AT190R-ALPNKW (1992)
Toyota Carina E Sed/Lb(Jpp)
(9202- )JPP
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 55539A - COVER, SPARE SWITCH HOLE | ||||
| 55539-12120J0 |
AT190,CT190,ST191..JPP..(GL,XL) DARK BLUE,TRIM8# |
1 | ||
| 55539-12120C0 |
AT190,CT190,ST191..JPP BLACK,TRIM2# |
1 | ||
| 55539-12120C0 |
AT190,CT190,ST191..JPP BLACK,TRIM2# |
1 | ||
| 55539B - COVER, SPARE SWITCH HOLE, NO.2 | ||||
| 55539-12120C0 |
AT190,CT190,ST191..JPP BLACK,TRIM2# |
1 | ||
| 55539-12120C0 |
AT190,CT190,ST191..JPP BLACK,TRIM2# |
1 | ||
| 55539-12120J0 |
AT190,CT190,ST191..JPP..(GL,XL) DARK BLUE,TRIM8# |
1 | ||
| 55539J - COVER, SPARE SWITCH HOLE | ||||
| 55539-12120C0 |
AT190,CT190,ST191..JPP BLACK,TRIM2# |
1 | ||
| 55539-12120C0 |
AT190,CT190,ST191..JPP BLACK,TRIM2# |
1 | ||
| 55539-12120J0 |
AT190,CT190,ST191..JPP..(GL,XL) DARK BLUE,TRIM8# |
1 | ||
| 55619D - COVER, CUP HOLDER HOLE | ||||
| 55619-20010C0 |
AT190,CT190,ST191..JPP BLACK,TRIM2# |
1 | ||
| 55619-20010J0 |
AT190,CT190,ST191..JPP..(GL,XL) DK.BLUE,TRIM8# |
1 | ||
| 58815A - CARPET, CONSOLE BOX | ||||
| 58815-20030J0 |
AT190,CT190,ST191..JPP..RHD..(GL,XL) DK.BLUE,TRIM8# |
1 | ||
| 58815-20030C0 |
AT190,CT190,ST191..JPP..RHD BLACK,TRIM2# |
1 | ||
| 58843 - BEZEL, SHIFTING HOLE | ||||
| 58843-20060 |
AT190,ST191..JPP..RHD..ATM |
1 | ||
| 58901A - BOX SUB-ASSY, CONSOLE, REAR | ||||
| 58901-20120C0 |
AT190,CT190,ST191..JPP..RHD BLACK,TRIM2# |
1 | ||
| 58901-20120C1 |
AT190,CT190,ST191..JPP..RHD BLACK,TRIM2# |
1 | ||
| 58901-20120J0 |
AT190,CT190,ST191..JPP..RHD..(GL,XL) DK.BLUE,TRIM8# |
1 | ||
| 58905 - DOOR SUB-ASSY, CONSOLE COMPARTMENT | ||||
| 58905-20170C0 |
AT190,CT190,ST191..JPP BLACK,TRIM2# |
1 | ||
| 58905-20170J0 |
AT190,CT190,ST191..JPP..(GL,XL) DK.BLUE,TRIM8# |
1 | ||
| 58909A - STOPPER SUB-ASSY, CONSOLE COMPARTMENT DOOR | ||||
| 58909-20030 |
AT190,CT190,ST191..JPP |
1 | ||
| 58941A - COVER, PARKING BRAKE HOLE | ||||
| 58904-20030C0 |
AT190,CT190,ST191..JPP..RHD BLACK,TRIM2# |
1 | ||
| 58904-20030J0 |
AT190,CT190,ST191..JPP..RHD..(GL,XL) DK.BLUE,TRIM8# |
1 | ||
| 58964 - STOPPER, CONSOLE COMPARTMENT DOOR, NO.1 | ||||
| 58964-12040 |
AT190,CT190,ST191..JPP RH |
1 | ||
| 58965-12040 |
AT190,CT190,ST191..JPP LH |
1 | ||
| 58976 - STRIKER, CONSOLE COMPARTMENT DOOR LOCK | ||||
| 58976-20020 |
AT190,CT190,ST191..JPP |
1 | ||
| 58985 - RETAINER, CONSOLE BOX | ||||
| 58985-20050 |
AT190,CT190,ST191..JPP |
2 | ||
| Common parts | ||||
| 90183-05094 | ||||
| 90468-04157 | ||||
| 90541-04024 | ||||
| 91665-40616 | ||||
| 93567-54512 | ||||
| 93567-55016 | ||||
| Linked diagrams | ||||
| 7404 | ||||
