ADT251L-AEFEYW (2005)
Toyota Avensis
(0504- )ADT25#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 52141G - STAY, FRONT BUMPER, RH | ||||
| 52141-05020 |
ADT251;AZT250..WG..HTWC;CDT250..TEC..DCRL;CDT250..RHD..WG..TEC;ZZT251..LHD..4FC..ENTRY;CDT250..LHD..ELEGT..DCRL;AZT250..RHD..(LB,WG)..ELEGT;ZZT251..RHD..LB..4FC..ELEGT;CDT250,ZZT251..RHD..5F..ELEGT;ZZT251..RHD..SED..4FC..(ELEGT,ENTRY) |
1 | ||
| 52142H - STAY, FRONT BUMPER, LH | ||||
| 52142-05020 |
ADT251;AZT250..WG..HTWC;CDT250..TEC..DCRL;CDT250..RHD..WG..TEC;ZZT251..LHD..4FC..ENTRY;CDT250..LHD..ELEGT..DCRL;AZT250..RHD..(LB,WG)..ELEGT;ZZT251..RHD..LB..4FC..ELEGT;CDT250,ZZT251..RHD..5F..ELEGT;ZZT251..RHD..SED..4FC..(ELEGT,ENTRY) |
1 | ||
| 53201 - SUPPORT SUB-ASSY, RADIATOR | ||||
| 53201-05903 |
ADT251 |
1 | ||
| 53211 - SUPPORT, RADIATOR, RH | ||||
| 53211-05050 |
ADT251 |
1 | ||
| 53212 - SUPPORT, RADIATOR, LH | ||||
| 53212-05040 |
ADT251 |
1 | ||
| 53213A - SUPPORT, RADIATOR, UPPER RH | ||||
| 53213-05010 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53214A - SUPPORT, RADIATOR, UPPER LH | ||||
| 53214-05010 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53216A - SUPPORT, RADIATOR, UPPER | ||||
| 53216-05050 |
ADT251 |
1 | ||
| 53217A - BRACE, HOOD LOCK SUPPORT | ||||
| 53208-05040 |
ADT251 |
1 | ||
| 53273A - REINFORCEMENT, RADIATOR SUPPORT, RH | ||||
| 53273-05020 |
ADT251 |
1 | ||
| 53274A - REINFORCEMENT, RADIATOR SUPPORT, LH | ||||
| 53274-05020 |
ADT251 |
1 | ||
| 53289A - COVER, RADIATOR SUPPORT OPENING | ||||
| 53141-05050 |
ADT251 |
1 | ||
| 53292A - SEAL, RADIATOR SUPPORT, UPPER | ||||
| 53882-30040 |
ADT251,AZT25#,CDT250,ZZT25# |
4 | ||
| 53293C - DEFLECTOR, RADIATOR SIDE, RH | ||||
| 53293-05040 |
ADT251 |
1 | ||
| 53294C - DEFLECTOR, RADIATOR SIDE, LH | ||||
| 53294-05020 |
ADT251 |
1 | ||
| 53701 - APRON SUB-ASSY, FRONT FENDER, RH | ||||
| 53701-05070 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53701-05060 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53702 - APRON SUB-ASSY, FRONT FENDER, LH | ||||
| 53702-05060 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53702-05070 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53711B - APRON, FRONT FENDER, FRONT RH | ||||
| 53711-05901 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53712B - APRON, FRONT FENDER, FRONT LH | ||||
| 53712-05901 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53714C - EXTENSION, FRONT FENDER APRON, FRONT LH | ||||
| 53714-20100 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53723A - REINFORCEMENT, FRONT SPRING SUPPORT, RH | ||||
| 53723-12080 |
AZT250..SED;ZZT251..TEC;ZZT251..5F..ENTRY;ADT251,AZT251,ZZT250;AZT250..(LB,WG)..TEC..D4;CDT250..(ENTRY,TEC)..DCR;ZZT251..RHD..LB..4FC..ENTRY;AZT250..LHD..(LB,WG)..ELEGT..D4;CDT250,ZZT251..LHD..ELEGT..(DCR,HTWC) |
1 | ||
| 53723-12080 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53724A - REINFORCEMENT, FRONT SPRING SUPPORT, LH | ||||
| 53724-12070 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53731D - MEMBER, FRONT APRON TO COWL SIDE, UPPER RH | ||||
| 53731-05030 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53732D - MEMBER, FRONT APRON TO COWL SIDE, UPPER LH | ||||
| 53732-05030 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53733C - PATCH, FRONT FENDER APRON | ||||
| 53733-05020 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53734 - PATCH, FRONT FENDER APRON, NO.4 | ||||
| 53734-05020 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53737G - PLATE, FRONT APRON TO COWL SIDE MEMBER, RH | ||||
| 53737-05010 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53738 - PLATE, FRONT APRON TO COWL SIDE MEMBER, LH | ||||
| 53738-05010 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53813C - EXTENSION, FRONT FENDER, RH | ||||
| 53813-05010 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53813-05010 |
AZT250..SED;ZZT251..TEC;ZZT251..5F..ENTRY;ADT251,AZT251,ZZT250;AZT250..(LB,WG)..TEC..D4;CDT250..(ENTRY,TEC)..DCR;ZZT251..RHD..LB..4FC..ENTRY;AZT250..LHD..(LB,WG)..ELEGT..D4;CDT250,ZZT251..LHD..ELEGT..(DCR,HTWC) |
1 | ||
| 53814C - EXTENSION, FRONT FENDER, LH | ||||
| 53814-05010 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 53814-05010 |
AZT250..SED;ZZT251..TEC;ZZT251..5F..ENTRY;ADT251,AZT251,ZZT250;AZT250..(LB,WG)..TEC..D4;CDT250..(ENTRY,TEC)..DCR;ZZT251..RHD..LB..4FC..ENTRY;AZT250..LHD..(LB,WG)..ELEGT..D4;CDT250,ZZT251..LHD..ELEGT..(DCR,HTWC) |
1 | ||
| 53951A - SUPPORT, FRONT END PANEL, UPPER | ||||
| 53951-05040 |
ADT251 |
1 | ||
| 55101 - PANEL SUB-ASSY, DASH | ||||
| 55101-05390 |
CDT250..LHD..DCRL;ADT251,AZT250..LHD..MTM..(D4,DCR,DCRL) |
1 | ||
| 55210 - INSULATOR ASSY, DASH PANEL | ||||
| 55210-05121 |
ADT251,AZT25#,CDT250,ZZT25#..LHD |
1 | ||
| 55210-05120 |
ADT251,AZT25#,CDT250,ZZT25#..LHD |
1 | ||
| 55223A - INSULATOR, DASH PANEL, OUTER | ||||
| 55223-05081 |
AZT250..LHD..D4;ADT251,AZT251,CDT250,ZZT25#..LHD |
1 | ||
| 55223-05080 |
AZT250..LHD..D4;ADT251,AZT251,CDT250,ZZT25#..LHD |
1 | ||
| 55257 - COVER, DASH PANEL OPENING | ||||
| 55257-13010 |
CDT250..DCR;CDT250..LHD..DCRL;ADT251,AZT25#,ZZT25# |
2 | ||
| 57104A - MEMBER SUB-ASSY, FRONT CROSS | ||||
| 57104-05070 |
ADT251 |
1 | ||
| 57165 - REINFORCEMENT, FRONT CROSSMEMBER, LOWER RH | ||||
| 57165-12070 |
ADT251;AZT250..WG..HTWC;CDT250..TEC..DCRL;CDT250..RHD..WG..TEC;ZZT251..LHD..4FC..ENTRY;CDT250..LHD..ELEGT..DCRL;AZT250..RHD..(LB,WG)..ELEGT;ZZT251..RHD..LB..4FC..ELEGT;CDT250,ZZT251..RHD..5F..ELEGT;ZZT251..RHD..SED..4FC..(ELEGT,ENTRY) |
1 | ||
| 57166 - REINFORCEMENT, FRONT CROSSMEMBER, LOWER LH | ||||
| 57166-12020 |
ADT251;AZT250..WG..HTWC;CDT250..TEC..DCRL;CDT250..RHD..WG..TEC;ZZT251..LHD..4FC..ENTRY;CDT250..LHD..ELEGT..DCRL;AZT250..RHD..(LB,WG)..ELEGT;ZZT251..RHD..LB..4FC..ELEGT;CDT250,ZZT251..RHD..5F..ELEGT;ZZT251..RHD..SED..4FC..(ELEGT,ENTRY) |
1 | ||
| 57167C - GUSSET, FRONT CROSSMEMBER SIDE, RH | ||||
| 57167-05050 |
ADT251 |
1 | ||
| 57168B - GUSSET, FRONT CROSSMEMBER SIDE, LH | ||||
| 57168-05050 |
ADT251 |
1 | ||
| 57169 - MEMBER, FRONT FLOOR, FRONT RH | ||||
| 57169-05020 |
ADT251 (L) |
1 | ||
| 57201G - EXTENSION SUB-ASSY, FRONT SIDE MEMBER, RH | ||||
| 57201-05010 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 57202F - EXTENSION SUB-ASSY, FRONT SIDE MEMBER, LH | ||||
| 57202-05010 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 57213A - PLATE, FRONT SIDE MEMBER, REAR RH | ||||
| 57213-05010 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 57214A - PLATE, FRONT SIDE MEMBER, REAR LH | ||||
| 57214-05010 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| 57218 - GUSSET, FRONT SIDE MEMBER, NO.1 | ||||
| 57218-05020 |
ADT251 |
1 | ||
| 57219 - GUSSET, FRONT SIDE MEMBER, NO.2 | ||||
| 57219-05020 |
ADT251 |
1 | ||
| 58441H - COVER, BATTERY SERVICE HOLE | ||||
| 58441-05020 |
ADT251 |
1 | ||
| 58773C - RETAINER(RADIATOR COVER) | ||||
| 58773-05050 |
ADT251,AZT25#,CDT250,ZZT25# |
1 | ||
| Common parts | ||||
| 53259-20030 | ||||
| 82817-1A810 | ||||
| 90119-06311 | ||||
| 90178-W0019 | ||||
| 90467-06061C0 | ||||
| 90467-06188 | ||||
| 90467-08217 | ||||
| 90541-15014 | ||||
| 91653-A0614 | ||||
| Linked diagrams | ||||
| 7403 | ||||
