GX81R-AEPQK (1988)
Toyota Cressida
(8808-9302)GX81..4FC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 32921 - TUBE, OIL COOLER INLET, NO.1 | ||||
| 32921-22420 |
GX81..4FC |
1 | ||
| 32921A - NUT, UNION(FOR OIL COOLER TUBE) | ||||
| 90402-14004 |
GX81,LX80,RX8#..4FC |
4 | ||
| 32921A - NUT, UNION(FOR OIL COOLER TUBE) | ||||
| 90402-14004 |
GX81,LX80,RX8#..4FC |
4 | ||
| 32921C - UNION(FOR OIL COOLER TUBE) | ||||
| 90404-14007 |
GX81,LX80,RX8#..4FC FR |
1 | ||
| 90407-14003 |
GX81,LX80,RX8#..4FC RR |
1 | ||
| 32921C - UNION(FOR OIL COOLER TUBE) | ||||
| 90404-14007 |
GX81,LX80,RX8#..4FC FR |
1 | ||
| 90407-14003 |
GX81,LX80,RX8#..4FC RR |
1 | ||
| 32921D - HOSE(FOR OIL COOLER INLET) | ||||
| 90445-16026 |
GX81..4FC |
1 | ||
| 32921G - RING, O(FOR OIL COOLER TUBE UNION) | ||||
| 90301-10189 |
GX81,LX80,MX81,RX8#..4FC |
2 | ||
| 32921G - RING, O(FOR OIL COOLER TUBE UNION) | ||||
| 90301-10189 |
GX81,LX80,MX81,RX8#..4FC |
2 | ||
| 32922 - TUBE, OIL COOLER OUTLET, NO.1 | ||||
| 32922-22440 |
GX81..4FC |
1 | ||
| 32922A - HOSE(FOR OIL COOLER OUTLET) | ||||
| 32941-22110 |
GX81..4FC |
1 | ||
| 32924 - CLAMP, OIL COOLER TUBE, NO.2 | ||||
| 32924-22061 |
GX81..4FC |
1 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-22010 |
GX81,RX8#..4FC L=35,ID=8 |
4 | ||
| 32926-22010 |
GX81..4FC L=35,ID=8 |
4 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-22010 |
GX81,RX8#..4FC L=35,ID=8 |
4 | ||
| 32926-22010 |
GX81..4FC L=35,ID=8 |
4 | ||
| 32928A - CLAMP(FOR FLEXIBLE HOSE CLAMP) | ||||
| 90462-12085 |
GX81,RX8#..4FC |
2 | ||
| 32928A - CLAMP(FOR FLEXIBLE HOSE CLAMP) | ||||
| 90462-12085 |
GX81,RX8#..4FC |
2 | ||
| Common parts | ||||
| 90467-13039 | ||||
| 91611-60612 | ||||
| 91611-60814 | ||||
(8808-9302)RX8#..4FC..V ; (9302- )4FC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 32921 - TUBE, OIL COOLER INLET, NO.1 | ||||
| 32921-22420 |
GX81..4FC |
1 | ||
| 32921A - NUT, UNION(FOR OIL COOLER TUBE) | ||||
| 90402-14004 |
GX81,LX80,RX8#..4FC |
4 | ||
| 32921A - NUT, UNION(FOR OIL COOLER TUBE) | ||||
| 90402-14004 |
GX81,LX80,RX8#..4FC |
4 | ||
| 32921C - UNION(FOR OIL COOLER TUBE) | ||||
| 90404-14007 |
GX81,LX80,RX8#..4FC FR |
1 | ||
| 90407-14003 |
GX81,LX80,RX8#..4FC RR |
1 | ||
| 32921C - UNION(FOR OIL COOLER TUBE) | ||||
| 90404-14007 |
GX81,LX80,RX8#..4FC FR |
1 | ||
| 90407-14003 |
GX81,LX80,RX8#..4FC RR |
1 | ||
| 32921D - HOSE(FOR OIL COOLER INLET) | ||||
| 90445-16026 |
GX81..4FC |
1 | ||
| 32921G - RING, O(FOR OIL COOLER TUBE UNION) | ||||
| 90301-10189 |
GX81,LX80,MX81,RX8#..4FC |
2 | ||
| 32921G - RING, O(FOR OIL COOLER TUBE UNION) | ||||
| 90301-10189 |
GX81,LX80,MX81,RX8#..4FC |
2 | ||
| 32922 - TUBE, OIL COOLER OUTLET, NO.1 | ||||
| 32922-22440 |
GX81..4FC |
1 | ||
| 32922A - HOSE(FOR OIL COOLER OUTLET) | ||||
| 32941-22110 |
GX81..4FC |
1 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-22010 |
GX81,RX8#..4FC L=35,ID=8 |
4 | ||
| 32926-22010 |
GX81..4FC L=35,ID=8 |
4 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-22010 |
GX81,RX8#..4FC L=35,ID=8 |
4 | ||
| 32926-22010 |
GX81..4FC L=35,ID=8 |
4 | ||
| 32928A - CLAMP(FOR FLEXIBLE HOSE CLAMP) | ||||
| 90462-12085 |
GX81,RX8#..4FC |
2 | ||
| 32928A - CLAMP(FOR FLEXIBLE HOSE CLAMP) | ||||
| 90462-12085 |
GX81,RX8#..4FC |
2 | ||
| Common parts | ||||
| 90467-13039 | ||||
| 91611-60612 | ||||
| 91611-61014 | ||||
| 91651-60614 | ||||
