AT151R-TEMDS (1983)
Toyota Corona/Carina 2
(8310- )EUR,GEN,SAA ; (8508-8608)XL..TH
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45201 - SHAFT SUB-ASSY, STEERING MAIN | ||||
| 45210-20150 |
AT151..RHD |
1 | ||
| 45210-20110 |
AT151,CT150,ST15#..(DX,GL,XL)..(EUR,GEN,SAA) W/POWER STEERING |
1 | ||
| 45201A - BEARING(FOR STEERING MAIN SHAFT) | ||||
| 90363-18038 |
AT151,CT150,ST15# |
1 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17196 |
AT151,CT150,ST15# T=1.35-1.45,T=1.4 |
2 | ||
| 90520-17042 |
AT151,CT150,ST15# T=1.20,T=1.2 |
2 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17196 |
AT151,CT150,ST15# T=1.35-1.45,T=1.4 |
2 | ||
| 90520-17042 |
AT151,CT150,ST15# T=1.20,T=1.2 |
2 | ||
| 45201D - RING(FOR STEERING MAIN SHAFT) | ||||
| 96152-00300 |
AT151,CT150,ST15# |
1 | ||
| 45205 - TUBE SUB-ASSY, STEERING COLUMN | ||||
| 45870-20110 |
AT151,CT150,ST15#..RHD..MTM..(EUR,GEN) |
1 | ||
| 45870-20130 |
AT151,CT150,ST15#..RHD..(EUR,GEN) W/TILT STEERING |
1 | ||
| 45209 - YOKE SUB-ASSY, STEERING SLIDING | ||||
| 45209-32010 |
AT151;ST150..LB..XL;ST150..SED..RHD..GEN;ST150..SED..XL..(SAA,TH);ST150..SED..LHD..XL..GEN |
1 | ||
| 45209-32020 |
AT151,CT150,ST15#..(DX,GL,XL)..(EUR,GEN,SAA) W/POWER STEERING |
1 | ||
| 45253 - COVER, STEERING COLUMN HOLE | ||||
| 45025-20130 |
AT151,CT150,ST15#..RHD |
1 | ||
| 45254 - SHIELD, STEERING COLUMN HOLE | ||||
| 45254-20080 |
AT151,CT150,ST15#..RHD |
1 | ||
| 45269 - RETAINER, MAIN SHAFT BEARING | ||||
| 45269-10010 |
AT151,CT150,ST15# |
1 | ||
| 45275 - BRACKET, STEERING COLUMN, UPPER | ||||
| 45280-20260 |
AT151,CT150,ST15#..RHD W/*EL |
1 | ||
| 45280-20240 |
AT151,CT150,ST15#..RHD |
1 | ||
| 45280-20261 |
AT151,CT150,ST15#..RHD W/*EL |
1 | ||
| 45280-20241 |
AT151,CT150,ST15#..RHD |
1 | ||
| 45281 - HOUSING, STEERING COLUMN | ||||
| 45286-2092504 |
AT151,CT150,ST150..RHD BLUE,BLUE,TRIM8# |
1 | ||
| 45286-2092503 |
AT151,CT150,ST15#..RHD..(EUR,GEN) GRAY,GRAY,TRIM1# |
1 | ||
| 45286-2092502 |
AT151,CT150,ST15#..RHD..(EUR,GEN) DEEP MAROON,RED/MAROON,TRIM3# |
1 | ||
| 45286-2092604 |
AT151,CT150,ST150..RHD BLUE,W/TILT STEERING,BLUE,TRIM8# |
1 | ||
| 45286-2092603 |
AT151,CT150,ST15#..RHD..(EUR,GEN) GRAY,W/TILT STEERING,GRAY,TRIM1# |
1 | ||
| 45286-2092614 |
AT151,CT150,ST15#..RHD..(EUR,GEN) BLUE,W/TILT STEERING,BLUE,TRIM8# |
1 | ||
| 45286-2092514 |
AT151,CT150,ST15#..RHD..(EUR,GEN) BLUE,BLUE,TRIM8# |
1 | ||
| 45286-2092602 |
AT151,CT150,ST15#..RHD..(EUR,GEN) MAROON,W/TILT STEERING,RED/MAROON,TRIM3# |
1 | ||
| 45281E - PLATE, SAFETY CAUTION | ||||
| 45283-22010 |
AT151,CT150,ST15#..RHD |
1 | ||
| 45817 - STOPPER, STEERING SHAFT THRUST | ||||
| 45808-20020 |
AT151,CT150,ST15# |
1 | ||
| 45817A - RING, O(FOR STEERING SHAFT THRUST STOPPER) | ||||
| 96711-24056 |
AT151,CT150,ST15# |
1 | ||
| 90301-54002 |
AT151,CT150,ST15# |
1 | ||
| 45897 - BOLT, STEERING LOCK SET | ||||
| 45897-12020 |
AT151,CT150,ST15# |
1 | ||
| Common parts | ||||
| 90101-08070 | ||||
| 90154-50011 | ||||
| 90179-06097 | ||||
| 90179-10053 | ||||
| 90201-08131 | ||||
| 90460-75003 | ||||
| 91611-40816 | ||||
| 91611-60818 | ||||
| 91651-40620 | ||||
| 91651-60614 | ||||
| 93315-14012 | ||||
| 93319-14008 | ||||
| 94512-00800 | ||||
(8310- )EUR,GEN,SAA ; (8508-8608)GL..TH
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45081 - SUPPORT SUB-ASSY, TILT STEERING | ||||
| 45081-20010 |
AT151,CT150,ST15#..RHD..(EUR,GEN) |
1 | ||
| 45082 - BRACKET SUB-ASSY, BREAK AWAY W/CAPSULE | ||||
| 45082-20030 |
AT151,CT150,ST15#..RHD..(EUR,GEN) |
1 | ||
| 45082-20031 |
AT151,CT150,ST15#..RHD |
1 | ||
| 45082A - SPRING, TORSION(FOR TILT STEERING RETURN) | ||||
| 90508-29015 |
AT151,CT150,ST15#..EUR,GEN,SAA |
2 | ||
| 45201 - SHAFT SUB-ASSY, STEERING MAIN | ||||
| 45210-20150 |
AT151..RHD |
1 | ||
| 45210-20110 |
AT151,CT150,ST15#..(DX,GL,XL)..(EUR,GEN,SAA) W/POWER STEERING |
1 | ||
| 45201A - BEARING(FOR STEERING MAIN SHAFT) | ||||
| 90363-18038 |
AT151,CT150,ST15# |
1 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17196 |
AT151,CT150,ST15# T=1.35-1.45,T=1.4 |
2 | ||
| 90520-17042 |
AT151,CT150,ST15# T=1.20,T=1.2 |
2 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17196 |
AT151,CT150,ST15# T=1.35-1.45,T=1.4 |
2 | ||
| 90520-17042 |
AT151,CT150,ST15# T=1.20,T=1.2 |
2 | ||
| 45201D - RING(FOR STEERING MAIN SHAFT) | ||||
| 96152-00300 |
AT151,CT150,ST15# |
1 | ||
| 45205 - TUBE SUB-ASSY, STEERING COLUMN | ||||
| 45870-20110 |
AT151,CT150,ST15#..RHD..MTM..(EUR,GEN) |
1 | ||
| 45870-20130 |
AT151,CT150,ST15#..RHD..(EUR,GEN) W/TILT STEERING |
1 | ||
| 45205A - BUSH(FOR STEERING COLUMN TUBE) | ||||
| 90389-11005 |
AT151,CT150,ST15#..EUR,GEN,SAA |
4 | ||
| 45205A - BUSH(FOR STEERING COLUMN TUBE) | ||||
| 90389-11005 |
AT151,CT150,ST15#..EUR,GEN,SAA |
4 | ||
| 45205G - RING, O(FOR STEERING COLUMN TUBE) | ||||
| 90301-11005 |
AT151,CT150,ST15#..EUR,GEN,SAA |
2 | ||
| 45209 - YOKE SUB-ASSY, STEERING SLIDING | ||||
| 45209-32010 |
AT151;ST150..LB..XL;ST150..SED..RHD..GEN;ST150..SED..XL..(SAA,TH);ST150..SED..LHD..XL..GEN |
1 | ||
| 45209-32020 |
AT151,CT150,ST15#..(DX,GL,XL)..(EUR,GEN,SAA) W/POWER STEERING |
1 | ||
| 45253 - COVER, STEERING COLUMN HOLE | ||||
| 45025-20130 |
AT151,CT150,ST15#..RHD |
1 | ||
| 45254 - SHIELD, STEERING COLUMN HOLE | ||||
| 45254-20080 |
AT151,CT150,ST15#..RHD |
1 | ||
| 45269 - RETAINER, MAIN SHAFT BEARING | ||||
| 45269-10010 |
AT151,CT150,ST15# |
1 | ||
| 45275 - BRACKET, STEERING COLUMN, UPPER | ||||
| 45280-20260 |
AT151,CT150,ST15#..RHD W/*EL |
1 | ||
| 45280-20240 |
AT151,CT150,ST15#..RHD |
1 | ||
| 45280-20261 |
AT151,CT150,ST15#..RHD W/*EL |
1 | ||
| 45280-20241 |
AT151,CT150,ST15#..RHD |
1 | ||
| 45281 - HOUSING, STEERING COLUMN | ||||
| 45286-2092504 |
AT151,CT150,ST150..RHD BLUE,BLUE,TRIM8# |
1 | ||
| 45286-2092503 |
AT151,CT150,ST15#..RHD..(EUR,GEN) GRAY,GRAY,TRIM1# |
1 | ||
| 45286-2092502 |
AT151,CT150,ST15#..RHD..(EUR,GEN) DEEP MAROON,RED/MAROON,TRIM3# |
1 | ||
| 45286-2092604 |
AT151,CT150,ST150..RHD BLUE,W/TILT STEERING,BLUE,TRIM8# |
1 | ||
| 45286-2092603 |
AT151,CT150,ST15#..RHD..(EUR,GEN) GRAY,W/TILT STEERING,GRAY,TRIM1# |
1 | ||
| 45286-2092614 |
AT151,CT150,ST15#..RHD..(EUR,GEN) BLUE,W/TILT STEERING,BLUE,TRIM8# |
1 | ||
| 45286-2092514 |
AT151,CT150,ST15#..RHD..(EUR,GEN) BLUE,BLUE,TRIM8# |
1 | ||
| 45286-2092602 |
AT151,CT150,ST15#..RHD..(EUR,GEN) MAROON,W/TILT STEERING,RED/MAROON,TRIM3# |
1 | ||
| 45281E - PLATE, SAFETY CAUTION | ||||
| 45283-22010 |
AT151,CT150,ST15#..RHD |
1 | ||
| 45804 - LEVER SUB-ASSY, STEERING TILT | ||||
| 45804-20010 |
AT151,CT150,ST15#..EUR,GEN,SAA |
1 | ||
| 45804B - BOLT(FOR STEERING TILT LEVER) | ||||
| 90105-08060 |
AT151,CT150,ST15#..EUR,GEN,SAA |
1 | ||
| 45804C - WASHER, PLATE(FOR STEERING TILT LEVER) | ||||
| 90201-08029 |
AT151,CT150,ST15#..EUR,GEN,SAA |
1 | ||
| 45817 - STOPPER, STEERING SHAFT THRUST | ||||
| 45808-20020 |
AT151,CT150,ST15# |
1 | ||
| 45817A - RING, O(FOR STEERING SHAFT THRUST STOPPER) | ||||
| 96711-24056 |
AT151,CT150,ST15# |
1 | ||
| 90301-54002 |
AT151,CT150,ST15# |
1 | ||
| 45831 - BOLT, TILT LEVER LOCK, NO.1 | ||||
| 45831-20010 |
AT151,CT150,ST15#..EUR,GEN,SAA |
1 | ||
| 45833 - NUT, TILT STEERING ADJUSTING, NO.1 | ||||
| 45833-20010 |
AT151,CT150,ST15#..EUR,GEN,SAA |
1 | ||
| 45839 - GROMMET, RETURN SPRING | ||||
| 45839-20010 |
AT151,CT150,ST15#..EUR,GEN,SAA |
2 | ||
| 45897 - BOLT, STEERING LOCK SET | ||||
| 45897-12020 |
AT151,CT150,ST15# |
1 | ||
| 45897A - BOLT, TILT STEERING PAWL SET | ||||
| 45897-26010 |
AT151,CT150,ST15#..EUR,GEN,SAA |
2 | ||
| 45898A - BOLT, RETURN SPRING SET | ||||
| 45898-20020 |
AT151,CT150,ST15#..EUR,GEN,SAA |
2 | ||
| Common parts | ||||
| 90101-08070 | ||||
| 90154-50011 | ||||
| 90179-06097 | ||||
| 90179-08061 | ||||
| 90179-10053 | ||||
| 90201-08131 | ||||
| 90460-75003 | ||||
| 90980-07232 | ||||
| 91611-40816 | ||||
| 91611-60818 | ||||
| 91651-40620 | ||||
| 91651-60614 | ||||
| 93219-55010 | ||||
| 93315-14012 | ||||
| 93319-14008 | ||||
| 94511-00500 | ||||
| 94512-00800 | ||||
