CT220L-ALMNTW (1997)
Toyota Avensis
(9710- )CDT220,CT220
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 78024 - BRACKET SUB-ASSY, ACCELERATOR CONTROL CABLE | ||||
| 78024-32140 |
CT220..TD |
1 | ||
| 78110A - SPRING (FOR ACCELERATOR PEDAL ROD) | ||||
| 90080-50107 |
CT220,ST220..LHD..MTM..(EFI,TD) |
1 | ||
| 78111 - PEDAL, ACCELERATOR | ||||
| 78111-20060 |
CT220..LHD..TDEFI;AT221,ST220..LHD..ATM |
1 | ||
| 78111-20060 |
AT22#,ST220,ZZT22#..RHD;AT221,ST220,ZZT221..LHD..ATM;AZT220,CDT220,CT220..D4,DCR,TDEFI |
1 | ||
| 78111 - PEDAL, ACCELERATOR | ||||
| 78111-20060 |
CT220..LHD..TDEFI;AT221,ST220..LHD..ATM |
1 | ||
| 78111-20060 |
AT22#,ST220,ZZT22#..RHD;AT221,ST220,ZZT221..LHD..ATM;AZT220,CDT220,CT220..D4,DCR,TDEFI |
1 | ||
| 78111C - PIN (FOR ACCELERATOR PEDAL) | ||||
| 90254-04019 |
AT22#,AZT220,CDT220,CT220,ST220,ZZT22# |
1 | ||
| 78111C - PIN (FOR ACCELERATOR PEDAL) | ||||
| 90254-04019 |
AT22#,AZT220,CDT220,CT220,ST220,ZZT22# |
1 | ||
| 78111C - PIN (FOR ACCELERATOR PEDAL) | ||||
| 90254-04019 |
AT22#,AZT220,CDT220,CT220,ST220,ZZT22# |
1 | ||
| 78120G - ROD ASSY, ACCELERATOR PEDAL | ||||
| 78120-05160 |
CT220,ST220..LHD..MTM..(EFI,TD) |
1 | ||
| 78120-05161 |
CT220,ST220..LHD..MTM..(EFI,TD) |
1 | ||
| 78010-20072 |
CDT220,CT220..LHD..(DCR,TDEFI) |
1 | ||
| 78010-20071 |
CT220..LHD..TDEFI |
1 | ||
| 78120G - ROD ASSY, ACCELERATOR PEDAL | ||||
| 78120-05160 |
CT220,ST220..LHD..MTM..(EFI,TD) |
1 | ||
| 78120-05161 |
CT220,ST220..LHD..MTM..(EFI,TD) |
1 | ||
| 78010-20072 |
CDT220,CT220..LHD..(DCR,TDEFI) |
1 | ||
| 78010-20071 |
CT220..LHD..TDEFI |
1 | ||
| 78120G - ROD ASSY, ACCELERATOR PEDAL | ||||
| 78120-05160 |
CT220,ST220..LHD..MTM..(EFI,TD) |
1 | ||
| 78120-05161 |
CT220,ST220..LHD..MTM..(EFI,TD) |
1 | ||
| 78010-20072 |
CDT220,CT220..LHD..(DCR,TDEFI) |
1 | ||
| 78010-20071 |
CT220..LHD..TDEFI |
1 | ||
| 78180P - CABLE ASSY, ACCELERATOR CONTROL | ||||
| 78180-05230 |
CT220..TD |
1 | ||
| 78183B - CLAMP, ACCELERATOR CONTROL CABLE | ||||
| 78183-20180 |
CT220..TD TYPE A:REFER TO ILLUSTRATION |
1 | ||
| 78183-20300 |
CT220..TD TYPE B:REFER TO ILLUSTRATION |
1 | ||
| 78183B - CLAMP, ACCELERATOR CONTROL CABLE | ||||
| 78183-20180 |
CT220..TD TYPE A:REFER TO ILLUSTRATION |
1 | ||
| 78183-20300 |
CT220..TD TYPE B:REFER TO ILLUSTRATION |
1 | ||
| Common parts | ||||
| 90080-17021 | ||||
| 90179-06158 | ||||
| 91611-F0612 | ||||
| 91651-A0612 | ||||
| 91651-B0614 | ||||
| 91651-F0625 | ||||
| 91652-60630 | ||||
| 96160-00600 | ||||
