ST182L-BKMGFW (1990)
Toyota Celica
(9108- )CVT
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 68211A - CLIP, DOOR BELT MOULDING | ||||
| 68211-20080 |
AT180,ST18# |
12 | ||
| 75623A - MOULDING, FRONT FENDER, OUTSIDE REAR RH | ||||
| 75623-2029008 |
ST182 SUPER WHITE 2,040 |
1 | ||
| 75623-2029012 |
ST182 SUPER RED 2,3E5 |
1 | ||
| 75623-2029002 |
ST182 RED MICA,3H4 |
1 | ||
| 75623-2029013 |
ST182 BLUISH GRAY M,182 |
1 | ||
| 75623-2029001 |
ST182 BLACK,202 |
1 | ||
| 75623-2029014 |
ST182 BLUE MICA M,8G7 |
1 | ||
| 75624A - MOULDING, FRONT FENDER, OUTSIDE REAR LH | ||||
| 75624-2028014 |
ST182 BLUE MICA M,8G7 |
1 | ||
| 75624-2028012 |
ST182 SUPER RED 2,3E5 |
1 | ||
| 75624-2028002 |
ST182 RED MICA,3H4 |
1 | ||
| 75624-2028008 |
ST182 SUPER WHITE 2,040 |
1 | ||
| 75624-2028013 |
ST182 BLUISH GRAY M,182 |
1 | ||
| 75624-2028001 |
ST182 BLACK,202 |
1 | ||
| 75651 - MOULDING, QUARTER, OUTSIDE RH | ||||
| 75651-2040008 |
ST182..NOB SUPER WHITE 2,040 |
1 | ||
| 75651-2040001 |
ST182..NOB BLACK,202 |
1 | ||
| 75651-2040012 |
ST182..NOB SUPER RED 2,3E5 |
1 | ||
| 75652 - MOULDING, QUARTER, OUTSIDE LH | ||||
| 75652-2037008 |
ST182..NOB SUPER WHITE 2,040 |
1 | ||
| 75652-2037001 |
ST182..NOB BLACK,202 |
1 | ||
| 75652-2037012 |
ST182..NOB SUPER RED 2,3E5 |
1 | ||
| 75710 - MOULDING ASSY, FRONT DOOR BELT, RH | ||||
| 75710-20330 |
AT180,ST18# |
1 | ||
| 75720 - MOULDING ASSY, FRONT DOOR BELT, LH | ||||
| 75720-20330 |
AT180,ST18# |
1 | ||
| 75731A - MOULDING, FRONT DOOR, OUTSIDE RH | ||||
| 75731-2052008 |
ST182 SUPER WHITE 2,040 |
1 | ||
| 75731-2052002 |
ST182 RED MICA,3H4 |
1 | ||
| 75731-2052013 |
ST182 BLUISH GRAY M,182 |
1 | ||
| 75731-2052014 |
ST182 BLUE MICA M,8G7 |
1 | ||
| 75731-2052012 |
ST182 SUPER RED 2,3E5 |
1 | ||
| 75731-2052001 |
ST182 BLACK,202 |
1 | ||
| 75732A - MOULDING, FRONT DOOR, OUTSIDE LH | ||||
| 75732-2052001 |
ST182 BLACK,202 |
1 | ||
| 75732-2052008 |
ST182 SUPER WHITE 2,040 |
1 | ||
| 75732-2052013 |
ST182 BLUISH GRAY M,182 |
1 | ||
| 75732-2052002 |
ST182 RED MICA,3H4 |
1 | ||
| 75732-2052012 |
ST182 SUPER RED 2,3E5 |
1 | ||
| 75732-2052014 |
ST182 BLUE MICA M,8G7 |
1 | ||
| Common parts | ||||
| 90159-60313 | ||||
| 90159-60318 | ||||
| 90164-40089 | ||||
| 90168-40079 | ||||
| 90183-04008 | ||||
| 90189-04182 | ||||
| 90467-06002 | ||||
| 90467-10081 | ||||
| Linked diagrams | ||||
| 6401 | ||||
(9010- )CVT
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 68211A - CLIP, DOOR BELT MOULDING | ||||
| 68211-20080 |
AT180,ST18# |
12 | ||
| 75623A - MOULDING, FRONT FENDER, OUTSIDE REAR RH | ||||
| 75623-2029008 |
ST182 SUPER WHITE 2,040 |
1 | ||
| 75623-2029012 |
ST182 SUPER RED 2,3E5 |
1 | ||
| 75623-2029002 |
ST182 RED MICA,3H4 |
1 | ||
| 75623-2029013 |
ST182 BLUISH GRAY M,182 |
1 | ||
| 75623-2029001 |
ST182 BLACK,202 |
1 | ||
| 75623-2029014 |
ST182 BLUE MICA M,8G7 |
1 | ||
| 75624A - MOULDING, FRONT FENDER, OUTSIDE REAR LH | ||||
| 75624-2028014 |
ST182 BLUE MICA M,8G7 |
1 | ||
| 75624-2028012 |
ST182 SUPER RED 2,3E5 |
1 | ||
| 75624-2028002 |
ST182 RED MICA,3H4 |
1 | ||
| 75624-2028008 |
ST182 SUPER WHITE 2,040 |
1 | ||
| 75624-2028013 |
ST182 BLUISH GRAY M,182 |
1 | ||
| 75624-2028001 |
ST182 BLACK,202 |
1 | ||
| 75651 - MOULDING, QUARTER, OUTSIDE RH | ||||
| 75651-2040008 |
ST182..NOB SUPER WHITE 2,040 |
1 | ||
| 75651-2040001 |
ST182..NOB BLACK,202 |
1 | ||
| 75651-2040012 |
ST182..NOB SUPER RED 2,3E5 |
1 | ||
| 75652 - MOULDING, QUARTER, OUTSIDE LH | ||||
| 75652-2037008 |
ST182..NOB SUPER WHITE 2,040 |
1 | ||
| 75652-2037001 |
ST182..NOB BLACK,202 |
1 | ||
| 75652-2037012 |
ST182..NOB SUPER RED 2,3E5 |
1 | ||
| 75710 - MOULDING ASSY, FRONT DOOR BELT, RH | ||||
| 75710-20330 |
AT180,ST18# |
1 | ||
| 75720 - MOULDING ASSY, FRONT DOOR BELT, LH | ||||
| 75720-20330 |
AT180,ST18# |
1 | ||
| 75731A - MOULDING, FRONT DOOR, OUTSIDE RH | ||||
| 75731-2052008 |
ST182 SUPER WHITE 2,040 |
1 | ||
| 75731-2052002 |
ST182 RED MICA,3H4 |
1 | ||
| 75731-2052013 |
ST182 BLUISH GRAY M,182 |
1 | ||
| 75731-2052014 |
ST182 BLUE MICA M,8G7 |
1 | ||
| 75731-2052012 |
ST182 SUPER RED 2,3E5 |
1 | ||
| 75731-2052001 |
ST182 BLACK,202 |
1 | ||
| 75732A - MOULDING, FRONT DOOR, OUTSIDE LH | ||||
| 75732-2052001 |
ST182 BLACK,202 |
1 | ||
| 75732-2052008 |
ST182 SUPER WHITE 2,040 |
1 | ||
| 75732-2052013 |
ST182 BLUISH GRAY M,182 |
1 | ||
| 75732-2052002 |
ST182 RED MICA,3H4 |
1 | ||
| 75732-2052012 |
ST182 SUPER RED 2,3E5 |
1 | ||
| 75732-2052014 |
ST182 BLUE MICA M,8G7 |
1 | ||
| Common parts | ||||
| 90159-60313 | ||||
| 90159-60318 | ||||
| 90164-40089 | ||||
| 90168-40079 | ||||
| 90183-04008 | ||||
| 90189-04182 | ||||
| 90467-06002 | ||||
| 90467-10081 | ||||
| Linked diagrams | ||||
| 6401 | ||||
