BB58L-ZEFSZ (1999)
Toyota Coaster
(9907- )BB50,58..LHD
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 44610 - BOOSTER ASSY, BRAKE | ||||
| 44610-36510 |
BB50..WOC..GEN;BB58,HZB50..LHD..CBU |
1 | ||
| 44610-36530 |
BB5#,HZB50,RZB50..LHD..(GCC,GEN) W(FR DISC BRAKE:RR AUTO ADJUSTER) |
1 | ||
| 44610-36510 |
BB50,58,HZB50..LHD..(20S,23S,30S)..(GCC,GEN) |
1 | ||
| 44610-36510 |
BB58 |
1 | ||
| 44610-36530 |
BB50,58,HZB50,RZB50..LHD..(20S,23S,30S)..(GCC,GEN) W(FR DISC BRAKE:RR AUTO ADJUSTER) |
1 | ||
| 44610-36530 |
BB58 W(FR DISC BRAKE:RR AUTO ADJUSTER) |
1 | ||
| 44610 - BOOSTER ASSY, BRAKE | ||||
| 44610-36510 |
BB50..WOC..GEN;BB58,HZB50..LHD..CBU |
1 | ||
| 44610-36530 |
BB5#,HZB50,RZB50..LHD..(GCC,GEN) W(FR DISC BRAKE:RR AUTO ADJUSTER) |
1 | ||
| 44610-36510 |
BB50,58,HZB50..LHD..(20S,23S,30S)..(GCC,GEN) |
1 | ||
| 44610-36510 |
BB58 |
1 | ||
| 44610-36530 |
BB50,58,HZB50,RZB50..LHD..(20S,23S,30S)..(GCC,GEN) W(FR DISC BRAKE:RR AUTO ADJUSTER) |
1 | ||
| 44610-36530 |
BB58 W(FR DISC BRAKE:RR AUTO ADJUSTER) |
1 | ||
| 44704 - RESERVOIR SUB-ASSY, VACUUM | ||||
| 44704-36260 |
BB50..EX..TDEFI;BB58,59,BZB40,50;BB50..(EUR,GEN)..6F..TDEFI;BB50..(17S,21S,30S)..(ARL,GEN) |
1 | ||
| 44704-36260 |
BZB50..EX;BB5#..TDEFI |
1 | ||
| 44729 - GASKET, VACUUM TUBE | ||||
| 44729-36020 |
BB4#,5#,HZB50,RZB40,50 |
1 | ||
| 44729-36020 |
BZB50..EX;BB5#..TDEFI |
1 | ||
| 44729-36020 |
BB42..WC..GCC;BB42..SRF..GEN;BB42..LHD..HRF..WOC;HZB50..HRF..30S..WC;HZB50..LHD..SRF..WC;HZB50,RZB40..LHD..WOC..GEN;BB50..(EUR,GEN)..6F..TDEFI;BB50..(17S,21S,30S)..(ARL,GEN);BB58,59,BZB40,50,RZB50..GCC,GEN;BB42,50..HRF..(20S,26S)..WC..(DSL,TDEFI);HZB50,RZB40..LHD..(17S,20S,26S)..WC..(GCC,GEN) |
1 | ||
| 44730J - WAY(FOR BOOSTER VACUUM) | ||||
| 90414-09001 |
BB43,5#,HZB50..TD |
1 | ||
| 90414-09001 |
BB58,59;BB50..EX..TDEFI;BB50..(EUR,GEN)..6F..TDEFI;BB50..(17S,21S,30S)..(ARL,GEN) |
1 | ||
| 90414-09001 |
BB5#..TDEFI |
1 | ||
| 44730P - VALVE ASSY, VACUUM CHECK, NO.1 | ||||
| 44730-60050 |
BB50..EX..TDEFI;BB58,59,BZB40,50;BB50..(EUR,GEN)..6F..TDEFI;BB50..(17S,21S,30S)..(ARL,GEN) |
2 | ||
| 44730-60050 |
BZB50..EX;BB5#..TDEFI |
2 | ||
| 44730-60050 |
BB43,5#,HZB50..TD |
2 | ||
| 44730P - VALVE ASSY, VACUUM CHECK, NO.1 | ||||
| 44730-60050 |
BB50..EX..TDEFI;BB58,59,BZB40,50;BB50..(EUR,GEN)..6F..TDEFI;BB50..(17S,21S,30S)..(ARL,GEN) |
2 | ||
| 44730-60050 |
BZB50..EX;BB5#..TDEFI |
2 | ||
| 44730-60050 |
BB43,5#,HZB50..TD |
2 | ||
| 44743 - UNION(FOR VACUUM PUMP) | ||||
| 90405-09182 |
BB5#..TDEFI |
1 | ||
| 90405-09182 |
BB5#..TDEFI |
1 | ||
| 44754C - BRACKET, VACUUM TUBE, NO.1 | ||||
| 44754-36090 |
BB50..EX;BB50..LHD;BB4#,58,HZB50 |
2 | ||
| 44754-36090 |
BB58,59;BB42..WC..GCC;BB42..SRF..GEN;HZB50..LHD..EX;HZB50..LHD..WOC;BB42..LHD..HRF..WOC;HZB50..HRF..30S..WC;HZB50..LHD..SRF..WC;BB50..(EUR,GEN)..6F..TDEFI;BB50..(17S,21S,30S)..(ARL,GEN);BB42,50..HRF..(20S,26S)..WC..(DSL,TDEFI) |
2 | ||
| 44754-36090 |
BB5#..TDEFI |
2 | ||
| 44754D - BRACKET, VACUUM TUBE, NO.2 | ||||
| 44754-36110 |
BB4#,5#,HZB50 |
1 | ||
| 44754-36110 |
BB58,59;BB42..WC..GCC;BB42..SRF..GEN;HZB50..LHD..EX;HZB50..LHD..WOC;BB42..LHD..HRF..WOC;HZB50..HRF..30S..WC;HZB50..LHD..SRF..WC;BB50..(EUR,GEN)..6F..TDEFI;BB50..(17S,21S,30S)..(ARL,GEN);BB42,50..HRF..(20S,26S)..WC..(DSL,TDEFI) |
1 | ||
| 44754-36110 |
BB5#..TDEFI |
1 | ||
| 44754E - BRACKET, VACUUM TUBE, NO.3 | ||||
| 44754-36120 |
BB4#,5#,HZB50 |
1 | ||
| 44754-36160 |
BB50..ARL;BB50,58..LHD..TDEFI |
1 | ||
| 44754-36160 |
BB50..ARL;BB50,58..LHD..TDEFI |
1 | ||
| 44754F - BRACKET, VACUUM TUBE, NO.4 | ||||
| 44754-36130 |
BB4#,5#,HZB50 |
1 | ||
| 44754-36130 |
BZB50..EX;BB5#..TDEFI |
1 | ||
| 44754-36130 |
BB42..WC..GCC;BB42..SRF..GEN;HZB50..LHD..EX;HZB50..LHD..WOC;BB58,59,BZB40,50;BB42..LHD..HRF..WOC;HZB50..HRF..30S..WC;HZB50..LHD..SRF..WC;BB50..(EUR,GEN)..6F..TDEFI;BB50..(17S,21S,30S)..(ARL,GEN);BB42,50..HRF..(20S,26S)..WC..(DSL,TDEFI) |
1 | ||
| 44754G - BRACKET, VACUUM TUBE, NO.5 | ||||
| 44754-36140 |
BB42..WC..GCC;BB42..SRF..GEN;HZB50..LHD..EX;HZB50..LHD..WOC;BB58,59,BZB40,50;BB42..LHD..HRF..WOC;HZB50..HRF..30S..WC;HZB50..LHD..SRF..WC;BB50..(EUR,GEN)..6F..TDEFI;BB50..(17S,21S,30S)..(ARL,GEN);BB42,50..HRF..(20S,26S)..WC..(DSL,TDEFI) |
1 | ||
| 44754-36140 |
BZB50..EX;BB5#..TDEFI |
1 | ||
| 44756 - BRACKET, VACUUM RESERVOIR | ||||
| 44757-36060 |
BB42..WC..GCC;BB42..SRF..GEN;HZB50..LHD..EX;HZB50..LHD..WOC;BB58,59,BZB40,50;BB42..LHD..HRF..WOC;HZB50..HRF..30S..WC;HZB50..LHD..SRF..WC;BB50..(EUR,GEN)..6F..TDEFI;BB50..(17S,21S,30S)..(ARL,GEN);BB42,50..HRF..(20S,26S)..WC..(DSL,TDEFI) |
1 | ||
| 44757-36060 |
BB4#,5#,HZB50 |
1 | ||
| 44757-36060 |
BZB50..EX;BB5#..TDEFI |
1 | ||
| 44761 - TUBE, INTAKE MANIFOLD OR VACUUM PUMP TO CONNECTOR | ||||
| 44761-36210 |
BB50..ARL;BB50,58..LHD..TDEFI |
1 | ||
| 44761-36210 |
BB50..ARL;BB50,58..LHD..TDEFI |
1 | ||
| 44764G - TUBE, CONNECTOR TO BRAKE BOOSTER | ||||
| 44764-36540 |
BB50..ARL;BB50,58..LHD..TDEFI |
1 | ||
| 44764-36540 |
BB50..ARL;BB50,58..LHD..TDEFI |
1 | ||
| 44765 - TUBE, CONNECTOR TO BRAKE BOOSTER, NO.2 | ||||
| 44765-36300 |
BB50..LHD..TDEFI;BB50,58..(23S,30S)..GEN |
1 | ||
| 44765-36300 |
BB50,58..LHD..TDEFI |
1 | ||
| 44771 - HOSE, VACUUM TUBE CONNECTOR | ||||
| 44771-36240 |
BB43,5#,HZB50,RZB40,50 |
1 | ||
| 44771-36240 |
RZB40..WOC..GEN;BB50..LHD..TDEFI;RZB40..(17S,26S)..WC..(GCC,GEN);BB50,58,HZB50,RZB50..LHD..(20S,23S,30S)..(GCC,GEN) |
1 | ||
| 44771-36240 |
BB50,58..LHD..TDEFI |
1 | ||
| 44772 - HOSE, CHECK VALVE TO CONNECTOR TUBE | ||||
| 44772-36090 |
BB43,5#,HZB50..TD |
2 | ||
| 44772-36090 |
BB50..EX..TDEFI;BB58,59,BZB40,50;BB50..(EUR,GEN)..6F..TDEFI;BB50..(17S,21S,30S)..(ARL,GEN) |
2 | ||
| 44772-36090 |
BZB50..EX;BB5#..TDEFI |
2 | ||
| 44772 - HOSE, CHECK VALVE TO CONNECTOR TUBE | ||||
| 44772-36090 |
BB43,5#,HZB50..TD |
2 | ||
| 44772-36090 |
BB50..EX..TDEFI;BB58,59,BZB40,50;BB50..(EUR,GEN)..6F..TDEFI;BB50..(17S,21S,30S)..(ARL,GEN) |
2 | ||
| 44772-36090 |
BZB50..EX;BB5#..TDEFI |
2 | ||
| 44774 - HOSE, UNION TO CONNECTOR TUBE | ||||
| 44774-36320 |
BB5#..TDEFI |
1 | ||
| 44774-36320 |
BB5#..TDEFI |
1 | ||
| 44775C - HOSE, CONNECTOR TO WAY | ||||
| 44775-36030 |
BZB50..EX;BB5#..TDEFI |
1 | ||
| 44775-36030 |
BB42..WC..GCC;BB42..SRF..GEN;HZB50..LHD..EX;HZB50..LHD..WOC;BB58,59,BZB40,50;BB42..LHD..HRF..WOC;HZB50..HRF..30S..WC;HZB50..LHD..SRF..WC;BB50..(EUR,GEN)..6F..TDEFI;BB50..(17S,21S,30S)..(ARL,GEN);BB42,50..HRF..(20S,26S)..WC..(DSL,TDEFI) |
1 | ||
| 44775E - HOSE, WAY TO CONNECTOR | ||||
| 44775-36030 |
BB42..WC..GCC;BB42..SRF..GEN;HZB50..LHD..EX;HZB50..LHD..WOC;BB58,59,BZB40,50;BB42..LHD..HRF..WOC;HZB50..HRF..30S..WC;HZB50..LHD..SRF..WC;BB50..(EUR,GEN)..6F..TDEFI;BB50..(17S,21S,30S)..(ARL,GEN);BB42,50..HRF..(20S,26S)..WC..(DSL,TDEFI) |
1 | ||
| 44775-36030 |
BZB50..EX;BB5#..TDEFI |
1 | ||
| 44776 - HOSE, BRAKE BOOSTER | ||||
| 44776-36100 |
BB42,5#,HZB50,RZB40,50..LHD |
1 | ||
| 44776-36100 |
BB58 |
1 | ||
| 44776-36100 |
BB42..WC..GCC;RZB40..WOC..GEN;BB42..LHD..26S..GEN;RZB40..(17S,26S)..WC..(GCC,GEN);BB50,58,HZB50,RZB50..LHD..(20S,23S,30S)..(GCC,GEN) |
1 | ||
| 44776 - HOSE, BRAKE BOOSTER | ||||
| 44776-36100 |
BB42,5#,HZB50,RZB40,50..LHD |
1 | ||
| 44776-36100 |
BB58 |
1 | ||
| 44776-36100 |
BB42..WC..GCC;RZB40..WOC..GEN;BB42..LHD..26S..GEN;RZB40..(17S,26S)..WC..(GCC,GEN);BB50,58,HZB50,RZB50..LHD..(20S,23S,30S)..(GCC,GEN) |
1 | ||
| 47289 - LABEL, BRAKE MASTER CYLINDER ADJUST INFORMATION | ||||
| 47289-60010 |
BB50,HZB50..5F;HZB50..30S..4FC;BB42,58,RZB40,50..LHD |
1 | ||
| 47289-60010 |
BB50..5F..TDEFI;BB58,BZB50..21S,23S |
1 | ||
| 47289-60010 |
HZB50..LHD;BB42..WC..GCC;BB50..EX..TDEFI;RZB40..WOC..GEN;BB42..LHD..26S..GEN;RZB40..(17S,26S)..WC..(GCC,GEN);BB50,58,BZB40,50,RZB50..(17S,21S,23S,30S)..(GCC,GEN) |
1 | ||
| Common parts | ||||
| 90179-06161 | ||||
| 90179-08038 | ||||
| 90179-08233 | ||||
| 90461-10780 | ||||
| 90464-00682 | ||||
| 90949-01916 | ||||
| 91611-60814 | ||||
| 91651-60616 | ||||
| 91651-B0820 | ||||
| 96133-41500 | ||||
| Linked diagrams | ||||
| 3104 | ||||
| 8401 | ||||
