AE92L-AEMDUA (1987)

Toyota Corolla Jpp

Production Aug 1987 - Aug 1989
Engine 4AF
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

(8708- )

Click highlighted areas on diagram

diagram 74515A 74529 74541 74541E 74552 74559A 74559A 74559A 74571A
Part # Description Qty Price
74515A - PLATE, THEFT WARNING
74515-14010

AE92..(DX,LE)..USA

 2
74529 - PLATE, CHILD PROOF OR CHILD PROTECTOR LOCK CAUTION
69339-12010

AE9#

 2
74541 - PLATE, TIRE PRESSURE CAUTION
42661-12830

AE92..USA

 1
74541E - PLATE, COMPACT SPARE TIRE CAUTION
42668-12010

AE9#..USA

 1
74559A - PLATE, FUEL CAUTION
74559-14050

AE9#..USA

 1
74559A - PLATE, FUEL CAUTION
74559-14050

AE9#..USA

 1
74559A - PLATE, FUEL CAUTION
74559-14050

AE9#..USA

 1
