EE100L-AWMDSW (1992)
Toyota Corolla Sed/Wg
(9205- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 53410 - HINGE ASSY, HOOD, RH | ||||
| 53410-12190 |
AE101,CE100,EE10# PAD T=1.0 |
1 | ||
| 53410-12220 |
AE101,CE100,EE10# PAD T=0.5 |
1 | ||
| 53410-12250 |
AE10#,CE100,EE10# PAD T=0.5 |
1 | ||
| 53410-12260 |
AE10#,CE100,EE10# PAD T=1.0 |
1 | ||
| 53420 - HINGE ASSY, HOOD, LH | ||||
| 53420-12240 |
AE10#,CE100,EE10# PAD T=0.5 |
1 | ||
| 53420-12210 |
AE101,CE100,EE10# PAD T=0.5 |
1 | ||
| 53420-12180 |
AE101,CE100,EE10# PAD T=1.0 |
1 | ||
| 53420-12250 |
AE10#,CE100,EE10# PAD T=1.0 |
1 | ||
| 53451 - ROD, HOOD SUPPORT | ||||
| 53451-12170 |
AE101,CE100,EE10# |
1 | ||
| 53451-12171 |
AE10#,CE100,EE10# |
1 | ||
| 53451A - GROMMET(FOR HOOD SUPPORT ROD) | ||||
| 90480-15027 |
AE101,CE100,EE10# |
1 | ||
| 90480-15020 |
AE10#,CE100,EE10# |
1 | ||
| 53455 - CLAMP, HOOD SUPPORT ROD | ||||
| 53455-12090 |
AE10#,CE100,EE10# |
1 | ||
| 53455-12060 |
AE101,CE100,EE10# |
1 | ||
| 53497 - PAD, HOOD HINGE, NO.1 | ||||
| 53497-12070 |
AE10#,CE100,EE10# T=0.5,PAD T=0.5 |
2 | ||
| 53497-12060 |
AE10#,CE100,EE10# T=1.0 |
2 | ||
| 53498 - PAD, HOOD HINGE, NO.2 | ||||
| 53498-12070 |
AE10#,CE100,EE10# PAD T=0.5 |
2 | ||
| 53498-12060 |
AE10#,CE100,EE10# PAD T=1.0 |
2 | ||
| 53510 - LOCK ASSY, HOOD | ||||
| 53510-12500 |
AE10#,CE100,EE10#..LHD |
1 | ||
| 53510A - SPRING, TENSION(FOR HOOD LOCK) | ||||
| 90506-20066 |
AE10#,CE100,EE10#..LHD WD=2.0,CW=17,WD=2.0,CW=17 |
1 | ||
| 90506-09055 |
AE10#,CE100,EE10#..LHD WD=0.9,CW=21,WD=0.9,CW=21 |
1 | ||
| 90506-12067 |
AE10#,CE100,EE10#..LHD WD=1.4,CW=7.25,WD=1.4,CW=7.25 |
1 | ||
| 53510A - SPRING, TENSION(FOR HOOD LOCK) | ||||
| 90506-20066 |
AE10#,CE100,EE10#..LHD WD=2.0,CW=17,WD=2.0,CW=17 |
1 | ||
| 90506-09055 |
AE10#,CE100,EE10#..LHD WD=0.9,CW=21,WD=0.9,CW=21 |
1 | ||
| 90506-12067 |
AE10#,CE100,EE10#..LHD WD=1.4,CW=7.25,WD=1.4,CW=7.25 |
1 | ||
| 53510A - SPRING, TENSION(FOR HOOD LOCK) | ||||
| 90506-20066 |
AE10#,CE100,EE10#..LHD WD=2.0,CW=17,WD=2.0,CW=17 |
1 | ||
| 90506-09055 |
AE10#,CE100,EE10#..LHD WD=0.9,CW=21,WD=0.9,CW=21 |
1 | ||
| 90506-12067 |
AE10#,CE100,EE10#..LHD WD=1.4,CW=7.25,WD=1.4,CW=7.25 |
1 | ||
| 53601 - LEVER SUB-ASSY, HOOD LOCK CONTROL | ||||
| 53601-20060P0 |
AE101,CE100,EE10# SHADOW GRAY,TRIM1# |
1 | ||
| 53601-20060J0 |
AE101,CE100,EE10# DARK BLUE,TRIM8# |
1 | ||
| 53601-2006001 |
EE101..XLI;EE101..WG..(GLI,STD);AE101,CE100,EE100..STD,XL,XLI BLACK,TRIM1#,8# |
1 | ||
| 53601-20060C0 |
EE101..XLI;EE101..WG..(GLI,STD);AE101,CE100,EE100..STD,XL,XLI BLACK,TRIM1#,8# |
1 | ||
| 53601-2006001 |
AE101,CE100,EE10#..WG BLACK,TRIM1#,8# |
1 | ||
| 53630 - CABLE ASSY, HOOD LOCK CONTROL | ||||
| 53630-12460 |
AE10#,CE100,EE10#..LHD |
1 | ||
| 53630-12440 |
AE101,CE100,EE10#..LHD |
1 | ||
| Common parts | ||||
| 90119-06183 | ||||
| 90119-08716 | ||||
| 90467-09043 | ||||
| 91651-40820 | ||||
| 93568-55014 | ||||
