ST162L-BCPVFW (1985)
Toyota Celica
(8508- )CP,CVT
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 67771-32010 | ||||
| 90119-06186 | ||||
| 90168-40008 | ||||
| 90168-40055 | ||||
| 90183-04046 | ||||
| 90463-05024 | ||||
| 90467-05023 | ||||
| 90467-10016 | ||||
| 90468-05060 | ||||
| 90468-06038 | ||||
| 90959-01007 | ||||
| 90959-01009 | ||||
| 90959-01165 | ||||
| 93560-55014 | ||||
| Linked diagrams | ||||
| 7102 | ||||
(8508- )CP,CVT
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 62103 - BOARD SUB-ASSY, COWL SIDE TRIM, RH | ||||
| 62101-2016003 |
AT160,ST162..LHD GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62101-2016006 |
AT160,ST162..(CP,LB)..LHD BROWN,BROWN,TRIM4# |
1 | ||
| 62101-2016004 |
AT160,ST162..(CP,LB)..LHD BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62103A - INSULATOR SUB-ASSY, COWL SIDE, RH | ||||
| 62105-20090 |
AT160,ST162..LHD |
1 | ||
| 62104 - BOARD SUB-ASSY, COWL SIDE TRIM, LH | ||||
| 62102-2013003 |
AT160,ST162..LHD GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62102-2013006 |
AT160,ST162..(CP,LB)..LHD BROWN,BROWN,TRIM4# |
1 | ||
| 62102-2013004 |
AT160,ST162..(CP,LB)..LHD BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62104A - INSULATOR SUB-ASSY, COWL SIDE, LH | ||||
| 62106-20090 |
AT160,ST162..LHD |
1 | ||
| 62211 - GARNISH, FRONT PILLAR, RH | ||||
| 62210-2002004 |
ST162..CP,LB BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62210-2002003 |
ST162 GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62210-2002006 |
ST162..CP,LB BROWN,BROWN,TRIM4# |
1 | ||
| 62212 - GARNISH, FRONT PILLAR, LH | ||||
| 62220-2002004 |
ST162..CP,LB BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62220-2002003 |
ST162 GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62220-2002006 |
ST162..CP,LB BROWN,BROWN,TRIM4# |
1 | ||
| 62310A - CLIP, ROOF SIDE RAIL WEATHERSTRIP | ||||
| 67869-30020 |
AT160,ST162 |
8 | ||
| 62310A - CLIP, ROOF SIDE RAIL WEATHERSTRIP | ||||
| 67869-30020 |
AT160,ST162 |
8 | ||
| 62361 - RETAINER, ROOF SIDE RAIL WEATHERSTRIP, FRONT RH | ||||
| 62361-20030 |
AT160,ST162 |
1 | ||
| 62362 - RETAINER, ROOF SIDE RAIL WEATHERSTRIP, FRONT LH | ||||
| 62362-20030 |
AT160,ST162 |
1 | ||
| 62363 - RETAINER, ROOF SIDE RAIL WEATHERSTRIP, REAR RH | ||||
| 62371-20040 |
AT160,ST162 |
1 | ||
| 62364 - RETAINER, ROOF SIDE RAIL WEATHERSTRIP, REAR LH | ||||
| 62372-20030 |
AT160,ST162 |
1 | ||
| 62381 - WEATHERSTRIP, ROOF SIDE RAIL, FRONT RH | ||||
| 62381-20040 |
AT160,ST162 |
1 | ||
| 62382 - WEATHERSTRIP, ROOF SIDE RAIL, FRONT LH | ||||
| 62382-20040 |
AT160,ST162 |
1 | ||
| 62411 - GARNISH, CENTER PILLAR, RH | ||||
| 62411-2023006 |
AT160,ST162..CP,LB BROWN,BROWN,TRIM4# |
1 | ||
| 62411-2023004 |
AT160,ST162..CP,LB BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62411-2023003 |
AT160,ST162..CP,LB GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62412 - GARNISH, CENTER PILLAR, LH | ||||
| 62412-2023004 |
AT160,ST162..CP,LB BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62412-2023003 |
AT160,ST162..CP,LB GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62412-2023006 |
AT160,ST162..CP,LB BROWN,BROWN,TRIM4# |
1 | ||
| 62431C - GARNISH, ROOF SIDE RAIL, FRONT RH | ||||
| 62431-2003004 |
AT160,ST162..CP,LB BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62431-2003003 |
AT160,ST162..CP,LB GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62431-2003006 |
AT160,ST162..CP,LB BROWN,BROWN,TRIM4# |
1 | ||
| 62432C - GARNISH, ROOF SIDE RAIL, FRONT LH | ||||
| 62431-2003004 |
AT160,ST162..CP,LB BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62431-2003003 |
AT160,ST162..CP,LB GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62431-2003006 |
AT160,ST162..CP,LB BROWN,BROWN,TRIM4# |
1 | ||
| 62461 - GARNISH, ROOF SIDE TRIM, RH | ||||
| 62471-2021004 |
AT160,ST162..CP..EUG W/O RR 3-POINT SEAT BELT,BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62471-2022004 |
AT160,ST162..CP W/RR 3-POINT SEAT BELT,BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62471-2021006 |
AT160,ST162..CP BROWN,BROWN,TRIM4# |
1 | ||
| 62471-2021006 |
AT160,ST162..CP..EUG W/O RR 3-POINT SEAT BELT,BROWN,BROWN,TRIM4# |
1 | ||
| 62471-2022006 |
AT160,ST162..CP W/RR 3-POINT SEAT BELT,BROWN,BROWN,TRIM4# |
1 | ||
| 62471-2021003 |
AT160,ST162..CP..EUG W/O RR 3-POINT SEAT BELT,GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62471-2021003 |
AT160,ST162..CP GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62471-2021004 |
AT160,ST162..CP BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62471-2022003 |
AT160,ST162..CP W/RR 3-POINT SEAT BELT,GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62462 - GARNISH, ROOF SIDE TRIM, LH | ||||
| 62472-2024003 |
AT160,ST162..CP W/RR 3-POINT SEAT BELT,GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62472-2023003 |
AT160,ST162..CP..EUG W/O RR 3-POINT SEAT BELT,GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62472-2023003 |
AT160,ST162..CP GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62472-2024006 |
AT160,ST162..CP W/RR 3-POINT SEAT BELT,BROWN,BROWN,TRIM4# |
1 | ||
| 62472-2023004 |
AT160,ST162..CP BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62472-2023004 |
AT160,ST162..CP..EUG W/O RR 3-POINT SEAT BELT,BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62472-2024004 |
AT160,ST162..CP W/RR 3-POINT SEAT BELT,BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62472-2023006 |
AT160,ST162..CP..EUG W/O RR 3-POINT SEAT BELT,BROWN,BROWN,TRIM4# |
1 | ||
| 62472-2023006 |
AT160,ST162..CP BROWN,BROWN,TRIM4# |
1 | ||
| 62511 - BOARD, QUARTER INSIDE TRIM, RH | ||||
| 62511-2010003 |
AT160,ST162..CP..EUG..TWC W/O RR 3-POINT SEAT BELT,GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62511-2010004 |
AT160,ST162..CP..EUG..TWC W/O RR 3-POINT SEAT BELT,BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62511-2012006 |
AT160,ST162..CP..TWC W/RR 3-POINT SEAT BELT,BROWN,BROWN,TRIM4# |
1 | ||
| 62511-2012004 |
AT160,ST162..CP..TWC W/RR 3-POINT SEAT BELT,BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62511-2010006 |
AT160,ST162..CP..EUG..TWC W/O RR 3-POINT SEAT BELT,BROWN,BROWN,TRIM4# |
1 | ||
| 62511-2012003 |
AT160,ST162..CP..TWC W/RR 3-POINT SEAT BELT,GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62511B - CLIP (FOR QUARTER INSIDE TRIM BOARD) | ||||
| 90467-0601625 |
AT160,ST162..CP..TWC BEIGE,BEIGE,TRIM4# |
2 | ||
| 90467-0601620 |
AT160,ST162..CP..TWC BLUE,DEEP BLUE,TRIM8# |
2 | ||
| 90467-0601633 |
AT160,ST162..(CP,CVT)..TWC GRAY,GRAY,TRIM1# |
2 | ||
| 62512 - BOARD, QUARTER INSIDE TRIM, LH | ||||
| 62512-2010003 |
AT160,ST162..CP..EUG..TWC W/O RR 3-POINT SEAT BELT,GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62512-2010006 |
AT160,ST162..CP..EUG..TWC W/O RR 3-POINT SEAT BELT,BROWN,BROWN,TRIM4# |
1 | ||
| 62512-2012003 |
AT160,ST162..CP..TWC W/RR 3-POINT SEAT BELT,GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 62512-2012006 |
AT160,ST162..CP..TWC W/RR 3-POINT SEAT BELT,BROWN,BROWN,TRIM4# |
1 | ||
| 62512-2012004 |
AT160,ST162..CP..TWC W/RR 3-POINT SEAT BELT,BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62512-2010004 |
AT160,ST162..CP..EUG..TWC W/O RR 3-POINT SEAT BELT,BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 62538C - COVER, QUARTER TRIM, HOLE | ||||
| 62538-1401003 |
AT160,ST162 GRAY,SHADOW GRAY,TRIM1# |
2 | ||
| 62538-1401016 |
AT160,ST162..CP,LB BROWN,BROWN,TRIM4# |
2 | ||
| 62538-1401014 |
AT160,ST162..CP,LB BLUE,DEEP BLUE,TRIM8# |
2 | ||
| 62561 - PROTECTOR, ROCKER PANEL, INNER FRONT | ||||
| 62561-20060 |
AT160,ST162..CP,LB RH |
1 | ||
| 62562-20040 |
AT160,ST162..CP,LB LH |
1 | ||
| 62561 - PROTECTOR, ROCKER PANEL, INNER FRONT | ||||
| 62561-20060 |
AT160,ST162..CP,LB RH |
1 | ||
| 62562-20040 |
AT160,ST162..CP,LB LH |
1 | ||
| 67707B - ORNAMENT SUB-ASSY, QUARTER TRIM, RH | ||||
| 67707-2014003 |
AT160,ST162..TWC GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 67707-2005006 |
AT160,ST162..TWC BROWN,BROWN,TRIM4# |
1 | ||
| 67707-2014006 |
AT160,ST162..(CP,LB)..TWC BROWN,BROWN,TRIM4# |
1 | ||
| 67707-2005003 |
AT160,ST162..TWC GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 67707-2014004 |
AT160,ST162..(CP,LB)..TWC BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 67707-2005004 |
AT160,ST162..TWC BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 67708B - ORNAMENT SUB-ASSY, QUARTER TRIM, LH | ||||
| 67708-2005006 |
AT160,ST162..TWC BROWN,BROWN,TRIM4# |
1 | ||
| 67708-2015006 |
AT160,ST162..(CP,LB)..TWC BROWN,BROWN,TRIM4# |
1 | ||
| 67708-2005003 |
AT160,ST162..TWC GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 67708-2005004 |
AT160,ST162..TWC BLUE,DEEP BLUE,TRIM8# |
1 | ||
| 67708-2015003 |
AT160,ST162..TWC GRAY,SHADOW GRAY,TRIM1# |
1 | ||
| 67708-2015004 |
AT160,ST162..(CP,LB)..TWC BLUE,DEEP BLUE,TRIM8# |
1 | ||
| Common parts | ||||
| 67771-32010 | ||||
| 90168-40008 | ||||
| 90168-40055 | ||||
| 90463-05024 | ||||
| 90467-05023 | ||||
| 90467-10016 | ||||
| 90468-05060 | ||||
| 90468-06038 | ||||
| 90959-01007 | ||||
| 90959-01009 | ||||
| 90959-01165 | ||||
| 93560-55014 | ||||
| Linked diagrams | ||||
| 7102 | ||||
