AT171L-ALMNUW (1987)
Toyota Carina 2
(8712- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 42304 - CARRIER SUB-ASSY, REAR AXLE, RH | ||||
| 42304-20050 |
AT171,ST171..(LB,SED)..GL W(*66 & 13INCHES DISC WHEEL) |
1 | ||
| 42304-32020 |
AT171,CT170,ST171 |
1 | ||
| 42304A - BOLT (FOR REAR AXLE CARRIER) | ||||
| 90105-15001 |
AT171,CT170,ST171 |
4 | ||
| 42304B - NUT (FOR REAR AXLE CARRIER) | ||||
| 90179-15001 |
AT171,CT170,ST171 |
4 | ||
| 42305 - CARRIER SUB-ASSY, REAR AXLE, LH | ||||
| 42305-20050 |
AT171,ST171..(LB,SED)..GL W(*66 & 13INCHES DISC WHEEL) |
1 | ||
| 42305-32020 |
AT171,CT170,ST171 |
1 | ||
| 48231 - SPRING, COIL, REAR | ||||
| 48231-2B090 |
AT171,CT170,ST171..LB |
2 | ||
| 48231-2B140 |
AT171,CT170,ST171..LB |
2 | ||
| 48231-2B880 |
AT171..LB |
1 | ||
| 48258A - INSULATOR, REAR COIL SPRING, LOWER | ||||
| 48258-32010 |
AT171,CT170,ST171 |
2 | ||
| 48341 - BUMPER, REAR SPRING | ||||
| 48341-20120 |
AT171,CT170 |
2 | ||
| 48409 - CAM SUB-ASSY, REAR SUSPENSION TOE ADJUST | ||||
| 48409-32020 |
AT171,CT170,ST171 |
2 | ||
| 48452R - PLATE, REAR SUSPENSION TOE ADJUST, NO.2 | ||||
| 48452-32020 |
AT171,CT170,ST171 |
2 | ||
| 48530 - ABSORBER ASSY, SHOCK, REAR RH | ||||
| 48530-20240 |
AT171,CT170..LB,SED MARK 48540-20240 |
1 | ||
| 48540 - ABSORBER ASSY, SHOCK, REAR LH | ||||
| 48540-20240 |
AT171,CT170..LB,SED MARK 48540-20240 |
1 | ||
| 48703C - NUT(FOR REAR SUSPENSION ARM) | ||||
| 90179-12063 |
AT171,CT170,ST171 BODY SIDE |
2 | ||
| 90179-14019 |
AT171,CT170,ST171 CARRIER SIDE |
2 | ||
| 48703C - NUT(FOR REAR SUSPENSION ARM) | ||||
| 90179-12063 |
AT171,CT170,ST171 BODY SIDE |
2 | ||
| 90179-14019 |
AT171,CT170,ST171 CARRIER SIDE |
2 | ||
| 48703D - WASHER(FOR REAR SUSPENSION ARM) | ||||
| 90201-14017 |
AT171,CT170,ST171 CARRIER SIDE |
4 | ||
| 90209-13008 |
AT171,CT170,ST171 BODY SIDE |
2 | ||
| 48703D - WASHER(FOR REAR SUSPENSION ARM) | ||||
| 90201-14017 |
AT171,CT170,ST171 CARRIER SIDE |
4 | ||
| 90209-13008 |
AT171,CT170,ST171 BODY SIDE |
2 | ||
| 48703D - WASHER(FOR REAR SUSPENSION ARM) | ||||
| 90201-14017 |
AT171,CT170,ST171 CARRIER SIDE |
4 | ||
| 90209-13008 |
AT171,CT170,ST171 BODY SIDE |
2 | ||
| 48703E - BOLT(FOR REAR SUSPENSION ARM) | ||||
| 90105-14036 |
AT171,CT170,ST171 *14-1.5PX248-30 |
2 | ||
| 90105-12132 |
AT171,CT170,ST171 *12-1.25PX80-20 |
2 | ||
| 90105-12159 |
AT171,CT170,ST171 *12-1.25PX81.5-24 |
2 | ||
| 48703E - BOLT(FOR REAR SUSPENSION ARM) | ||||
| 90105-14036 |
AT171,CT170,ST171 *14-1.5PX248-30 |
2 | ||
| 90105-12132 |
AT171,CT170,ST171 *12-1.25PX80-20 |
2 | ||
| 90105-12159 |
AT171,CT170,ST171 *12-1.25PX81.5-24 |
2 | ||
| 48703E - BOLT(FOR REAR SUSPENSION ARM) | ||||
| 90105-14036 |
AT171,CT170,ST171 *14-1.5PX248-30 |
2 | ||
| 90105-12132 |
AT171,CT170,ST171 *12-1.25PX80-20 |
2 | ||
| 90105-12159 |
AT171,CT170,ST171 *12-1.25PX81.5-24 |
2 | ||
| 48710A - ARM ASSY, REAR SUSPENSION, NO.1 RH | ||||
| 48710-20060 |
AT171,CT170,ST171 |
1 | ||
| 48720A - ARM ASSY, REAR SUSPENSION, NO.1 LH | ||||
| 48720-20050 |
AT171,CT170,ST171 |
1 | ||
| 48730A - ARM ASSY, REAR SUSPENSION, NO.2 | ||||
| 48730-20060 |
AT171,CT170,ST171..LB,SED |
2 | ||
| 48750 - SUPPORT ASSY, REAR SUSPENSION | ||||
| 48750-20050 |
AT171,CT170,ST171 |
2 | ||
| 48750A - NUT(FOR REAR SUPPORT TO REAR SHOCK ABSORBER) | ||||
| 90179-14015 |
AT171,CT170,ST171 |
2 | ||
| 48750B - COLLAR(FOR REAR SUPPORT TO REAR SHOCK ABSORBER) | ||||
| 90387-15012 |
AT171,CT170,ST171 |
2 | ||
| 48750G - NUT(FOR REAR SUSPENSION SUPPORT) | ||||
| 90179-08122 |
AT171,CT170,ST171 |
6 | ||
| 48753 - COVER, REAR SUSPENSION SUPPORT | ||||
| 48753-12010 |
AT171,CT170,ST171 |
2 | ||
| 48780A - ROD ASSY, STRUT, REAR | ||||
| 48780-20040 |
AT171,CT170,ST171 |
2 | ||
| 48780B - BOLT(FOR STRUT ROD) | ||||
| 90119-12131 |
AT171,CT170,ST171 |
4 | ||
| 48780B - BOLT(FOR STRUT ROD) | ||||
| 90119-12131 |
AT171,CT170,ST171 |
4 | ||
| 48780C - NUT(FOR STRUT ROD) | ||||
| 90179-12065 |
AT171,CT170,ST171 BODY SIDE |
2 | ||
| 90179-12062 |
AT171,CT170,ST171 CARRIER SIDE |
2 | ||
| 48780C - NUT(FOR STRUT ROD) | ||||
| 90179-12065 |
AT171,CT170,ST171 BODY SIDE |
2 | ||
| 90179-12062 |
AT171,CT170,ST171 CARRIER SIDE |
2 | ||
| 48812 - BAR, STABILIZER, REAR | ||||
| 48812-20250 |
AT171,CT170 |
1 | ||
| 48818 - BUSH, STABILIZER, REAR | ||||
| 48818-20080 |
AT171,CT170 |
2 | ||
| 48830 - LINK ASSY, REAR STABILIZER | ||||
| 48830-32010 |
AT171,CT170,ST171 |
2 | ||
| 48830A - NUT(FOR REAR STABILIZER LINK) | ||||
| 90179-10054 |
AT171,CT170,ST171 |
4 | ||
| 48832A - BRACKET, REAR STABILIZER BAR, NO.1 | ||||
| 48832-32020 |
AT171..(LB,SED)..GL W(*66) |
2 | ||
| 48832-20020 |
AT171,CT170,ST171 |
2 | ||
| Common parts | ||||
| 48559-12070 | ||||
| 91615-60820 | ||||
