TE71RG-EWKDS (1979)
Toyota Corolla
(7908- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04412 - GASKET KIT, REAR DIFFERENTIAL CARRIER | ||||
| 04412-12040 |
TE71..WG |
1 | ||
| 41110A - BOLT, NO.1 (FOR REAR DIFFERENTIAL CARRIER SET) | ||||
| 90116-08236 |
TE71..(DX,SE,SR,STD,XE)..(EUR,GEN) S=12 & 15,L=78,L=78,S=15 & S=12 |
1 | ||
| 90116-08235 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) S=12 & 15,L=34,L=34,S=15 & S=12 |
7 | ||
| 42110 - HOUSING ASSY, REAR AXLE | ||||
| 42110-13050 |
CE70,TE71..DV,WG |
1 | ||
| 42110A - PLUG (FOR REAR AXLE HOUSING FILLER) | ||||
| 90341-18049 |
AE71,CE70,KE70,TE7#..EUR,GEN,SA,SAA |
1 | ||
| 42110B - GASKET (FOR REAR AXLE HOUSING FILLER PLUG) | ||||
| 12157-10010 |
AE71,CE70,KE70,TE7#..EUR,GEN,SA,SAA |
1 | ||
| 42110C - PLUG, BREATHER (FOR REAR AXLE HOUSING) | ||||
| 90930-03031 |
AE71,CE70,KE70,TE7#..EUR,GEN,SA,SAA |
1 | ||
| 42110D - GASKET (FOR REAR AXLE HOUSING DRAIN PLUG) | ||||
| 12157-10010 |
AE71,CE70,KE70,TE7#..EUR,GEN,SA,SAA |
1 | ||
| 42110E - PLUG (FOR REAR AXLE HOUSING DRAIN) | ||||
| 90341-18057 |
AE71,CE70,KE70,TE7#..EUR,GEN,SA,SAA |
1 | ||
| 42139 - DEFLECTOR, REAR AXLE HOUSING OIL | ||||
| 42108-12020 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) |
2 | ||
| 42181 - GASKET, REAR DIFFERENTIAL CARRIER | ||||
| 42181-20010 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) |
1 | ||
(7908- )CE70,TE71..DX,GL,SE,SR,STD,XE..EUR,GEN,SAA ; (8308-8406)AE71..STD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 41101 - CARRIER SUB-ASSY, DIFFERENTIAL, REAR | ||||
| 41101-20010 |
TE71..(DX,SE,SR,STD,XE)..(EUR,GEN) |
1 | ||
| 41110 - CARRIER ASSY, DIFFERENTIAL, REAR | ||||
| 41110-12110 |
TE71..RHD..XE..EUG;TE71..4F..(EUR,GEN,SAA) *AXC=S314,*FGR=43:11 |
1 | ||
| 41114 - BOLT, REAR DIFFERENTIAL BEARING CAP | ||||
| 90101-10128 |
KE70,TE71..(DX,SE,SR,STD,XE,XL)..(EUR,GEN) |
4 | ||
| 41201 - FINAL GEAR KIT, DIFFERENTIAL, REAR | ||||
| 41201-19186 |
TE71..4F *AXC=S312 & S314,*FGR=43:11 |
1 | ||
| 41201A - BEARING (FOR REAR DRIVE PINION REAR) | ||||
| 90368-33021 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) |
1 | ||
| 41201B - BEARING (FOR REAR DRIVE PINION FRONT) | ||||
| 90368-30002 |
CE70,TE71..EUR,GEN;TE72..(DX,SE)..(ARL,EUR) |
1 | ||
| 41201C - SEAL, OIL (FOR REAR DIFFERENTIAL CARRIER) | ||||
| 90311-38014 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) |
1 | ||
| 41201D - WASHER, PLATE (FOR REAR DIFFERENTIAL DRIVE PINION) | ||||
| 90209-33039 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=2.55,T=2.55 |
1 | ||
| 90209-33038 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=2.52,T=2.52 |
1 | ||
| 90209-33041 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=2.61,T=2.61 |
1 | ||
| 90209-33040 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=2.58,T=2.58 |
1 | ||
| 90209-33043 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=2.67,T=2.67 |
1 | ||
| 90209-33042 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=2.64,T=2.64 |
1 | ||
| 90209-33046 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=2.76,T=2.76 |
1 | ||
| 90209-33044 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=2.70,T=2.70 |
1 | ||
| 90209-33045 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=2.73,T=2.73 |
1 | ||
| 41204 - FLANGE SUB-ASSY, REAR DRIVE PINION COMPANION, REAR | ||||
| 41204-20012 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) |
1 | ||
| 41204A - WASHER, PLATE (FOR REAR DRIVE PINION) | ||||
| 90201-18485 |
CE70,TE71..EUR,GEN;TE72..(DX,SE)..(ARL,EUR) |
1 | ||
| 41204B - NUT (FOR REAR DRIVE PINION) | ||||
| 90179-18001 |
CE70,TE71..EUR,GEN;TE72..(DX,SE)..(ARL,EUR) |
1 | ||
| 41214 - SLINGER, REAR DIFFERENTIAL DRIVE PINION OIL | ||||
| 41214-20020 |
CE70,TE71..EUR,GEN;TE72..(DX,SE)..(ARL,EUR) |
1 | ||
| 41222 - PLATE, REAR DIFFERENTIAL RING GEAR SET BOLT LOCK | ||||
| 41222-20020 |
TE71..(DX,SE,SR,STD,XE)..(EUR,GEN) |
4 | ||
| 41222A - BOLT (FOR REAR DIFFERENTIAL RING GEAR SET) | ||||
| 90109-10015 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) |
8 | ||
| 41231 - SPACER, REAR DIFFERENTIAL DRIVE PINION BEARING | ||||
| 41231-20020 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) |
1 | ||
| 41252 - DEFLECTOR, DUST (FOR REAR DIFFERENTIAL) | ||||
| 37341-20010 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) |
1 | ||
| 41301A - BEARING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90368-34020 |
CE70,KE70,TE71..(DX,GL,SE,SR,STD,XE,XL)..(EUR,GEN,SAA) |
2 | ||
| 41302 - CASE SUB-ASSY, REAR DIFFERENTIAL | ||||
| 41301-22020 |
TE71..DX,SE,SR,STD,XE |
1 | ||
| 41301-22021 |
TE71..(DX,SE,SR,STD,XE)..(EUR,GEN) |
1 | ||
| 41302A - BOLT(FOR REAR DIFFERENTIAL CASE) | ||||
| 90101-08241 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) |
5 | ||
| 41302B - WASHER, SPRING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90204-08024 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) |
8 | ||
| 41302B - WASHER, SPRING(FOR REAR DIFFERENTIAL CASE) | ||||
| 90204-08024 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) |
8 | ||
| 41315 - NUT, REAR DIFFERENTIAL BEARING ADJUSTING | ||||
| 41315-20010 |
TE71..(DX,SE,SR,STD,XE)..(EUR,GEN) |
2 | ||
| 41316 - LOCK, REAR DIFFERENTIAL BEARING ADJUSTING NUT | ||||
| 41316-20010 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) SINGLE TYPE |
2 | ||
| 41316-20020 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) DOUBLE TYPE |
2 | ||
| 41316 - LOCK, REAR DIFFERENTIAL BEARING ADJUSTING NUT | ||||
| 41316-20010 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) SINGLE TYPE |
2 | ||
| 41316-20020 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) DOUBLE TYPE |
2 | ||
| 41331 - GEAR, REAR DIFFERENTIAL SIDE | ||||
| 41331-22011 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) |
2 | ||
| 41331 - GEAR, REAR DIFFERENTIAL SIDE | ||||
| 41331-22011 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) |
2 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-22010 |
TE71..DX,SE,SR,STD,XE |
4 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-22010 |
TE71..DX,SE,SR,STD,XE |
4 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-22010 |
TE71..DX,SE,SR,STD,XE |
4 | ||
| 41341 - PINION, REAR DIFFERENTIAL | ||||
| 41341-22010 |
TE71..DX,SE,SR,STD,XE |
4 | ||
| 41342 - SHAFT, REAR DIFFERENTIAL PINION | ||||
| 41342-20010 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) L=94 |
1 | ||
| 41342-20020 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) L=24 |
2 | ||
| 41342 - SHAFT, REAR DIFFERENTIAL PINION | ||||
| 41342-20010 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) L=94 |
1 | ||
| 41342-20020 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) L=24 |
2 | ||
| 41343 - PIN, REAR DIFFERENTIAL PINION SHAFT | ||||
| 41343-22010 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) |
3 | ||
| 41361 - WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-12080 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=1.55 |
2 | ||
| 41361-12090 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=1.60 |
2 | ||
| 41361-12070 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=1.50 |
2 | ||
| 41361-12120 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=1.75 |
2 | ||
| 41361-12110 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=1.70 |
2 | ||
| 41361-12100 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=1.65 |
2 | ||
| 41361 - WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1 | ||||
| 41361-12080 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=1.55 |
2 | ||
| 41361-12090 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=1.60 |
2 | ||
| 41361-12070 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=1.50 |
2 | ||
| 41361-12120 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=1.75 |
2 | ||
| 41361-12110 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=1.70 |
2 | ||
| 41361-12100 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) T=1.65 |
2 | ||
| 41375 - HOLDER, REAR DIFFERENTIAL PINION SHAFT | ||||
| 41375-20010 |
CE70,TE71..(DX,GL,SE,SR,STD,XE)..(EUR,GEN,SAA) |
1 | ||
| Common parts | ||||
| 90170-08204 | ||||
| 91111-40814 | ||||
| 94512-00800 | ||||
