AE95L-CWPDKK (1990)
Toyota Corolla Wagon
(9009- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71015 - FRAME SUB-ASSY, REAR SEAT CUSHION | ||||
| 71015-12290 |
AE95 |
1 | ||
| 71017 - FRAME SUB-ASSY, REAR SEAT BACK, RH | ||||
| 71017-12330 |
AE95 |
1 | ||
| 71018 - FRAME SUB-ASSY, REAR SEAT BACK, LH | ||||
| 71018-12110 |
AE95 |
1 | ||
| 71075B - COVER, REAR SEAT CUSHION (FOR BENCH TYPE) | ||||
| 71075-1E51204 |
AE95..DX..CND DARK BLUE,TRIM8# |
1 | ||
| 71075-1E51203 |
AE95..DX..CND SHADOW GRAY,TRIM1# |
1 | ||
| 71077S - COVER, REAR SEAT BACK, RH (FOR SEPARATE TYPE) | ||||
| 71077-1K31204 |
AE95..DX..CND DARK BLUE,TRIM8# |
1 | ||
| 71077-1K31203 |
AE95..DX..CND SHADOW GRAY,TRIM1# |
1 | ||
| 71078S - COVER, REAR SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71078-1A73203 |
AE95..DX..CND SHADOW GRAY,TRIM1# |
1 | ||
| 71078-1A73204 |
AE95..DX..CND DARK BLUE,TRIM8# |
1 | ||
| 71303C - HINGE SUB-ASSY, REAR SEAT BACK, RH | ||||
| 71303-12090 |
AE95 |
1 | ||
| 71304C - HINGE SUB-ASSY, REAR SEAT BACK, LH | ||||
| 71304-12030 |
AE95 |
1 | ||
| 71305A - HINGE SUB-ASSY, REAR SEAT BACK, CENTER | ||||
| 71305-12090 |
AE95 |
1 | ||
| 71611 - PAD, REAR SEAT CUSHION | ||||
| 71611-12610 |
AE95 |
1 | ||
| 71611-12620 |
AE95 |
1 | ||
| 71651S - PAD, REAR SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71651-12700 |
AE95 |
1 | ||
| 71651-12710 |
AE95 |
1 | ||
| 71652S - PAD, REAR SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71652-12500 |
AE95 |
1 | ||
| 71652-12490 |
AE95 |
1 | ||
| 71832A - CLIP, REAR SEAT BACK CARPET OR MAT | ||||
| 90467-0603713 |
AE95 GRAY,TRIM1#,TYPE A |
6 | ||
| 90467-0603724 |
AE95 DARK BLUE,TRIM8#,TYPE A |
6 | ||
| 90467-07049J0 |
AE95 DARK BLUE,TRIM8#,TYPE B |
6 | ||
| 90467-0704903 |
AE95 GRAY,TRIM1#,TYPE B |
6 | ||
| 71832A - CLIP, REAR SEAT BACK CARPET OR MAT | ||||
| 90467-0603713 |
AE95 GRAY,TRIM1#,TYPE A |
6 | ||
| 90467-0603724 |
AE95 DARK BLUE,TRIM8#,TYPE A |
6 | ||
| 90467-07049J0 |
AE95 DARK BLUE,TRIM8#,TYPE B |
6 | ||
| 90467-0704903 |
AE95 GRAY,TRIM1#,TYPE B |
6 | ||
| 72601A - STRIKER SUB-ASSY, REAR SEAT BACK LOOK, RH | ||||
| 72601-16050 |
AE95 |
1 | ||
| 72602A - STRIKER SUB-ASSY, REAR SEAT BACK LOCK, LH | ||||
| 72601-16050 |
AE95 |
1 | ||
| 72603 - LOCK SUB-ASSY, REAR SEAT BACK, RH | ||||
| 72630-12190 |
AE95 |
1 | ||
| 72604 - LOCK SUB-ASSY, REAR SEAT BACK, LH | ||||
| 72640-12180 |
AE95 |
1 | ||
| 72655A - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72655-2002059 |
AE95 DARK BLUE,TRIM8# |
1 | ||
| 72655-2002023 |
AE95 GRAY,TRIM1# |
1 | ||
| 72656A - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72655-2002059 |
AE95 DARK BLUE,TRIM8# |
1 | ||
| 72655-2002023 |
AE95 GRAY,TRIM1# |
1 | ||
| 72656B - BUTTON, REAR SEAT BACK STOP RELEASE | ||||
| 72656-2001023 |
AE95 GRAY,TRIM1# |
1 | ||
| 72656-2001059 |
AE95 DARK BLUE,TRIM8# |
1 | ||
| 72656C - BUTTON, REAR SEAT BACK STOP RELEASE | ||||
| 72656-2001023 |
AE95 GRAY,TRIM1# |
1 | ||
| 72656-2001059 |
AE95 DARK BLUE,TRIM8# |
1 | ||
| 72693 - HOOK, REAR SEAT CUSHION LOCK | ||||
| 72693-12040 |
AE95 |
2 | ||
| Common parts | ||||
| 90105-08102 | ||||
| 90119-06207 | ||||
| 90468-18071 | ||||
| 91521-60814 | ||||
| 91651-60614 | ||||
| 91655-60820 | ||||
(9009- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90105-08102 | ||||
| 90119-06207 | ||||
| 90468-18071 | ||||
| 91521-60814 | ||||
| 91651-60614 | ||||
| 91655-60820 | ||||
