AT171L-ALMNKG (1987)
Toyota Carina 2
(8712- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45025D - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.1 | ||||
| 45025-20210 |
AT171..LHD W(POWER STEERING) |
1 | ||
| 45025-20190 |
AT171..LHD |
1 | ||
| 45026 - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.2 | ||||
| 45025-20220 |
AT171,CT170,ST171 |
1 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17196 |
AT171,CT170,ST171 T=1.35-1.45 |
2 | ||
| 90520-17042 |
AT171,CT170,ST171 T=1.20 |
2 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17196 |
AT171,CT170,ST171 T=1.35-1.45 |
2 | ||
| 90520-17042 |
AT171,CT170,ST171 T=1.20 |
2 | ||
| 45210 - SHAFT ASSY, STEERING MAIN | ||||
| 45210-12400 |
AT171,CT170,ST171 W(TILT STEERING) |
1 | ||
| 45210-20260 |
AT171,CT170,ST171 W(RIGID STEERING) |
1 | ||
| 45260 - SHAFT ASSY, STEERING INTERMEDIATE, NO.2 | ||||
| 45260-20100 |
AT171..LHD W(POWER STEERING) |
1 | ||
| 45260-20080 |
AT171..LHD |
1 | ||
| 45271 - CLAMP, STEERING COLUMN, UPPER | ||||
| 45271-12050 |
AT171,CT170,ST171 |
1 | ||
| 45271-12060 |
AT171,CT170,ST171 W(TILT STEERING) |
1 | ||
| 45273 - BUSH, STEERING MAIN SHAFT | ||||
| 45273-16010 |
AT171,CT170,ST171 |
1 | ||
| 45280A - BRACKET ASSY, STEERING COLUMN, UPPER | ||||
| 45280-12100 |
AT171,CT170,ST171 |
1 | ||
| 45280-20450 |
AT171 W(POWER STEERING & TILT STEERING) |
1 | ||
| 45280-12130 |
AT171 W(TILT STEERING) OR W(TILT STEERING & *EL) |
1 | ||
| 45280-12120 |
AT171 W(POWER STEERING & TILT STEERING) |
1 | ||
| 45280-20460 |
AT171 W(TILT STEERING) OR W(TILT STEERING & *EL) |
1 | ||
| 45280-12110 |
AT171,CT170,ST171 W(*EL) |
1 | ||
| 45286 - COVER, STEERING COLUMN | ||||
| 45286-2093801 |
AT171,ST171..LHD..LB..GL W(TILT STEERING),BLACK,TRIM1# |
1 | ||
| 45286-2093604 |
AT171,ST171..LHD..GL BLUE,TRIM8# |
1 | ||
| 45286-2093803 |
AT171,ST171..LHD..GL W(TILT STEERING),GRAY,TRIM1# |
1 | ||
| 45286-2093804 |
AT171,ST171..LHD..GL W(TILT STEERING),BLUE,TRIM8# |
1 | ||
| 45286-2093603 |
AT171,ST171..LHD..GL GRAY,TRIM1# |
1 | ||
| 45286-2093606 |
AT171,ST171..LHD..GL SABLE,TRIM4# |
1 | ||
| 45286-2093814 |
AT171,ST171..LHD..GL W(TILT STEERING),DARK BLUE,TRIM8# |
1 | ||
| 45286-2093806 |
AT171,ST171..LHD..GL W(TILT STEERING),SABLE,TRIM4# |
1 | ||
| 45286-2093614 |
AT171,ST171..LHD..GL DARK BLUE,TRIM8# |
1 | ||
| 45870 - TUBE ASSY, STEERING COLUMN | ||||
| 45870-12251 |
AT171,CT170,ST171..LHD |
1 | ||
| 45870-20230 |
AT171,CT170,ST171..LHD |
1 | ||
| 45870-12252 |
AT171,CT170,ST171..LHD |
1 | ||
| 45897 - BOLT, STEERING LOCK SET | ||||
| 45897-12020 |
AT171,CT170,ST171 |
2 | ||
| Common parts | ||||
| 90119-08560 | ||||
| 90154-50011 | ||||
| 90179-06097 | ||||
| 90179-10016 | ||||
| 90460-81001 | ||||
| 91656-40620 | ||||
| 93315-14012 | ||||
(8712- )
W(TILT STEERING)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45025D - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.1 | ||||
| 45025-20210 |
AT171..LHD W(POWER STEERING) |
1 | ||
| 45025-20190 |
AT171..LHD |
1 | ||
| 45026 - COVER SUB-ASSY, STEERING COLUMN HOLE, NO.2 | ||||
| 45025-20220 |
AT171,CT170,ST171 |
1 | ||
| 45201A - BEARING(FOR STEERING MAIN SHAFT) | ||||
| 90363-18004 |
AT171,CT170,ST171 |
1 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17196 |
AT171,CT170,ST171 T=1.35-1.45 |
2 | ||
| 90520-17042 |
AT171,CT170,ST171 T=1.20 |
2 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17196 |
AT171,CT170,ST171 T=1.35-1.45 |
2 | ||
| 90520-17042 |
AT171,CT170,ST171 T=1.20 |
2 | ||
| 45201G - SPRING, COMPRESSION(FOR STEERING MAIN SHAFT) | ||||
| 90501-40017 |
AT171,CT170,ST171 |
1 | ||
| 45204 - TUBE ASSY, STEERING COLUMN, LOWER | ||||
| 45204-20121 |
AT171,CT170,ST171 |
1 | ||
| 45204-20121 |
AT171,CT170,ST171 |
1 | ||
| 45204-20120 |
AT171,CT170,ST171 |
1 | ||
| 45205J - TUBE SUB-ASSY, STEERING COLUMN, UPPER | ||||
| 45205-12260 |
AT171,CT170,ST171..LHD |
1 | ||
| 45209 - YOKE SUB-ASSY, STEERING SLIDING | ||||
| 45209-32010 |
AT171,CT170,ST171 |
1 | ||
| 45210 - SHAFT ASSY, STEERING MAIN | ||||
| 45210-12400 |
AT171,CT170,ST171 W(TILT STEERING) |
1 | ||
| 45210-20260 |
AT171,CT170,ST171 W(RIGID STEERING) |
1 | ||
| 45215 - COLLAR, MAIN SHAFT BEARING THRUST | ||||
| 45215-12010 |
AT171,CT170,ST171 |
1 | ||
| 45231D - RING, HOLE SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90521-01005 |
AT171,CT170,ST171 |
1 | ||
| 45260 - SHAFT ASSY, STEERING INTERMEDIATE, NO.2 | ||||
| 45260-20100 |
AT171..LHD W(POWER STEERING) |
1 | ||
| 45260-20080 |
AT171..LHD |
1 | ||
| 45271 - CLAMP, STEERING COLUMN, UPPER | ||||
| 45271-12050 |
AT171,CT170,ST171 |
1 | ||
| 45271-12060 |
AT171,CT170,ST171 W(TILT STEERING) |
1 | ||
| 45273 - BUSH, STEERING MAIN SHAFT | ||||
| 45273-16010 |
AT171,CT170,ST171 |
1 | ||
| 45280A - BRACKET ASSY, STEERING COLUMN, UPPER | ||||
| 45280-12100 |
AT171,CT170,ST171 |
1 | ||
| 45280-20450 |
AT171 W(POWER STEERING & TILT STEERING) |
1 | ||
| 45280-12130 |
AT171 W(TILT STEERING) OR W(TILT STEERING & *EL) |
1 | ||
| 45280-12120 |
AT171 W(POWER STEERING & TILT STEERING) |
1 | ||
| 45280-20460 |
AT171 W(TILT STEERING) OR W(TILT STEERING & *EL) |
1 | ||
| 45280-12110 |
AT171,CT170,ST171 W(*EL) |
1 | ||
| 45286 - COVER, STEERING COLUMN | ||||
| 45286-2093801 |
AT171,ST171..LHD..LB..GL W(TILT STEERING),BLACK,TRIM1# |
1 | ||
| 45286-2093604 |
AT171,ST171..LHD..GL BLUE,TRIM8# |
1 | ||
| 45286-2093803 |
AT171,ST171..LHD..GL W(TILT STEERING),GRAY,TRIM1# |
1 | ||
| 45286-2093804 |
AT171,ST171..LHD..GL W(TILT STEERING),BLUE,TRIM8# |
1 | ||
| 45286-2093603 |
AT171,ST171..LHD..GL GRAY,TRIM1# |
1 | ||
| 45286-2093606 |
AT171,ST171..LHD..GL SABLE,TRIM4# |
1 | ||
| 45286-2093814 |
AT171,ST171..LHD..GL W(TILT STEERING),DARK BLUE,TRIM8# |
1 | ||
| 45286-2093806 |
AT171,ST171..LHD..GL W(TILT STEERING),SABLE,TRIM4# |
1 | ||
| 45286-2093614 |
AT171,ST171..LHD..GL DARK BLUE,TRIM8# |
1 | ||
| 45804C - WASHER, PLATE(FOR STEERING TILT LEVER) | ||||
| 90201-10283 |
AT171,CT170,ST171 |
2 | ||
| 45804C - WASHER, PLATE(FOR STEERING TILT LEVER) | ||||
| 90201-10283 |
AT171,CT170,ST171 |
2 | ||
| 45805A - SUPPORT SUB-ASSY, TILT STEERING | ||||
| 45805-12010 |
AT171,CT170,ST171 |
1 | ||
| 45805-12010 |
AT171,CT170,ST171 |
1 | ||
| 45805B - BUSH(FOR TILT STEERING SUPPORT) | ||||
| 90386-06031 |
AT171,CT170,ST171 |
4 | ||
| 90386-06031 |
AT171,CT170,ST171 |
4 | ||
| 45805C - SPRING, COMPRESSION(FOR TILT STEERING SUPPORT) | ||||
| 90501-20072 |
AT171,CT170,ST171 |
2 | ||
| 90501-20072 |
AT171,CT170,ST171 |
2 | ||
| 45819 - RETAINER, TILT LEVER | ||||
| 45819-12010 |
AT171,CT170,ST171 |
2 | ||
| 45819 - RETAINER, TILT LEVER | ||||
| 45819-12010 |
AT171,CT170,ST171 |
2 | ||
| 45826 - LEVER, STEERING TILT | ||||
| 45826-12020 |
AT171,CT170,ST171 |
1 | ||
| 45826A - SPRING, TENSION(FOR STEERING TILT LEVER) | ||||
| 90507-12029 |
AT171,CT170,ST171 |
2 | ||
| 45826A - SPRING, TENSION(FOR STEERING TILT LEVER) | ||||
| 90507-12029 |
AT171,CT170,ST171 |
2 | ||
| 45827A - LEVER, STEERING TILT SUB | ||||
| 45827-12011 |
AT171,CT170,ST171 |
1 | ||
| 45827-12010 |
AT171,CT170,ST171 |
1 | ||
| 45831 - BOLT, TILT LEVER LOCK, NO.1 | ||||
| 45831-12010 |
AT171,CT170,ST171 |
1 | ||
| 45855 - BOLT, TILT STEERING, NO.1 | ||||
| 45855-12020 |
AT171,CT170,ST171 OD=9.998-10.007 |
1 | ||
| 45855-12010 |
AT171,CT170,ST171 OD=9.989-9.998 |
1 | ||
| 45856 - BOLT, TILT STEERING, NO.2 | ||||
| 45856-12010 |
AT171,CT170,ST171 OD=9.989-9.998 |
1 | ||
| 45856-12020 |
AT171,CT170,ST171 OD=9.998-10.007 |
1 | ||
| 45865 - COLLAR, STEERING MAIN SHAFT | ||||
| 45865-12050 |
AT171,CT170,ST171 |
1 | ||
| 45866A - STOPPER, STEERING MAIN SHAFT BUSH | ||||
| 45866-12010 |
AT171,CT170,ST171 |
1 | ||
| 45890A - PAWL ASSY, TILT STEERING | ||||
| 45890-12020 |
AT171,CT170,ST171 LH |
1 | ||
| 45890-12030 |
AT171,CT170,ST171 RH |
1 | ||
| 45890A - PAWL ASSY, TILT STEERING | ||||
| 45890-12020 |
AT171,CT170,ST171 LH |
1 | ||
| 45890-12030 |
AT171,CT170,ST171 RH |
1 | ||
| 45890C - COLLAR(FOR TILT STEERING PAWL) | ||||
| 90389-07004 |
AT171,CT170,ST171 MARK 0 |
1 | ||
| 90389-07008 |
AT171,CT170,ST171 MARK A |
1 | ||
| 90389-07006 |
AT171,CT170,ST171 MARK 3 |
1 | ||
| 90389-07007 |
AT171,CT170,ST171 MARK 4 |
1 | ||
| 90389-07009 |
AT171,CT170,ST171 MARK 6 |
1 | ||
| 90389-07010 |
AT171,CT170,ST171 MARK 7 |
1 | ||
| 90389-07005 |
AT171,CT170,ST171 MARK 2 |
1 | ||
| 90389-07011 |
AT171,CT170,ST171 MARK 8 |
1 | ||
| 45890C - COLLAR(FOR TILT STEERING PAWL) | ||||
| 90389-07004 |
AT171,CT170,ST171 MARK 0 |
1 | ||
| 90389-07008 |
AT171,CT170,ST171 MARK A |
1 | ||
| 90389-07006 |
AT171,CT170,ST171 MARK 3 |
1 | ||
| 90389-07007 |
AT171,CT170,ST171 MARK 4 |
1 | ||
| 90389-07009 |
AT171,CT170,ST171 MARK 6 |
1 | ||
| 90389-07010 |
AT171,CT170,ST171 MARK 7 |
1 | ||
| 90389-07005 |
AT171,CT170,ST171 MARK 2 |
1 | ||
| 90389-07011 |
AT171,CT170,ST171 MARK 8 |
1 | ||
| 45893A - STOPPER, TILT STEERING PAWL | ||||
| 45893-12070 |
AT171,CT170,ST171 |
1 | ||
| 45893A - STOPPER, TILT STEERING PAWL | ||||
| 45893-12070 |
AT171,CT170,ST171 |
1 | ||
| 45897 - BOLT, STEERING LOCK SET | ||||
| 45897-12020 |
AT171,CT170,ST171 |
2 | ||
| Common parts | ||||
| 90119-06378 | ||||
| 90119-06569 | ||||
| 90119-08560 | ||||
| 90154-50011 | ||||
| 90179-06045 | ||||
| 90179-06097 | ||||
| 90179-10016 | ||||
| 90179-10065 | ||||
| 90206-10009 | ||||
| 90460-81001 | ||||
| 91611-60820 | ||||
| 91656-40620 | ||||
| 93315-14012 | ||||
| 94614-10600 | ||||
