AE82R-ELMNCQ (1984)
Toyota Corolla Sed/Lb
(8305-8511)4ALC..SDZ ; (8305-8511)2ALC,4ALC..ARL; (8511- )4ALC..SDZ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17303E - HOSE, NO.1(FOR AIR PIPE) | ||||
| 77791-12040 |
2AL,4AL..AE8# |
1 | ||
| 77791-12080 |
4AL..AE82 |
1 | ||
| 77791-12050 |
4ALC..AE82;4AL..AE82..4DS..5F..GL..EUG |
1 | ||
| 17303F - HOSE, NO.2(FOR AIR PIPE) | ||||
| 90445-14102 |
4ALC..AE82..SDZ;2ALC,4ALC..AE8#..ARL NO.1 |
1 | ||
| 90447-14010 |
2AL,4AL..AE8# |
1 | ||
| 17303F - HOSE, NO.2(FOR AIR PIPE) | ||||
| 90445-14102 |
4ALC..AE82..SDZ;2ALC,4ALC..AE8#..ARL NO.1 |
1 | ||
| 90447-14010 |
2AL,4AL..AE8# |
1 | ||
| 21381 - BIMETAL, THERMOSTATIC | ||||
| 21381-71010 |
4AL..AE82;4ALC..AE82..SDZ |
1 | ||
| 21381-71010 |
2AL#,4AL..AE8#;4ALC..AE82..ARL;4ALC..AE82..SDZ |
1 | ||
| 23265 - FILTER, GAS, NO.1 | ||||
| 90917-11023 |
4AL..AE82;2AL,4ALC..AE8#..EUR |
1 | ||
| 23271 - VALVE, THERMOSTATIC VACUUM SWITCHING, NO.1 | ||||
| 90925-02076 |
4AL..AE82;2AL,4ALC..AE8#..EUR |
1 | ||
| 23281 - VALVE, VACUUM TRANSMITTING, NO.1 | ||||
| 90925-01014 |
2ALC,4ALC..AE8#;4AL..AE82..4DS..5F..GL..EUG |
2 | ||
| 23282 - VALVE, VACUUM TRANSMITTING, NO.2 | ||||
| 90925-01043 |
4ALC..AE82..SDZ;2ALC,4ALC..AE8#..ARL |
1 | ||
| 23285A - VALVE, CHECK, NO.1 | ||||
| 90917-10049 |
2ALC,4ALC..AE8#;4AL..AE82..4DS..5F..GL..EUG |
2 | ||
| 23286A - VALVE, CHECK, NO.2 | ||||
| 90917-10064 |
4ALC..AE82..SDZ;2ALC,4ALC..AE8#..ARL |
1 | ||
| 23288 - JET, NO.1 | ||||
| 90925-04003 |
4AL..AE82;2AL,4ALC..AE8#..EUR |
1 | ||
| Common parts | ||||
| 90339-03002 | ||||
| 90413-04008 | ||||
| 90445-11040 | ||||
| 90467-12001 | ||||
| 90467-13010 | ||||
| 90467-13027 | ||||
| 90999-92002 | ||||
| 91611-40812 | ||||
(8504-8505)4ALC ; (8508- )4ALC..FRG
(8504-8505)FRG SPEC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 23265 - FILTER, GAS, NO.1 | ||||
| 90917-11023 |
4AL..AE82;2AL,4ALC..AE8#..EUR |
1 | ||
| 23271 - VALVE, THERMOSTATIC VACUUM SWITCHING, NO.1 | ||||
| 90925-02076 |
4AL..AE82;2AL,4ALC..AE8#..EUR |
1 | ||
| 23281 - VALVE, VACUUM TRANSMITTING, NO.1 | ||||
| 90925-01014 |
2ALC,4ALC..AE8#;4AL..AE82..4DS..5F..GL..EUG |
2 | ||
| 23285A - VALVE, CHECK, NO.1 | ||||
| 90917-10049 |
2ALC,4ALC..AE8#;4AL..AE82..4DS..5F..GL..EUG |
2 | ||
| 23285A - VALVE, CHECK, NO.1 | ||||
| 90917-10049 |
2ALC,4ALC..AE8#;4AL..AE82..4DS..5F..GL..EUG |
2 | ||
| 23288 - JET, NO.1 | ||||
| 90925-04003 |
4AL..AE82;2AL,4ALC..AE8#..EUR |
1 | ||
| Common parts | ||||
| 90119-06053 | ||||
| 90413-04005 | ||||
| 90445-11040 | ||||
| 90445-14075 | ||||
| 90447-04025 | ||||
| 90447-04026 | ||||
| 90447-04027 | ||||
| 90447-04046 | ||||
| 90447-04059 | ||||
| 90447-05007 | ||||
| 90447-05008 | ||||
| 90464-00329 | ||||
| 90467-12001 | ||||
| 90467-13010 | ||||
| 90999-92002 | ||||
| 91651-40614 | ||||
| 91651-40814 | ||||
| 93319-14010 | ||||
| 93319-15010 | ||||
| 95411-19930 | ||||
| 95413-49933 | ||||
(8511- )2ALC,4ALC..ARL
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 23265 - FILTER, GAS, NO.1 | ||||
| 90917-11023 |
4AL..AE82;2AL,4ALC..AE8#..EUR |
1 | ||
| 23271 - VALVE, THERMOSTATIC VACUUM SWITCHING, NO.1 | ||||
| 90925-02076 |
4AL..AE82;2AL,4ALC..AE8#..EUR |
1 | ||
| 23281 - VALVE, VACUUM TRANSMITTING, NO.1 | ||||
| 90925-01014 |
2ALC,4ALC..AE8#;4AL..AE82..4DS..5F..GL..EUG |
2 | ||
| 23281 - VALVE, VACUUM TRANSMITTING, NO.1 | ||||
| 90925-01014 |
2ALC,4ALC..AE8#;4AL..AE82..4DS..5F..GL..EUG |
2 | ||
| 23285A - VALVE, CHECK, NO.1 | ||||
| 90917-10049 |
2ALC,4ALC..AE8#;4AL..AE82..4DS..5F..GL..EUG |
2 | ||
| 23288 - JET, NO.1 | ||||
| 90925-04003 |
4AL..AE82;2AL,4ALC..AE8#..EUR |
1 | ||
| Common parts | ||||
| 90339-03002 | ||||
| 90445-11040 | ||||
| 90445-14075 | ||||
| 90464-00329 | ||||
| 90467-12001 | ||||
| 90467-13010 | ||||
| 90999-92002 | ||||
| 90999-92003 | ||||
| 91651-40814 | ||||
| Linked diagrams | ||||
| 7751 | ||||
