AT171L-AEMDUG (1987)
Toyota Carina 2
(8712- )SED..XL
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71015 - FRAME SUB-ASSY, REAR SEAT CUSHION | ||||
| 71015-20290 |
AT171,CT170,ST171..SED |
1 | ||
| 71017A - FRAME SUB-ASSY, REAR SEAT BACK | ||||
| 71017-20380 |
AT171,CT170..SED..XL |
1 | ||
| 71075B - COVER, REAR SEAT CUSHION (FOR BENCH TYPE) | ||||
| 71065-2083003 |
AT171,CT170..SED..XL GRAY,TRIM1# |
1 | ||
| 71065-2083006 |
AT171,CT170..SED..XL SABLE,TRIM4# |
1 | ||
| 71065-2083004 |
AT171,CT170..SED..XL BLUE,TRIM8# |
1 | ||
| 71077B - COVER, REAR SEAT BACK (FOR BENCH TYPE) | ||||
| 71077-2D07006 |
AT171,CT170..SED..XL SABLE,TRIM4# |
1 | ||
| 71077-2D07003 |
AT171,CT170..SED..XL GRAY,TRIM1# |
1 | ||
| 71077-2D07004 |
AT171,CT170..SED..XL BLUE,TRIM8# |
1 | ||
| 71460B - CUSHION ASSY, REAR SEAT (FOR BENCH TYPE) | ||||
| 71560-2077006 |
AT171,CT170..SED..XL ***,SABLE,TRIM4# |
1 | ||
| 71560-2077004 |
AT171,CT170..SED..XL ***,BLUE,TRIM8# |
1 | ||
| 71560-2077003 |
AT171,CT170..SED..XL ***,GRAY,TRIM1# |
1 | ||
| 71480B - BACK ASSY, REAR SEAT (FOR BENCH TYPE) | ||||
| 71480-2D07003 |
AT171,CT170..SED..XL ***,GRAY,TRIM1# |
1 | ||
| 71480-2D07006 |
AT171,CT170..SED..XL ***,SABLE,TRIM4# |
1 | ||
| 71480-2D07004 |
AT171,CT170..SED..XL ***,BLUE,TRIM8# |
1 | ||
| 71611 - PAD, REAR SEAT CUSHION | ||||
| 71611-20420 |
AT171,CT170,ST171..SED |
1 | ||
| 71651B - PAD, REAR SEAT BACK(FOR BENCH TYPE) | ||||
| 71651-20470 |
AT171,CT170..SED..XL |
1 | ||
| 72693 - HOOK, REAR SEAT CUSHION LOCK | ||||
| 72693-20010 |
AT171,CT170,ST171..SED |
2 | ||
| Common parts | ||||
| 90119-08160 | ||||
| 90468-18071 | ||||
(8712- )SED
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 71015 - FRAME SUB-ASSY, REAR SEAT CUSHION | ||||
| 71015-20290 |
AT171,CT170,ST171..SED |
1 | ||
| 71017 - FRAME SUB-ASSY, REAR SEAT BACK, RH | ||||
| 71017-20380 |
AT171,CT170..SED..XL |
1 | ||
| 71017-20390 |
AT171,CT170..SED..XL W(FABRIC SEAT) |
1 | ||
| 71018 - FRAME SUB-ASSY, REAR SEAT BACK, LH | ||||
| 71018-20120 |
AT171,CT170,ST171..SED |
2 | ||
| 71075B - COVER, REAR SEAT CUSHION (FOR BENCH TYPE) | ||||
| 71065-2083003 |
AT171,CT170..SED..XL GRAY,TRIM1# |
1 | ||
| 71065-2083006 |
AT171,CT170..SED..XL SABLE,TRIM4# |
1 | ||
| 71065-2083004 |
AT171,CT170..SED..XL BLUE,TRIM8# |
1 | ||
| 71077S - COVER, REAR SEAT BACK, RH (FOR SEPARATE TYPE) | ||||
| 71077-2D08003 |
AT171,CT170..SED..XL GRAY,TRIM1# |
1 | ||
| 71077-2D08006 |
AT171,CT170..SED..XL SABLE,TRIM4# |
1 | ||
| 71077-2D08004 |
AT171,CT170..SED..XL BLUE,TRIM8# |
1 | ||
| 71078S - COVER, REAR SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71078-2049005 |
AT171,CT170..SED..XL SABLE,TRIM4# |
1 | ||
| 71078-2049003 |
AT171,CT170..SED..XL GRAY,TRIM1# |
1 | ||
| 71078-2049004 |
AT171,CT170..SED..XL BLUE,TRIM8# |
1 | ||
| 71303C - HINGE SUB-ASSY, REAR SEAT BACK, RH | ||||
| 71303-20040 |
AT171,CT170,ST171..SED |
1 | ||
| 71304C - HINGE SUB-ASSY, REAR SEAT BACK, LH | ||||
| 71304-20040 |
AT171,CT170,ST171..SED |
1 | ||
| 71305A - HINGE SUB-ASSY, REAR SEAT BACK, CENTER | ||||
| 71305-20070 |
AT171,CT170,ST171..SED |
1 | ||
| 71349C - COVER, REAR SEAT BACK HINGE | ||||
| 71349-32030J0 |
AT171,CT170,ST171 DARK BLUE,TRIM8# |
1 | ||
| 71349-3203006 |
AT171,CT170,ST171..LB,SED SABLE,TRIM4# |
1 | ||
| 71349-3203013 |
AT171,CT170,ST171 GRAY,TRIM1# |
1 | ||
| 71349-3203004 |
AT171,CT170,ST171 DARK BLUE,TRIM8# |
1 | ||
| 71460B - CUSHION ASSY, REAR SEAT (FOR BENCH TYPE) | ||||
| 71560-2077006 |
AT171,CT170..SED..XL ***,SABLE,TRIM4# |
1 | ||
| 71560-2077004 |
AT171,CT170..SED..XL ***,BLUE,TRIM8# |
1 | ||
| 71560-2077003 |
AT171,CT170..SED..XL ***,GRAY,TRIM1# |
1 | ||
| 71480S - BACK ASSY, REAR SEAT, RH (FOR SEPARATE TYPE) | ||||
| 71480-2D30003 |
AT171,CT170..SED..XL ***,GRAY,TRIM1# |
1 | ||
| 71480-2D30004 |
AT171,CT170..SED..XL ***,BLUE,TRIM8# |
1 | ||
| 71480-2D30006 |
AT171,CT170..SED..XL ***,SABLE,TRIM4# |
1 | ||
| 71490S - BACK ASSY, REAR SEAT, LH (FOR SEPARATE TYPE) | ||||
| 71490-2059003 |
AT171,CT170..SED..XL ***,GRAY,TRIM1# |
1 | ||
| 71490-2059006 |
AT171,CT170..SED..XL ***,SABLE,TRIM4# |
1 | ||
| 71490-2059004 |
AT171,CT170..SED..XL ***,BLUE,TRIM8# |
1 | ||
| 71611 - PAD, REAR SEAT CUSHION | ||||
| 71611-20420 |
AT171,CT170,ST171..SED |
1 | ||
| 71651S - PAD, REAR SEAT BACK, RH(FOR SEPARATE TYPE) | ||||
| 71651-20490 |
AT171,CT170,ST171..SED |
1 | ||
| 71652S - PAD, REAR SEAT BACK, LH(FOR SEPARATE TYPE) | ||||
| 71652-20290 |
AT171,CT170,ST171..SED |
1 | ||
| 71667A - PAD, REAR SEAT BACK, CENTER A | ||||
| 71667-20080 |
AT171,CT170,ST171 |
1 | ||
| 71880A - CARPET ASSY, REAR SEAT BACK BOARD, RH | ||||
| 71880-2007006 |
AT171,CT170..SED..XL SABLE,TRIM4# |
1 | ||
| 71880-2007004 |
AT171,CT170..SED..XL BLUE,TRIM8# |
1 | ||
| 71880-2007003 |
AT171,CT170..SED..XL GRAY,TRIM1# |
1 | ||
| 71880B - CLIP(FOR REAR SEAT BACK CARPET) | ||||
| 90467-09066J0 |
AT171..SED..GL;CT170,ST171..SED;AT171..SED..5F..XL..EFI;AT171..LHD..SED..XL..CBR BLUE,TRIM8#,TYPE B |
5 | ||
| 90467-0601657 |
AT171,CT170,ST171..SED SABLE,TRIM4#,TYPE A |
13 | ||
| 90467-0601640 |
AT171,CT170,ST171..SED DARK BLUE,TRIM8#,TYPE A |
13 | ||
| 90467-0601633 |
AT171,CT170,ST171..SED GRAY,TRIM1#,TYPE A |
13 | ||
| 90467-09066E0 |
AT171..SED..GL;CT170,ST171..SED;AT171..SED..5F..XL..EFI;AT171..LHD..SED..XL..CBR SABLE,TRIM1#,TYPE B |
5 | ||
| 90467-09066B0 |
AT171,CT170..SED..XL GRAY,TRIM1#,4#,8#,TYPE B |
5 | ||
| 90467-09066B1 |
AT171,CT170,ST171..SED GRAY,TRIM4#,TYPE B |
5 | ||
| 90467-0601658 |
AT171,CT170,ST171..SED GRAY,TRIM1#,4#,8#,TYPE A |
13 | ||
| 71890A - CARPET ASSY, REAR SEAT BACK BOARD, LH | ||||
| 71890-2001003 |
AT171,CT170..SED..XL GRAY,TRIM1# |
1 | ||
| 71890-2001006 |
AT171,CT170..SED..XL SABLE,TRIM4# |
1 | ||
| 71890-2001004 |
AT171,CT170..SED..XL BLUE,TRIM8# |
1 | ||
| 72067 - LEVER SUB-ASSY, REAR BACK LOCK CONTROL, RH | ||||
| 72067-20010 |
AT171,CT170,ST171..LB,SED |
1 | ||
| 72068 - LEVER SUB-ASSY, REAR BACK LOCK CONTROL, LH | ||||
| 72068-20010 |
AT171,CT170,ST171..LB,SED |
1 | ||
| 72069 - CABLE SUB-ASSY, REAR SEAT BACK LOCK CONTROL | ||||
| 72069-20020 |
AT171,CT170,ST171..LB,SED |
2 | ||
| 72069 - CABLE SUB-ASSY, REAR SEAT BACK LOCK CONTROL | ||||
| 72069-20020 |
AT171,CT170,ST171..LB,SED |
2 | ||
| 72601 - STRIKER SUB-ASSY, REAR SEAT LOCK | ||||
| 72601-16060 |
AT171,CT170,ST171 |
2 | ||
| 72601 - STRIKER SUB-ASSY, REAR SEAT LOCK | ||||
| 72601-16060 |
AT171,CT170,ST171 |
2 | ||
| 72603 - LOCK SUB-ASSY, REAR SEAT BACK, RH | ||||
| 72603-20030 |
AT171,CT170,ST171..LB,SED |
1 | ||
| 72604 - LOCK SUB-ASSY, REAR SEAT BACK, LH | ||||
| 72604-20030 |
AT171,CT170,ST171..LB,SED |
1 | ||
| 72646A - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-2004004 |
AT171,CT170,ST171 BLUE,TRIM8# |
1 | ||
| 72646-2004006 |
AT171,CT170,ST171..LB,SED SABLE,TRIM4# |
1 | ||
| 72646-2004003 |
AT171,CT170,ST171 GRAY,TRIM1# |
1 | ||
| 72646B - GROMMET, REAR SEAT BACK STOP BUTTON | ||||
| 72646-2004004 |
AT171,CT170,ST171 BLUE,TRIM8# |
1 | ||
| 72646-2004006 |
AT171,CT170,ST171..LB,SED SABLE,TRIM4# |
1 | ||
| 72646-2004003 |
AT171,CT170,ST171 GRAY,TRIM1# |
1 | ||
| 72658A - KNOB, REAR SEAT BACK LOCKING | ||||
| 72658-2301006 |
AT171,CT170,ST171..LB,SED SABLE,TRIM4# |
1 | ||
| 72658-23010J0 |
AT171,CT170,ST171 DARK BLUE,TRIM8# |
1 | ||
| 72658-2301014 |
AT171,CT170,ST171 DARK BLUE,TRIM8# |
1 | ||
| 72658-2301023 |
AT171,CT170,ST171 GRAY,TRIM1# |
1 | ||
| 72658E - KNOB, REAR SEAT BACK LOCKING | ||||
| 72658-23010J0 |
AT171,CT170,ST171 DARK BLUE,TRIM8# |
1 | ||
| 72658-2301014 |
AT171,CT170,ST171 DARK BLUE,TRIM8# |
1 | ||
| 72658-2301006 |
AT171,CT170,ST171..LB,SED SABLE,TRIM4# |
1 | ||
| 72658-2301023 |
AT171,CT170,ST171 GRAY,TRIM1# |
1 | ||
| 72679 - BEZEL, REAR SEAT BACK LOCK CONTROL | ||||
| 72679-1601014 |
AT171,CT170,ST171..LB,SED DARK BLUE,TRIM8# |
2 | ||
| 72679-1601003 |
AT171,CT170,ST171..LB,SED GRAY,TRIM1# |
2 | ||
| 72679-1601016 |
AT171,CT170,ST171..LB,SED SABLE,TRIM4# |
2 | ||
| 72693 - HOOK, REAR SEAT CUSHION LOCK | ||||
| 72693-20010 |
AT171,CT170,ST171..SED |
2 | ||
| 72830 - ARMREST ASSY, REAR SEAT, CENTER | ||||
| 72830-2024004 |
AT171,CT170,ST171..XL BLUE,TRIM8# |
1 | ||
| 72830-2024006 |
AT171,CT170..(LB,SED)..XL SABLE,TRIM4# |
1 | ||
| 72830-2024003 |
AT171,CT170,ST171..XL GRAY,TRIM1# |
1 | ||
| 72830B - BUSH(FOR REAR SEAT CENTER ARMREST) | ||||
| 90386-06002 |
AT171,CT170,ST171 TYPE A |
1 | ||
| 90386-06028 |
AT171,CT170,ST171 TYPE B |
1 | ||
| Common parts | ||||
| 90105-08072 | ||||
| 90105-08102 | ||||
| 90119-06207 | ||||
| 90468-18071 | ||||
| 91621-40608 | ||||
| 91655-60616 | ||||
| 91655-60825 | ||||
| 91656-40630 | ||||
| 93530-54010 | ||||
