ADT251L-AEFEYW (2005)
Toyota Avensis
(0301- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 55539B - COVER, SPARE SWITCH HOLE, NO.2 | ||||
| 55539-05070B0 |
CDT250..LHD..DCR;ADT251,AZT25#,ZZT25#..LHD W(FRONT SEAT HEATER),DK.GRAY,TRIM1# |
1 | ||
| 55539-05070B0 |
CDT250..LHD..DCR;ADT251,AZT25#,ZZT25#..LHD DK.GRAY,TRIM1# |
1 | ||
| 55618A - HOLDER, CONSOLE BOX CUP | ||||
| 55630-05030 |
CDT250..(ELEGT,TEC)..DCR;CDT250..LHD..ELEGT..DCRL;ADT251,AZT25#,ZZT25#..ELEGT,TEC |
1 | ||
| 58805B - PANEL SUB-ASSY, CONSOLE, LOWER | ||||
| 58805-05020B0 |
AZT250..LHD..(LB,WG);AZT250..LHD..SED..D4;CDT250..LHD..(ELEGT,TEC)..DCR;ADT251,AZT251,ZZT251..LHD..(ELEGT,TEC) MAP NAVI,DK.GRAY,TRIM1# |
1 | ||
| 58805-05010B0 |
CDT250..LHD..DCR;ADT251,AZT25#,ZZT25#..LHD DK.GRAY,TRIM1# |
1 | ||
| 58805B - PANEL SUB-ASSY, CONSOLE, LOWER | ||||
| 58805-05020B0 |
AZT250..LHD..(LB,WG);AZT250..LHD..SED..D4;CDT250..LHD..(ELEGT,TEC)..DCR;ADT251,AZT251,ZZT251..LHD..(ELEGT,TEC) MAP NAVI,DK.GRAY,TRIM1# |
1 | ||
| 58805-05010B0 |
CDT250..LHD..DCR;ADT251,AZT25#,ZZT25#..LHD DK.GRAY,TRIM1# |
1 | ||
| 58808 - COVER SUB-ASSY, SHIFTING HOLE | ||||
| 58808-05080 |
ADT251 |
1 | ||
| 58815A - CARPET, CONSOLE BOX | ||||
| 58815-05010 |
CDT250..DCR;ADT251,AZT25#,ZZT25# |
1 | ||
| 58815B - CARPET, CONSOLE BOX | ||||
| 58815-05020 |
CDT250..DCR;ADT251,AZT25#,ZZT25# |
1 | ||
| 58815C - CARPET, CONSOLE BOX | ||||
| 58815-05030 |
CDT250..(ELEGT,TEC)..DCR;CDT250..LHD..ELEGT..DCRL;ADT251,AZT25#,ZZT25#..ELEGT,TEC |
1 | ||
| 58821C - PANEL, CONSOLE, UPPER | ||||
| 58821-05050 |
ADT251..TEC |
1 | ||
| 58831A - GARNISH, CONSOLE UPPER PANEL, FRONT | ||||
| 58831-05020 |
ADT251 |
1 | ||
| 58836B - PAD, CONSOLE BOX SILENCER, NO.1 | ||||
| 58836-05010 |
CDT250..DCR;ADT251,AZT25#,ZZT25# |
1 | ||
| 58837A - PAD, CONSOLE BOX SILENCER, NO.2 | ||||
| 58837-05010 |
CDT250..DCR;ADT251,AZT25#,ZZT25# |
1 | ||
| 58905 - DOOR SUB-ASSY, CONSOLE COMPARTMENT | ||||
| 58905-05030B3 |
CDT250..TEC..DCR;ADT251,AZT25#,ZZT25#..TEC DK.GRAY,TRIM1# |
1 | ||
| 58907 - HINGE SUB-ASSY, CONSOLE COMPARTMENT DOOR | ||||
| 58907-05010 |
CDT250..(ELEGT,TEC)..DCR;CDT250..LHD..ELEGT..DCRL;ADT251,AZT25#,ZZT25#..ELEGT,TEC NO.1 |
1 | ||
| 58907-05020 |
CDT250..(ELEGT,TEC)..DCR;CDT250..LHD..ELEGT..DCRL;ADT251,AZT25#,ZZT25#..ELEGT,TEC NO.2 |
1 | ||
| 58907 - HINGE SUB-ASSY, CONSOLE COMPARTMENT DOOR | ||||
| 58907-05010 |
CDT250..(ELEGT,TEC)..DCR;CDT250..LHD..ELEGT..DCRL;ADT251,AZT25#,ZZT25#..ELEGT,TEC NO.1 |
1 | ||
| 58907-05020 |
CDT250..(ELEGT,TEC)..DCR;CDT250..LHD..ELEGT..DCRL;ADT251,AZT25#,ZZT25#..ELEGT,TEC NO.2 |
1 | ||
| 58908A - LOCK SUB-ASSY, CONSOLE COMPARTMENT DOOR | ||||
| 58908-05010 |
CDT250..(ELEGT,TEC)..DCR;CDT250..LHD..ELEGT..DCRL;ADT251,AZT25#,ZZT25#..ELEGT,TEC |
1 | ||
| 58910C - BOX ASSY, CONSOLE, REAR | ||||
| 58911-05070B0 |
CDT250..DCR;ADT251,AZT25#,ZZT25# DK.GRAY,TRIM1# |
1 | ||
| 58923A - PANEL, CONSOLE REAR END | ||||
| 58923-05020B0 |
CDT250..(ELEGT,TEC)..DCR;ADT251,AZT25#,ZZT25#..ELEGT,TEC DK.GRAY,TRIM1# |
1 | ||
| 58951D - DOOR, CONSOLE COMPARTMENT, OUTER | ||||
| 58951-05030B2 |
CDT250..TEC..DCR;ADT251,AZT25#,ZZT25#..TEC DK.GRAY,TRIM1# |
1 | ||
| 58995A - BRACKET, CONSOLE BOX MOUNTING, NO.1 | ||||
| 58995-05030 |
CDT250..DCR;ADT251,AZT250,ZZT25#..MTM |
1 | ||
| Common parts | ||||
| 90161-30003 | ||||
| 90167-W0007 | ||||
| 90467-10130 | ||||
| 90467-10201 | ||||
| 90468-05135 | ||||
| 90541-03078 | ||||
| 91631-60622 | ||||
| 91631-B0610 | ||||
| 93540-54014 | ||||
| 93540-55016 | ||||
| 93560-15016 | ||||
| 93567-14514 | ||||
| 93568-55014 | ||||
| Linked diagrams | ||||
| 7404 | ||||
| 8401 | ||||
