ADE150R-AEFNYW (2006)
Toyota Corolla Sed (Jpp)
(0611-1004)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52021 - REINFORCEMENT SUB-ASSY, FRONT BUMPER | ||||
| 52021-12240 |
ADE150 |
1 | ||
| 52115A - SUPPORT, FRONT BUMPER SIDE, RH | ||||
| 52115-12430 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS |
1 | ||
| 52116A - SUPPORT, FRONT BUMPER SIDE, LH | ||||
| 52116-12390 |
ADE150 |
1 | ||
| 52119A - COVER, FRONT BUMPER | ||||
| 52119-12941 |
ADE150,NDE150,ZRE151,ZZE150 PAINT REQ. |
1 | ||
| 52119-12948 |
ADE150 PAINT REQ. |
1 | ||
| 52119D - SCREW, NO.1 | ||||
| 90159-60488 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS |
2 | ||
| 52127C - COVER, FRONT BUMPER HOLE | ||||
| 52127-12230D2 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS SUPER RED II,3E5 |
1 | ||
| 52127-12230B0 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS SILVER ME.,1F7 |
1 | ||
| 52127-12230J2 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS DK.BLUE ME.,8T8 |
1 | ||
| 52127-12230J0 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS LT.BLUE M.M.,8S1 |
1 | ||
| 52127-12230A0 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS SUPER WHITE 2,040 |
1 | ||
| 52127-12230B1 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS GRAY ME.,1G3 |
1 | ||
| 52127-12230C0 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS BLACK MC.,209 |
1 | ||
| 52127-12230J1 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS DK.BLUE MC.,8S6 |
1 | ||
| 52127D - COVER, FRONT BUMPER HOLE, RH | ||||
| 81481-12080 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS |
1 | ||
| 52128B - COVER, FRONT BUMPER HOLE, LH | ||||
| 52128-12150A0 |
ADE150 SUPER WHITE 2,040 |
1 | ||
| 52128-12150C0 |
ADE150 BLACK MC.,209 |
1 | ||
| 52128-12150B0 |
ADE150 SILVER ME.,1F7 |
1 | ||
| 52128-12150B1 |
ADE150 GRAY ME.,1G3 |
1 | ||
| 52128-12150J1 |
ADE150 DK.BLUE MC.,8S6 |
1 | ||
| 52128-12150J0 |
ADE150 LT.BLUE M.M.,8S1 |
1 | ||
| 52128-12150D2 |
ADE150 SUPER RED II,3E5 |
1 | ||
| 52128-12150J2 |
ADE150 DK.BLUE ME.,8T8 |
1 | ||
| 52128C - COVER, FRONT BUMPER HOLE, LH | ||||
| 81482-12060 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS |
1 | ||
| 52161C - PIECE, FRONT BUMPER | ||||
| 52161-16010 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS |
9 | ||
| 52161C - PIECE, FRONT BUMPER | ||||
| 52161-16010 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS |
9 | ||
| 52521 - RETAINER, FRONT BUMPER, UPPER CENTER | ||||
| 90467-05063C0 |
ADE150 BLACK |
3 | ||
| 52521A - CLIP(FOR FRONT BUMPER RETAINER) | ||||
| 90467-05090B1 |
ADE150 DK.GRAY |
2 | ||
| 52611 - ABSORBER, FRONT BUMPER ENERGY | ||||
| 52611-12190 |
ADE150 |
1 | ||
| 53112E - GRILLE, RADIATOR, LOWER NO.1 | ||||
| 53112-12131 |
ADE150 NO PAINT REQ. |
1 | ||
| 53112-12130 |
ADE150,NDE150,ZRE151,ZZE150 NO PAINT REQ. |
1 | ||
| 53119E - PROTECTOR, RADIATOR GRILLE | ||||
| 53119-42020 |
ADE150 |
2 | ||
| 53395E - SEAL, HOOD TO FRONT END PANEL | ||||
| 53395-12050 |
ADE150 |
1 | ||
| 53879H - RETAINER, FRONT FENDER LINER | ||||
| 53879-58010 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS |
2 | ||
| 76851G - GROMMET, SCREW, NO.1 | ||||
| 90189-06193 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS |
6 | ||
| 76851G - GROMMET, SCREW, NO.1 | ||||
| 90189-06193 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS |
6 | ||
| 81481E - COVER, FOG LAMP, RH | ||||
| 81481-12090 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS FRONT FOG LAMP-WITH(FOG LAMP) |
1 | ||
| 81482C - COVER, FOG LAMP, LH | ||||
| 81482-12070 |
ADE150,ZZE150;NDE150,ZRE151..5F,5FS FRONT FOG LAMP-WITH(FOG LAMP) |
1 | ||
| Common parts | ||||
| 90109-06383 | ||||
| 90179-06127 | ||||
| 91674-A1028 | ||||
| Linked diagrams | ||||
| 5102 | ||||
| 5301 | ||||
| 5302 | ||||
| 7501 | ||||
| 8101 | ||||
| 8102 | ||||
| 8505 | ||||
