Toyota Coaster BB42 AUTOMATIC DOOR

BB42R-BRMSS (2011)

Toyota Coaster

Production Aug 2011 - Dec 2016

Engine 14B

Transmission 5F MTM

Displacement 2500cc

Power 168 HP (125 kW)

ILLUST NO. 1 OF 5(1209- )

Click highlighted areas on diagram

GLIDING TYPE

Part #	Description	Period	Qty
86650D - BUZZER ASSY
86650-36060	BB4#,5#,HZB50..CBU 24V	01/1993 - 11/1997	1
86659C - BRACKET, BUZZER, AUTOMATIC DOOR
86659-36010	BB4#,5#,HZB50,RZB40,50..CBU	01/1993 - 11/1997	1
Common parts
90109-06122
90119-08511
90202-08039
91651-40612
91651-40616

ILLUST NO. 1 OF 5(9301-1209)

Click highlighted areas on diagram

FOLDING TYPE

Part #	Description	Period	Qty
85610A - ACTUATOR ASSY, ACCEL INTER LOCK
85610-36020	BB4#,HZB50..RHD..DSL	01/1993 - 05/1997	1
85610-36070	BZB40,50,XZB40,5#..RHD 12V	01/2015 - 12/2999	1
85610-36060	BB42,HZB50..RHD 24V	01/2015 - 12/2999	1
85610A - ACTUATOR ASSY, ACCEL INTER LOCK
85610-36020	BB4#,HZB50..RHD..DSL	01/1993 - 05/1997	1
85610-36070	BZB40,50,XZB40,5#..RHD 12V	01/2015 - 12/2999	1
85610-36060	BB42,HZB50..RHD 24V	01/2015 - 12/2999	1
85629 - HOLDER, AUTOMATIC DOOR
85629-90B01	HZB50..SCO;BB4#,HZB50,RZB40,50..STD..CBU	01/1993 - 05/1997	1
85980B - RELAY ASSY, DOOR CONTROL (FOR AUTOMATIC DOOR)
85980-36090	BB40;BB42..WC;HZB50..WOC..ARL;HZB50..HRF..WC..DSL;HZB50..LHD..SRF..WC 24V	01/1993 - 09/1993	1
85980-36111	BB42,HZB50..RHD 24V	01/2015 - 12/2999	1
85980-36120	BZB40,50,XZB40,5#..RHD 12V	01/2015 - 12/2999	1
85980B - RELAY ASSY, DOOR CONTROL (FOR AUTOMATIC DOOR)
85980-36090	BB40;BB42..WC;HZB50..WOC..ARL;HZB50..HRF..WC..DSL;HZB50..LHD..SRF..WC 24V	01/1993 - 09/1993	1
85980-36111	BB42,HZB50..RHD 24V	01/2015 - 12/2999	1
85980-36120	BZB40,50,XZB40,5#..RHD 12V	01/2015 - 12/2999	1
86650D - BUZZER ASSY
86650-36060	BB4#,5#,HZB50..CBU 24V	01/1993 - 11/1997	1
86659C - BRACKET, BUZZER, AUTOMATIC DOOR
86659-36010	BB4#,5#,HZB50,RZB40,50..CBU	01/1993 - 11/1997	1
Common parts
90119-06255
90119-08354
90119-08357
90119-08535
91551-80608
91651-40616
91651-60835
Linked diagrams
7851

ILLUST NO. 2 OF 5(9301-1209)

Click highlighted areas on diagram

FOLDING TYPE UNIT

Part #	Description	Period	Qty
85069 - HOUSING SUB-ASSY, AUTO DOOR
85069-36020	HZB50..SCO;BB4#,HZB50,RZB40,50..STD..CBU FOLDING ELECTRIC AUTO DOOR,W(BUZZER)	01/1993 - 05/1997	1
85607 - GEAR SUB-ASSY, IDLE
85607-36010	HZB50..SCO;BB4#,HZB50,RZB40,50..STD..CBU FOLDING AUTO DOOR	01/1993 - 05/1997	1
85612 - GEAR, AUTOMATIC DOOR WORM WHEEL
85612-36010	HZB50..SCO;BB4#,HZB50..STD..DSL	01/1993 - 04/1993	1
85620 - MOTOR ASSY, AUTOMATIC DOOR REGULATOR
85620-36120	BB4#,HZB50..RHD..STD..DSL	01/1993 - 05/1995	1
85620-36510	BB42,HZB50..RHD FOLDING AUTO DOOR,24V	09/2012 - 01/2015	1
85620-36510	BB42,HZB50..RHD FOLDING AUTO DOOR,24V	01/2015 - 12/2999	1
85621 - MOTOR & LINK, AUTOMATIC DOOR REGULATOR
85621-36020	HZB50..SCO;BB4#,HZB50..RHD..STD..DSL FOLDING INTER LOCK	01/1993 - 05/1997	1
85622 - MOTOR & GEAR, AUTOMATIC DOOR REGULATOR
85622-36040	BB4#,HZB50..RHD..STD..DSL 24V,FOLDING DOOR	01/1993 - 05/1997	1
85622-36080	BB42,50,HZB50 24V,FOLDING DOOR	09/2012 - 01/2015	1
85622-36080	BB42,HZB50 24V,FOLDING DOOR	01/2015 - 12/2999	1
85623 - LINK, AUTOMATIC DOOR REGULATOR
85623-36020	HZB50..SCO;BB4#,HZB50,RZB40,50..STD..CBU FOLDING AUTO DOOR	01/1993 - 05/1995	1
85623-36050	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..CBU FOLDING AUTO DOOR	09/2012 - 01/2015	1
85623-36050	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..5F FOLDING AUTO DOOR	01/2015 - 12/2999	1
85624 - LEVER, AUTOMATIC DOOR REGULATOR, NO.1
85624-36010	HZB50..SCO;BB4#,HZB50,RZB40,50..STD..CBU FOLDING AUTO DOOR	01/1993 - 05/1997	1
85625A - RACK, AUTOMATIC DOOR
85625-36020	HZB50..SCO;BB4#,HZB50,RZB40,50..STD..CBU FOLDING AUTO DOOR	01/1993 - 05/1997	1
85625-36030	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..CBU FOLDING AUTO DOOR	09/2012 - 01/2015	1
85625-36030	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..5F FOLDING AUTO DOOR	01/2015 - 12/2999	1
85627 - STAY, AUTOMATIC DOOR REGULATOR
85627-36010	HZB50..SCO;BB4#,HZB50,RZB40,50..STD..CBU	01/1993 - 05/1995	1
85637 - REMOVER, AUTOMATIC DOOR
85637-90B00	BB4#,HZB50,RZB40,50..CBU	01/1993 - 05/1997	1
85980C - RELAY ASSY, DOOR CONTROL, NO.2 (FOR AUTOMATIC DOOR)
85980-36050	BB4#,HZB50..RHD..STD..DSL	01/1993 - 05/1997	1
85980-36210	BB42,HZB50 W(FOLDING DOOR AUTO) 24V	01/2015 - 12/2016	1
85980-36210	BB42,50,HZB50 W(FOLDING DOOR AUTO) 24V	09/2012 - 01/2015	1
85980D - RELAY ASSY, DOOR CONTROL, NO.3 (FOR AUTOMATIC DOOR)
85980-36080	HZB50..SCO;BB4#,HZB50..STD..DSL	01/1993 - 04/1993	2
85980D - RELAY ASSY, DOOR CONTROL, NO.3 (FOR AUTOMATIC DOOR)
85980-36080	HZB50..SCO;BB4#,HZB50..STD..DSL	01/1993 - 04/1993	2
Common parts
90463-12005
96150-01600

ILLUST NO. 3 OF 5(9301- )

Click highlighted areas on diagram

LABEL

Part #	Description	Period	Qty
85628 - LABEL, AUTOMATIC DOOR, NO.1
85628-90B03	BB50..EX;HZB50..SCO;BB50..WOC..GEN;BB4#,58,HZB50,RZB40,50..STD..CBU FOLDING AUTO DOOR	01/1993 - 07/1999	1
85628 - LABEL, AUTOMATIC DOOR, NO.1
85628-90B03	BB50..EX;HZB50..SCO;BB50..WOC..GEN;BB4#,58,HZB50,RZB40,50..STD..CBU FOLDING AUTO DOOR	01/1993 - 07/1999	1
85628A - LABEL, AUTOMATIC DOOR, NO.2
85628-36050	HZB50..SCO;BB4#,50..RHD..CBU;HZB50..RHD..STD..DSL FOLDING AUTO DOOR	01/1993 - 07/1999	1
85628-36210	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..5F FOLDING AUTO DOOR	01/2015 - 12/2999	1
85628-36210	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..CBU FOLDING AUTO DOOR	09/2012 - 01/2015	1
85628A - LABEL, AUTOMATIC DOOR, NO.2
85628-36050	HZB50..SCO;BB4#,50..RHD..CBU;HZB50..RHD..STD..DSL FOLDING AUTO DOOR	01/1993 - 07/1999	1
85628-36210	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..5F FOLDING AUTO DOOR	01/2015 - 12/2999	1
85628-36210	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..CBU FOLDING AUTO DOOR	09/2012 - 01/2015	1
85628F - LABEL, AUTOMATIC DOOR
85628-36111	BZB40,50,XZB40,5#..RHD..GEN	01/2015 - 12/2999	1
85628J - LABEL, AUTOMATIC DOOR NO.6
85628-36230	BB42,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..5F	01/2015 - 12/2999	1
85628-36230	BB42,50,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..CBU	09/2012 - 01/2015	1

ILLUST NO. 4 OF 5(9301-1501)

Click highlighted areas on diagram

AUTO DOOR OPENING SWITCH

Part #	Description	Period	Qty
84931A - SWITCH, AUTOMATIC DOOR CONTROL
84931-36011	BB42,HZB50,TRB40,50..GCC;BZB40,50,XZB40,5#..ARL,GEN,TAIW	08/2011 - 01/2015	1
84932 - BRACKET, DOOR CONTROL SWITCH
84932-36011	BZB40,50,XZB40,5#..RHD	01/2015 - 12/2999	1
84932 - BRACKET, DOOR CONTROL SWITCH
84932-36011	BZB40,50,XZB40,5#..RHD	01/2015 - 12/2999	1
85628F - LABEL, AUTOMATIC DOOR
85628-36111	BZB40,50,XZB40,5#..RHD..GEN	01/2015 - 12/2999	1
Common parts
90119-08354
90179-06162
90179-06308
93383-15010

ILLUST NO. 2 OF 5(1209- )

Click highlighted areas on diagram

FOLDING TYPE UNIT

Part #	Description	Period	Qty
69608A - LINK SUB-ASSY, CENTER DOOR REMOTE CONTROL
69608-36030	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..CBU	09/2012 - 01/2015	1
69608-36030	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..5F	01/2015 - 12/2999	1
82023 - WIRING SUB-ASSY, AUTO DOOR
82023-36020	BB42,HZB50..RHD W(FOLDING DOOR AUTO) 24V	09/2012 - 01/2015	1
82023-36020	BB42,HZB50..RHD W(FOLDING DOOR AUTO) 24V	01/2015 - 12/2999	1
84290N - SWITCH ASSY, LIMIT
84290-36010	BB42,50,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..CBU	09/2012 - 01/2015	1
84290-36010	BB42,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..5F	01/2015 - 12/2999	1
84934A - COVER, DOOR CONTROL SWITCH
84934-36010	BB42,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..5F	01/2015 - 12/2999	1
84934-36010	BB42,50,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..CBU	09/2012 - 01/2015	1
85620 - MOTOR ASSY, AUTOMATIC DOOR REGULATOR
85620-36120	BB4#,HZB50..RHD..STD..DSL	01/1993 - 05/1995	1
85620-36510	BB42,HZB50..RHD FOLDING AUTO DOOR,24V	09/2012 - 01/2015	1
85620-36510	BB42,HZB50..RHD FOLDING AUTO DOOR,24V	01/2015 - 12/2999	1
85621A - SWITCH & BASE, AUTO DOOR
85621-36040	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..5F	01/2015 - 12/2999	1
85621-36040	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..CBU	09/2012 - 01/2015	1
85622 - MOTOR & GEAR, AUTOMATIC DOOR REGULATOR
85622-36040	BB4#,HZB50..RHD..STD..DSL 24V,FOLDING DOOR	01/1993 - 05/1997	1
85622-36080	BB42,50,HZB50 24V,FOLDING DOOR	09/2012 - 01/2015	1
85622-36080	BB42,HZB50 24V,FOLDING DOOR	01/2015 - 12/2999	1
85623 - LINK, AUTOMATIC DOOR REGULATOR
85623-36020	HZB50..SCO;BB4#,HZB50,RZB40,50..STD..CBU FOLDING AUTO DOOR	01/1993 - 05/1995	1
85623-36050	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..CBU FOLDING AUTO DOOR	09/2012 - 01/2015	1
85623-36050	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..5F FOLDING AUTO DOOR	01/2015 - 12/2999	1
85625A - RACK, AUTOMATIC DOOR
85625-36020	HZB50..SCO;BB4#,HZB50,RZB40,50..STD..CBU FOLDING AUTO DOOR	01/1993 - 05/1997	1
85625-36030	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..CBU FOLDING AUTO DOOR	09/2012 - 01/2015	1
85625-36030	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..5F FOLDING AUTO DOOR	01/2015 - 12/2999	1
85628A - LABEL, AUTOMATIC DOOR, NO.2
85628-36050	HZB50..SCO;BB4#,50..RHD..CBU;HZB50..RHD..STD..DSL FOLDING AUTO DOOR	01/1993 - 07/1999	1
85628-36210	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..5F FOLDING AUTO DOOR	01/2015 - 12/2999	1
85628-36210	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..CBU FOLDING AUTO DOOR	09/2012 - 01/2015	1
85628J - LABEL, AUTOMATIC DOOR NO.6
85628-36230	BB42,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..5F	01/2015 - 12/2999	1
85628-36230	BB42,50,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..CBU	09/2012 - 01/2015	1
85639 - PLATE, AUTOMATIC DOOR
85639-36020	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..5F	01/2015 - 12/2999	1
85639-36020	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..CBU	09/2012 - 01/2015	1
85980C - RELAY ASSY, DOOR CONTROL, NO.2 (FOR AUTOMATIC DOOR)
85980-36050	BB4#,HZB50..RHD..STD..DSL	01/1993 - 05/1997	1
85980-36210	BB42,HZB50 W(FOLDING DOOR AUTO) 24V	01/2015 - 12/2016	1
85980-36210	BB42,50,HZB50 W(FOLDING DOOR AUTO) 24V	09/2012 - 01/2015	1
87116D - SPRING, HOLDING
87116-36010	BB42,50,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..CBU	09/2012 - 01/2015	1
87116-36010	BB42,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..5F	01/2015 - 12/2999	1
89136A - COVER, ECU AGGREGATION, NO.1
89136-36010	BB42,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..5F	01/2015 - 12/2999	1
89136-36010	BB42,50,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..CBU	09/2012 - 01/2015	1
89343A - BUZZER, CLEARANCE WARNING
89343-30010	BB42,50,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..CBU	09/2012 - 01/2015	1
89343-30010	BB42,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..5F	01/2015 - 12/2016	1
Common parts
85635-36010
90240-08053
90468-16028
Linked diagrams
8401

ILLUST NO. 1 OF 5(1209- )

Click highlighted areas on diagram

FOLDING TYPE

Part #	Description	Period	Qty
69068D - CABLE SUB-ASSY, CENTER DOOR REMOTE CONTROL, NO.2
69068-36020	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..5F	01/2015 - 12/2999	1
69068-36020	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..CBU	09/2012 - 01/2015	1
69638A - COVER, CENTER DOOR REMOTE CONTROL, NO.1
69638-36020B0	BB42,50,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..CBU MD.CHARCOAL,TRIM1#	09/2012 - 01/2015	1
69638-36020B0	BB42,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..5F MD.CHARCOAL,TRIM1#	01/2015 - 12/2016	1
89747G - BUZZER, WIRELESS DOOR LOCK
89747-30040	BB42,50,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..CBU	09/2012 - 01/2015	1
89747-30040	BB42,BZB40,50,HZB50,TRB40,50,XZB40,50..(EX,STD)..5F	01/2015 - 12/2999	1
Common parts
46451-36070
46452-36030
46453-36060
63399-36010B1
90119-08357
91653-A0616
91673-80835

ILLUST NO. 5 OF 5(1209- )

Click highlighted areas on diagram

ACCEL INTER LOCK & RELAY

Part #	Description	Period	Qty
85610A - ACTUATOR ASSY, ACCEL INTER LOCK
85610-36020	BB4#,HZB50..RHD..DSL	01/1993 - 05/1997	1
85610-36070	BZB40,50,XZB40,5#..RHD 12V	01/2015 - 12/2999	1
85610-36060	BB42,HZB50..RHD 24V	01/2015 - 12/2999	1
85610A - ACTUATOR ASSY, ACCEL INTER LOCK
85610-36020	BB4#,HZB50..RHD..DSL	01/1993 - 05/1997	1
85610-36070	BZB40,50,XZB40,5#..RHD 12V	01/2015 - 12/2999	1
85610-36060	BB42,HZB50..RHD 24V	01/2015 - 12/2999	1
85980B - RELAY ASSY, DOOR CONTROL (FOR AUTOMATIC DOOR)
85980-36090	BB40;BB42..WC;HZB50..WOC..ARL;HZB50..HRF..WC..DSL;HZB50..LHD..SRF..WC 24V	01/1993 - 09/1993	1
85980-36111	BB42,HZB50..RHD 24V	01/2015 - 12/2999	1
85980-36120	BZB40,50,XZB40,5#..RHD 12V	01/2015 - 12/2999	1
85980B - RELAY ASSY, DOOR CONTROL (FOR AUTOMATIC DOOR)
85980-36090	BB40;BB42..WC;HZB50..WOC..ARL;HZB50..HRF..WC..DSL;HZB50..LHD..SRF..WC 24V	01/1993 - 09/1993	1
85980-36111	BB42,HZB50..RHD 24V	01/2015 - 12/2999	1
85980-36120	BZB40,50,XZB40,5#..RHD 12V	01/2015 - 12/2999	1
85980B - RELAY ASSY, DOOR CONTROL (FOR AUTOMATIC DOOR)
85980-36090	BB40;BB42..WC;HZB50..WOC..ARL;HZB50..HRF..WC..DSL;HZB50..LHD..SRF..WC 24V	01/1993 - 09/1993	1
85980-36111	BB42,HZB50..RHD 24V	01/2015 - 12/2999	1
85980-36120	BZB40,50,XZB40,5#..RHD 12V	01/2015 - 12/2999	1
Common parts
90119-06255
91551-80608

ILLUST NO. 1 OF 5(9301-1209)

Click highlighted areas on diagram

GLIDING TYPE

Part #	Description	Period	Qty
85610A - ACTUATOR ASSY, ACCEL INTER LOCK
85610-36020	BB4#,HZB50..RHD..DSL	01/1993 - 05/1997	1
85610-36070	BZB40,50,XZB40,5#..RHD 12V	01/2015 - 12/2999	1
85610-36060	BB42,HZB50..RHD 24V	01/2015 - 12/2999	1
85610A - ACTUATOR ASSY, ACCEL INTER LOCK
85610-36020	BB4#,HZB50..RHD..DSL	01/1993 - 05/1997	1
85610-36070	BZB40,50,XZB40,5#..RHD 12V	01/2015 - 12/2999	1
85610-36060	BB42,HZB50..RHD 24V	01/2015 - 12/2999	1
85980B - RELAY ASSY, DOOR CONTROL (FOR AUTOMATIC DOOR)
85980-36090	BB40;BB42..WC;HZB50..WOC..ARL;HZB50..HRF..WC..DSL;HZB50..LHD..SRF..WC 24V	01/1993 - 09/1993	1
85980-36111	BB42,HZB50..RHD 24V	01/2015 - 12/2999	1
85980-36120	BZB40,50,XZB40,5#..RHD 12V	01/2015 - 12/2999	1
85980B - RELAY ASSY, DOOR CONTROL (FOR AUTOMATIC DOOR)
85980-36090	BB40;BB42..WC;HZB50..WOC..ARL;HZB50..HRF..WC..DSL;HZB50..LHD..SRF..WC 24V	01/1993 - 09/1993	1
85980-36111	BB42,HZB50..RHD 24V	01/2015 - 12/2999	1
85980-36120	BZB40,50,XZB40,5#..RHD 12V	01/2015 - 12/2999	1
86650D - BUZZER ASSY
86650-36060	BB4#,5#,HZB50..CBU 24V	01/1993 - 11/1997	1
86659C - BRACKET, BUZZER, AUTOMATIC DOOR
86659-36010	BB4#,5#,HZB50,RZB40,50..CBU	01/1993 - 11/1997	1
Common parts
90109-06122
90119-06255
90119-08511
90202-08039
91551-80608
91651-40612
91651-40616
Linked diagrams
7851

ILLUST NO. 4 OF 5(1501- )

Click highlighted areas on diagram

AUTO DOOR OPENING SWITCH

Part #	Description	Period	Qty
84931A - SWITCH, AUTOMATIC DOOR CONTROL
84931-36011	BB42,HZB50,TRB40,50..GCC;BZB40,50,XZB40,5#..ARL,GEN,TAIW	08/2011 - 01/2015	1
84932 - BRACKET, DOOR CONTROL SWITCH
84932-36011	BZB40,50,XZB40,5#..RHD	01/2015 - 12/2999	1
85628F - LABEL, AUTOMATIC DOOR
85628-36111	BZB40,50,XZB40,5#..RHD..GEN	01/2015 - 12/2999	1
Common parts
90179-06308
93383-15010

ILLUST NO. 2 OF 5(9301- )

Click highlighted areas on diagram

GLIDING TYPE UNIT

Part #	Description	Period	Qty
85069 - HOUSING SUB-ASSY, AUTO DOOR
85069-36020	HZB50..SCO;BB4#,HZB50,RZB40,50..STD..CBU FOLDING ELECTRIC AUTO DOOR,W(BUZZER)	01/1993 - 05/1997	1
85607 - GEAR SUB-ASSY, IDLE
85607-36010	HZB50..SCO;BB4#,HZB50,RZB40,50..STD..CBU FOLDING AUTO DOOR	01/1993 - 05/1997	1
85620 - MOTOR ASSY, AUTOMATIC DOOR REGULATOR
85620-36120	BB4#,HZB50..RHD..STD..DSL	01/1993 - 05/1995	1
85620-36510	BB42,HZB50..RHD FOLDING AUTO DOOR,24V	09/2012 - 01/2015	1
85620-36510	BB42,HZB50..RHD FOLDING AUTO DOOR,24V	01/2015 - 12/2999	1
85621 - MOTOR & LINK, AUTOMATIC DOOR REGULATOR
85621-36020	HZB50..SCO;BB4#,HZB50..RHD..STD..DSL FOLDING INTER LOCK	01/1993 - 05/1997	1
85622 - MOTOR & GEAR, AUTOMATIC DOOR REGULATOR
85622-36040	BB4#,HZB50..RHD..STD..DSL 24V,FOLDING DOOR	01/1993 - 05/1997	1
85622-36080	BB42,50,HZB50 24V,FOLDING DOOR	09/2012 - 01/2015	1
85622-36080	BB42,HZB50 24V,FOLDING DOOR	01/2015 - 12/2999	1
85623 - LINK, AUTOMATIC DOOR REGULATOR
85623-36020	HZB50..SCO;BB4#,HZB50,RZB40,50..STD..CBU FOLDING AUTO DOOR	01/1993 - 05/1995	1
85623-36050	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..CBU FOLDING AUTO DOOR	09/2012 - 01/2015	1
85623-36050	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..5F FOLDING AUTO DOOR	01/2015 - 12/2999	1
85624 - LEVER, AUTOMATIC DOOR REGULATOR, NO.1
85624-36010	HZB50..SCO;BB4#,HZB50,RZB40,50..STD..CBU FOLDING AUTO DOOR	01/1993 - 05/1997	1
85625A - RACK, AUTOMATIC DOOR
85625-36020	HZB50..SCO;BB4#,HZB50,RZB40,50..STD..CBU FOLDING AUTO DOOR	01/1993 - 05/1997	1
85625-36030	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..CBU FOLDING AUTO DOOR	09/2012 - 01/2015	1
85625-36030	BB42,BZB40,50,HZB50,XZB40,50..RHD..(EX,STD)..5F FOLDING AUTO DOOR	01/2015 - 12/2999	1
85637 - REMOVER, AUTOMATIC DOOR
85637-90B00	BB4#,HZB50,RZB40,50..CBU	01/1993 - 05/1997	1
85980C - RELAY ASSY, DOOR CONTROL, NO.2 (FOR AUTOMATIC DOOR)
85980-36050	BB4#,HZB50..RHD..STD..DSL	01/1993 - 05/1997	1
85980-36210	BB42,HZB50 W(FOLDING DOOR AUTO) 24V	01/2015 - 12/2016	1
85980-36210	BB42,50,HZB50 W(FOLDING DOOR AUTO) 24V	09/2012 - 01/2015	1
85980D - RELAY ASSY, DOOR CONTROL, NO.3 (FOR AUTOMATIC DOOR)
85980-36080	HZB50..SCO;BB4#,HZB50..STD..DSL	01/1993 - 04/1993	2
Common parts
90159-50131
90463-12005
90540-06004
96150-01800

BB42R-BRMSS (2011)

ILLUST NO. 1 OF 5(1209- )

ILLUST NO. 1 OF 5(9301-1209)

ILLUST NO. 2 OF 5(9301-1209)

ILLUST NO. 3 OF 5(9301- )

ILLUST NO. 4 OF 5(9301-1501)

ILLUST NO. 2 OF 5(1209- )

ILLUST NO. 1 OF 5(1209- )

ILLUST NO. 5 OF 5(1209- )

ILLUST NO. 1 OF 5(9301-1209)

ILLUST NO. 4 OF 5(1501- )

ILLUST NO. 2 OF 5(9301- )

Part Price Details
