RA61L-BLPSSW (1981)
Toyota Celica
(8108- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 86011A - CONDENSER, RADIO SETTING | ||||
| 90980-04036 |
MA61,RA6#,TA60 |
1 | ||
| 86120 - RECEIVER ASSY, RADIO | ||||
| 86120-14610 |
RA61,63,TA60..LHD..EUG (I)LW/MW/UKWMONA./ARI,5-BUTTON |
1 | ||
| 86120-14400 |
MA61,RA61,63,TA60..LHD..EUG (H)LW/MW/UKW,MONAURAL,5-BUTTON |
1 | ||
| 86120-14630 |
MA61,RA61,63,TA60..LHD..EUG (K)LW/MW/UKWSTEREO/TAPE PLAYER |
1 | ||
| 86120-14631 |
MA61,RA61,63,TA60..LHD..EUG (K)LW/MW/UKWSTEREO/TAPE PLAYER |
1 | ||
| 86120 - RECEIVER ASSY, RADIO | ||||
| 86120-14610 |
RA61,63,TA60..LHD..EUG (I)LW/MW/UKWMONA./ARI,5-BUTTON |
1 | ||
| 86120-14400 |
MA61,RA61,63,TA60..LHD..EUG (H)LW/MW/UKW,MONAURAL,5-BUTTON |
1 | ||
| 86120-14630 |
MA61,RA61,63,TA60..LHD..EUG (K)LW/MW/UKWSTEREO/TAPE PLAYER |
1 | ||
| 86120-14631 |
MA61,RA61,63,TA60..LHD..EUG (K)LW/MW/UKWSTEREO/TAPE PLAYER |
1 | ||
| 86124 - KNOB, RADIO RECEIVER CONTROL | ||||
| 86128-22030 |
MA61,RA61,63,TA60..EUG (J)(K)..(VOL) |
1 | ||
| 86128-22110 |
MA61,RA61,63,TA60..EUG (J)(K)..(TUNE) |
1 | ||
| 86128-14260 |
MA61,RA61,63,TA60..EUR (G)(H)(I)..(TONE) |
1 | ||
| 86128-14240 |
MA61,RA61,63,TA60..EUR (G)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86128-14520 |
AA63,MA61,RA61,63,TA60..LHD..EUG (H)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86124 - KNOB, RADIO RECEIVER CONTROL | ||||
| 86128-22030 |
MA61,RA61,63,TA60..EUG (J)(K)..(VOL) |
1 | ||
| 86128-22110 |
MA61,RA61,63,TA60..EUG (J)(K)..(TUNE) |
1 | ||
| 86128-14260 |
MA61,RA61,63,TA60..EUR (G)(H)(I)..(TONE) |
1 | ||
| 86128-14240 |
MA61,RA61,63,TA60..EUR (G)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86128-14520 |
AA63,MA61,RA61,63,TA60..LHD..EUG (H)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86124 - KNOB, RADIO RECEIVER CONTROL | ||||
| 86128-22030 |
MA61,RA61,63,TA60..EUG (J)(K)..(VOL) |
1 | ||
| 86128-22110 |
MA61,RA61,63,TA60..EUG (J)(K)..(TUNE) |
1 | ||
| 86128-14260 |
MA61,RA61,63,TA60..EUR (G)(H)(I)..(TONE) |
1 | ||
| 86128-14240 |
MA61,RA61,63,TA60..EUR (G)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86128-14520 |
AA63,MA61,RA61,63,TA60..LHD..EUG (H)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86124 - KNOB, RADIO RECEIVER CONTROL | ||||
| 86128-22030 |
MA61,RA61,63,TA60..EUG (J)(K)..(VOL) |
1 | ||
| 86128-22110 |
MA61,RA61,63,TA60..EUG (J)(K)..(TUNE) |
1 | ||
| 86128-14260 |
MA61,RA61,63,TA60..EUR (G)(H)(I)..(TONE) |
1 | ||
| 86128-14240 |
MA61,RA61,63,TA60..EUR (G)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86128-14520 |
AA63,MA61,RA61,63,TA60..LHD..EUG (H)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86124 - KNOB, RADIO RECEIVER CONTROL | ||||
| 86128-22030 |
MA61,RA61,63,TA60..EUG (J)(K)..(VOL) |
1 | ||
| 86128-22110 |
MA61,RA61,63,TA60..EUG (J)(K)..(TUNE) |
1 | ||
| 86128-14260 |
MA61,RA61,63,TA60..EUR (G)(H)(I)..(TONE) |
1 | ||
| 86128-14240 |
MA61,RA61,63,TA60..EUR (G)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86128-14520 |
AA63,MA61,RA61,63,TA60..LHD..EUG (H)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86211 - BRACKET, RADIO, NO.1 | ||||
| 86211-14170 |
RA61,63,TA60..LHD..EUG |
1 | ||
| 86212 - BRACKET, RADIO, NO.2 | ||||
| 86212-14140 |
RA61,63,TA60..LHD..EUG |
1 | ||
| 86280 - AMPLIFIER ASSY, STEREO COMPONENT | ||||
| 86280-19055 |
MA61,RA61,63,TA60..LHD..EUG LW/MW/UKW,W/5-SPEAKER |
1 | ||
| Common parts | ||||
| 90119-06005 | ||||
| 93229-15008 | ||||
| 93560-55012 | ||||
| 93567-15014 | ||||
(8108- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 86011A - CONDENSER, RADIO SETTING | ||||
| 90980-04036 |
MA61,RA6#,TA60 |
1 | ||
| 86120 - RECEIVER ASSY, RADIO | ||||
| 86120-14610 |
RA61,63,TA60..LHD..EUG (I)LW/MW/UKWMONA./ARI,5-BUTTON |
1 | ||
| 86120-14400 |
MA61,RA61,63,TA60..LHD..EUG (H)LW/MW/UKW,MONAURAL,5-BUTTON |
1 | ||
| 86120-14630 |
MA61,RA61,63,TA60..LHD..EUG (K)LW/MW/UKWSTEREO/TAPE PLAYER |
1 | ||
| 86120-14631 |
MA61,RA61,63,TA60..LHD..EUG (K)LW/MW/UKWSTEREO/TAPE PLAYER |
1 | ||
| 86124 - KNOB, RADIO RECEIVER CONTROL | ||||
| 86128-22030 |
MA61,RA61,63,TA60..EUG (J)(K)..(VOL) |
1 | ||
| 86128-22110 |
MA61,RA61,63,TA60..EUG (J)(K)..(TUNE) |
1 | ||
| 86128-14260 |
MA61,RA61,63,TA60..EUR (G)(H)(I)..(TONE) |
1 | ||
| 86128-14240 |
MA61,RA61,63,TA60..EUR (G)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86128-14520 |
AA63,MA61,RA61,63,TA60..LHD..EUG (H)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86124 - KNOB, RADIO RECEIVER CONTROL | ||||
| 86128-22030 |
MA61,RA61,63,TA60..EUG (J)(K)..(VOL) |
1 | ||
| 86128-22110 |
MA61,RA61,63,TA60..EUG (J)(K)..(TUNE) |
1 | ||
| 86128-14260 |
MA61,RA61,63,TA60..EUR (G)(H)(I)..(TONE) |
1 | ||
| 86128-14240 |
MA61,RA61,63,TA60..EUR (G)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86128-14520 |
AA63,MA61,RA61,63,TA60..LHD..EUG (H)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86124 - KNOB, RADIO RECEIVER CONTROL | ||||
| 86128-22030 |
MA61,RA61,63,TA60..EUG (J)(K)..(VOL) |
1 | ||
| 86128-22110 |
MA61,RA61,63,TA60..EUG (J)(K)..(TUNE) |
1 | ||
| 86128-14260 |
MA61,RA61,63,TA60..EUR (G)(H)(I)..(TONE) |
1 | ||
| 86128-14240 |
MA61,RA61,63,TA60..EUR (G)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86128-14520 |
AA63,MA61,RA61,63,TA60..LHD..EUG (H)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86124 - KNOB, RADIO RECEIVER CONTROL | ||||
| 86128-22030 |
MA61,RA61,63,TA60..EUG (J)(K)..(VOL) |
1 | ||
| 86128-22110 |
MA61,RA61,63,TA60..EUG (J)(K)..(TUNE) |
1 | ||
| 86128-14260 |
MA61,RA61,63,TA60..EUR (G)(H)(I)..(TONE) |
1 | ||
| 86128-14240 |
MA61,RA61,63,TA60..EUR (G)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86128-14520 |
AA63,MA61,RA61,63,TA60..LHD..EUG (H)(I)..(TUNE)(SW/VOL) |
2 | ||
| 86211 - BRACKET, RADIO, NO.1 | ||||
| 86211-14170 |
RA61,63,TA60..LHD..EUG |
1 | ||
| 86212 - BRACKET, RADIO, NO.2 | ||||
| 86212-14140 |
RA61,63,TA60..LHD..EUG |
1 | ||
| 86280 - AMPLIFIER ASSY, STEREO COMPONENT | ||||
| 86280-19055 |
MA61,RA61,63,TA60..LHD..EUG LW/MW/UKW,W/5-SPEAKER |
1 | ||
| Common parts | ||||
| 90119-06005 | ||||
| 93229-15008 | ||||
| 93567-15014 | ||||
