6 |
2 | ||
| 13511A - PIN, STRAIGHT(FOR CAMSHAFT KNOCK) | ||||
| 90250-06001 |
21R#..RX60 L=14,OD=6,L=14,OD=6 |
2 | ||
| 13523 - GEAR OR SPROCKET, CAMSHAFT TIMING | ||||
| 13523-38011 |
21R#..RX60 N=36 |
1 | ||
| 13523 - GEAR OR SPROCKET, CAMSHAFT TIMING | ||||
| 13523-38011 |
21R#..RX60 N=36 |
1 | ||
| 13711 - VALVE, INTAKE | ||||
| 13711-37010 |
21R#..RX60 |
4 | ||
| 13711A - SEAL OR RING, O(FOR VALVE STEM OIL) | ||||
| 90913-02023 |
21R#..RX60 |
8 | ||
| 13711A - SEAL OR RING, O(FOR VALVE STEM OIL) | ||||
| 90913-02023 |
21R#..RX60 |
8 | ||
| 13711C - SPRING, COMPRESSION(FOR OUTER) | ||||
| 90501-47001 |
21R#..RX60 WD=4.7,CW=6.31 |
8 | ||
| 13711C - SPRING, COMPRESSION(FOR OUTER) | ||||
| 90501-47001 |
21R#..RX60 WD=4.7,CW=6.31 |
8 | ||
| 13711D - WASHER, PLATE(FOR VALVE SPRING SEAT) | ||||
| 90201-20579 |
21R#..RX60 |
8 | ||
| 13711D - WASHER, PLATE(FOR VALVE SPRING SEAT) | ||||
| 90201-20579 |
21R#..RX60 |
8 | ||
| 13715 - VALVE, EXHAUST | ||||
| 13715-38011 |
21R#..RX60 |
4 | ||
| 13741 - RETAINER, VALVE SPRING | ||||
| 13741-38010 |
21R#..RX60 |
8 | ||
| 13741 - RETAINER, VALVE SPRING | ||||
| 13741-38010 |
21R#..RX60 |
8 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03005 |
21R#,18R..RX6# |
24 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03005 |
21R#,18R..RX6# |
24 | ||
| 13801 - ARM SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13811-38010 |
21R#..RX60 |
8 | ||
| 13801B - NUT, HEXAGON(FOR VALVE ADJUSTING) | ||||
| 90170-08210 |
21R#..RX60 |
12 | ||
| 13801C - SCREW, VALVE ADJUSTING | ||||
| 90913-05016 |
21R#..RX60 |
12 | ||
| 13801D - SPRING, COMPRESSION(FOR ROCKER ARM) | ||||
| 90501-12008 |
21R#..RX60 |
8 | ||
| 13901 - SHAFT SUB-ASSY, VALVE ROCKER, NO.1 | ||||
| 13911-38011 |
21R#..RX60 |
1 | ||
| 13901G - WASHER, ROCKER SHAFT | ||||
| 90560-16448 |
21R#..RX60 |
2 | ||
| 13902 - SHAFT SUB-ASSY, VALVE ROCKER, NO.2 | ||||
| 13912-38011 |
21R#..RX60 |
1 | ||
| 13951 - SUPPORT, VALVE ROCKER, NO.1 | ||||
| 13951-38012 |
21R#..RX60 |
1 | ||
| 13951B - SCREW OR BOLT(FOR VALVE ROCKER SHAFT LOCK) | ||||
| 93210-16008 |
21R#..RX60 |
3 | ||
| 13951B - SCREW OR BOLT(FOR VALVE ROCKER SHAFT LOCK) | ||||
| 93210-16008 |
21R#..RX60 |
3 | ||
| 13951C - BOLT, STUD(FOR ROCKER SUPPORT) | ||||
| 90116-08089 |
21R#..RX60 L=58,S=9&32 |
4 | ||
| 13951C - BOLT, STUD(FOR ROCKER SUPPORT) | ||||
| 90116-08089 |
21R#..RX60 L=58,S=9&32 |
4 | ||
| 13952 - SUPPORT, VALVE ROCKER, NO.2 | ||||
| 13952-38010 |
21R#..RX60 |
1 | ||
| 13953 - SUPPORT, VALVE ROCKER, NO.3 | ||||
| 13953-38010 |
21R#..RX60 |
1 | ||
| 13954 - SUPPORT, VALVE ROCKER, NO.4 | ||||
| 13954-38011 |
21R#..RX60 |
1 | ||
| 13955 - SUPPORT, VALVE ROCKER, NO.5 | ||||
| 13955-38010 |
21R#..RX60 |
1 | ||
