SV11L-UHMEEK (1983)
Toyota Camry
(8210-8308)5F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 91121-51070 | ||||
| 91665-40830 | ||||
| 94110-41000 | ||||
| 94511-01000 | ||||
(8308- )5F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33503F - LEVER SUB-ASSY, SHIFT(FOR FLOOR SHIFT) | ||||
| 33503-32060 |
CV10,SV11..5F |
1 | ||
| 33504F - KNOB SUB-ASSY, SHIFT LEVER | ||||
| 33504-2401001 |
SV11..5F..LE BLACK,BLACK,TRIM1#,8# |
1 | ||
| 33504-2401043 |
SV11..5F..LE DARK GRAY,GRAY,TRIM1# |
1 | ||
| 33504-2401004 |
SV11..5F..LE BLUE,BLUE,TRIM8# |
1 | ||
| 33504-2401026 |
SV11..5F..LE DEEP BROWN,BROWN,TRIM4# |
1 | ||
| 33504-2401006 |
SV11..5F..LE DARK BROWN,BROWN,TRIM4# |
1 | ||
| 33504-2401030 |
SV11..5F..LE BLUE,BLUE,TRIM8# |
1 | ||
| 33534B - CRANK, SELECTING BELL, NO.1 | ||||
| 33509-12050 |
SV11..5F |
1 | ||
| 33509-12030 |
CV10,SV11..5F |
1 | ||
| 33534C - BUSH (FOR SELECTING BELLCRANK NO.1) | ||||
| 90386-12013 |
CV10,SV11..5F |
2 | ||
| 33534C - BUSH (FOR SELECTING BELLCRANK NO.1) | ||||
| 90386-12013 |
CV10,SV11..5F |
2 | ||
| 33534D - SPRING, TORSION (FOR SELECTING BELLCRANK NO.1) | ||||
| 90508-23074 |
CV10,SV11..5F |
1 | ||
| 33534P - WASHER, PLATE (FOR SELECTING BELLCRANK NO.1) | ||||
| 90201-12029 |
CV10,SV11..5F |
2 | ||
| 33534P - WASHER, PLATE (FOR SELECTING BELLCRANK NO.1) | ||||
| 90201-12029 |
CV10,SV11..5F |
2 | ||
| 33534Q - RING, E (FOR SELECTING BELLCRANK NO.1) | ||||
| 96160-00900 |
CV10,SV11..5F |
1 | ||
| 33554 - CAP, SHIFT LEVER | ||||
| 33554-12040 |
CV10,SV11..5F |
1 | ||
| 33556F - SEAT, TRANSMISSION SHIFT LEVER BALL | ||||
| 33556-12030 |
CV10,SV11..5F UPR |
1 | ||
| 33556-12020 |
CV10,SV11..5F LWR |
1 | ||
| 33556F - SEAT, TRANSMISSION SHIFT LEVER BALL | ||||
| 33556-12030 |
CV10,SV11..5F UPR |
1 | ||
| 33556-12020 |
CV10,SV11..5F LWR |
1 | ||
| 33556G - SPRING (FOR TRANSMISSION SHIFT LEVER BALL SEAT) | ||||
| 90501-10075 |
CV10,SV11..5F |
1 | ||
| 33556H - SHIM (FOR TRANSMISSION SHIFT LEVER BALL SEAT) | ||||
| 90564-30005 |
CV10,SV11..5F T=0.7,MARK E 0R 7,T=0.7 |
1 | ||
| 90564-30009 |
CV10,SV11..5F T=1.1,MARK K 0R 11,T=1.1 |
1 | ||
| 90564-30004 |
CV10,SV11..5F T=0.6,MARK D 0R 6,T=0.6 |
1 | ||
| 90564-30003 |
CV10,SV11..5F T=0.5,MARK C 0R 5,T=0.5 |
1 | ||
| 90564-30006 |
CV10,SV11..5F T=0.8,MARK F 0R 8,T=0.8 |
1 | ||
| 90564-30007 |
CV10,SV11..5F T=0.9,MARK G 0R 9,T=0.9 |
1 | ||
| 90564-30010 |
CV10,SV11..5F T=1.2,MARK L 0R 12,T=1.2 |
1 | ||
| 90564-30008 |
CV10,SV11..5F T=1.0,MARK H 0R 10,T=1.0 |
1 | ||
| 33575 - RETAINER, CONTROL SHIFT LEVER (FOR FLOOR SHIFT) | ||||
| 33506-32030 |
CV10,SV11..5F |
1 | ||
| 33575A - BUSH, NO.1 (FOR CONTROL SHIFT LEVER RETAINER) | ||||
| 90389-08031 |
CV10,SV11..5F |
4 | ||
| 33575B - BUSH, NO.2 (FOR CONTROL SHIFT LEVER RETAINER) | ||||
| 90389-10015 |
CV10,SV11..5F |
4 | ||
| 33593F - HOLDER, SPRING (FOR FLOOR SHIFT) | ||||
| 33593-12020 |
SV11..5F |
1 | ||
| 33593-32020 |
CV10,SV11..5F |
1 | ||
| 33618 - SUPPORT, SELECTING BELLCRANK, NO.1 | ||||
| 33618-12021 |
CV10,SV11..5F |
1 | ||
| 33618A - BOLT (FOR SELECTING BELLCRANK SUPPORT) | ||||
| 90105-06048 |
CV10,SV11..5F *6-1.00PX25-10 |
1 | ||
| 90105-08078 |
CV10,SV11..5F *8-1.25PX28-13,*8-1.25PX28-13 |
1 | ||
| 90119-06268 |
SV11..5F *6-1.00PX24-20,*6-1.00PX24-20 |
1 | ||
| 33618A - BOLT (FOR SELECTING BELLCRANK SUPPORT) | ||||
| 90105-06048 |
CV10,SV11..5F *6-1.00PX25-10 |
1 | ||
| 90105-08078 |
CV10,SV11..5F *8-1.25PX28-13,*8-1.25PX28-13 |
1 | ||
| 90119-06268 |
SV11..5F *6-1.00PX24-20,*6-1.00PX24-20 |
1 | ||
| 33618A - BOLT (FOR SELECTING BELLCRANK SUPPORT) | ||||
| 90105-06048 |
CV10,SV11..5F *6-1.00PX25-10 |
1 | ||
| 90105-08078 |
CV10,SV11..5F *8-1.25PX28-13,*8-1.25PX28-13 |
1 | ||
| 90119-06268 |
SV11..5F *6-1.00PX24-20,*6-1.00PX24-20 |
1 | ||
| Common parts | ||||
| 90119-06047 | ||||
| 91111-50608 | ||||
| 91665-48830 | ||||
| 94110-70600 | ||||
| 94110-70800 | ||||
| 94511-00600 | ||||
| 94511-00800 | ||||
| 94612-10601 | ||||
(8301- )5F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33503F - LEVER SUB-ASSY, SHIFT(FOR FLOOR SHIFT) | ||||
| 33503-32060 |
CV10,SV11..5F |
1 | ||
| 33504F - KNOB SUB-ASSY, SHIFT LEVER | ||||
| 33504-2401001 |
SV11..5F..LE BLACK,BLACK,TRIM1#,8# |
1 | ||
| 33504-2401043 |
SV11..5F..LE DARK GRAY,GRAY,TRIM1# |
1 | ||
| 33504-2401004 |
SV11..5F..LE BLUE,BLUE,TRIM8# |
1 | ||
| 33504-2401026 |
SV11..5F..LE DEEP BROWN,BROWN,TRIM4# |
1 | ||
| 33504-2401006 |
SV11..5F..LE DARK BROWN,BROWN,TRIM4# |
1 | ||
| 33504-2401030 |
SV11..5F..LE BLUE,BLUE,TRIM8# |
1 | ||
| 33534B - CRANK, SELECTING BELL, NO.1 | ||||
| 33509-12050 |
SV11..5F |
1 | ||
| 33509-12030 |
CV10,SV11..5F |
1 | ||
| 33534C - BUSH (FOR SELECTING BELLCRANK NO.1) | ||||
| 90386-12013 |
CV10,SV11..5F |
2 | ||
| 33534C - BUSH (FOR SELECTING BELLCRANK NO.1) | ||||
| 90386-12013 |
CV10,SV11..5F |
2 | ||
| 33534D - SPRING, TORSION (FOR SELECTING BELLCRANK NO.1) | ||||
| 90508-23074 |
CV10,SV11..5F |
1 | ||
| 33534P - WASHER, PLATE (FOR SELECTING BELLCRANK NO.1) | ||||
| 90201-12029 |
CV10,SV11..5F |
2 | ||
| 33534P - WASHER, PLATE (FOR SELECTING BELLCRANK NO.1) | ||||
| 90201-12029 |
CV10,SV11..5F |
2 | ||
| 33534Q - RING, E (FOR SELECTING BELLCRANK NO.1) | ||||
| 96160-00900 |
CV10,SV11..5F |
1 | ||
| 33554 - CAP, SHIFT LEVER | ||||
| 33554-12040 |
CV10,SV11..5F |
1 | ||
| 33556F - SEAT, TRANSMISSION SHIFT LEVER BALL | ||||
| 33556-12030 |
CV10,SV11..5F UPR |
1 | ||
| 33556-12020 |
CV10,SV11..5F LWR |
1 | ||
| 33556F - SEAT, TRANSMISSION SHIFT LEVER BALL | ||||
| 33556-12030 |
CV10,SV11..5F UPR |
1 | ||
| 33556-12020 |
CV10,SV11..5F LWR |
1 | ||
| 33556G - SPRING (FOR TRANSMISSION SHIFT LEVER BALL SEAT) | ||||
| 90501-10075 |
CV10,SV11..5F |
1 | ||
| 33556H - SHIM (FOR TRANSMISSION SHIFT LEVER BALL SEAT) | ||||
| 90564-30005 |
CV10,SV11..5F T=0.7,MARK E 0R 7,T=0.7 |
1 | ||
| 90564-30009 |
CV10,SV11..5F T=1.1,MARK K 0R 11,T=1.1 |
1 | ||
| 90564-30004 |
CV10,SV11..5F T=0.6,MARK D 0R 6,T=0.6 |
1 | ||
| 90564-30003 |
CV10,SV11..5F T=0.5,MARK C 0R 5,T=0.5 |
1 | ||
| 90564-30006 |
CV10,SV11..5F T=0.8,MARK F 0R 8,T=0.8 |
1 | ||
| 90564-30007 |
CV10,SV11..5F T=0.9,MARK G 0R 9,T=0.9 |
1 | ||
| 90564-30010 |
CV10,SV11..5F T=1.2,MARK L 0R 12,T=1.2 |
1 | ||
| 90564-30008 |
CV10,SV11..5F T=1.0,MARK H 0R 10,T=1.0 |
1 | ||
| 33575 - RETAINER, CONTROL SHIFT LEVER (FOR FLOOR SHIFT) | ||||
| 33506-32030 |
CV10,SV11..5F |
1 | ||
| 33575A - BUSH, NO.1 (FOR CONTROL SHIFT LEVER RETAINER) | ||||
| 90389-08031 |
CV10,SV11..5F |
4 | ||
| 33575B - BUSH, NO.2 (FOR CONTROL SHIFT LEVER RETAINER) | ||||
| 90389-10015 |
CV10,SV11..5F |
4 | ||
| 33593F - HOLDER, SPRING (FOR FLOOR SHIFT) | ||||
| 33593-12020 |
SV11..5F |
1 | ||
| 33593-32020 |
CV10,SV11..5F |
1 | ||
| 33618 - SUPPORT, SELECTING BELLCRANK, NO.1 | ||||
| 33618-12021 |
CV10,SV11..5F |
1 | ||
| 33618A - BOLT (FOR SELECTING BELLCRANK SUPPORT) | ||||
| 90105-06048 |
CV10,SV11..5F *6-1.00PX25-10 |
1 | ||
| 90105-08078 |
CV10,SV11..5F *8-1.25PX28-13,*8-1.25PX28-13 |
1 | ||
| 90119-06268 |
SV11..5F *6-1.00PX24-20,*6-1.00PX24-20 |
1 | ||
| 33618A - BOLT (FOR SELECTING BELLCRANK SUPPORT) | ||||
| 90105-06048 |
CV10,SV11..5F *6-1.00PX25-10 |
1 | ||
| 90105-08078 |
CV10,SV11..5F *8-1.25PX28-13,*8-1.25PX28-13 |
1 | ||
| 90119-06268 |
SV11..5F *6-1.00PX24-20,*6-1.00PX24-20 |
1 | ||
| 33618A - BOLT (FOR SELECTING BELLCRANK SUPPORT) | ||||
| 90105-06048 |
CV10,SV11..5F *6-1.00PX25-10 |
1 | ||
| 90105-08078 |
CV10,SV11..5F *8-1.25PX28-13,*8-1.25PX28-13 |
1 | ||
| 90119-06268 |
SV11..5F *6-1.00PX24-20,*6-1.00PX24-20 |
1 | ||
| Common parts | ||||
| 90119-06047 | ||||
| 91111-50608 | ||||
| 91665-48830 | ||||
| 94110-70600 | ||||
| 94110-70800 | ||||
| 94511-00600 | ||||
| 94511-00800 | ||||
| 94612-10601 | ||||
(8301- )5F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33282A - PIN, LEVER LOCK (FOR CONTROL SHIFT LEVER) | ||||
| 33282-35010 |
CV10,SV11..5F |
1 | ||
| 33527 - LEVER, CONTROL SHIFT (FOR FLOOR SHIFT) | ||||
| 33527-32010 |
CV10,SV11..5F |
1 | ||
| 33527B - BUSH (FOR CONTROL SHIFT LEVER) | ||||
| 90389-10009 |
CV10,SV11..5F |
1 | ||
| 33534E - CRANK, SELECTING BELL, NO.2 | ||||
| 33534-32020 |
CV10,SV11..5F |
1 | ||
| 33534F - BUSH (FOR SELECTING BELLCRANK NO.2) | ||||
| 90386-12022 |
CV10,SV11..5F |
2 | ||
| 33534F - BUSH (FOR SELECTING BELLCRANK NO.2) | ||||
| 90386-12022 |
CV10,SV11..5F |
2 | ||
| 33534G - WASHER, PLATE (FOR SELECTING BELLCRANK NO.2) | ||||
| 90201-08028 |
CV10,SV11..5F |
1 | ||
| 33557A - COVER, SELECTING BELLCRANK DUST, NO.1 | ||||
| 33557-32010 |
CV10,SV11..5F |
1 | ||
| 33558 - COVER, SELECTING BELLCRANK DUST, NO.2 | ||||
| 33558-32010 |
CV10,SV11..5F |
1 | ||
| 33574A - RETAINER, SHIFT CABLE GROMMET, NO.1 | ||||
| 33574-32010 |
CV1#,SV11 |
1 | ||
| 33574B - RETAINER, SHIFT CABLE GROMMET, NO.2 | ||||
| 33574-32020 |
CV1#,SV11 |
1 | ||
| 33608 - SUPPORT SUB-ASSY, SELECTING BELLCRANK | ||||
| 33608-32010 |
CV10,SV11..5F |
1 | ||
| 33821 - CABLE TRANSMISSION CONTROL SHIFT (FOR FLOOR SHIFT) | ||||
| 33821-32060 |
SV11..5F |
1 | ||
| 33821-32050 |
CV10,SV11..5F |
1 | ||
| 33821A - GROMMET, NO.1 (FOR TRANSMISSION CONTROL CABLE) | ||||
| 90480-01177 |
CV10,SV11..5F |
1 | ||
| 33821B - GROMMET, NO.2 (FOR TRANSMISSION CONTROL CABLE) | ||||
| 90480-01154 |
CV10,SV11..5F |
1 | ||
| 33821C - WASHER, PLATE (FOR TRANSMISSION CONTROL CABLE) | ||||
| 90201-08267 |
CV10,SV11..5F OD=28,TRANSAXLE SIDE |
2 | ||
| 90201-10042 |
CV10,SV11..5F SHIFT LEVER SIDE |
1 | ||
| 33821C - WASHER, PLATE (FOR TRANSMISSION CONTROL CABLE) | ||||
| 90201-08267 |
CV10,SV11..5F OD=28,TRANSAXLE SIDE |
2 | ||
| 90201-10042 |
CV10,SV11..5F SHIFT LEVER SIDE |
1 | ||
| 33821C - WASHER, PLATE (FOR TRANSMISSION CONTROL CABLE) | ||||
| 90201-08267 |
CV10,SV11..5F OD=28,TRANSAXLE SIDE |
2 | ||
| 90201-10042 |
CV10,SV11..5F SHIFT LEVER SIDE |
1 | ||
| 33822 - CABLE TRANSMISSION CONTROL SELECT (FOR FLOOR SHIFT) | ||||
| 33822-32030 |
CV10,SV11..5F |
1 | ||
| 33825 - INSULATOR, TRANSMISSION CONTROL CABLE | ||||
| 33825-32010 |
CV1#,SV11 |
1 | ||
| Common parts | ||||
| 90468-14011 | ||||
| 90468-14014 | ||||
| 90468-14016 | ||||
| 91612-61020 | ||||
| 91656-40616 | ||||
| 93560-15016 | ||||
| 94110-40600 | ||||
| 94110-40800 | ||||
| 94511-00600 | ||||
| 94511-00800 | ||||
