BB50L-ZRMRW1 (1997)
Toyota Coaster
(9301-9902)14B,15BFT,3B
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 29300 - PUMP ASSY, VACUUM | ||||
| 29300-58060 |
15BFT..BB50..GEN..IV;14B,15BFT,3B..BB40,42,58 |
1 | ||
| 29300-58050 |
15BFT..BB50..GEN..IV;14B,15BFT,3B..BB40,42,58 |
1 | ||
| 29300-58060 |
14B..BB42..22S;14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;14B..BB42..RHD..HRF..WOC |
1 | ||
| 29311 - PIN, VACUUM PUMP DOWEL, NO.1 | ||||
| 29311-76010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;1HZ..HZB50..RHD..SRF;1HZ..HZB50..RHD..(20S,22S)..GEN;14B,15BFT..BB4#,50..17S,19S,22S;14B,1HZ..BB42,HZB50..RHD..HRF..WOC..GEN |
2 | ||
| 29311-76010 |
14B,15BFT,3B,1HZ#..BB4#,5#,HZB50 |
2 | ||
| 29322B - BEARING, VACUUM PUMP | ||||
| 90099-10185 |
14B,15BFT,3B,1HZ#..BB4#,5#,HZB50 |
1 | ||
| 90099-10185 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;1HZ..HZB50..RHD..SRF;1HZ..HZB50..RHD..(20S,22S)..GEN;14B,15BFT..BB4#,50..17S,19S,22S;14B,1HZ..BB42,HZB50..RHD..HRF..WOC..GEN |
1 | ||
| 29331 - BLADE, VACUUM PUMP, A | ||||
| 29331-67020 |
15BFT..BB50..GEN..IV;14B,15BFT,3B,1HZ..BB40,42,58,HZB50 |
5 | ||
| 29331-27010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S |
5 | ||
| 29336 - SHAFT, VACUUM PUMP | ||||
| 29336-58050 |
14B,15BFT,3B,1HZ#..BB4#,5#,HZB50 |
1 | ||
| 29336-58060 |
14B,15BFT..BB4#,50 |
1 | ||
| 29336-58060 |
14B,15BFT,3B..BB4#,5# |
1 | ||
| 29336-58040 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S |
1 | ||
| 29342B - RING, O | ||||
| 29342-64010 |
14B,15BFT,3B..BB4#,5# NO.2 |
2 | ||
| 29342-58010 |
14B,15BFT,3B..BB4#,5# NO.1 |
2 | ||
| 29342-58010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S NO.1 |
2 | ||
| 29342-64010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S NO.2 |
2 | ||
| 29342B - RING, O | ||||
| 29342-64010 |
14B,15BFT,3B..BB4#,5# NO.2 |
2 | ||
| 29342-58010 |
14B,15BFT,3B..BB4#,5# NO.1 |
2 | ||
| 29342-58010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S NO.1 |
2 | ||
| 29342-64010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S NO.2 |
2 | ||
| 29342B - RING, O | ||||
| 29342-64010 |
14B,15BFT,3B..BB4#,5# NO.2 |
2 | ||
| 29342-58010 |
14B,15BFT,3B..BB4#,5# NO.1 |
2 | ||
| 29342-58010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S NO.1 |
2 | ||
| 29342-64010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S NO.2 |
2 | ||
| 29342B - RING, O | ||||
| 29342-64010 |
14B,15BFT,3B..BB4#,5# NO.2 |
2 | ||
| 29342-58010 |
14B,15BFT,3B..BB4#,5# NO.1 |
2 | ||
| 29342-58010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S NO.1 |
2 | ||
| 29342-64010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S NO.2 |
2 | ||
| 29351 - GEAR, VACUUM PUMP | ||||
| 29351-58050 |
14B,15BFT,3B..BB4#,5# |
1 | ||
| 29351-58050 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S |
1 | ||
| 29364 - WASHER, VACUUM PUMP | ||||
| 29364-66010 |
14B,15BFT,3B,1HZ#..BB4#,5#,HZB50 |
1 | ||
| 29364-66010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;1HZ..HZB50..RHD..SRF;1HZ..HZB50..RHD..(20S,22S)..GEN;14B,15BFT..BB4#,50..17S,19S,22S;14B,1HZ..BB42,HZB50..RHD..HRF..WOC..GEN |
1 | ||
| 29369 - VALVE SUB-ASSY, CHECK | ||||
| 29369-64030 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;1HZ..HZB50..RHD..SRF;1HZ..HZB50..RHD..(20S,22S)..GEN;14B,15BFT..BB4#,50..17S,19S,22S;14B,1HZ..BB42,HZB50..RHD..HRF..WOC..GEN |
1 | ||
| 29369-64030 |
14B,15BFT,3B,1HZ#..BB4#,5#,HZB50 |
1 | ||
| Common parts | ||||
| 90096-90031 | ||||
| 90099-04577 | ||||
| 90099-05185 | ||||
| 90201-14099 | ||||
| 90401-09001 | ||||
| 91612-61032 | ||||
| 95161-10413 | ||||
(9902- )14B,15B#,1BZFPE,3B
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 29300 - PUMP ASSY, VACUUM | ||||
| 29300-58060 |
15BFT..BB50..GEN..IV;14B,15BFT,3B..BB40,42,58 |
1 | ||
| 29300-58050 |
15BFT..BB50..GEN..IV;14B,15BFT,3B..BB40,42,58 |
1 | ||
| 29300-58060 |
14B..BB42..22S;14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;14B..BB42..RHD..HRF..WOC |
1 | ||
| 29300 - PUMP ASSY, VACUUM | ||||
| 29300-58060 |
15BFT..BB50..GEN..IV;14B,15BFT,3B..BB40,42,58 |
1 | ||
| 29300-58050 |
15BFT..BB50..GEN..IV;14B,15BFT,3B..BB40,42,58 |
1 | ||
| 29300-58060 |
14B..BB42..22S;14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;14B..BB42..RHD..HRF..WOC |
1 | ||
| 29303 - ROTOR SUB-ASSY, VACUUM PUMP | ||||
| 29337-27010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S |
1 | ||
| 29311 - PIN, VACUUM PUMP DOWEL, NO.1 | ||||
| 29311-76010 |
14B,15BFT,3B,1HZ#..BB4#,5#,HZB50 |
2 | ||
| 29311-76010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;1HZ..HZB50..RHD..SRF;1HZ..HZB50..RHD..(20S,22S)..GEN;14B,15BFT..BB4#,50..17S,19S,22S;14B,1HZ..BB42,HZB50..RHD..HRF..WOC..GEN |
2 | ||
| 29311 - PIN, VACUUM PUMP DOWEL, NO.1 | ||||
| 29311-76010 |
14B,15BFT,3B,1HZ#..BB4#,5#,HZB50 |
2 | ||
| 29311-76010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;1HZ..HZB50..RHD..SRF;1HZ..HZB50..RHD..(20S,22S)..GEN;14B,15BFT..BB4#,50..17S,19S,22S;14B,1HZ..BB42,HZB50..RHD..HRF..WOC..GEN |
2 | ||
| 29322B - BEARING, VACUUM PUMP | ||||
| 90099-10185 |
14B,15BFT,3B,1HZ#..BB4#,5#,HZB50 |
1 | ||
| 90099-10185 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;1HZ..HZB50..RHD..SRF;1HZ..HZB50..RHD..(20S,22S)..GEN;14B,15BFT..BB4#,50..17S,19S,22S;14B,1HZ..BB42,HZB50..RHD..HRF..WOC..GEN |
1 | ||
| 29331 - BLADE, VACUUM PUMP, A | ||||
| 29331-67020 |
15BFT..BB50..GEN..IV;14B,15BFT,3B,1HZ..BB40,42,58,HZB50 |
5 | ||
| 29331-27010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S |
5 | ||
| 29336 - SHAFT, VACUUM PUMP | ||||
| 29336-58050 |
14B,15BFT,3B,1HZ#..BB4#,5#,HZB50 |
1 | ||
| 29336-58060 |
14B,15BFT..BB4#,50 |
1 | ||
| 29336-58060 |
14B,15BFT,3B..BB4#,5# |
1 | ||
| 29336-58040 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S |
1 | ||
| 29342B - RING, O | ||||
| 29342-64010 |
14B,15BFT,3B..BB4#,5# NO.2 |
2 | ||
| 29342-58010 |
14B,15BFT,3B..BB4#,5# NO.1 |
2 | ||
| 29342-58010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S NO.1 |
2 | ||
| 29342-64010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S NO.2 |
2 | ||
| 29342B - RING, O | ||||
| 29342-64010 |
14B,15BFT,3B..BB4#,5# NO.2 |
2 | ||
| 29342-58010 |
14B,15BFT,3B..BB4#,5# NO.1 |
2 | ||
| 29342-58010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S NO.1 |
2 | ||
| 29342-64010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S NO.2 |
2 | ||
| 29342B - RING, O | ||||
| 29342-64010 |
14B,15BFT,3B..BB4#,5# NO.2 |
2 | ||
| 29342-58010 |
14B,15BFT,3B..BB4#,5# NO.1 |
2 | ||
| 29342-58010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S NO.1 |
2 | ||
| 29342-64010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S NO.2 |
2 | ||
| 29342B - RING, O | ||||
| 29342-64010 |
14B,15BFT,3B..BB4#,5# NO.2 |
2 | ||
| 29342-58010 |
14B,15BFT,3B..BB4#,5# NO.1 |
2 | ||
| 29342-58010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S NO.1 |
2 | ||
| 29342-64010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S NO.2 |
2 | ||
| 29351 - GEAR, VACUUM PUMP | ||||
| 29351-58050 |
14B,15BFT,3B..BB4#,5# |
1 | ||
| 29351-58050 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;14B..BB42..RHD..HRF..WOC;14B,15BFT..BB4#,50..17S,19S,22S |
1 | ||
| 29364 - WASHER, VACUUM PUMP | ||||
| 29364-66010 |
14B,15BFT,3B,1HZ#..BB4#,5#,HZB50 |
1 | ||
| 29364-66010 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;1HZ..HZB50..RHD..SRF;1HZ..HZB50..RHD..(20S,22S)..GEN;14B,15BFT..BB4#,50..17S,19S,22S;14B,1HZ..BB42,HZB50..RHD..HRF..WOC..GEN |
1 | ||
| 29369 - VALVE SUB-ASSY, CHECK | ||||
| 29369-64030 |
14B..BB42..WOC..GCC;15BFT..BB50..WOC..5F;15BFT..BB50..EX..GEN;1HZ..HZB50..RHD..SRF;1HZ..HZB50..RHD..(20S,22S)..GEN;14B,15BFT..BB4#,50..17S,19S,22S;14B,1HZ..BB42,HZB50..RHD..HRF..WOC..GEN |
1 | ||
| 29369-64030 |
14B,15BFT,3B,1HZ#..BB4#,5#,HZB50 |
1 | ||
| Common parts | ||||
| 90096-90031 | ||||
| 90099-04577 | ||||
| 90099-05185 | ||||
| 90201-14099 | ||||
| 90401-09001 | ||||
| 91612-61032 | ||||
| 95161-10413 | ||||
| Linked diagrams | ||||
| 4703 | ||||
