ADT251R-AEFGYW (2005)
Toyota Avensis
(0301-0604)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 81110B - BULB(FOR HEADLAMP, NO.1) | ||||
| 90080-81067 |
ADT251,AZT25#,CDT250,ZZT25# 12V 55W |
2 | ||
| 81110D - BULB(FOR HEADLAMP, NO.2) | ||||
| 90981-WD005 |
ADT251,AZT25#,CDT250,ZZT25# 12V 55W,*HAL *WH |
2 | ||
| 81110D - BULB(FOR HEADLAMP, NO.2) | ||||
| 90981-WD005 |
ADT251,AZT25#,CDT250,ZZT25# 12V 55W,*HAL *WH |
2 | ||
| 81110L - BULB, DISCHARGE HEADLAMP | ||||
| 90981-WL001 |
CDT250..RHD..TEC..DCR;ADT251,AZT251..RHD..(ELEGT,TEC) 85V 35W,HEAD LAMP-DISCHARGE&HEAD LAMP AIMING-RH |
2 | ||
| 90981-WL001 |
ADT251,AZT251,CDT250..RHD..(ELEGT,TEC) 85V 35W,HEAD LAMP-DISCHARGE&HEAD LAMP AIMING-RH |
2 | ||
| 90981-WL001 |
AZT250,ZZT251..LHD..(ELEGT,TEC);ADT251,AZT251,CDT250,ZZT250..ELEGT,TEC 85V 35W,HEAD LAMP-DISCHARGE |
2 | ||
| 90981-WL001 |
CDT250..TEC..DCR;AZT250..LHD..WG..D4;AZT250..LHD..(LB,SED);CDT250..LHD..ELEGT..DCR;ZZT251..LHD..(ELEGT,TEC);ADT251,AZT251,ZZT250..ELEGT,TEC 85V 35W,HEAD LAMP-DISCHARGE |
2 | ||
| 81115B - SOCKET,HEADLAMP, NO.1 | ||||
| 90069-81049 |
ADT251,AZT25#,CDT250,ZZT25# |
2 | ||
| 81115B - SOCKET,HEADLAMP, NO.1 | ||||
| 90069-81049 |
ADT251,AZT25#,CDT250,ZZT25# |
2 | ||
| 81135 - UNIT ASSY, HEADLAMP, RH | ||||
| 81130-05163 |
ADT251,AZT25#,CDT250,ZZT25#..RHD LABEL=62 |
1 | ||
| 81130-05182 |
ADT251,AZT251,CDT250..RHD..(ELEGT,TEC) HEAD LAMP-DISCHARGE,LABEL=82 |
1 | ||
| 81130-05212 |
ADT251,AZT251,CDT250..RHD..(ELEGT,TEC) HEAD LAMP-DISCHARGE&HEAD LAMP AIMING-RH,LABEL=12 |
1 | ||
| 81130-05194 |
ADT251,AZT25#,CDT250,ZZT25#..RHD HEAD LAMP AIMING-RH |
1 | ||
| 81135 - UNIT ASSY, HEADLAMP, RH | ||||
| 81130-05163 |
ADT251,AZT25#,CDT250,ZZT25#..RHD LABEL=62 |
1 | ||
| 81130-05182 |
ADT251,AZT251,CDT250..RHD..(ELEGT,TEC) HEAD LAMP-DISCHARGE,LABEL=82 |
1 | ||
| 81130-05212 |
ADT251,AZT251,CDT250..RHD..(ELEGT,TEC) HEAD LAMP-DISCHARGE&HEAD LAMP AIMING-RH,LABEL=12 |
1 | ||
| 81130-05194 |
ADT251,AZT25#,CDT250,ZZT25#..RHD HEAD LAMP AIMING-RH |
1 | ||
| 81144 - COVER, HEADLAMP, NO.1 | ||||
| 81139-05160 |
ADT251,AZT25#,CDT250,ZZT25# |
2 | ||
| 81144 - COVER, HEADLAMP, NO.1 | ||||
| 81139-05160 |
ADT251,AZT25#,CDT250,ZZT25# |
2 | ||
| 81145 - COVER, HEADLAMP, NO.2 | ||||
| 81175-05161 |
ADT251,AZT25#,CDT250,ZZT25# LH |
1 | ||
| 81135-05161 |
ADT251,AZT25#,CDT250,ZZT25# RH |
1 | ||
| 81175-05160 |
ADT251,AZT25#,CDT250,ZZT25# LH |
1 | ||
| 81135-05160 |
ADT251,AZT25#,CDT250,ZZT25# RH |
1 | ||
| 81145 - COVER, HEADLAMP, NO.2 | ||||
| 81175-05161 |
ADT251,AZT25#,CDT250,ZZT25# LH |
1 | ||
| 81135-05161 |
ADT251,AZT25#,CDT250,ZZT25# RH |
1 | ||
| 81175-05160 |
ADT251,AZT25#,CDT250,ZZT25# LH |
1 | ||
| 81135-05160 |
ADT251,AZT25#,CDT250,ZZT25# RH |
1 | ||
| 81175 - UNIT ASSY, HEADLAMP, LH | ||||
| 81170-05182 |
ADT251,AZT251,CDT250..RHD..(ELEGT,TEC) HEAD LAMP-DISCHARGE,LABEL=82 |
1 | ||
| 81170-05194 |
ADT251,AZT25#,CDT250,ZZT25#..RHD HEAD LAMP AIMING-RH |
1 | ||
| 81170-05212 |
ADT251,AZT251,CDT250..RHD..(ELEGT,TEC) HEAD LAMP-DISCHARGE&HEAD LAMP AIMING-RH,LABEL=12 |
1 | ||
| 81170-05163 |
ADT251,AZT25#,CDT250,ZZT25#..RHD LABEL=62 |
1 | ||
| 81175 - UNIT ASSY, HEADLAMP, LH | ||||
| 81170-05182 |
ADT251,AZT251,CDT250..RHD..(ELEGT,TEC) HEAD LAMP-DISCHARGE,LABEL=82 |
1 | ||
| 81170-05194 |
ADT251,AZT25#,CDT250,ZZT25#..RHD HEAD LAMP AIMING-RH |
1 | ||
| 81170-05212 |
ADT251,AZT251,CDT250..RHD..(ELEGT,TEC) HEAD LAMP-DISCHARGE&HEAD LAMP AIMING-RH,LABEL=12 |
1 | ||
| 81170-05163 |
ADT251,AZT25#,CDT250,ZZT25#..RHD LABEL=62 |
1 | ||
| 81189 - COVER, HEADLAMP | ||||
| 81136-05160 |
ADT251,AZT25#,CDT250,ZZT25# |
2 | ||
| 81189 - COVER, HEADLAMP | ||||
| 81136-05160 |
ADT251,AZT25#,CDT250,ZZT25# |
2 | ||
| 81193 - RETAINER, HEADLAMP PROTECTOR, UPPER RH | ||||
| 81193-05020 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 81194 - RETAINER, HEADLAMP PROTECTOR, UPPER LH | ||||
| 81194-05020 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 81195A - RETAINER, HEADLAMP PROTECTOR, LOWER RH | ||||
| 81195-05010 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 81196A - RETAINER, HEADLAMP PROTECTOR, LOWER LH | ||||
| 81196-05010 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 81197 - BRACKET, HEADLAMP, LOWER RH | ||||
| 81197-05010 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 81198 - BRACKET, HEADLAMP, LWR LH | ||||
| 81198-05010 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 81615D - SOCKET, CLEARANCE LAMP | ||||
| 90069-81050 |
ADT251,AZT25#,CDT250,ZZT25# |
2 | ||
| 81615D - SOCKET, CLEARANCE LAMP | ||||
| 90069-81050 |
ADT251,AZT25#,CDT250,ZZT25# |
2 | ||
| Common parts | ||||
| 90069-32012 | ||||
| 90159-50311 | ||||
| 90189-05142 | ||||
| 90189-05162 | ||||
