ZZE121R-DHPDKW (2001)
Toyota Corolla Hb (Ukp)
(0111-0405)UKP
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52159 - COVER, REAR BUMPER | ||||
| 52159-02910 |
CDE120,ZZE12#..UKP..(DCR,DCRL,HTWC,TWC) |
1 | ||
| 52159-02923 |
CDE120,NDE120,ZZE120,121..UKP..TERRA W(BUMPER SPOILER) |
1 | ||
| 52159-02924 |
CDE120,NDE120,ZZE120,121..UKP |
1 | ||
| 52161B - PIECE, REAR BUMPER | ||||
| 52161-16010 |
CDE120,ZZE12#..UKP |
4 | ||
| 52161-02030 |
CDE120,ZZE12#..UKP (L) |
4 | ||
| 52161-02030 |
CDE120,NDE120,ZZE12#..UKP (L) |
4 | ||
| 52161-16010 |
CDE120,NDE120,ZZE12#..UKP (J) |
4 | ||
| 52161-16010 |
CDE120,ZZE12#..UKP (J) |
4 | ||
| 52171A - REINFORCEMENT, REAR BUMPER, NO.1 | ||||
| 52023-02060 |
CDE120,NDE120,ZZE12#..UKP |
1 | ||
| 52023-02060 |
CDE120,ZZE12#..UKP..(DCR,DCRL,HTWC,TWC) |
1 | ||
| 52185B - BRACKET, REAR BUMPER SIDE MOUNTING, RH | ||||
| 52185-02040 |
CDE120,NDE120,ZZE12#..UKP |
1 | ||
| 52185-02040 |
CDE120,ZZE12#..UKP |
1 | ||
| 52186B - BRACKET, REAR BUMPER SIDE MOUNTING, LH | ||||
| 52186-02030 |
CDE120,NDE120,ZZE12#..UKP |
1 | ||
| 52186-02030 |
CDE120,ZZE12#..UKP |
1 | ||
| 52562B - RETAINER, REAR BUMPER, UPPER RH | ||||
| 52562-02010 |
CDE120,ZZE12#..UKP |
1 | ||
| 52562-02010 |
CDE120,NDE120,ZZE12#..UKP |
1 | ||
| 52563A - RETAINER, REAR BUMPER, UPPER LH | ||||
| 52563-02010 |
CDE120,ZZE12#..UKP |
1 | ||
| 52563-02010 |
CDE120,NDE120,ZZE12#..UKP |
1 | ||
| 52575 - RETAINER, REAR BUMPER SIDE, RH | ||||
| 52575-02060 |
CDE120,NDE120,ZZE12#..UKP |
1 | ||
| 52575-02040 |
CDE120,ZZE12#..UKP |
1 | ||
| 52576 - RETAINER, REAR BUMPER SIDE, LH | ||||
| 52576-02040 |
CDE120,ZZE12#..UKP |
1 | ||
| 52576-02060 |
CDE120,NDE120,ZZE12#..UKP |
1 | ||
| 52581B - PROTECTOR, REAR BUMPER | ||||
| 52581-02020 |
CDE120,NDE120,ZZE12#..UKP |
4 | ||
| 52581-02020 |
CDE120,ZZE12#..UKP |
4 | ||
| 52791 - BOLT, BUMPER MOULDING SET, NO.1 | ||||
| 52791-12040 |
CDE120,NDE120,ZZE12#..UKP |
4 | ||
| 52791-12040 |
CDE120,ZZE12#..UKP |
4 | ||
| Common parts | ||||
| 90119-08B46 | ||||
| 90159-50270 | ||||
| 90159-60602 | ||||
| 90179-06274 | ||||
| 90189-06057 | ||||
| 90189-06145 | ||||
| 90430-05019 | ||||
| Linked diagrams | ||||
| 7601 | ||||
(0405- )UKP
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52159 - COVER, REAR BUMPER | ||||
| 52159-02910 |
CDE120,ZZE12#..UKP..(DCR,DCRL,HTWC,TWC) |
1 | ||
| 52159-02923 |
CDE120,NDE120,ZZE120,121..UKP..TERRA W(BUMPER SPOILER) |
1 | ||
| 52159-02924 |
CDE120,NDE120,ZZE120,121..UKP |
1 | ||
| 52161B - PIECE, REAR BUMPER | ||||
| 52161-16010 |
CDE120,ZZE12#..UKP |
4 | ||
| 52161-02030 |
CDE120,ZZE12#..UKP (L) |
4 | ||
| 52161-02030 |
CDE120,NDE120,ZZE12#..UKP (L) |
4 | ||
| 52161-16010 |
CDE120,NDE120,ZZE12#..UKP (J) |
4 | ||
| 52161-16010 |
CDE120,ZZE12#..UKP (J) |
4 | ||
| 52161B - PIECE, REAR BUMPER | ||||
| 52161-16010 |
CDE120,ZZE12#..UKP |
4 | ||
| 52161-02030 |
CDE120,ZZE12#..UKP (L) |
4 | ||
| 52161-02030 |
CDE120,NDE120,ZZE12#..UKP (L) |
4 | ||
| 52161-16010 |
CDE120,NDE120,ZZE12#..UKP (J) |
4 | ||
| 52161-16010 |
CDE120,ZZE12#..UKP (J) |
4 | ||
| 52161B - PIECE, REAR BUMPER | ||||
| 52161-16010 |
CDE120,ZZE12#..UKP |
4 | ||
| 52161-02030 |
CDE120,ZZE12#..UKP (L) |
4 | ||
| 52161-02030 |
CDE120,NDE120,ZZE12#..UKP (L) |
4 | ||
| 52161-16010 |
CDE120,NDE120,ZZE12#..UKP (J) |
4 | ||
| 52161-16010 |
CDE120,ZZE12#..UKP (J) |
4 | ||
| 52161B - PIECE, REAR BUMPER | ||||
| 52161-16010 |
CDE120,ZZE12#..UKP |
4 | ||
| 52161-02030 |
CDE120,ZZE12#..UKP (L) |
4 | ||
| 52161-02030 |
CDE120,NDE120,ZZE12#..UKP (L) |
4 | ||
| 52161-16010 |
CDE120,NDE120,ZZE12#..UKP (J) |
4 | ||
| 52161-16010 |
CDE120,ZZE12#..UKP (J) |
4 | ||
| 52171A - REINFORCEMENT, REAR BUMPER, NO.1 | ||||
| 52023-02060 |
CDE120,NDE120,ZZE12#..UKP |
1 | ||
| 52023-02060 |
CDE120,ZZE12#..UKP..(DCR,DCRL,HTWC,TWC) |
1 | ||
| 52185B - BRACKET, REAR BUMPER SIDE MOUNTING, RH | ||||
| 52185-02040 |
CDE120,NDE120,ZZE12#..UKP |
1 | ||
| 52185-02040 |
CDE120,ZZE12#..UKP |
1 | ||
| 52186B - BRACKET, REAR BUMPER SIDE MOUNTING, LH | ||||
| 52186-02030 |
CDE120,NDE120,ZZE12#..UKP |
1 | ||
| 52186-02030 |
CDE120,ZZE12#..UKP |
1 | ||
| 52462 - PAD, REAR BUMPER, RH | ||||
| 52462-02030 |
CDE120,NDE120,ZZE12#..UKP |
2 | ||
| 52562B - RETAINER, REAR BUMPER, UPPER RH | ||||
| 52562-02010 |
CDE120,ZZE12#..UKP |
1 | ||
| 52562-02010 |
CDE120,NDE120,ZZE12#..UKP |
1 | ||
| 52563A - RETAINER, REAR BUMPER, UPPER LH | ||||
| 52563-02010 |
CDE120,ZZE12#..UKP |
1 | ||
| 52563-02010 |
CDE120,NDE120,ZZE12#..UKP |
1 | ||
| 52575 - RETAINER, REAR BUMPER SIDE, RH | ||||
| 52575-02060 |
CDE120,NDE120,ZZE12#..UKP |
1 | ||
| 52575-02040 |
CDE120,ZZE12#..UKP |
1 | ||
| 52576 - RETAINER, REAR BUMPER SIDE, LH | ||||
| 52576-02040 |
CDE120,ZZE12#..UKP |
1 | ||
| 52576-02060 |
CDE120,NDE120,ZZE12#..UKP |
1 | ||
| 52581B - PROTECTOR, REAR BUMPER | ||||
| 52581-02020 |
CDE120,NDE120,ZZE12#..UKP |
4 | ||
| 52581-02020 |
CDE120,ZZE12#..UKP |
4 | ||
| 52581B - PROTECTOR, REAR BUMPER | ||||
| 52581-02020 |
CDE120,NDE120,ZZE12#..UKP |
4 | ||
| 52581-02020 |
CDE120,ZZE12#..UKP |
4 | ||
| 52581B - PROTECTOR, REAR BUMPER | ||||
| 52581-02020 |
CDE120,NDE120,ZZE12#..UKP |
4 | ||
| 52581-02020 |
CDE120,ZZE12#..UKP |
4 | ||
| 52581B - PROTECTOR, REAR BUMPER | ||||
| 52581-02020 |
CDE120,NDE120,ZZE12#..UKP |
4 | ||
| 52581-02020 |
CDE120,ZZE12#..UKP |
4 | ||
| 52791 - BOLT, BUMPER MOULDING SET, NO.1 | ||||
| 52791-12040 |
CDE120,NDE120,ZZE12#..UKP |
4 | ||
| 52791-12040 |
CDE120,ZZE12#..UKP |
4 | ||
| 75392 - RETAINER, OUTSIDE MOULDING | ||||
| 75392-35200 |
CDE120,NDE120,ZZE120,121..UKP..TERRA |
6 | ||
| 75392 - RETAINER, OUTSIDE MOULDING | ||||
| 75392-35200 |
CDE120,NDE120,ZZE120,121..UKP..TERRA |
6 | ||
| Common parts | ||||
| 90119-08B46 | ||||
| 90159-50270 | ||||
| 90159-60602 | ||||
| 90159-60603 | ||||
| 90179-06274 | ||||
| 90183-06019 | ||||
| 90189-06057 | ||||
| 90189-06145 | ||||
| 90430-05019 | ||||
| Linked diagrams | ||||
| 7601 | ||||
