CT220R-ALMNTW (1997)
Toyota Avensis
(9710-0007)CT220,ST220..MTM ; (0007- )AZT220,ST220..MTM
S50,S54,S55
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33038E - RING SET, SYNCHRONIZER, NO.2 | ||||
| 33038-33011 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33111R - RING, HOLE SNAP(FOR OUTPUT SHAFT REAR BEARING) | ||||
| 90521-66004 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33125 - RECEIVER, MANUAL TRANSAXLE CASE | ||||
| 33326-21010 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33125A - BOLT(FOR TRANSAXLE CASE RECEIVER) | ||||
| 91611-60616 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33134B - COVER, OUTPUT SHAFT(MTM) | ||||
| 33134-33010 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33151D - RETAINER, BEARING, REAR(MTM) | ||||
| 33151-32012 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33151E - BOLT(FOR REAR BEARING RETAINER) | ||||
| 90105-08237 |
AZT220,CT220,ST220..MTM |
5 | ||
| 33311 - SHAFT, INPUT | ||||
| 33311-33022 |
AZT220,CT220..MTM |
1 | ||
| 33311A - BEARING (FOR INPUT SHAFT FRONT) | ||||
| 90365-30017 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33311E - BEARING, RADIAL BALL (FOR INPUT SHAFT REAR) | ||||
| 90363-29006 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33311P - RING, SHAFT SNAP (FOR INPUT SHAFT REAR BEARING) | ||||
| 90520-27021 |
AZT220,CT220,ST220..MTM T=2.30-2.35,MARK D |
1 | ||
| 90520-27019 |
AZT220,CT220,ST220..MTM T=2.20-2.25,MARK B |
1 | ||
| 90520-27022 |
AZT220,CT220,ST220..MTM T=2.35-2.40,MARK E |
1 | ||
| 90520-27018 |
AZT220,CT220,ST220..MTM T=2.15-2.20,MARK A |
1 | ||
| 90520-27020 |
AZT220,CT220,ST220..MTM T=2.25-2.30,MARK C |
1 | ||
| 33311X - RING, HOLE SNAP (FOR INPUT SHAFT REAR BEARING) | ||||
| 90521-76001 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33321 - SHAFT, OUTPUT | ||||
| 33321-33020 |
AZT220,CT220..MTM |
1 | ||
| 33321A - BEARING (FOR OUTPUT SHAFT REAR) | ||||
| 90363-25056 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33321G - NUT (FOR MANUAL TRANSMISSION OUTPUT SHAFT REAR SET) | ||||
| 90179-18003 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33321N - BEARING (FOR OUTPUT SHAFT FRONT) | ||||
| 90365-32013 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33326 - PLATE, BEARING LOCK | ||||
| 33326-32010 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33326A - BOLT (FOR BEARING LOCK PLATE) | ||||
| 91611-60820 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33331 - GEAR, REVERSE | ||||
| 33331-33022 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33332 - GEAR, 2ND | ||||
| 33332-33031 |
AZT220,CT220..MTM |
1 | ||
| 33332B - BEARING, NEEDLE ROLLER (FOR 2ND GEAR) | ||||
| 90364-39013 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33333 - GEAR, 3RD | ||||
| 33034-32032 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33333A - BEARING, NEEDLE ROLLER (FOR 3RD GEAR) | ||||
| 90364-33001 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33334 - GEAR, 4TH | ||||
| 33035-32040 |
CT220 |
1 | ||
| 33334A - BEARING, NEEDLE ROLLER (FOR 4TH GEAR) | ||||
| 90364-32013 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33334B - SPACER (FOR 4TH GEAR BEARING) | ||||
| 90560-32007 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33335 - GEAR, 1ST | ||||
| 33032-32022 |
AZT220,CT220..MTM |
1 | ||
| 33335C - BEARING, NEEDLE ROLLER(FOR 1ST GEAR) | ||||
| 90364-38004 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33336 - GEAR, 5TH | ||||
| 33336-33020 |
CT220 |
1 | ||
| 33336A - BEARING, NEEDLE ROLLER (FOR 5TH GEAR) | ||||
| 90364-27005 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33336B - SPACER (FOR 5TH GEAR BEARING) | ||||
| 90560-27004 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33343D - BUSH, 2ND GEAR | ||||
| 33343-33010 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33343E - BALL (FOR 2ND GEAR BUSH) | ||||
| 90360-05012 |
AZT220,CDT220,CT220,ST220..MTM |
1 | ||
| 33348 - WASHER, 1ST GEAR THRUST | ||||
| 33348-32010 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33361 - HUB, TRANSMISSION CLUTCH, NO.1 | ||||
| 33361-33021 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33362 - HUB, TRANSMISSION CLUTCH, NO.2 | ||||
| 33362-33011 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33362A - RING, SHAFT SNAP (FOR CLUTCH HUB NO.2 SETTING) | ||||
| 90520-30002 |
AZT220,CT220,ST220,ZZT221..MTM T=1.95-1.99,MARK 1 |
1 | ||
| 90520-30006 |
AZT220,CT220,ST220,ZZT221..MTM T=2.15-2.19,MARK 5 |
1 | ||
| 90520-30004 |
AZT220,CT220,ST220,ZZT221..MTM T=2.05-2.09,MARK 3 |
1 | ||
| 90520-30005 |
AZT220,CT220,ST220,ZZT221..MTM T=2.10-2.14,MARK 4 |
1 | ||
| 90520-30003 |
AZT220,CT220,ST220,ZZT221..MTM T=2.00-2.04,MARK 2 |
1 | ||
| 90520-30007 |
AZT220,CT220,ST220,ZZT221..MTM T=2.20-2.24,MARK 6 |
1 | ||
| 33364 - SLEEVE, TRANSMISSION HUB, NO.2 | ||||
| 33364-32013 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33365 - KEY, SYNCHROMESH SHIFTING, NO.1 | ||||
| 33365-33020 |
AZT220,CT220,ST220..MTM |
3 | ||
| 33366 - KEY, SYNCHROMESH SHIFTING, NO.2 | ||||
| 33366-32020 |
AZT220,CT220,ST220..MTM |
3 | ||
| 33367 - RING, SYNCHRONIZER, NO.1 | ||||
| 33367-33010 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33368 - RING, SYNCHRONIZER, NO.2 | ||||
| 33368-32020 |
AZT220,CT220,ST220..MTM NO.2 |
1 | ||
| 33368-20050 |
CT220 NO.1 |
1 | ||
| 33368 - RING, SYNCHRONIZER, NO.2 | ||||
| 33368-32020 |
AZT220,CT220,ST220..MTM NO.2 |
1 | ||
| 33368-20050 |
CT220 NO.1 |
1 | ||
| 33391 - SPRING, SYNCHROMESH SHIFTING KEY, NO.2 | ||||
| 33391-32010 |
AZT220,CT220,ST220..MTM |
2 | ||
| 33391 - SPRING, SYNCHROMESH SHIFTING KEY, NO.2 | ||||
| 33391-32010 |
AZT220,CT220,ST220..MTM |
2 | ||
| 33392 - SPRING, SYNCHROMESH SHIFTING KEY, NO.3 | ||||
| 33392-33010 |
AZT220,CT220,ST220..MTM OUTER RING SIDE |
1 | ||
| 33392-33021 |
AZT220,CT220,ST220..MTM PULL RING SIDE |
1 | ||
| 33392 - SPRING, SYNCHROMESH SHIFTING KEY, NO.3 | ||||
| 33392-33010 |
AZT220,CT220,ST220..MTM OUTER RING SIDE |
1 | ||
| 33392-33021 |
AZT220,CT220,ST220..MTM PULL RING SIDE |
1 | ||
| 33393 - HUB, TRANSMISSION CLUTCH, NO.3 | ||||
| 33393-33010 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33393A - RING, SHAFT SNAP (FOR TRANSMISSION CLUTCH HUB NO.3) | ||||
| 90520-20035 |
AZT220,CT220,ST220..MTM T=2.25-2.30,MARK 14 |
1 | ||
| 90520-20057 |
AZT220,CT220,ST220..MTM T=2.65-2.69,MARK 22 |
1 | ||
| 90520-20051 |
AZT220,CT220,ST220..MTM T=2.35-2.39,MARK 16 |
1 | ||
| 90520-20036 |
AZT220,CT220,ST220..MTM T=2.30-2.35,MARK 15 |
1 | ||
| 90520-20034 |
AZT220,CT220,ST220..MTM T=2.20-2.25,MARK 13 |
1 | ||
| 90520-20052 |
AZT220,CT220,ST220..MTM T=2.40-2.44,MARK 17 |
1 | ||
| 90520-20055 |
AZT220,CT220,ST220..MTM T=2.55-2.59,MARK 20 |
1 | ||
| 90520-20053 |
AZT220,CT220,ST220..MTM T=2.45-2.49,MARK 18 |
1 | ||
| 90520-20054 |
AZT220,CT220,ST220..MTM T=2.50-2.54,MARK 19 |
1 | ||
| 90520-20062 |
AZT220,CT220,ST220..MTM T=2.90-2.94,MARK 27 |
1 | ||
| 90520-20060 |
AZT220,CT220,ST220..MTM T=2.80-2.84,MARK 25 |
1 | ||
| 90520-20058 |
AZT220,CT220,ST220..MTM T=2.70-2.74,MARK 23 |
1 | ||
| 90520-20056 |
AZT220,CT220,ST220..MTM T=2.60-2.64,MARK 21 |
1 | ||
| 90520-20061 |
AZT220,CT220,ST220..MTM T=2.85-2.89,MARK 26 |
1 | ||
| 90520-20059 |
AZT220,CT220,ST220..MTM T=2.75-2.79,MARK 24 |
1 | ||
| 33394C - SPRING, COMPRESSION | ||||
| 90501-08141 |
AZT220,CT220,ST220..MTM |
3 | ||
| 33395 - SLEEVE, TRANSMISSION HUB, NO.3 | ||||
| 33395-33010 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33396A - RING, SYNCHRONIZER PULL | ||||
| 33396-33012 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33396B - RING, SNAP (FOR SYNCHRONIZER PULL RING) | ||||
| 90520-46035 |
AZT220,CDT220,CT220,ST220..MTM |
1 | ||
| 33397A - RING, SYNCHRONIZER, INNER NO.5 | ||||
| 33397-33012 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33398A - RING, SYNCHRONIZER, MIDDLE NO.5 | ||||
| 33398-12010 |
AZT220,CDT220,CT220,ST220..MTM |
1 | ||
| 33399D - RING, SYNCHRONIZER, OUTER NO.5 | ||||
| 33399-33010 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33402 - GEAR SUB-ASSY, REVERSE IDLER | ||||
| 33402-33011 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33422B - GEAR, 4TH DRIVEN | ||||
| 33422-32040 |
CT220 |
1 | ||
| 33423A - GEAR, 3RD DRIVEN | ||||
| 33423-32030 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33428C - GEAR, 5TH DRIVEN | ||||
| 33428-32040 |
CT220 |
1 | ||
| 33431C - SPACER, OUTPUT GEAR | ||||
| 33431-32020 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33451 - SHAFT, REVERSE IDLER GEAR | ||||
| 33451-32010 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33451H - BOLT (FOR REVERSE IDLER GEAR SHAFT) | ||||
| 90105-08041 |
AZT220,CT220,ST220..MTM |
1 | ||
| 33451J - GASKET (FOR REVERSE IDLER GEAR SHAFT) | ||||
| 90430-08010 |
AT22#,AZT220,CDT220,CT220,ST220,ZZT22#..MTM |
1 | ||
| 33462 - WASHER, REVERSE IDLER THRUST | ||||
| 33462-12010 |
AT22#,AZT220,CT220,ST220,ZZT22#..MTM |
1 | ||
