AT190L-BEMNKW (1992)
Toyota Carina E (Ukp)
(9212-9505)UKP
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 53704D - SUPPORT SUB-ASSY, BATTERY, LH | ||||
| 53704-20010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57101 - MEMBER SUB-ASSY, FRONT SIDE, RH | ||||
| 57101-05011 |
AT19#..UKP |
1 | ||
| 57101-05012 |
AT19#..UKP |
1 | ||
| 57101-05900 |
AT19#..UKP |
1 | ||
| 57102 - MEMBER SUB-ASSY, FRONT SIDE, LH | ||||
| 57102-05900 |
AT19#..UKP |
1 | ||
| 57102-05011 |
AT19#..UKP |
1 | ||
| 57111 - MEMBER, FRONT SIDE, RH | ||||
| 57111-05010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57112 - MEMBER, FRONT SIDE, LH | ||||
| 57112-05010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57113 - EXTENSION, FRONT SIDE MEMBER, RH | ||||
| 57113-20150 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57113-20151 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57114 - EXTENSION, FRONT SIDE MEMBER, LH | ||||
| 57114-20121 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57114-20120 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57115A - PLATE, FRONT SIDE MEMBER, OUTER RH | ||||
| 57115-20150 |
AT190,ST191..UKP |
1 | ||
| 57115-20160 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57115-20160 |
AT19#,CT190,ST191..UKP..LHD |
1 | ||
| 57115-20150 |
AT190..UKP |
1 | ||
| 57116A - PLATE, FRONT SIDE MEMBER, OUTER LH | ||||
| 57116-20181 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57116-20170 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57197 - BOX, TORQUE, FRONT RH | ||||
| 57197-20040 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57198 - BOX, TORQUE, FRONT LH | ||||
| 57198-20050 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57271 - EXTENSION, STEERING GEAR BOX SUPPORT MEMBER, RH | ||||
| 57271-20041 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57271-20040 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57272 - EXTENSION, STEERING GEAR BOX SUPORT MEMBER, LH | ||||
| 57272-20040 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57272-20041 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57401 - MEMBER SUB-ASSY, MAIN FLOOR SIDE, RH | ||||
| 57401-05030 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57401-05020 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57401-05010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57402 - MEMBER SUB-ASSY, MAIN FLOOR SIDE, LH | ||||
| 57402-05010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57402-05030 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57402-05020 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57417 - REINFORCEMENT, FRONT FLOOR UNDER, RH | ||||
| 57505-05010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57418 - REINFORCEMENT, FRONT FLOOR UNDER, LH | ||||
| 57506-05010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57451 - MEMBER, FRONT FLOOR CROSS | ||||
| 57408-05020 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57408-05900 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57475 - PLATE, FRONT FLOOR CROSSMEMBER | ||||
| 57475-05010 |
AT19#,CT190,ST191..UKP |
2 | ||
| 57512A - REINFORCEMENT, FRONT FLOOR, RH | ||||
| 57512-05010 |
AT19#,CT190,ST191..UKP..(LB,SED) |
1 | ||
| 57513A - REINFORCEMENT, FRONT FLOOR, LH | ||||
| 57513-05010 |
AT19#,CT190,ST191..UKP..(LB,SED) |
1 | ||
| 57601 - MEMBER SUB-ASSY, REAR FLOOR SIDE, RH | ||||
| 57601-05040 |
AT19#,CT190,ST191..UKP..SED |
1 | ||
| 57601-05010 |
AT19#,CT190,ST191..UKP..SED |
1 | ||
| 57602 - MEMBER SUB-ASSY, REAR FLOOR SIDE, LH | ||||
| 57602-05010 |
AT19#,CT190,ST191..UKP..SED |
1 | ||
| 57602-05020 |
AT19#,CT190,ST191..UKP..SED |
1 | ||
| 57605B - MEMBER SUB-ASSY, REAR FLOOR CROSS, NO.1 | ||||
| 57605-05010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57606C - MEMBER SUB-ASSY, REAR FLOOR CROSS, NO.2 | ||||
| 57606-05900 |
AT190,ST191..UKP |
1 | ||
| 57606-05030 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57606-05901 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57615A - MEMBER, REAR FLOOR SIDE, REAR RH | ||||
| 57615-20918 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57615-05900 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57616A - MEMBER, REAR FLOOR SIDE, REAR LH | ||||
| 57616-05900 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57695 - EXTENSION, REAR FLOOR CROSS REAR SIDE, RH | ||||
| 57695-20020 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57695-20020 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57696 - EXTENSION, REAR FLOOR CROSS REAR SIDE, LH | ||||
| 57696-20020 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57696-20020 |
AT19#,CT190,ST191..UKP |
1 | ||
| Common parts | ||||
| 90179-06060 | ||||
| 90333-30002 | ||||
| 90333-30004 | ||||
| 90950-01148 | ||||
| 90950-01259 | ||||
| 90950-01310 | ||||
| 90950-01356 | ||||
| 90950-01392 | ||||
| 90950-01511 | ||||
| 90950-01518 | ||||
| 90950-01527 | ||||
| 90950-01539 | ||||
| 90950-01631 | ||||
| 90950-01711 | ||||
| 90950-01826 | ||||
| 90950-01839 | ||||
(9505- )UKP
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 53704D - SUPPORT SUB-ASSY, BATTERY, LH | ||||
| 53704-20010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57101 - MEMBER SUB-ASSY, FRONT SIDE, RH | ||||
| 57101-05011 |
AT19#..UKP |
1 | ||
| 57101-05012 |
AT19#..UKP |
1 | ||
| 57101-05900 |
AT19#..UKP |
1 | ||
| 57102 - MEMBER SUB-ASSY, FRONT SIDE, LH | ||||
| 57102-05900 |
AT19#..UKP |
1 | ||
| 57102-05011 |
AT19#..UKP |
1 | ||
| 57111 - MEMBER, FRONT SIDE, RH | ||||
| 57111-05010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57112 - MEMBER, FRONT SIDE, LH | ||||
| 57112-05010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57113 - EXTENSION, FRONT SIDE MEMBER, RH | ||||
| 57113-20150 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57113-20151 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57114 - EXTENSION, FRONT SIDE MEMBER, LH | ||||
| 57114-20121 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57114-20120 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57115A - PLATE, FRONT SIDE MEMBER, OUTER RH | ||||
| 57115-20150 |
AT190,ST191..UKP |
1 | ||
| 57115-20160 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57115-20160 |
AT19#,CT190,ST191..UKP..LHD |
1 | ||
| 57115-20150 |
AT190..UKP |
1 | ||
| 57116A - PLATE, FRONT SIDE MEMBER, OUTER LH | ||||
| 57116-20181 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57116-20170 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57197 - BOX, TORQUE, FRONT RH | ||||
| 57197-20040 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57198 - BOX, TORQUE, FRONT LH | ||||
| 57198-20050 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57271 - EXTENSION, STEERING GEAR BOX SUPPORT MEMBER, RH | ||||
| 57271-20041 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57271-20040 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57272 - EXTENSION, STEERING GEAR BOX SUPORT MEMBER, LH | ||||
| 57272-20040 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57272-20041 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57401 - MEMBER SUB-ASSY, MAIN FLOOR SIDE, RH | ||||
| 57401-05030 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57401-05020 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57401-05010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57402 - MEMBER SUB-ASSY, MAIN FLOOR SIDE, LH | ||||
| 57402-05010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57402-05030 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57402-05020 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57417 - REINFORCEMENT, FRONT FLOOR UNDER, RH | ||||
| 57505-05010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57418 - REINFORCEMENT, FRONT FLOOR UNDER, LH | ||||
| 57506-05010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57451 - MEMBER, FRONT FLOOR CROSS | ||||
| 57408-05020 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57408-05900 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57452B - MEMBER, FRONT FLOOR CROSS, NO.2 | ||||
| 57452-05010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57453B - MEMBER, FRONT FLOOR CROSS, NO.3 | ||||
| 57453-05010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57475 - PLATE, FRONT FLOOR CROSSMEMBER | ||||
| 57475-05010 |
AT19#,CT190,ST191..UKP |
2 | ||
| 57512A - REINFORCEMENT, FRONT FLOOR, RH | ||||
| 57512-05010 |
AT19#,CT190,ST191..UKP..(LB,SED) |
1 | ||
| 57513A - REINFORCEMENT, FRONT FLOOR, LH | ||||
| 57513-05010 |
AT19#,CT190,ST191..UKP..(LB,SED) |
1 | ||
| 57601 - MEMBER SUB-ASSY, REAR FLOOR SIDE, RH | ||||
| 57601-05040 |
AT19#,CT190,ST191..UKP..SED |
1 | ||
| 57601-05010 |
AT19#,CT190,ST191..UKP..SED |
1 | ||
| 57602 - MEMBER SUB-ASSY, REAR FLOOR SIDE, LH | ||||
| 57602-05010 |
AT19#,CT190,ST191..UKP..SED |
1 | ||
| 57602-05020 |
AT19#,CT190,ST191..UKP..SED |
1 | ||
| 57605B - MEMBER SUB-ASSY, REAR FLOOR CROSS, NO.1 | ||||
| 57605-05010 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57606C - MEMBER SUB-ASSY, REAR FLOOR CROSS, NO.2 | ||||
| 57606-05900 |
AT190,ST191..UKP |
1 | ||
| 57606-05030 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57606-05901 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57606C - MEMBER SUB-ASSY, REAR FLOOR CROSS, NO.2 | ||||
| 57606-05900 |
AT190,ST191..UKP |
1 | ||
| 57606-05030 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57606-05901 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57615A - MEMBER, REAR FLOOR SIDE, REAR RH | ||||
| 57615-20918 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57615-05900 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57616A - MEMBER, REAR FLOOR SIDE, REAR LH | ||||
| 57616-05900 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57695 - EXTENSION, REAR FLOOR CROSS REAR SIDE, RH | ||||
| 57695-20020 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57695-20020 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57696 - EXTENSION, REAR FLOOR CROSS REAR SIDE, LH | ||||
| 57696-20020 |
AT19#,CT190,ST191..UKP |
1 | ||
| 57696-20020 |
AT19#,CT190,ST191..UKP |
1 | ||
| Common parts | ||||
| 90179-06060 | ||||
| 90333-30002 | ||||
| 90590-01539 | ||||
| 90950-01060 | ||||
| 90950-01259 | ||||
| 90950-01310 | ||||
| 90950-01426 | ||||
| 90950-01511 | ||||
| 90950-01518 | ||||
| 90950-01711 | ||||
| 90950-01871 | ||||
